AIRLITE®CONFIGURABLE RADIO POUCH OPERATOR’S MANUAL

EQUIPMENT INFORMATION
INTRODUCTION................................................................... 1
INCLUDED COMPONENTS.................................................2
OPERATOR INSTRUCTIONS
ATTACHING POUCH TO CARRIER.......................................... 5
ADJUSTING HEIGHT OF RADIO POUCH................................. 6
USING SHOCK CORD ADJUSTMENT AND HOOK TAB ............. 9
CARE INSTRUCTIONS .......................................................... 14
CONTENTS

1AIRLITE® CONFIGURABLE RADIO POUCH
INTRODUCTION
FEATURES
�Made with lightweight durable AIRLITE®material
�2 oz weight
�Compatible with all VELCRO®front ap designs
�Vertically adjustable bottom allows height adjustment for a radio
�Heavy duty durable side elastic holds radio securely
�Front buckle can be removed and replaced with shock cord/hook tab retention
�Fits 152, MBITR or two 30 round M4 magazines
�Large slot for compatibility with the STRUCTURAL CUMMERBUND
�Ambidextrous design allows pouch to be attached to the left or right side
of carrier
The AIRLITE®CONFIGURABLE RADIO POUCH adds a new level of comfort and
adjustability when wearing a radio on your carrier. Multiple slots on the front and
rear allow for a wide range of height adjustment and allows the pouch to be used
on the operators left or right side. Additionally, heavy-duty side elastic and an
adjustable top cord provides a secure t without interfering with controls on top
of the radio. The AIRLITE®CONFIGURABLE RADIO POUCH will adjust to t most radios
and magazines, including the 152, MBITR and two M-4 30 round magazines.

2EQUIPMENT INFORMATION
1RADIO POUCH
2
3
4
RADIO POUCH BOTTOM
ADJUSTABLE SIDE RELEASE BUCKLE
ADJUSTABLE SHOCK CORD W/ HOOK TAB
1
2
3
4

OPERATOR INSTRUCTIONS

5AIRLITE® CONFIGURABLE RADIO POUCH
ATTACHING POUCH TO CARRIER
The AIRLITE®CONFIGURABLE RADIO POUCH is designed to t multiple platforms such as the JPC™, AVS™, CPC™ and the SPC™ carrier.
To attach the pouch to your carrier, complete the following:
1 2
Pouch can be adjusted horizontally or vertically for comfort.
43
Close front ap.
Lift front ap of carrier and nd approximate position of where you
want your pouch.
Place radio pouch on main loop body of carrier.
NOTE: If using the SPC™ place open slot of radio pouch over
opening for structural cummerbund.

6OPERATOR INSTRUCTIONS
ADJUSTING HEIGHT OF RADIO POUCH
The AIRLITE®CONFIGURABLE RADIO POUCH bottom can be adjusted vertically to accommodate a wide range of radios and other items. The
pouch bottom can also be removed and ipped so the pouch can be used on either side of the carrier. To adjust or remove the bottom,
complete the following:
TO REMOVE FRONT BUCKLE:
1
2
Pinch top tab together.
Slide buckle out.

7AIRLITE® CONFIGURABLE RADIO POUCH
Adjust to desired height. Push top cord through back two holes and tied through top tab
opening.
TO ADJUST BOTTOM:
Lift bottom front tab and push under main pocket slot. Lift bottom back tab and push under main pocket slot.
1 2
43

8OPERATOR INSTRUCTIONS
Lift bottom front and back tabs under main pocket slots in same
manner to adjust.
Remove bottom pouch from main pouch.
Turn main pocket body upside down (VELCRO®attachment panel
facing desired direction) and feed bottom pocket adjustment tabs
back through main pocket slots to desired position.
Flip bottom front and rear tab over main pocket slots and attach
top adjustment cords.
SWITCH L/R ORIENTATION:
1 2
43

9
USING SHOCK CORD ADJUSTMENT AND HOOK TAB:
The shock cord with hook tab can be used in place of the buckle and cord adjuster. To install, do the following:
1
3
2
Remove front buckle.
Route front bottom so loop is exposed on front of main pocket.
Feed ends of shock cord through back two holes on main pocket
body.
AIRLITE® RADIO POUCH

10OPERATOR INSTRUCTIONS
Route ends of shock cord through back top tab and tie in a knot.
Place front hook tab over item. Bottom of front tab can be used to
help secure hook tab in place
4
5

CARE INSTRUCTIONS

13 AIRLITE® CONFIGURABLE RADIO POUCH

14FURTHER INSTRUCTIONS
CARE INSTRUCTIONS
Care instructions must be read prior to each use.
Do not machine wash or dry clean. Remove dirt by using a cloth or soft brush. Hand wash with warm water and cloth or soft brush. Air dry
indoors or in shade. Do not apply iron or any heat.
