CTC Giersch MG40 Series Manual

January 2019 edition
In the interests of contin uous product im-
pro vemen t, tech nical specifica tions are
su bject to change without prio r n otice!
Gas
Technical Information • Installation Instructions
MG40-ZM-L-LN
GB

2/44 22.01.19, Subject to alterations
Declaration of Conformity for gas burner
We, Enertech GmbH, Adjutantenkamp 18 in D-58675 Hemer declare under
our sole responsibility that
Gas burner type MG40/..
complies with the stipulations of directives
MD2006/42/EG
EMV2014/30/EG
LVD2014/35/EG
GAR 2016/426/EG
MCP2015/2193/EU
1. BImSchV 2010
RoHS 2011/65/EU
DIN EN 676
and is designated as follows:
CE-0085
Hemer, 15.07.2018

Subject to alterations, 22.01.19 3/44
Contents Page
1 Safety-relevant information 4
1.1 Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 General information on safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5 Restriction of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.6 Qualifified personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.7 Transport and intermediate storage at installation location . . . . . . . . . . 7
1.8 Behaviour if there is a smell of gas 7
1.9 Hazards when handling electrical current . . . . . . . . . . . . . . . . . . . . . . . 7
1.10 Behaviour in the case of an emergency . . . . . . . . . . . . . . . . . . . . . . . . 7
1.11 Atmospheric explosion protection (ATEX) . . . . . . . . . . . . . . . . . . . . . . . 7
1.12 Recycling and disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2 Type code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Working ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.4 Gas train dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.5 Selection diagram for gas fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.6 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 Burner assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 Installing the gas jacket at the boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Gas mixer head adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.3 Electrodes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.4 Gas fitting installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.5 Installing the burner housing at the gas jacket . . . . . . . . . . . . . . . . . . . 13
3.6 Swivel position / service position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4 Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Air / gas actuator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 Air pressure monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.3 Gas input pressure min. with leakage check . . . . . . . . . . . . . . . . . . . . . 16
4.4 Gas pressure switch max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.5 Flame monitor with ionisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.6 Connection diagram for connector assignment . . . . . . . . . . . . . . . . . . . 18
4.7 Burner management system LMV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5 Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.1 Gas supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.2 Setting tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.3 Principles of calculation for gas burner adjustment . . . . . . . . . . . . . . . . 23
6 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1 Prior to commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.2 Operation and device desription . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.3 LMV programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.4 Adjustment protocol - first commissioning 33
6.5 LMV phase display / operating display . . . . . . . . . . . . . . . . . . . . . . . . . 34
7 Decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.1 Prior to maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
82. Maintenenace positions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.3 Maintenance schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
9 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
9.1 LMV fault code list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
9.2 Exploded view / spare parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
