Cub Cadet 1515 User manual

PRINTED IN U.S.A. FORM NO. 770-10604A
(01/2002)
Parts Manual
Hydrostatic Lawn Tractor
Models 1515
1517
Series 1500
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019

-1-
DESCRIPTION PAGE
Axle, Front ....................................................... 5, 6
Battery ............................................................. 15, 16
Brake Pedal ..................................................... 11, 12
Bulkhead .......................................................... 17, 18
Mower Deck, 38-inch ........................................ 21, 22
Mower Deck, 42-inch ........................................ 23, 24
Dash Panel ...................................................... 15, 16
Drive System ................................................... 3, 4
Electrical Sysytem ........................................... 27, 28
Engine
Air Filter ........................................................
Blower Housing ............................................
Breather ........................................................
Carburetor ....................................................
Controls ........................................................
Crankcase ....................................................
Crankshaft ....................................................
Cylinder Head ...............................................
Electrical .......................................................
Exhaust..........................................................
Fuel System ..................................................
Oil Pan ..........................................................
Starter ...........................................................
Valves ...........................................................
41
37
33, 34
39, 40
38
29, 30
29, 30
33, 34
35, 36
41
39, 40
31, 32
35, 36
33, 34
Engine Mounting .............................................. 14
Fender ............................................................. 9
Frame .............................................................. 7, 8
Fuel Tank ......................................................... 9
Grille ................................................................ 17, 18
Hood ................................................................ 17, 18
Deck Lift Handle/Linkage ................................. 10
Muffler .............................................................. 14
PTO Clutch ...................................................... 19, 20
Seat ................................................................. 13
Side Panels ..................................................... 17, 18
Steering ........................................................... 5, 6
Transmission, Hydrostatic ............................... 25, 26
Wheels, Front & Rear ...................................... 2
DESCRIPTION PAGE
MODELS 1515 & 1517
TABLE OF CONTENTS
NOTE, For painted parts, please refer
to the list of color codes below. Please
add the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part,
numbered 700-xxxx, is painted Cub
Yellow, the part number to order would
be 700-xxxx-0498.
Cub Yellow: 0498
Cub Beige: 0499
Powder Black: 0637

-2-
WHEELS
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 634-0245 Rim/Wheel Assembly, 20 x 9 x 8 (4-Lug) 2
2 634-3012A Wheel, Complete, 15 x 6 x 6 2
3 734-3189 Tire, Turf, Cub Cadet 20 x 9 x 8 2
4 634-0246 Rim Assembly, 8.0 x 6.19 (4-Lug) 2
5 712-3050 Lug Nut, 7/16-14 8
6 741-3032 Bearing, Ball, .75 ID x 1.75 OD 4
7 634-3015 Rim Assembly, Bead Lock, 6 x 4.5 2
8 731-3020 Hub Cap 2
9 734-3186 Tire, Turf, Cub Cadet 15 x 6 x 6 2
— 737-0224 Gease Fitting 2
— 734-0255 Valve, Tubeless Air 4
2
1
3
4
56
7
6
8
9

-3-
DRIVE SYSTEM
B
52
A
16
Attach Spring (732-1716) Here
10
44
36
36
35
23
51
30
36
32
26
28
44
43
15
14
38
24
50
12
18
46
48
47
40
41
45
31
22
11
39
37
36
35
23
33 49
29
17
21
34
13
20
27
18
22
18
36
23
25
19
42
4
6
79
8
9
8
5
2
3
1
A
B
BB
22
37

-4-
DRIVE SYSTEM
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 17840 Bracket, Mounting, Transaxle 2
2 618-0365 Hub Assembly, Wheel 2
3 618-0667 Transmission, Hydrostatic 1
4 629-0949A Harness Assembly, Ground & Reverse 1
5 683-0251 Bracket Assembly, Idler, Center Dbl 1
6 710-0176 Hex Cap Screw, 5/16-18, 2.75, Gr5 4
7 710-0227 Screw, #8-18, 0.500 2
8 710-0344 Hex Cap Screw, 3/8-16, 1.50, Gr5 3
9 710-0604A Screw, 5/16-18, 0.625 6
10 710-0653 Screw, 1/4-20, 0.375 1
11 710-3007 Screw, #12-24, 0.375 3
12 710-3011 Hex Cap Screw, 3/8-16, 2.25, Gr5 1
13 710-3103 Hex Cap Screw, 5/16-18, 2.00, Gr5 1
14 711-0677 Ferrule, 5/16-18 x .312 Dia 1
15 711-0832 Ferrule, 3/8-24 x .375 Dia 1
16 712-0291 Nut, Hex Lock, 1/4-20 1
17 712-0333 Nut, Hex, 1/2-20, Gr2 1
18 712-0431 Nut, Flange Lock, 3/8-16 3
19 712-1329 Nut, 3/4-16, Grb, Hx 2
20 712-3004A Nut, Flange Lock, 5/16-18, Gr5 5
21 712-3010 Nut, Hex, 5/16-18, Gr5 1
22 712-3017 Nut, Hex, 3/8-16, Gr8 4
23 714-0104 Pin, Cotter, .072 Dia. x 1.13 Lg 2
24 714-0111 Pin, Cotter, 3/32, 1.0 1
25 725-0157 Cable, Tie, 3/16 x .05 x 7.4 2
26 725-1644 Switch, Spring, Short 1
27 726-0154 Tie, Cable, Push Mount 7.5 Lg 1
28 726-0320 Plate, Insulator Nut 1
29 731-1449A Fan, Blade, 10” 1
30 732-0209 Spring, .48 OD x 2.03 Extension 1
31 732-0429A Spring, Extension, .50 Dia x 3.97 Lg 1
32 732-0716 Spring, Extension, .59 OD x 4.00 Lg 1
33 732-0729 Ring, Wire 1
34 732-0994 Spring, Extension, .500 Dia x 7.0 Lg 1
35 732-3118 Spring, Extension, 3/8 OD x 1.44 Lg 1
36 736-0140 Washer, Flat, .385 x .62 x .063 3
37 736-0169 Washer, Lock, 3/8 , Regular Duty 2
38 736-0275 Washer, Flat, .344 x .688 x .065 1
39 736-0921 Washer, Lock, 1/2 , Regular Duty 1
40 736-3010 Washer, Flat, .407 x .812 x .135 Hdn 1
41 738-0372B Spacer, Shoulder, 1.00 x .38 x .38 1
42 747-1149 Rod, Hydro Bypass 1
43 747-1150 Rod, Brake, Hydro 1
44 747-1151 Rod, Control, Hydro 1
45 750-0535 Spacer, .376 ID x .625 OD x .22 1
46 754-0640 Belt, V Type, Poly 1
47 756-0116 Pulley, Idler, V Type x 3.06 Dia 2
48 756-0981A Pulley, Idler, Flat 2.75 OD 1
49 756-1166 Pulley, Input, 5.0 Dia 1
50 783-0810 Bracket, Transmission, Torque Hydro 1
51 783-1019 Bracket, Actuator, Switch 1
52 756-0639 Pulley, Engine, 3.56 Dia

-5-
STEERING
18
20
20
10
19
19
17
15
11
9
8
7
2
9
3
1
13
6
5
12
23
27
21
26
24
7
22
25
14
4
28
29

-6-
STEERING
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0514 Hex Cap Screw, 3/8-16, 1.00, Gr5, Std 2
2 711-1408 Link, Drag, RH 1
3 711-1409A Link, Drag, LH 1
4 712-0237 Nut, Hex Lock, 5/16-24 1
5 712-0240 Nut, Jam, 7/16-20, Gr2 2
6 712-0241 Nut, Hex, 3/8-24, Gr5 2
7 712-0431 Nut, Flange Lock, 3/8-16 4
8 712-0459 Nut, Flange Lock, 7/16-20 1
9 712-3004A Nut, Flange Lock, 5/16-18 2
10 717-1550D Gear, Steering, 11/90 Ratio 1
11 717-1554 Gear, Pinion, Steering 1
12 723-0610 Ball Joint, 7/16-20 2
13 736-0169 Washer, Lock, 3/8 , Regular Duty 2
14 736-0242 Washer, Bell, .340 x .872 x .060 1
15 736-3084 Washer, Flat, .510 x 1.120 x .060 1
16 737-3007 Grease, Alvania Ep 2 1
17 738-0372B Spacer, Shoulder, 1.00 x .38 x .38 2
18 738-1194 Shaft, Steering, .625 OD x 25.00 Lg 1
19 741-0475 Bushing, Plastic, .380 ID 2
20 741-0656 Bearing, Hex Flange, 5/8 1
21 683-0605 Axle Assembly, LH .750 Dia 1
22 683-0606 Axle Assembly, RH .750 Dia 1
23 712-0417A Nut, Hex, Flange, 5/8-18 2
24 714-0162 Pin, Cot, 5/32, 1.25 2
25 719-0583 Axle, Pivot, Cast .750 Dia 1
26 736-0866 Washer, Flat, .755 x 1.92 x.060 2
27 738-1011 Spacer, Shoulder, .500 x 2.230, 3/8-16 2
28 731-3209 Wheel, Steering, Soft Grip, Three Spoke 1
29 731-3210 Cover, Steering Wheel 1

-7-
FRAME
13
10
13
17
20
10
14
15
11
23 21
19
16
12
19
16
22
23
17
20
710-0607 Used
3
3
3
3
4
5
1
6
7
9
2
8
6
7
3
At This Location Only
26

-8-
FRAME
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 683-0304A Frame Assembly, Lower 1
2 683-0612 Bumper Assembly 1
3 710-0604A Screw, Self-tapping, 5/16-18, 0.625 19
4 710-0607 Screw, Self-tapping, 5/16-18, 0.500 1
5 710-0642 Screw, Self-tapping, 1/4-20, 0.750 1
6 710-1238 Screw, 5/16-18, .875, Gr5 2
7 710-1260A Screw, 5/16-18, 0.750 2
8 711-0332 Pin, Clevis, .50 Dia x .78 Lg 2
9 712-0431 Nut, Flange Lock, 3/8-16 2
10 712-0459 Nut, Flange Lock, 7/16-20 2
11 712-3006 Nut, Hex, 1/4-20, Gr5 1
12 714-0145 Pin, Click, .092 x 1.64 Lg 2
13 732-3080A Spring, Compression, 1.28 OD x 3.50 Lg 2
14 736-0222 Washer, Lock, Ext 1/4 2
15 736-0329 Washer, Lock, 1/4, Regular Duty 1
16 736-0331 Washer, Bell, .390 x 1.13 x .062 2
17 736-0407 Washer, Bell .45 x 1.00 x .062 2
18 737-3007 Grease, Alvania Ep 2 1
19 738-0143 Shoulder Screw, 3/8-16 2
20 738-1020 Shoulder Screw .625 x .500, 7/16-20 2
21 783-0726B Bracket, Pivot, Support RH 1
22 783-0727A Bracket, Pivot, Support LH 1
23 783-0728 Bracket, Pivot, Bar 1
24 783-1462 Frame, Upper, Cub 1500 1
25 783-1463 Bracket, Frame, Seat 1
26 722-3022 Foam Tape, .625 x .25 18

-9-
FENDER & FUEL TANK
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0260A Bolt, Carriage, 5/16-18 x .62 Lg 2
2 710-0604A Screw, 5/16-18, 0.625 8
3 710-0895 Screw, 1/4-15, 0.750 9
4 712-3004A Nut, Flange Lock, 5/16-18 2
5 731-0511 Strip, Trim 1.5
6 731-2616 Cover, Fender, RH 1
7 731-2617 Cover, Fender, LH 1
8 736-3078 Washer, Flat, .349 x 1.00 x .063 2
9 783-0677 Bracket, Lift, Adjustment 1
10 783-1461 Fender 1
11 783-1489 Bracket, Seat, Mount 2
12 726-3046 Clip, Ratchet, .250 Dia 12
13 735-0697 Pad, Foot, LH 1
14 735-0698A Pad, Foot, RH 1
15 751-0819 Tank, Fuel 1
16 751-3124B Cap, Fuel 1
10
13
12
14
6
2
3
9
2
1
5
8
1
8
4
4
7
2
11 16
15

-10-
LIFT ASSEMBLY
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1683-0197B Shaft Assembly, Lift 1
2711-0332 Pin, Clevis, .50 Dia x .78 Lg 2
3712-0206 Nut, Hex, 1/2-13, Gr5 2
4 712-0431 Nut, Flange Lock, 3/8-16 2
5 712-3004A Nut, Flange Lock, 5/16-18, Gr5 2
6712-3083 Nut, Hex Lock, 1/2-13, Gr8, Nylon 2
7 714-0104 Pin, Cotter, .072 Dia. x 1.13 Lg 2
8 714-0111 Pin, Cotter, 3/32, 1.0 2
9714-0145A Pin, Click, .092 x 1.64 Lg 2
10 716-0106 E-ring, .625 Dia. Shaft 2
11 731-2111A Knob 1
12 732-0874 Spring, Torsion 1
13 736-0160 Washer, Flat, .53 x .93 x .050 2
14 736-0275 Washer, Flat, .344 x .688 x .065 4
15 736-0921 Washer, Lock, 1/2 , Regular Duty 2
16 736-3019 Washer, Flat, .531 x 1.062 x .134 2
17 736-3084 Washer, Flat, .510 x 1.120 x .060 3
18 738-0138A Screw, Hex Cap, 5/16-18x.620 Gr2 2
19 738-0143 Shoulder Screw, 3/8-16 2
20 741-0225 Bearing, Hex Flange 2
21 741-0715 Bearing, Flange, Snap .500 ID 2
22 746-0968 Cable, Lift, 16.16 Lg 2
23 747-1111A Handle, Lift 1
24 747-1130B Rod, Deck, Front Adjustment .5" Dia 1
25 756-1154 Pulley, Roller 2
26 783-0678A Lift, Arm 2
27 783-0720A Bracket, Adjustment, Front Deck Rod 1
5
8
4
4
8
5
9
1
722
20
25
11
18
14
26
19 13
23
18
14
10
12
21
25
14
22
20
10
21
17
26 13
19
24
15
17
27
16
15
2
3
9
6
3
B
B
A
A

-11-
PEDAL ASSEMBLY
8
6
10
20
6
11
10
20
27
28
19
25
10
12
18 29
10
32
17 30
21
13
23 25
19
11
26
14
18
10
24
33
22
26
7
8
2
9
9
1
3
5
4
5
16
31
Hook to Flange
In Frame (783-0650)
15

-12-
PEDAL ASSEMBLY
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 647-0031 Control Assembly, Brake 1
2 647-0049 Control Assembly, Hydro 1
3 710-0604A Screw, Self-tapping, 5/16-18, 0.625 4
4 710-0650 Screw, Self-tapping, 5/16-18, 0.875 1
5 710-1260A Screw, 5/16-18, 0.750 3
6 711-0736 Adjustment Ferrule 1/4-20 x 1.0 2
7 711-1363 Pin, 3/8-16, 3/8 x 2.43 Lg 1
8 712-0431 Nut, Flange Lock, 3/8-16 2
9 712-3004A Nut, Flange Lock, 5/16-18, Gr5 2
10 714-0104 Pin, Cotter, .072 Dia. x 1.13 Lg 6
11 714-0111 Pin, Cotter, 3/32, 1.0 2
12 719-0584 Pedal, Control 1
13 732-0335 Spring, Compression, .405 x 1.17 1
14 732-0955 Spring, Extension, .50 OD x 1.41 Lg 1
15 732-0963 Spring, Extension, .50 Dia x 6.37 Lg 1
16 735-3049 Pad, Brake, Control 1
17 736-0133 Washer, Flat, .411 x 1.25 x .100 1
18 736-0142 Washer, Flat, .281 x .50 x .063 2
19 736-0187 Washer, Flat .64 ID x 1.24 x .06 2
20 736-0204 Washer, Flat, .344 ID x .62 OD 2
21 736-3004 Washer, Flat, .406 ID x .875 OD x .105 1
22 736-3008 Washer, Flat, .344 x .750 x .120 1
23 738-0155 Shoulder, Screw .437 x 1.62 Lg 1
24 738-0507B Screw, Shoulder, .500 Dia x .434 1
25 741-0225 Bearing, Hex Flange 2
26 741-3065B Bearing, Hex Flange, .628 ID, Split 2
27 747-1137 Rod, Control, Cruise 1
28 747-1138 Rod, Control, Brake Lock 1
29 748-0413 Latch, Cruise 1
30 748-0415B Spacer, .385 ID x .635 OD x 1.54 1
31 783-0653F Bracket, Support, Stearing 1
32 783-0663C Bracket, Lockout, Hydro 1
33 783-1469 Pedal, Brake 1

-13-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-1268 Screw, #10-16, 0.375 2
2 712-3004A Nut, Flange Lock, 5/16-18, Gr5 2
3 712-3027 Nut, Flange Lock, 1/4-20 1
4 720-0433 Grip, Seat, Adjustment (Yellow) 1
5 726-0201 Nut, Speed, .3125 ID 2
6 731-1989 Spacer, Seat, Adjustment 4
7 732-0499 Spring, Compression .41 OD x 1.50 1
8 732-1184 Spring, Extension, .84 Dia x 4.6 Lg. 1
9 736-0175 Washer, Spring, .265 x .562 x.025 1
10 736-0204 Washer, Flat, .344 ID x .62 OD 1
11 736-0275 Washer, Flat, .344 x .688 x .065 2
12 736-3019 Washer, Flat, .531 x 1.062 x .134 2
13 738-0137A Screw, Shoulder, .340 x .285, 1/4-20 1
14 738-0296 Shoulder, Screw .437 x .286 Lg 2
15 738-1198 Screw, Shoulder, .50 x.50, 5/16-18 4
16 783-0209A Bracket, Lift, Seat 1
17 783-0611 Stop, Seat, Adjustment 1
18 783-0738 Bracket, Pivot, Seat 1
19 783-0739 Lever, Seat, Adjustment 1
20 783-0753 Selector, Seat, Adjustment 1
21 757-3003 Seat, Mid-back, V-1480 1
ADJUSTABLE SEAT
18
6
11
12
15 14
17
19
20
15
10
13
9
3
4
2
1
7
5
16
2
8
21

-14-
Fits Over Fuel Line Routed Behind The Engine.
For Choke
Secures The Headlight Harness Slack To The Hood Hinge.
ENGINE ACCESSORIES
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0227 Screw, #8-18, 0.500 4
2 710-0599 Screw, Self-tapping, 1/4-20, 0.500 4
3 710-0604A Screw, 5/16-18, 0.625 4
4 710-3206A Screw, M8-1.25, 25.0, Gr8.8 4
5 712-3017 Nut, Hex, 3/8-16, Gr8 1
6 712-3086 Nut, M8, 1.25-6h, Flange 2
7 783-0615B Shield, Heat, Muffler 1
8 721-0375 Gasket, Exhaust, Kohler Single 1
9 722-0263 Foam, .625 x 1.50 x 10.0 Lg 2
10 725-0157 Cable, Tie, 3/16 x .05 x 7.4 1
11 726-0205 Clamp, Hose, .490 Dia. 2
12 751-3142 Cap, Oil, Drain 1
13 736-0300 Washer, Flat, .406 x .875 x .059 1
14 736-0607 Washer, External Lock, 5/16 4
15 746-1087 Cable, Throttle, 27.4 Lg 1
16 751-0535 Hose, Fuel Line 60
17 751-0564 Deflector, Muffler 1
18 751-0617 Muffler, Single Inlet 1
19 751-0824 Pipe, Exhaust, Kohler Single 1
20 751-3140 Drain, Oil 1
21 751-3141 Hose, Extension, Oil Drain 12
2
15
12
20
7
3
8
6
1
4
95
7
20
13
16
11
10
14
18
19
17

-15-
DASH PANEL
6
11
7
14
21
3
16
16
16
12
3
16
20
2
13
1
15
23
8
9
24
19
18
4
17
25
5
3
2
22
10
5
26
3
27
2
28
29
30
31
32
8
3
34
33
35
37
36

-16-
DASH PANEL
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0136 Screw, 1/4-20, 1.75, Gr5 1
2 710-0599 Screw, Self-tapping, 1/4-20, 0.500 6
3 710-0604A Screw, 5/16-18, 0.625 8
4 710-0895 Screw, 1/4-15, 0.750 1
5 710-1238 Screw, 5/16-18, .875, Gr5 4
6 710-3217 Screw, Machine, #8-32, 0.375, Trus Phillips 1
7 712-0142 Nut, 8-32 1
8 712-0271 Nut, Hex, 1/4-20, Sems 2
9 712-0397 Nut, Wing, 1/4-20 w/ Bell Washer 2
10 712-3004A Nut, Flange Lock, 5/16-18, Gr5 4
11 731-2615 Dash 1
12 731-2620 Lever, Dash, Cruise 1
13 731-2621 Lever, Dash, Brake 1
14 731-3161 Knob, Throttle Control 1
15 731-3232 Roller, Latch, Hood 1
16 736-3078 Washer, Flat, .349 x 1.00 x .063 6
17 747-1323A Rod, .250 Dia x 4.25 Lg. 1
18 747-2130 Rod, Support, Side Panel RH 1
19 747-2131 Rod, Support, Side Panel LH 1
20 749-04000 Tube, Dash, Support 1
21 783-0462 Bracket, PTO Switch Retainer 1
22 783-1447 Bracket, Support, Battery 1
23 783-1448 Bracket, Support, Hood Latch 1
24 783-1449 Bracket, Battery, Hold Down 1
25 783-1499 Bracket, Rod, Dash 1
26 746-1149 Control, Choke, 23 Lg. 1
27 736-0222 Washer, External Lock, 1/4 2
28 725-1426 Solenoid, 12V, 100 Amp 1
29 725-1706 Battery, 270 CCA, Wet 1
30 712-3087 Nut, Wing, 1/4-20 1
31 738-1132 Screw, Shoulder, 1/4-20, .25 x .15 1
32 710-0751 Screw, 1/4-20, .620, Gr5 1
33 710-0192 Screw, #10-24 X .375 2
34 714-0104 Internal Cotter Pin, .072 x 1.13 1
35 710-0837 Screw, Oval Countersunk, #10-16 X .625 1
36 741-0501 Bearing, Steering Column, .634 ID x 1.36 1
37 783-04003 Steering Bracket 1

-17-
HOOD & GRILLE
3
23
5
13
21
19
14
22
27
17
22
10
26
27
12
15
29
28
24
16
31
20
25
11
7
4
1
8
2
6
18
30
14

-18-
HOOD & GRILLE
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0211 Bracket Assembly, Grille LH 1
2 603-0212 Bracket Assembly, Grille RH 1
3 603-0583A Bracket Assembly, Hood 1
4 625-0053 Headlight Assembly, Front 1
725-0963 Miniature Lamp, 12V Socket-type 2
725-1649 Socket, Lamp, Nylon 1/4-Turn 2
731-3138A Lens 1
731-3295 Leflector, Headlight 1
5 703-05000 Hood 1
6 703-2396 Side Panel, RH 1
7 703-2397 Side Panel, LH 1
8 703-2398 Grille 1
9 703-2465 Link, Hood Upper 6.06 2
10 703-2466A Link, Hood, Rear 2
11 703-2495 Screen, LH Side Panel 1
12 703-2496 Screen, RH Side Panel 1
13 703-2563A Bulkhead, Hood, Upper 1
14 710-0351 Screw, #10-16, 0.500, Pan Phillips 6
15 710-0599 Screw, Self-tapping, 1/4-20, 0.500 6
16 712-3027 Nut, Flange Lock, 1/4-20 8
17 712-3087 Nut, Wing, 1/4-20 2
18 722-3021 Tape, Two-sided Adhesive Foam 9
19 723-3061 Seal, Heat Baffle 19
20 726-0139 Nut, Speed, 10z U-type 2
21 728-0117 Rivet, Pop, .125 OD, #42 4
22 732-0334 Spring, Compression, .50 OD x .5 Lg 4
23 732-0855A Spring, Latch, Hood 1
24 736-0175 Washer, Spring, .265 x.562 x.025 8
25 736-0400 Washer, Flat, .194 x .62 OD x .063 2
26 738-3141 Screw, Shoulder, .31x .75, 1/4-20 2
27 748-3055 Bushing, Tapered, .32 ID x .69 OD 4
28 783-1467A Bracket, Mounting, Grille LH 1
29 783-1468A Bracket, Mounting, Grille RH 1
30 731-04009 Plenum, Hood 1
31 710-0436 Hex Screw, #10-16 x 0.625 2

-19-
POWER TAKE-OFF (PTO) SYSTEM
20
11
14
17
27
18
1
13
10
12
15
16
26
19
25
16
7
22
23
24
2
3
5
9
6
8
4
7
7
21
