CRZ Technology Cosmos+ User manual

Cosmos+ OpenSSD Board Quick Start Guide
CRZ Technology 1
Cosmos+ OpenSSD Board Quick Start
Guide
Revision 1.0
2020. 04. 23
CRZ Technology
http://www.mangoboard.com/

Cosmos+ OpenSSD Board Quick Start Guide
2 CRZ Technology
Document History
Revision
Date
Change note
1.0
2020.04.23
First draft

Cosmos+ OpenSSD Board Quick Start Guide
CRZ Technology 3
Table of Contents
1. Introduction......................................................................................................................................................................................... 4
1.1. Aboud this guide ......................................................................................................................................................................................................4
1.2. Before starting, check list....................................................................................................................................................................................4
1.2.1 Gears ....................................................................................................................................................................................................................................4
2. HW Setup ............................................................................................................................................................................................ 5
2.1. Cosmos+ OpenSSD Environment....................................................................................................................................................................5
2.2. Hardware Componets ............................................................................................................................................................................................6
2.3. Steps to connect HW components ................................................................................................................................................................7
3. SW Setup ........................................................................................................................................................................................... 12
3.1. Vivado Installation ................................................................................................................................................................................................12
3.2. Launch Vivado .........................................................................................................................................................................................................14
4. Operating Cosmos+ OpenSSD (Linux) ......................................................................................................................................... 18
4.1. Check device recognition.................................................................................................................................................................................. 18
4.2. Create a partition...................................................................................................................................................................................................20
4.3. Check the created partition............................................................................................................................................................................. 20
4.4. Format the partition ............................................................................................................................................................................................21
4.5. Create a mount point.......................................................................................................................................................................................... 21
4.6. Mount the partition .............................................................................................................................................................................................22
4.7. Check the mounted partition ......................................................................................................................................................................... 22

Cosmos+ OpenSSD Board Quick Start Guide
4 CRZ Technology
1. Introduction
1.1. Aboud this guide
This document provides an introduction to using the Cosmos+ OpenSSD platform board.
This guide describes the steps to test the Cosmos+ OpenSSD platform board and check list.
It contains the following chapters:
⚫Chapter 1, provides general overview.
⚫Chapter 2, describes HW setup.
⚫Chapter 3, describes SW setup.
⚫Chapter 4, provides the steps to test the Cosmos+ OpenSSD platform board
1.2. Before starting, check list
1.2.1 Gears
-Cosmos+ OpenSSD platform board
-External PCIe Adaptor
-External PCIe cable
-USB type A to USB type micro B cable (for JTAG digilent module)
-USB type A to USB type A cable (for UART)
-1+ NAND flash modules
-12V DC power adaptor

Cosmos+ OpenSSD Board Quick Start Guide
CRZ Technology 5
2. HW Setup
2.1. Cosmos+ OpenSSD Environment
■1 Development PC
●Downloading hardware/software design (JTAG)
●Monitoring Cosmos+ OpenSSD internals (UART)
■1 Host PC
●Executing applications such as a benchmark (PCIe)
■1 Platform board with 1+ NAND flash modules installed
●Working as a storage device to the host PC

Cosmos+ OpenSSD Board Quick Start Guide
6 CRZ Technology
2.2. Hardware Componets
■Cosmos+ OpenSSD platform board
●Consists of a Zynq FPGA and other peripherals
■NAND flash modules
●Configured as multi-channel and multi-way flash array
●Inserted into Cosmos+ OpenSSD platform board
■External PCIe adapter and cable
●Connected with host PC
■USB cables for JTAG and UART
●Connected with development PC
■Power cable and adapter
●12V supply voltage

Cosmos+ OpenSSD Board Quick Start Guide
CRZ Technology 7
2.3. Steps to connect HW components
-Turn off Host PC
-Insert NAND Flash Modules
-
-Connect PCIe Adaptor to Host PC
Push first
Push next

Cosmos+ OpenSSD Board Quick Start Guide
8 CRZ Technology
-Connect PCIe Cable between Cosmos+ OpenSSD platform board and PCIe Adaptor
Hold here
Push

Cosmos+ OpenSSD Board Quick Start Guide
CRZ Technology 9
-Make sure that jumper pins on board are set as default below

Cosmos+ OpenSSD Board Quick Start Guide
10 CRZ Technology
-Connect USB type A to USB type micro B cable to development PC
-Connect USB type A to USB type A cable to development PC

Cosmos+ OpenSSD Board Quick Start Guide
CRZ Technology 11
-Connect 12V DC power adaptor to Cosmos+ OpenSSD platform board(J182)
-Turn on the power of Cosmos+ OpenSSD platform board(SW12)

Cosmos+ OpenSSD Board Quick Start Guide
12 CRZ Technology
3. SW Setup
3.1. Vivado Installation
Install Vivado 2019.1 through below link.
https://www.xilinx.com/support/download/index.html/content/xilinx/en/downloadNav/vivado-design-tools/2019-1.html

Cosmos+ OpenSSD Board Quick Start Guide
CRZ Technology 13
Make sure that Vivado is system edition and that “Software Development Kit” and “Zynq-7000” are checked

Cosmos+ OpenSSD Board Quick Start Guide
14 CRZ Technology
3.2. Launch Vivado
Open Cosmos+ OpenSSD Vivado project.(OpenSSD2-8C8W-16K_19.1)
Launch SDK.

Cosmos+ OpenSSD Board Quick Start Guide
CRZ Technology 15
Run Debug Configuration on SDK.
Select “Program FPGA”.

Cosmos+ OpenSSD Board Quick Start Guide
16 CRZ Technology
Uncheck “Stop at main” and Press “Debug”.
Launch terminal program on the Development PC.
Press ‘n’ to maintain the bad block table

Cosmos+ OpenSSD Board Quick Start Guide
CRZ Technology 17
Turn on the Host PC when the firmware reset is done.
NVMe SSD initialization steps are on going

Cosmos+ OpenSSD Board Quick Start Guide
18 CRZ Technology
4. Operating Cosmos+ OpenSSD (Linux)
4.1. Check device recognition
-Click the pointed icon
-Click the terminal icon

Cosmos+ OpenSSD Board Quick Start Guide
CRZ Technology 19
-Types “lspci” -> press ENTER -> check “Non-Volatile memory controller: Xilinx Corporation Device 7028” on the PCI
device list
-Types “ls /dev” -> press ENTER -> check “nvme0nxxxx” on the device list

Cosmos+ OpenSSD Board Quick Start Guide
20 CRZ Technology
4.2. Create a partition
-Type “sudo fdisk /dev/nvme0nxxxx”, press ENTER -> type your password, press ENTER -> type “n”, press ENTER ->
type “p”, press ENTER -> type “1”, press ENTER -> type “4096”, press ENTER
4.3. Check the created partition
-Types “ls /dev” -> press ENTER -> check “nvme0nxxxxp1” on the device list
