CTA Hyperflex PAD-HSKSBP User manual

Hyperflex Universal Security Kiosk w/
Power Bank Holder for Medium Tablets
PAD-HSKSBP
INSTALLATION - MANUAL
1A - Align holes at the base (B) with the holes on the base of the body (A). Rotate in screws (H) with provided allen key
tool (K) until securely tightened. As shown above.
x1
A
I
x3
J
x3
x4
F
M5 x 14 M5 x 8
H
x3
H
M5 x 8
K
M5 Allen Key
A
B
2. (Optional) Fasten to create a fixed setup: 3. (Optional) Mounting to surface top :
2A - Using provided tool (K), rotate clockwise at the
shown location on kiosk body to create a locked
fixed setup. Rotate until securely tightened.
K
3A - Using a screwdriver (not included) rotate in screws (I) with anchors (J) until
securely bolted into surface top.
**Screwdriver for illustration
purposes and not included
I
J
Power
Bank
Holder
x1
K
M5 Allen
Key
x1
B
x1
1.Assembling base to body :
CONTENTS :
INSTALLATION:
Secuirity
Enclosure
x1
CDG
M5 Nut
x4 x3
x1
Security
Lock Key
L
A
B
x1
Foam Adapter &
Sheet Bundle
M

x4
M5x14
5.Attaching enclosure to Power bank holder to kiosk :
5A. Align VESA holes of enclosure (C) with VESA holes in power bank holder (D) to the VESA holes of kiosk (A,B). Rotate in screws (F) from front
using included allen key tool (K) while holding hex nuts (G) from behind with your hand. Continue rotating until securely tightened.As shown above.
6. Setting up Device & Enclosure :
M5 Nut
x4
4A. Using the provided allen key tool (K) , slightly
loosen all the joints on the holder (D) so you can
flex the size with your hands. (Joints are shown
with dash circles)
4. Setting up PowerBank into Holder
**Powerbank is for illustration
purposes and not included
4B. Insert your powerbank into the holder (D). 4C. Slide and adjust all the holder components
(D) until they are a tight secure fit. Rotate all the
joint screws after fitting until they are securely
tightened with provided Allen key tool (K).
K
D
D
K
K
FC
D
A
G
6A. Insert the
appropriate foam
piece (M) that is
compatible with
your tablet.
6B. Insert tablet as
shown. Plug in power
cable to tablet and cable
route through the back.
6C.Place the appropriate
provided tablet cover (M)
to match your tablet.
6D.Close the enclosure
and lock it with the included
set of keys (L).
M
ML
