Cubix HostEngine 5URP24 User manual

Cubix Corporation 2800 Lockheed Way Carson City, NV 89706-0719 Page 1
Sales 800.829.0550 http://www.cubix.com [e-mail] he5urp24-x11dai-n-12g20181016
HostEngine 5URP24
Computer User Guide
Front and Rear View
HostEngine 5URP24 (HE5URP24) computer features Intel® Xeon®Scalable (Skylake
FCLGA3647 socket) Series dual processors with the Intel C621 chipset. HE5URP24 supports
up to 2TBytes error-correcting code (ECC) 3DS load-reduced, dual in-line memory module
(RDIMM) memory or 1TByte ECC registered ECC DIMM memory. It provides 4 x PCI Express
(PCIe) Gen 3.0 x16 expansion slots and 2 x PCIe Gen 3.0 x8 slots. Each x16 slot
accommodates a full-height, full-length GPU. One x16 slot supports a double-wide GPU if one
x8 slot is not populated. It also supports 2 x half-height, half-length, single-wide Cubix Host
Interface Controller (HIC) that connects to Cubix Xpander Rackmount 8 and 1 or 2 x RAID
controllers that connect to 24 x SAS hard disk drives (HDDs) or solid-state drives (SSDs). Each
HIC connects to multiple slots within Xpander and each RAID controller connects to 24 x HDDs
or SSDs within HE5URP24.
To support the 24 x Serial-Attached SCSI (SAS with 12Gbits / second or 12Gbps transfer rate)
2.5” or 3.5” hot-plug hard-disk drives (HDDs) requires 1 x 24-port or 2 x 12-port SAS (12Gbps)
RAID controller(s) in one or two of the 8 x slots. Each RAID controller port connects to a 4-port
SAS backplane with a 1.0meter SFF-8643 mini-SAS to SFF-8643 mini-SAS HD cable, and in
turn, each 4-port SAS backplane connects to 4 x SAS HDDs for a total of 24 x HDDs in each
HE5URP24 and XPRM8G3-5URP24 chassis. The two chassis form a system with 48 x SAS
HDDs. The total storage capacity is 48TBytes to 672TBytes, or 0.672PBytes, of direct-attached
storage.
It also provides 6 x rear-panel USB ports –4 x USB 3.0 and 2 x USB 3.1, a type A and a type C.
HE4U also provides 2 x GbE network ports, one of which supports both local and remote
management using IPMI 2.0. Each HE5URP24 and XPRM8G3-5URP24 also features a power
supply with 3 + 1 hot-plug, redundant power modules and 4 x hot-plug cooling fans. Each is also
rack-mountable with a tool-less access top cover.
By connecting HostEngine 5URP24 to Xpander Rackmount 8 RP24, you can add up to 8 x
double-wide GPUs such as NVIDIA® Quadro P6000 to the HostEngine 4U computer for running
Autodesk® 3ds Max with NVIDIA iray or BlackMagic Design® DaVinci Resolve® for Linux or
Windows.

Cubix Corporation 2800 Lockheed Way Carson City, NV 89706-0719 Page 2
Sales 800.829.0550 http://www.cubix.com [e-mail] he5urp25-x11dai-n-12g20181016
HostEngine 5URP24 Technical Specifications
Central Processing Unit (CPU)
Intel® Xeon Scalable Processor Series
Number CPUs
2 with identical revision, core voltage and bus (core) speed
Sockets
2 x Socket P LGA 3647
Speeds / Cores / Threads
1.8 –3.5GHz / up to 28 cores / up to 56 threads
Intel Smart Cache
Up to 38.5MByte L3 cache
UltraPath Interconnect (UPI)
Up to 10.4 GigaTransfers/second (GT/s) across 2 x UPI links
Chipset
Intel C621
Front Side Bus Speed
2666MHz
System Memory Sizes
RDIMM: 64GByte, 32GByte, 16GByte or 8GByte
LRDIMM: 128GByte, 64GByte or 32GByte
Type
Standard ECC Registered DIMMs (RDIMMs)
Optional 3DS ECC Load-Reduced DIMMs (LRDIMMs)
Configuration
DDR4-2666MHz, 2400MHz, 2133MHz
Maximum Size
1TByte using 16 x ECC Registered DIMMs (RDIMMs)
2TByte using 16 x 3DS ECC Load-Reduced DIMMs (LRDIMMs)
PCI Express Gen 3.0 Slots
PCIe Expansion
4 x PCI-E 3.0 x16: Slot 1 / 2 from CPU1; Slot 3 / 5 from CPU 2
2 x PCI-E 3.0 x8: Slot 4 / 6 from CPU 2
M.2 Expansion Sockets
1 x PCIe 3.0 x4 from CPU 1, M-Key 2280 and 22110
U.2 Expansion Sockets
2 x PCIe 3.0 x4 from CPU 1 (each requires 1 x data / power cable kit)
System BIOS
AMI® User Extensible Firmware Interface (UEFI) BIOS
Feature Support
Advanced Configuration and Power Interface (ACPI) 3.0 / 4.0
USB keyboard
Plug-n-Play (PnP)
Serial Peripheral Interface (SPI) dual / quad speed
System Management BIOS (SMBIOS) 2.7 or later
Ethernet ports
2 x Intel RJ-45 ports supported by PCH C621
1 x port shared by Aspeed AST2500 BMC with dedicated IPMI
Support
10 / 100 / 1000Mb/s
Boot device
Non-Volatile Memory Express (NVMe)
Drive Format
Solid-state drive (SSD)
Transfer Rate / Connection
M.2 / PCIe Gen 3 x4
Capacity, Terabytes (TB)
2, 1, 0.5
Solid-state drive (SSD) No.
24
Storage devices
Serial-Attached SCSI (SAS) with 24-port RAID controller
SSD Maximum Devices
24
Drive Format
2.5-inch (63.5mm) SSD
3.5-inch (88.5mm) SSD
Transfer Rate / Connection
12.0Gbit/second (12Gbps) / SAS / 1.0meter mini-SAS HD SFF-8643
Capacity, TB
14, 12, 10, 8, 6, 4, 2, 1, 0.5
Maximum 336TB with all drives operating
RAID configuration
0, 1, 5, 6 or 10 hardware with 24-port RAID controller
DVD Rewriter
8x SATA, access via front panel
Baseboard Mgt Controller (BMC)
Aspeed AST2500 BMC
Graphics
VGA
Feature support
IP Management Interface (IPMI) 2.0
Network
1 x GbE port shares LAN support with IPMI 2.0
Audio Controller
High-Definition (HD) 7.1 with SPDIF-input digital header
Universal Serial Bus (USB)
Version 3.0
Ports
4 x USB 3.0 (5.0Gbits/sec)

Cubix Corporation 2800 Lockheed Way Carson City, NV 89706-0719 Page 3
Sales 800.829.0550 http://www.cubix.com [e-mail] he5urp25-x11dai-n-12g20181016
2 x USB 3.1 (Type-A and Type-C 10.0Gbits/sec)
Cooling Fans
4
Maximum air flow each
178 cubic feet / minute (cfm)
Remove / Replace
Hot-plug
AC Power Supply
One single-phase, auto-ranging, 100-240VAC, 45-24Amps, 50/60Hz
with 3 + 1 x 1,280Watt redundant modules; total output power is not
to exceed 3,840Watts
Operating Environment
0° to 30° Celsius (32° to 86° Fahrenheit) temperature
5% to 80% non-condensing humidity
Altitude
Maximum
Operating
10,000ft (3,050meters)
Storage
50,000ft (15,240meters)
Dimensions
8.75” H x 19.00” W x 28.00” D (22.22cm H x 48.26cm W x 71.12cm D)
Weight
49.00 lbs. (24.50kg)
Warranty / Period
Parts & labor return to manufacturer / 2 year
Ext. Warranty Period
Optional 3rd year
Memory Configuration
Memory Population Guidelines
Use DDR4 DIMMs only.
Do not mix LRDIMMs and RDIMMs.
Do not mix 3DS and non-3DS
LRDIMMs.
If only one DIMM is populated in a
channel, use the slot furthest from
the CPU.
DIMM Configurations for CPU1 Only
# DIMMs
Location
Memory Scheme
4
P1-DIMMF1
P1-DIMMC1
P1-DIMME1
P1-DIMMB1
Interleaved
DIMMs must be identical
type and speed
8
P1-DIMMF1
P1-DIMMC1
P1-DIMME1
P1-DIMMB1
P1-DIMMA1
P1-DIMMA2
P1-DIMMD1
P1-DIMMD2
DIMM Configurations for CPU1 and CPU2
16
P1-DIMMF1
P1-DIMMC1
P1-DIMME1
P1-DIMMB1
P1-DIMMA1
P1-DIMMA2
P1-DIMMD1
P1-DIMMD2
P2-DIMMC1
P2-DIMMF1
P2-DIMMB1
P2-DIMME1
P2-DIMMA1
P2-DIMMD1
P2-DIMMA2
P1-DIMMD2
Interleaved
DIMMs must be identical
type and speed

Cubix Corporation 2800 Lockheed Way Carson City, NV 89706-0719 Page 4
Sales 800.829.0550 http://www.cubix.com [e-mail] he5urp25-x11dai-n-12g20181016
Boot Device
HostEngine provides one M.2 slot in 2280
and 22110 form factor such as the 80mm,
2TByte Samsung 960 Pro (see image at
right). It also provides two U.2 slots for
NVMe SSDs such as Intel SSD 750
Series. Both the M.2 and U.2 slots are
PCIe Gen 3.0 x4.
PCIe Gen 3 Slots
When installing a HIC in
HE4U, make sure you seat it
in one of the PCIe Gen 3 x16
slots, which are numbered
CPU1 Slot1, CPU1 Slot 2,
CPU2 Slot4 and CPU2 Slot5.
See the illustration at the right
for the optimal configuration
for BlackMagic Design DaVinci
Resolve, for example.
For double-wide accelerators
like NVIDIA Quadro Series or
AMD Firepro W Series, use
slots 1, 3 and 5. If you add a
single-wide display controller
like AMD Firepro W2100 /
W4100 or NVIDIA Quadro
P4000 for connecting one or
more 4K / UHD displays, use a
PCIe x16 slot. For SAN
controllers, which usually
provide PCIe Gen 3 x8
connectivity, use CPU2 Slot 4
or Slot 6.
Remove and replace PCIe devices
PCIe devices can be removed and replaced from the top once you power down HostEngine,
disconnect power and remove the top cover. See the image at the right for the features of each
PCIe slot. Generally, install x16 devices like GPUs or Cubix HICs in x16 slots.
•Power down gracefully using the OS.
•Remove the power cord and wait for standby power to turn off.
•Loosen the two retention screws on the HostEngine front panel.
•Gently tug the HostEngine handles toward you.
•Remove the screws holding the top cover and set it aside.

Cubix Corporation 2800 Lockheed Way Carson City, NV 89706-0719 Page 5
Sales 800.829.0550 http://www.cubix.com [e-mail] he5urp25-x11dai-n-12g20181016
•Disconnect auxiliary power cables from the PCIe devices such as accelerators, if needed.
•Remove / replace the PCIe devices and re-connect the drive power and data cables.
•Replace the top cover and its retaining screws.
•Slide HostEngine into the cabinet.
•Replace and tighten the retention screws.
•Power up HostEngine.
Remove and replace a SATA drive
SATA drives are removable from the front one by one after removal of the front panel.
•Remove the front panel, which is held in place with magnetic contacts. No tools needed.
•Remove / replace the drive.
•Replace the front panel.
Remove / Replace HostEngine
HostEngine can be removed and replaced from the front once you remove power.
•Power down gracefully using the OS or the front-panel on / off switch.
•Wait for the power to shut off.
•Disconnect power and all other cables from HostEngine.
•Loosen the two retention screws on the HostEngine front panel.
•Gently tug the HostEngine handles toward you.
•Extract the HostEngine while supporting its weight.
•Slide the replacement HostEngine into the rack mount slide mounts.
•Slide HostEngine into the cabinet.
•Replace and tighten the retention screws.
•Connect power and all other cables to HostEngine.
•Power up HostEngine.
Controls, Indicators and Connections
HE5URP24 front panel:
•2 x USB 3 ports
•Press Power button
to power up / down
the OS –Windows
or Linux.
•Press and hold
Power button 4
seconds to force
power down.
•Press Reset button
(recessed) to
recycle power or
reset OS

Cubix Corporation 2800 Lockheed Way Carson City, NV 89706-0719 Page 6
Sales 800.829.0550 http://www.cubix.com [e-mail] he5urp25-x11dai-n-12g20181016
Connections
On the rear panel, HostEngine provides USB 3 ports, Gbps Ethernet ports, a VGA port and HD
audio ports. The AC power receptacle is also on the rear panel.
HostEngine also provides access for Cubix HICs that connect to GPU-Xpander Rackmount 8 or
other Xpander enclosures using external PCIe x16 cables, if needed. With these connections,
you can mount HostEngine immediately above or below GPU-Xpander Rackmount 8. You can
also install PCIe cards inside HostEngine 4U. For example, install 4 x full-length, full-height,
double-wide GPUs inside HostEngine 4U.
On the front panel, HostEngine provides 2 x local USB ports.
Troubleshooting Procedure
Issue: The Cubix HIC in HostEngine is linking at x8 or x4, or at Gen 2, with Cubix
Xpander, and not linking at the specified PCIE Gen 3 x16 transfer rate.
Resolution: Confirm that the Cubix HIC is installed in HostEngine slot 1, 2, 3 or 5.
Issue: The Cubix HICs in HostEngine are installed in PCIE Gen 3 x16 slots 1 & 3 or 2 &
5, but not all 8 x GPUs in Xpander Rackmount 8 show up in the operating system
(ls pci in Linux or Windows Device Manager > Display adapters).

Cubix Corporation 2800 Lockheed Way Carson City, NV 89706-0719 Page 7
Sales 800.829.0550 http://www.cubix.com [e-mail] he5urp25-x11dai-n-12g20181016
Resolution: Confirm the following setting in HostEngine system BIOS > Advanced > PCI
Plug-n-Play > Above 4G Decoding > Enabled.
Issue: How can I tell whether each GPU in Xpander connected to HostEngine is running
at optimal bandwidth?
Resolution: Download Cubix GPU Manager for either Linux or Microsoft Windows
(http://www.cubix.com/gpumanager/) and install it. Documentation is on-line here.
Issue:
Resolution:
