CROWNFUL BM4406-UL User manual

I
CROWNFUL
I
INSTRUCTION MANUAL
MODEL: BM4406-UL
Read this booklet thoroughly before using and save it for future reference

Page 1 of 12
IMPORTANT SAFETY PRECAUTIONS:
Before using the electrical appliance, the following basic precautions should always be
followed:
1. Please read the instruction carefully before use.
2. Confirm whether the voltage range used is consistent with that on the nameplate, and
ensure that the socket is well grounded.
3. When not in use or before cleaning, you must turn off the toaster, and then unplug the
power plug.
4. Do not touch hot surfaces. Use handles or knobs.
5. To protect against electric shock do not immerse cord, plugs, or housing in water or
other liquid.
6. Unplug from outlet when not in use, before putting on or taking off parts, and before
cleaning.
7. Do not let the cord hang over the edge of table or hot surfaces.
8. Using other accessory attachments that are not recommended by the appliance
manufacturer may cause injuries.
9. Children should be supervised to ensure that they do not play with the appliance.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Do not touch any moving or spinning parts of the machine when baking.
12. Never switch on the appliance without properly placing the bread pan filled with
ingredients.
13. Do not knock the surface or edge off of the bread bucket to avoid damage.
14. Sheets of metal or other conductive material are not allowed to be inserted into the
toaster to prevent fire or short circuit.
15. The heat and steam generated during the baking process need to be continuously
expelled. Towels or other objects should never be used to cover the chartered aircraft to
avoid fire.
16. Do not operate the appliance for other than its intended use.
17. Do not use outdoors.
18. Please keep the instruction manual.

Page 2 of 12
Know your bread maker

Page 3 of 12
Function Introduction
1. Basic 7. Gluten Free
2. French 8. Cake
3. Whole Wheat 9. Sandwich
4. Quick 10. Butter Milk
5. Sweet 11. Kneading
6. Dough 12. Bake

Page 4 of 12
AFTER POWER-UP
As soon as the bread maker is plugged in the power supply a beep will be heard and
“3:00” will appear in the display after a short time. But the two dots between the “3” and
“00” don’t flash constantly. The arrow points to 2.0LB and MEDIUM. This is the default
setting.
: START / STOP
For starting and stopping the selected baking program.
To start a program, press the “START/STOP” button once. A short beep will be heard and
the two dots in the time display begins to flash, that means the program starts. Any other
button is deactivated except the “START/STOP” button after a program has begun.
To stop the program, press the “START/STOP” button for approx. 3 seconds until a beep
confirms that the program has been switched off. This feature will help to prevent any
unintentional disruption to the operation of the program.
:MENU
It is used to set different programs. Each time it is pressed (accompanied by a short beep)
it will show the different programs. Press the button continuously to show the 12 menus on
the LCD display. Select your desired program. The functions of 12 menus will be
explained below.
1. Basic: kneading, rise and baking normal bread. You may also add ingredients to add
flavor.
2. French: kneading, rise and baking with a longer rise time. The bread baked in this
menu usually will have a crispier crust and light texture.

Page 5 of 12
3. Whole wheat: kneading, rise and baking of whole wheat bread. This setting has longer
preheat time to allow the grain to absorb the water and expand. It is not advisable to use
the delay function as this can produce poor results.
4. Quick: kneading, rise and baking loaf with baking soda or baking powder. Bread baked
on this setting is usually smaller with a dense texture.
5. Sweet: kneading, rise and baking the sweet bread. For baking crispy and sweet bread.
6. Dough: kneading and rise, but without baking. Remove the dough and shape it to make
bread rolls, pizza, steamed bread, and more.
7. Gluten Free: kneading, rise and baking of Gluten Free bread. This setting has longer
preheat time to allow the grain to absorb the water and expand. It is not advisable to use
the delay function as this can produce poor results.
8. Cake: kneading, rise and baking, rise with soda or baking powder.
9. Sandwich: kneading, rise and baking sandwich. For baking light texture bread with
a thinner crust. (This menu is just baking loaf bread which the texture is sandwich.
After finished the bread, you can cut it into sliced bread. And then you can put sauce,
vegetable, deli meat, sausage patties or anything what you like between the bread
layers)
10.Butter Milk: kneading, rise and baking butter milk bread. You can add butter and milk.
11. Bake: only baking, no kneading and rise. Also used to increase the baking time on
selected settings
:COLOR
With the button you can select a LIGHT,MEDIUM or DARK color for the crust. Press
this button to select your desired color.
: DELAY (TIME + or TIME -)
If you don’t want the appliance to start working immediately you can use this button to set
the delay time.
You must decide how long it will be before your bread is ready by pressing the “TIME
+”or “TIME -”. Please note the delay time should include the baking time of program.
That is, at the completion of the delay time, a hot bread can be served. At first the program
and degree of browning must be selected, then press “TIME+” or “TIME-” to increase or
decrease the delay time at the increment of 10 minutes. The maximum delay time is 13
hours.
Example: The current time is 8:30p.m. You would like your bread to be ready the next
morning at 7 o’clock, i.e. in 10 hours and 30 minutes. What you need to do is, select your
: LOAF SIZE
Press this button to select the Loaf size of the bread. Please note the total operation time
may vary with different loaf sizes.
Note: For Preset "Cake” with default size, and can't select the size with Loaf button.

Page 6 of 12
temperature inside is still too high. Then the program has to be stopped. Open the lid
and let the machine cool down for 10 to 20 minutes.
2. If the display shows “Err” after you have pressed START/STOP, (see below figure 2)
the temperature sensor may have been disconnected. Please have the sensor carefully
checked by an Authorized expert.
3. If the display shows“LLL”after pressing the Start/Stop button (except the programs
BAKE), it means the temperature inside is too low
（accompanied by 5 beeping sounds）
,
stop the sound by pressing the Start/Stop button, open the lid and let the machine rest
for 10 to 20 minutes to return to room temperature or select the BAKE program and
make the temperature inside the chamber increase rapidly”
NOTE: The bread maker’s temperature is lower than the room temperature if you place
the bread maker in a cooler place (such as air conditioned room, cold storage) after a
period of time. You can then move it to a room with normal temperature immediately to
make bread．
menu, color, loaf size then press the TIME+ or TIME - to add the time until 10:30
appears on the LCD. Then press the STOP/START button to activate this delay program.
You will see the dot flashes and LCD display will count down to show the remaining time.
You will get fresh bread at 7:00 in the morning and if you don’t want to take out the bread
immediately, the keeping warm time of 1 hour starts.
Note: For time delayed baking, do not use any easily perishable ingredients such as eggs,
fresh milk, fruits, onions, etc.
KEEP WARM
Bread can be automatically kept warm for 60 minutes after baking. If you would like to
take the bread out, switch the program off with the START/STOP button.
MEMORY
If the power supply has been interrupted during the course of bread making, the process of
bread making will continue automatically within 10 minutes, even without pressing
Start/stop button. If the break time exceeds 10 minutes the memory may or may not save,
so the bread maker may continue the process or shall be restarted. But if the dough does
not exceed the kneading phase when the power supply breaks off, you can press the
“START/STOP” immediately to continue the program from the beginning. How to
operate depends on what happens.
ENVIRONMENT
The machine may work well in a wide range of temperatures, but there could be a
difference in loaf sizes between a very warm room and a very cold room. We suggest the
room temperature should be between 59℉and 93℉.
WARNING DISPLAY:
1. If the display shows “HHH” after the program has been started, (see below figure 1) the

Page 7 of 12
Figure 1 Figure 2 Figure 3
For the first use
1. Please check if all parts and accessories are complete and undamaged.
2. Clean all the parts according to the latter section“Cleaning and Maintenance”
3. Set the bread maker in baking mode and bake empty for about 10 minutes. After cooling
it down clean once more.
4. Dry all parts thoroughly and assemble them. Then, the appliance is ready for using.
How to make bread
1. Place the pan in position, then turn it clockwise until they click in correct position. Fix
the kneading blade onto the drive shafts. Turn the kneaders clockwise until they click into
place. It is recommended to fill holes with heat-resisting margarine prior to placing the
kneaders, this avoids the dough to stick below the kneaders and the kneaders could be
removed from bread easily.
2. Place the ingredients into the bread pan. Please keep to the order mentioned in the
recipe. Usually the water or liquid substance should be put first, then add sugar, salt and
flour, always add yeast or baking powder as the last ingredient. In case of heavy dough
with high Rye or wholemeal portion we advise to reverse the order of ingredients. i.e. so
fill it in first with the dry yeast and flour, and finally the liquid to get a better kneading
result.
Note: To know the maximum quantity of the flour and yeast that can be used, please refer
to the recipe.
3. Using your finger make a small indentation on one side of the flour. Add yeast to
indentation. Make sure it does not come into contact with the liquid ingredients or salt.
4. Close the lid gently and plug the power cord into a wall outlet.
5. Press the Menu button until your desired program is selected.
6. Press the COLOR button to select the desired crust color.
7. Press the LOAF SIZE button to select the desired size (1.5LB or 2.0LB).
8. Set the delay time by pressing Time+ or Time- button. You can skip this part if you
want the bread maker to start working immediately.

Page 8 of 12
9. Press the START/STOP button to start working.
10. For the program of BASIC,FRENCH, WHOLE WHEAT, SWEET, GLUTEN
FREE, a long beep sound will be heard during operation. This is to prompt you to add
ingredients. Open the Lid and put in the ingredients. It is possible that a steam will escape
through the vent slits in the lid during baking. This is normal.
11. Once the process has been completed 10 beeping sound will be heard. You can press
START/STOP button for approx. 3-5 seconds to stop the process and take out the bread.
Open the Lid and while using oven mitts, firmly grasp the bread pan handle. Turn the pan
counter-clockwise and gently pull the pan straight up and out of the machine.
12. Use non-stick spatula to gently loosen the sides of the bread from the pan.
Caution: The Bread pan and bread may be very hot! Always handle with care and use
oven mitts.
13. Turn bread pan upside down onto a clean cooking surface and gently shake until bread
falls out from the rack.
14. Remove the bread carefully from the pan and let it cool for about 20 minutes before
slicing.
15. If you are outside of the room or have not pressed START/STOP button at the end of
the operation, the bread will be kept warm automatically for 1 hour and then the “keeping
warm” function will stop.
16. When not in use or the operation is complete, unplug the power cord.
Note: Before slicing the loaf, use the hook to remove the kneading blade hidden on the
bottom of loaf. The loaf is hot, never use the hand to remove the kneading blade.
.Special introduction
1. For Quick breads
Quick breads are made with baking powder and baking soda that are activated by moisture
and heat. For perfect quick breads, it is suggested that all liquids be placed in the bottom
of the bread pan, dry ingredients on top. During the initial mixing of quick bread batters
and dry ingredients may collect in the corners of the pan, it may be necessary to help
machine mix to avoid flour clumps. If so, use a rubber spatula.
.Cleaning and Maintenance
Disconnect the machine from the power and let it cool down prior to cleaning.
1. Bread pan: Rub the bread pan inside and outside with a damp cloth. Do not use any
sharp or abrasive agents for the consideration of protecting the non-stick coating. The
pan must be dried completely prior to installing.
2. Kneading blade: If the kneading bar is difficult to remove from the axle, fill the
container with warm water and allow it to soak for approx. 30 minutes. The kneader can
then be easily removed for cleaning. Also wipe the blade carefully with a cotton damp
cloth. Please note that both the bread pan and kneading blade are dishwasher safe
components.

Page 9 of 12
3. Lid and Window: Clean the lid inside and outside with a slightly damp cloth.
4. Housing: Gently wipe the outer surface of housing with a wet cloth. Do not use any
abrasive cleaner to clean as this would degrade the high polish of the surface. Never
immerse the housing into water for cleaning.
5. Before the bread maker is packed away for storage, ensure that it has completely cooled
down, is clean and dry, and put the spoon and the kneading blade in the drawer, and the
lid is closed.
Introduction of bread ingredients
1. Bread flour
Bread flour has high content of high gluten (so it can be also called high-gluten flour
which contains high protein), it has good elastic and can keep the size of the bread from
sunken after rising. As the gluten content is higher than the common flour so it can be
used for making bread with large size and better inner fiber. Bread flour is the most
important ingredient of making bread.
2. Plain flour
Plain flour is made by mixing well-chosen soft and hard wheat and applicable for
making express bread or cakes.
3. Whole wheat flour
Whole wheat flour is made by grinding whole wheat, it contains wheat skin and gluten
whole wheat flour is heavier and has more nutrient than common flour. The bread made
by whole wheat flour is usually small in size. So many recipes usually combine the
whole wheat flour and bread flour to achieve best results.
4. Black wheat flour
Black wheat flour, also named as “rough flour”, is a kind of high fiber flour that is
similar to the whole wheat flour. To obtain the large size after rising it must be used in
combination with high proportion of bread flour.
5. Cake powder
Cake powder is made by grinding soft wheat or low protein wheat, which is specially
used for making cakes. Different flour seems to be alike, actually yeast performance or
absorbability of various flour differs largely for growing areas, growth reasons, grinding
process and storage life. You may choose flour with different trademark to test, taste and
compare in local market, and select the one which could produce the best result
according to your own experiences and taste.
6. Corn flour and oatmeal flour
Corn flour and oat flour are made by grinding corn and oatmeal respectively, they both
are the additive ingredients of making rough bread, which are used for enhancing the
flavor and texture.
7. Sugar
Sugar is very important ingredient to add sweet taste and color of bread. While it helps
to yeast bread as nourishment, white sugar is largely used. Brown sugar, powder sugar
or cotton sugar may be called by special requirements.
8. Yeast
Yeast passes doughy yeasting process, then produces carbon dioxide, making bread

Page 10 of 12
expand and inner fibre soft. However, yeast fast breeding needs carbohydrate in sugar
and flour as nourishment.
1tsp. active dry yeast =3/4 tsp. instant yeast
1.5tsp. active dry yeast =1 tsp. instant yeast
2tsp. active dry yeast =1.5 tsp. instant yeast
Salt is necessary to improve bread flavor and crust color. But salt can also restrain yeast
from rising. Never use too much salt in a recipe. If you don't want to use salt, omit it.
And bread would be larger if without salt.
10. Egg
Eggs can improve bread texture, make the bread more nourish and larger in size. Add
special egg flavor to bread. When using it must be peeled and stirred evenly.
11. Grease, butter and vegetable oil
Grease can make bread be soft and delay storage life. Butter should be melted or
chopped to small pieces before using, so it can be stirred evenly when you take it out
from refrigerator.
12. Baking powder
Baking powder is mainly used for rising the Quick bread and cake as it does not need
rise time and produce gas which will form bubble or soften the texture of bread
utilizing chemical principle.
13. Soda
The same principle as above. It can also be used in combination with baking powder.
14. Water and other liquid
One of the important steps for making good bread is using proper amount of ingredients.
It is strongly suggest to use measuring cup or measuring spoon to obtain accurate
amount, as it can largely affect the baking process and result.
Yeast must be stored in refrigerator as it will be killed at high temperature. Before using,
check the date and storage life of your yeast. Store it back to the refrigerator as soon as
possible after each use. Usually the failure of bread rising is caused by the dead yeast.
The ways described below will check whether your yeast is fresh and active or not.
（1）pour 1/2 cup warm water 113-122℉into a measuring cup
（2）Put 1 tsp. white sugar into the cup and stir, then sprinkle 2tsp. yeast over the water.
（3）Place the measuring cup in a warm place for about 10min. Do not stir the water.
（4）The froth will be up to 1 cup. Otherwise the yeast is dead or inactive.
9. Salt
Water is essential ingredient for making bread. Generally speaking, water temperature
between 68℉and 77℉is the most proper. But the water temperature should be
within 113-122℉for achieving rising speed for making Quick bread.
The water may be
replaced with fresh milk or water mixed with 2% milk powder, which may enhance
bread flavor and improve crust color. Some recipes may call for juice for the purpose
of enhancing bread flavor, e.g.: apple juice, orange juice, lemon juice and so on.
Ingredients weight

Page 11 of 12
1. Weighing liquid ingredients
Water, fresh milk or milk powder solution should be measured with measuring cups.
Observe the level of the measuring cup with your eyes horizontally.
When you measure cooking oil or other ingredients, clean the measuring cup thoroughly
without any other ingredients.
2. Measure dry powder
Dry powder should be kept in natural and loose conditions, level the cup mouth gently
by blade to ensure accurate measure.
3. Ingredient sequence
The sequence of placing ingredients should be observed, generally speaking, the
sequence is: liquid ingredients, eggs, salt and milk powder etc. When placing the
ingredients, the flour can't be wet by liquid completely. The yeast can only be placed on
the dry flour. Exclusively, yeast can't touch with salt. After the flour has been kneaded
for some time, a beep will remind you to put Fruit ingredients into the mixture. If the
fruit ingredients are added too early the flavor will be diminished after long time mixing.
When you use the delaying function for a long time, never add the perishable
ingredients such as eggs, fruit ingredient, etc.
Trouble shooting guide
No.
Problem
Course
Solution
1
Smoke from ventilation
hole when baking
Some ingredients adhere to the heat
element or nearby, for the first use,
oil remained on the surface of heat
element
Unplug the bread maker and clean the
heating element, but be careful to not burn
yourself, during the first use, dry operating
and open the lid.
2
Bread bottom crust is
too thick
Keeping the bread warm and leaving
it in the bread pan for a long time so
that water is losing too much
Take the bread out immediately without
keeping it warm
3
It is very difficult to take
the bread out
Kneader adheres tightly to the shaft
in bread pan
After taking the bread out, put a hot water
into the bread pan and immerse kneader for
10 minutes, then take it out and clean.
4
Stirred ingredients not
even and bake badly
1.selected program menu is improper
Select the proper program menu
2.after operating, opening the cover
several times and bread is dry, no
brown crust color
Don’t open cover at the last rise
3.Stir resistance is too large so the
kneader can’t almost rotate and stir
adequately
Check kneader hole, then take the bread pan
out and operate without load, if not normal,
contact with the authorized service facility.
5
Display “H:HH” after
pressing “start/stop”
button
The temperature in the bread maker
is too high to make bread.
Press “start/stop” button and unplug the
bread maker, then take bread pan out and
open the cover until the bread maker cools
down
6
Hear the motor noises
but dough isn’t stirred
Bread pan is fixed improperly or
dough is too large to be stirred
Check whether bread pan is fixed properly
and dough is made according to recipe and
the ingredients are weighed accurately
7
Bread size is so large it
pushes the cover
Yeast is too much or flour is
excessive or water is too much or
environment temperature is too high
Check the above factors, reduce properly
the amount according to the true reasons

Page 12 of 12
8
Bread size is too small
or bread has not risen
No yeast or the amount of yeast is
not enough, moreover, yeast may
have a poor activity as water
temperature is too high or yeast is
mixed together with salt, or the
environment temperature is lower.
Check the amount and performance of the
yeast, increase the environment
temperature properly.
9
Dough is so large it
overflows in the bread
pan
The amount of liquids is too much as
to make dough soft and yeast is also
too much
Reduce the amount of liquids and improve
dough rigidity
10
Bread collapses in the
middle parts when
baking dough
1.used flour is not strong powder and
can’t make dough rise
Use bread flour or strong powder.
2.yeast rate is too fast or yeast
temperature is too high
Yeast is used under room temperature
2. Excessive water makes dough too
wet and soft.
According to the ability of absorbing water,
adjust water on recipe
11
Bread weight is very
large and organization
construct is too dense
1.too much flour or short of water
Reduce flour or increase water
2.too many fruit ingredients or too
much whole wheat flour
Reduce the amount of corresponding
ingredients and increase yeast
12
Middle parts are hollow
after cutting bread
1. Excessive water or yeast or no salt
Reduce properly water or yeast and check
salt
2.water temperature is too high
Check water temperature
13
Bread surface is adhered
to dry powder
1.there is strong glutinous
ingredients in bread such as butter
and bananas etc.
Do not add strong glutinous ingredients
into the bread.
2. not stirring adequately or short of
water
Check water and mechanical construction
of the bread maker
14
Crust is too thick and
baking color is too dark
when making cakes or
food with excessive
sugar
Different recipes or ingredients have
great effect on making bread, baking
color will become very dark because
of too much sugar
If baking color is too dark for the recipe
with excessive sugar, press start/stop to
interrupt the program ahead 5-10min of
intended finishing time. Before removing
out the bread you should keep the bread or
cake in bread pan for about 20 minutes
with cover closed
Customer Support
Should you encounter any issues or if you have any questions regarding your new product, feel free to contact our
helpful Customer Support Team. Your satisfaction is our goal!
Email: [e-mail]
Support Hours
Monday - Friday:
9:00 am - 5:00 pm PST
* Please have your order invoice or order number ready before contacting
customer support.
