IEI Technology iSignager-1000-Q354 User manual

iSignager-1000-Q354 Digital Signage Player
Page i
IEI Technology Corp.
User Manual
iSignager-1000-Q354 Digital Signage Player
MODEL:
iSignager-1000-Q354
Intel® Core™2 Duo CPU Based Digital Signage Player with
320 GB HDD, DVD Combo, 2.0 GB DDR2, GbE LAN,
PoweredUSB, 5V/12V RS-232, RoHS Compliant
Rev. 1.00 – 28 April, 2009

iSignager-1000-Q354 Digital Signage Player
Page ii
Revision
Date Version Changes
28 April, 2009 1.00 Initial release

iSignager-1000-Q354 Digital Signage Player
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

iSignager-1000-Q354 Digital Signage Player
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 ISIGNAGER-1000-Q354 OVERVIEW............................................................................ 2
1.1.1 iSignager-1000-Q354 Benefits........................................................................... 2
1.1.2 iSignager-1000-Q354 Features ......................................................................... 3
1.2 TECHNICAL SPECIFICATIONS ...................................................................................... 3
1.3 POWER SUPPLY .......................................................................................................... 5
1.4 WIRELESS LAN MODULE .......................................................................................... 6
2 MECHANICAL DESCRIPTION................................................................................. 7
2.1 ISIGNAGER-1000-Q354 MECHANICAL OVERVIEW ..................................................... 8
2.2 ISIGNAGER-1000-Q354 PHYSICAL DIMENSIONS ........................................................ 8
2.3 EXTERNAL OVERVIEW.............................................................................................. 10
2.3.1 Front Panel ...................................................................................................... 10
2.3.2 Rear Panel Overview....................................................................................... 10
2.3.2.1 Rear Panel Connectors and Indicators.......................................................11
2.4 INTERNAL OVERVIEW............................................................................................... 12
3 SYSTEM COMPONENTS ......................................................................................... 14
3.1 ISIGNAGER-1000-Q354 MOTHERBOARD.................................................................. 15
3.1.1 POS Motherboard Overview............................................................................ 15
3.1.2 CPU Support.................................................................................................... 16
3.1.3 Onboard Chipsets ............................................................................................ 17
3.1.3.1 Northbridge and Southbridge Chipsets..................................................... 17
3.1.3.2 Intel®Q35 Northbridge Chipset................................................................ 17
3.1.3.3 ICH9DO Southbridge Chipset.................................................................. 18
3.1.4 Ethernet Controllers ........................................................................................ 18
3.1.4.1 Intel® 82566MM PCIe Gigabit LAN Controller ..................................... 18
3.1.5 Intel® 82573L PCIe Gigabit Ethernet (GbE) Controller................................ 19
3.2 PERIPHERAL INTERFACE CONNECTORS..................................................................... 19
3.2.1 Peripheral Interface Connectors ..................................................................... 19
3.2.2 External Interface Panel Connectors............................................................... 20

iSignager-1000-Q354 Digital Signage Player
Page v
3.3 ON-BOARD JUMPERS ................................................................................................ 20
3.3.1 ATX Power Select Jumper Settings.................................................................. 21
3.3.2 Clear CMOS Jumper........................................................................................ 22
3.3.3 COM 1/2 Pin 9 Setting Jumper........................................................................ 23
3.3.4 COM 3/4 Pin 9 Setting Jumper........................................................................ 25
4 INSTALLATION ......................................................................................................... 26
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 27
4.2 INSTALLATION PROCEDURE...................................................................................... 27
4.2.1 Installation Procedure Overview..................................................................... 27
4.2.2 Unpacking........................................................................................................ 28
4.2.3 CompactFlash® Card Installation .................................................................. 29
4.2.4 Foot Pad Installation....................................................................................... 29
4.2.5 Cable Connections........................................................................................... 29
4.3 POWER-ON PROCEDURE........................................................................................... 30
4.3.1 Installation Checklist....................................................................................... 30
4.3.2 Power-on Procedure ........................................................................................ 30
5 AMI BIOS..................................................................................................................... 32
5.1 INTRODUCTION......................................................................................................... 33
5.1.1 Starting Setup................................................................................................... 33
5.1.2 Using Setup...................................................................................................... 33
5.1.3 Getting Help..................................................................................................... 34
5.1.4 Unable to Reboot After Configuration Changes.............................................. 34
5.1.5 BIOS Menu Bar................................................................................................ 34
5.2 MAIN........................................................................................................................ 35
5.3ADVANCED............................................................................................................... 36
5.3.1 CPU Configuration.......................................................................................... 37
5.3.2 IDE Configuration........................................................................................... 38
5.3.2.1 IDE Master, IDE Slave ............................................................................. 40
5.3.3 Super IO Configuration ................................................................................... 44
5.3.4 Hardware Health Configuration...................................................................... 48
5.3.5 ICP Power Configuration................................................................................ 50
5.3.5.1 ACPI Configuration .................................................................................. 51
5.3.5.2 Power Configuration................................................................................. 52

iSignager-1000-Q354 Digital Signage Player
Page vi
5.3.6 AHCI Configuration......................................................................................... 53
5.3.6.1 AHCI Port n .............................................................................................. 54
5.3.7 Intel AMT Configuration.................................................................................. 56
5.3.7.1 ME Subsystem Configuration................................................................... 57
5.3.8 Remote Access Configuration.......................................................................... 59
5.3.9 USB Configuration........................................................................................... 62
5.4 PCI/PNP................................................................................................................... 64
5.5 BOOT........................................................................................................................ 66
5.5.1 Boot Settings Configuration............................................................................. 67
5.5.2 Boot Device Priority........................................................................................ 69
5.5.3 CD/DVD Drives............................................................................................... 69
5.6 SECURITY................................................................................................................. 70
5.7 CHIPSET ................................................................................................................... 71
5.7.1 Northbridge Configuration.............................................................................. 72
5.7.2 Southbridge Configuration .............................................................................. 74
5.8 EXIT......................................................................................................................... 75
6 DRIVER INSTALLATION......................................................................................... 77
6.1AVAILABLE SOFTWARE DRIVERS .............................................................................. 78
6.2 DRIVER CD.............................................................................................................. 78
6.3 INTEL®CHIPSET DRIVER INSTALLATION .................................................................. 79
6.4 REALTEK HDAUDIO DRIVER INSTALLATION ........................................................... 82
6.4.1 BIOS Setup....................................................................................................... 82
6.4.2 Driver Installation ........................................................................................... 82
6.5 INTEL®GRAPHICS MEDIAACCELERATOR DRIVER INSTALLATION............................ 85
6.6 LAN DRIVER (FOR GBELAN) INSTALLATION......................................................... 88
6.7ATHEROS WIRELESS LAN DRIVER INSTALLATION ................................................... 92
6.8 INTEL®ACTIVE MANAGEMENT TECHNOLOGY DRIVER INSTALLATION.................... 97
7 SOFTWARE APPLICATION (ISMM).................................................................... 103
7.1 ISMM INTRODUCTION ........................................................................................... 104
7.2 ISMM INSTALLATION............................................................................................. 104
7.3 VOLTAGE PAGE....................................................................................................... 106
7.3.1 Refresh Time Setting....................................................................................... 107
7.3.2 High Limit Value and Low Limit Value Setting.............................................. 107

iSignager-1000-Q354 Digital Signage Player
Page vii
7.4 FAN PAGE ............................................................................................................... 108
7.4.1 Refresh Time Setting....................................................................................... 109
7.4.2 High Limit Value and Low Limit Value Setting.............................................. 109
7.4.3 Smart Fan Setting ...........................................................................................110
7.4.3.1 On/Off Mode............................................................................................110
7.4.3.2 PWM Mode..............................................................................................110
7.4.3.3 Automatic Mode.......................................................................................111
7.5 TEMPERATURE PAGE ...............................................................................................112
7.5.1 Refresh Time Setting........................................................................................113
7.5.2 High Limit Value and Low Limit Value Setting...............................................114
7.6 CASH DRAWER PAGE...............................................................................................115
7.7 WATCHDOG TIMER PAGE .........................................................................................116
7.8 DIO PAGE ...............................................................................................................117
7.8.1 GPO Information Setting................................................................................117
7.9 LOAD/SAVE PAGE....................................................................................................118
8 TROUBLESHOOTINGAND MAINTENANCE ................................................... 120
8.1 ISIGNAGER-1000-Q354 SYSTEM MAINTENANCE OVERVIEW ................................. 121
8.2 SYSTEM TROUBLESHOOTING.................................................................................. 121
8.2.1 The System Doesn’t Turn On.......................................................................... 121
8.2.2 The System Doesn’t Boot Up.......................................................................... 122
8.3 JUMPER SETTING AND EXPANSION CARD INSTALLATION........................................ 123
8.3.1 Cover Case Removal...................................................................................... 123
8.3.2 Configure the Jumper Settings....................................................................... 124
8.3.3 Expansion Card Installation (Optional) ........................................................ 124
8.4 COMPONENT REPLACEMENT PROCEDURE .............................................................. 125
8.4.1 System Fan Replacement ............................................................................... 126
8.4.2 HDD Replacement......................................................................................... 127
8.4.2.1 HDD Removal ........................................................................................ 127
8.4.2.2 HDD Installation..................................................................................... 128
8.4.3 Motherboard Replacement............................................................................. 129
8.4.3.1 Motherboard Removal............................................................................ 129
8.4.3.2 Motherboard Installation......................................................................... 131
8.4.4 Power Supply Replacement............................................................................ 132
8.4.4.1 Power Supply Removal........................................................................... 132

iSignager-1000-Q354 Digital Signage Player
Page viii
8.4.4.2 Power Supply Installation....................................................................... 134
8.4.5 DIMM Replacement....................................................................................... 135
8.4.6 ODD Replacement (Optional) ....................................................................... 135
8.4.6.1 ODD Removal ........................................................................................ 136
8.4.6.2 ODD Installation..................................................................................... 137
8.4.7 PCIe Riser Card Replacement (Optional) ..................................................... 138
A SAFETY PRECAUTIONS....................................................................................... 140
A.1 SAFETY PRECAUTIONS .......................................................................................... 141
A.1.1 General Safety Precautions........................................................................... 141
A.1.2 Anti-static Precautions .................................................................................. 142
A.2 MAINTENANCE AND CLEANING PRECAUTIONS...................................................... 142
A.2.1 Maintenance and Cleaning............................................................................ 142
A.2.2 Cleaning Tools............................................................................................... 143
B INTERFACE CONNECTORS ................................................................................ 145
B.1 PERIPHERAL INTERFACE CONNECTORS.................................................................. 146
C BIOS MENU OPTIONS........................................................................................... 152
C.1 BIOS CONFIGURATION OPTIONS ........................................................................... 153
D WATCHDOG TIMER .............................................................................................. 156
E HAZARDOUS MATERIALS DISCLOSURE ....................................................... 159
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 160
F INTEL®MATRIX STORAGE MANAGER........................................................... 163
F.1 INTRODUCTION....................................................................................................... 164
F.1.1 Precautions .................................................................................................... 164
F.2 FEATURES AND BENEFITS ....................................................................................... 165
F.3 ACCESSING THE INTEL®MATRIX STORAGE MANAGER........................................... 165
F.4 RAID CONFIGURATION.......................................................................................... 166
F.4.1 Creating a RAID Volume................................................................................ 166
F.4.2 Deleting a RAID Volume................................................................................ 170
F.4.3 Resetting a Disk to Non-RAID....................................................................... 172
F.4.4 Exiting the Matrix Storage Manager ............................................................. 174

iSignager-1000-Q354 Digital Signage Player
Page ix
List of Figures
Figure 1-1: iSignager-1000-Q354 Digital Signage Player............................................................2
Figure 1-2: ACE-A627A Power Supply .........................................................................................5
Figure 2-1: iSignager-1000-Q354 Dimensions (mm)...................................................................9
Figure 2-2: iSignager-1000-Q354 Front Panel............................................................................10
Figure 2-3: iSignager-1000-Q354 Rear Panel.............................................................................11
Figure 2-4: Internal Overview ......................................................................................................13
Figure 3-1: POS-Q354 Jumper and Connector Locations........................................................16
Figure 3-2: Jumpers .....................................................................................................................20
Figure 3-3: ATX Power Select Jumper Location .......................................................................22
Figure 3-4: Clear CMOS Jumper .................................................................................................23
Figure 3-5: COM 1/2 Pin 9 Setting Jumper Location.................................................................24
Figure 3-6: COM 3/4 Pin 9 Setting Jumper Location.................................................................25
Figure 4-1: CF Card Slot Cover Retention Screw......................................................................29
Figure 4-2: Power Button and Power LED .................................................................................31
Figure 6-1: Available Drivers.......................................................................................................78
Figure 6-2: Chipset Driver Installation Program........................................................................79
Figure 6-3: Chipset Driver Installation Welcome Screen..........................................................80
Figure 6-4: Chipset Driver Installation License Agreement.....................................................80
Figure 6-5: Chipset Driver Readme File Information ................................................................81
Figure 6-6: Chipset Driver Installation Complete......................................................................81
Figure 6-7: The InstallShield Wizard Starts ...............................................................................82
Figure 6-8: Preparing Setup Screen ...........................................................................................83
Figure 6-9: InstallShield Wizard Welcome Screen....................................................................83
Figure 6-10: Audio Driver Software Configuration....................................................................84
Figure 6-11: Installation Wizard Updates the System...............................................................84
Figure 6-12: Restart the Computer .............................................................................................85
Figure 6-13: Intel® Graphics Media Accelerator InstallShield Wizard....................................86
Figure 6-14: InstallShield Wizard Extracting Files ....................................................................86
Figure 6-15: Intel® Graphics Media Accelerator Driver Welcome Screen..............................87
Figure 6-16: Intel® Graphics Media Accelerator Driver License Agreement .........................87
Figure 6-17: Intel® Graphics Media Accelerator Driver Installing Notice...............................88

iSignager-1000-Q354 Digital Signage Player
Page x
Figure 6-18: Intel® Graphics Media Accelerator Installation Complete..................................88
Figure 6-19: Windows Control Panel..........................................................................................89
Figure 6-20: System Icon.............................................................................................................89
Figure 6-21: Device Manager Tab ...............................................................................................90
Figure 6-22: Device Manager List ...............................................................................................90
Figure 6-23: Search for Suitable Driver......................................................................................91
Figure 6-24: Locate Driver Files..................................................................................................91
Figure 6-25: Location Browsing Window...................................................................................92
Figure 6-26: Atheros Client Installation Program Screen.........................................................93
Figure 6-27: Atheros Wireless LAN Driver License Agreement ..............................................93
Figure 6-28: Wireless LAN Driver Setup Type...........................................................................94
Figure 6-29: Driver Destination Location...................................................................................94
Figure 6-30: Wireless LAN Driver Important Notice..................................................................95
Figure 6-31: Wireless LAN Configuration Tool Selection.........................................................95
Figure 6-32: Single Sign On Feature Selection .........................................................................96
Figure 6-33: Wireless LAN Driver Installation ...........................................................................96
Figure 6-34: Wireless LAN Driver Install Wizard Completed ...................................................97
Figure 6-35: Intel® AMT Driver Directory...................................................................................98
Figure 6-36: Intel® AMT Driver Installation Icon .......................................................................98
Figure 6-37: Intel® AMT Welcome Screen .................................................................................99
Figure 6-38: Intel® AMT License Agreement.............................................................................99
Figure 6-39: Intel® AMT Readme File...................................................................................... 100
Figure 6-40: Intel® AMT Setup Operations............................................................................. 100
Figure 6-41: Completed Installation......................................................................................... 101
Figure 6-42: Intel® AMT Driver Directory................................................................................ 101
Figure 6-43: HECI Driver Installation Icon............................................................................... 102
Figure 7-1: iSMM Installation Welcome Screen...................................................................... 104
Figure 7-2: iSMM Installation Customer Information............................................................. 105
Figure 7-3: Ready to Install the Program Window ................................................................. 105
Figure 7-4: Voltage Page........................................................................................................... 106
Figure 7-5: Voltage Refresh Time Setting............................................................................... 107
Figure 7-6: Voltage Page – High Limit and Low Limit............................................................ 107
Figure 7-7: Fan Page ................................................................................................................. 108
Figure 7-8: Fan Speed Refresh Time Setting.......................................................................... 109
Figure 7-9: Fan Page – High Limit and Low Limit .................................................................. 109

iSignager-1000-Q354 Digital Signage Player
Page xi
Figure 7-10: Smart Fan Setting – On/Off Mode....................................................................... 110
Figure 7-11: Smart Fan Setting – PWM Mode......................................................................... 111
Figure 7-12: Smart Fan Setting – Automatic Mode ................................................................ 112
Figure 7-13: Temperature Page................................................................................................ 113
Figure 7-14: Temperature Refresh Time Setting .................................................................... 113
Figure 7-15: Temperature Page – High Limit and Low Limit................................................. 114
Figure 7-16: Cash Drawer Page................................................................................................ 115
Figure 7-17: WDT Page ............................................................................................................. 116
Figure 7-18: DIO Page ............................................................................................................... 117
Figure 7-19: Load/Save Page.................................................................................................... 119
Figure 8-1: Cover Case Thumb Screws................................................................................... 123
Figure 8-2: Cover Case Removal ............................................................................................. 123
Figure 8-3: Expansion Slot Cover Retention Screw............................................................... 124
Figure 8-4: Expansion Slot Cover Retention Screw (Rear Panel) ........................................ 125
Figure 8-5: System Fan Bracket Retention Screws ............................................................... 126
Figure 8-6: System Fan Retention Screws.............................................................................. 126
Figure 8-7: HDD Bracket Retention Screws............................................................................ 127
Figure 8-8: HDD Retention Screws.......................................................................................... 128
Figure 8-9: Rear Panel Connector Retention Screws............................................................ 129
Figure 8-10: Motherboard Connectors.................................................................................... 130
Figure 8-11: Motherboard Retention Screws.......................................................................... 131
Figure 8-12: Power Supply Retention Screws........................................................................ 133
Figure 8-13: Power Supply Removal ....................................................................................... 133
Figure 8-14: Power Supply Bracket Retention Screws.......................................................... 134
Figure 8-15: DIMM Installation..................................................................................................135
Figure 8-16: ODD Bracket Retention Screws.......................................................................... 136
Figure 8-17: SATA Cable Retention Screws ........................................................................... 137
Figure 8-18: ODD Retention Screws........................................................................................ 137
Figure 8-19: PCIe Riser Card Retention Screws..................................................................... 138

iSignager-1000-Q354 Digital Signage Player
Page xii
List of Tables
Table 1-2: Technical Specifications..............................................................................................4
Table 1-3: Power Supply Specifications.......................................................................................5
Table 1-4: Wireless Module Specifications..................................................................................6
Table 3-1: Peripheral Interface Connectors...............................................................................19
Table 3-2: Rear Panel Connectors..............................................................................................20
Table 3-3: Jumpers.......................................................................................................................21
Table 3-4: ATX Power Select Jumper Settings..........................................................................21
Table 3-5: Clear CMOS Jumper Settings....................................................................................23
Table 3-6: COM 1/2 Pin 9 Setting Jumper Settings...................................................................24
Table 3-7: COM 3/4 Pin 9 Setting Jumper Settings...................................................................25
Table 4-1: Package List Contents...............................................................................................28
Table 5-1: BIOS Navigation Keys................................................................................................34

iSignager-1000-Q354 Digital Signage Player
Page xiii
List of BIOS Menus
Menu 1: Main.................................................................................................................................35
Menu 2: Advanced........................................................................................................................37
Menu 3: CPU Configuration.........................................................................................................37
Menu 4: IDE Configuration...........................................................................................................38
Menu 5: IDE Master and IDE Slave Configuration.....................................................................40
Menu 6: Super IO Configuration .................................................................................................44
Menu 7: Hardware Health Configuration....................................................................................48
Menu 8: Power Configuration......................................................................................................50
Menu 9: ACPI Configuration [Advanced\Power Configuration] ..............................................51
Menu 10: Power Configuration....................................................................................................52
Menu 11: AHCI Configuration......................................................................................................54
Menu 12: AHCI Port n Configuration Menu................................................................................55
Menu 13: Intel AMT Configuration..............................................................................................56
Menu 14: ME Subsystem Configuration.....................................................................................57
Menu 15: Remote Access Configuration [Advanced]...............................................................59
Menu 16: USB Configuration.......................................................................................................62
Menu 17: PCI/PnP Configuration ................................................................................................64
Menu 18: Boot...............................................................................................................................66
Menu 19: Boot Settings Configuration.......................................................................................67
Menu 20: Security.........................................................................................................................70
Menu 21: Chipset..........................................................................................................................71
Menu 22: Northbridge Chipset Configuration ...........................................................................72
Menu 23:Southbridge Chipset Configuration............................................................................74
Menu 24:Exit..................................................................................................................................75

iSignager-1000-Q354 Digital Signage Player
Page 1
1 Introduction
Chapter
1

iSignager-1000-Q354 Digital Signage Player
Page 2
1.1 iSignager-1000-Q354 Overview
Figure 1-1: iSignager-1000-Q354 Digital Signage Player
The iSignager-1000-Q354 is an Intel® based integrated service solution that can be
applied in diverse operational environments and implemented in multi-faceted
point-of-sale applications. The iSignager-1000-Q354 comes fully kitted with a
high-performance motherboard and a host of other peripheral interface connectors. The
two integrated GbE LANs ensure the uninterrupted network connection. The preinstalled
320 GB HDD and 2 GB DDR2 SDRAM make the iSignager-1000-Q354 a ready-to-use
system. The flexible PCI/PCIe expansion allows the iSignager-1000-Q354 to meet
multiple application requirements. The iSignager-1000-Q354 is designed for ease of use
and easy installation.
1.1.1 iSignager-1000-Q354 Benefits
The iSignager-1000-Q354 has the following benefits:
Easy installation and maintenance
Complete integration saves solution development time and cost
A full range of I/O interfaces compatible with most multimedia external
devices
Quick access CF storage card interface
Powerful preinstalled Intel® Core™2 Duo/Core™2 Quad CPU and
motherboard ensures rigorous processing needs can be met

iSignager-1000-Q354 Digital Signage Player
Page 3
1.1.2 iSignager-1000-Q354 Features
The iSignager-1000-Q354 has the following features
RoHS compliant design
CPU preinstalled
o3.0 GHz Intel® Core™2 Duo E8400 or
o2.66 GHz Intel® Core™2 Quad Q9400
2 GB DDR2 SDRAM DIMM preinstalled
Two GbE RJ-45 connectors supported
One CompactFlash® Type I or Type II card supported
Serial port 5 V or 12 V LED indicators on the rear panel
802.11b/g wireless LAN module preinstalled on the PCIe riser card
3.5” 320 GB HDD and DVD combo drive preinstalled
PCIe x1 and PCIe x16 expansion cards supported
1.2 Technical Specifications
The specifications for the Intel® based iSignager-1000-Q354 listed below.
iSignager-1000-Q354
CPU 3.0 GHz Intel® Core™2 Duo E8400 with 6 MB L2 cache or
2.66 GHz Intel® Core™2 Quad Q9400 with 6 MB L2 cache
System Chipset Northbridge: Intel® Q35
Southbridge: ICH9DO
System Memory Two 240-pin 1 GB 667 MHz DDR2 SDRAM DIMM preinstalled
Ethernet Two RJ-45 for GbE
Display One VGA integrated in Intel® Q35
USB Seven USB 2.0 supported:
6 x Standard USB 2.0 ports (two on the front, four on the rear)
1 x PoweredUSB port provides 12 V output

iSignager-1000-Q354 Digital Signage Player
Page 4
Serial Port Four RS-232 ports:
2 x Powered RS-232 ports (COM3 and COM4) providing 5 V or 12 V
power output via Pin 9 (indicated by LEDs on the rear panel)
2 x RS-232 ports (COM1 and COM2)
Parallel Port One DB-25 parallel port
Digital I/O Two RJ-12 connectors for cash drawer
Audio 1 x Line-out
1 x Mic-in
Keyboard/Mouse 1 x PS/2 Keyboard connector
1 x PS/2 Mouse connector
ODD One DVD combo drive (supports CD-R/CD-RW/DVD-R)
HDD One preinstalled 3.5” 320 GB HDD
(the system supports two 3.5” HDD drive bays)
SSD One CompactFlash® Type II slot
Expansion Slot One preinstalled PCIe riser card including:
1 x PCIe mini slot (preinstalled with a wireless LAN module)
1 x PCIe x1
1 x PCIe x16
Power Supply 270 W ATX power supply preinstalled, input voltage:
90 V AC ~ 264 V AC
Operating Temperature 0ºC ~ 45ºC
Net Weight 5.1 kg
Dimensions (W x D x H) 350 mm x 309 mm x 95 mm
EMC/Safety CE, FCC class B, UL, CCC
Table 1-1: Technical Specifications

iSignager-1000-Q354 Digital Signage Player
Page 5
1.3 Power Supply
The iSignager-1000-Q354 models all preinstalled with a 270 W 1U AC input ATX power
supply.
Figure 1-2: ACE-A627A Power Supply
The specifications for the ACE-A627A power supply are listed in Table 1-2:
Model ACE-A627A
Input Type 90~264 V AC full range
+3.3 V +5 V +12 V +12 V 2 -12 V +5 VSB
Output Voltage
16 A
(0.5 A min.)
18 A
(0.5 A min.)
16 A
(1 A min.)
10 A
(1 A min.)
0.8 A
(0 A min.)
2.5 A
(0 A min.)
Efficiency 80%
Temperature Operating: 0ºC ~ 50ºC
Storage: -20ºC ~ 80ºC
MTBF 100,000 hrs
Output Connector 1 x 20-pin ATX connector
1 x 4-pin 12 V CPU connector
3 x HDD power connector
Dimensions 150 mm x 81.5 mm x 40.5 mm
Table 1-2: Power Supply Specifications

iSignager-1000-Q354 Digital Signage Player
Page 6
1.4 Wireless LAN Module
An Azurewave AW-GE780 wireless 802.11b/g PCIe mini card is installed on the PCIe riser
card. The specifications for the wireless LAN module are listed in Table 1-3:
AW-GE780
Standard IEEE 802.11 b/g
Interface PCIe mini card
Connectors 2 x U.FL-R-SMT Antenna connectors
Frequency Band 2412 MHz ~ 2472 MHz
Modulation 802.11g: OFDM
802.11b: CCK (11, 5.5 Mbps), DQPSK (2 Mbps), BPSK (1 Mbps)
Output Power 802.11b: typical 16 ± 1.5 dBm
802.11g: typical 13 ± 1.5 dBm
Receive Sensitivity 802.11b: typical -76 dBm at 11 Mbps
802.11g: typical -68 dBm at 54 Mbps
Operating Voltage 3.3 V
Dimensions 30.00 mm x 51 mm x 3.3 mm
Table 1-3: Wireless Module Specifications
