Cuddeback G Series User manual

G Size Camera Manual
Version 4.0.0
R E A D T H I S M A N U A L
This manual explains the camera hardware. Refer to
the Advanced User Interface Manual for instrucons
to program and deploy the camera.
F R E E 2 Y E A R E X T E N D E D W A R R A N T Y
See page 13 for details

2
Design Highlights
This Cuddeback camera has been designed for
reliability.
 User Interface is weather resistant and covered
with a sealing door. This resilient rubber/plasc
door is more robust than a convenonal hinge
door.
 The SD card ts into a socket in the boom of the
camera to prevent water from entering the
camera when you check your camera in the rain.
 The SD card socket is not spring loaded. We
believe pull-out style sockets are more reliable.
 The baery door and SD card door are secured
with brass thumb screws instead of breakable
latches.
 The moon sensor’s Fresnel lens is user
replaceable.
 The Genius mount is inexpensive and replaceable.
If abused by a person or animal, the bracket will
break before the camera, potenally saving your
camera from damage.

3
Flash LEDs
Moon
Sensor
Zone Control
Camera
User Interface
(behind door)
Test LED
(behind lens)
SD card on boom

4
SD Card
This Cuddeback camera is compable with SD cards
sizes 2GB to 32GB. Do not use SDXC cards. Micro SD
cards will funcon with the proper adapter (usually
included with the micro SD card). Treat your SD cards
nice. They are very sophiscated electronic devices
made with billions of stac sensive transistors. Keep
them dry and do not bend them.
WARNING – Never insert a wet or damp SD card into your
camera or computer.
Internal Memory
You can use this camera without an SD card. Up to
120MB of internal memory is available for image
storage - videos and me lapse images cannot be
stored to internal memory. Images stored in internal
memory will automacally be copied to an SD card
when a card is inserted. This feature is handy if you
check a camera without a spare SD card. You can
remove the SD card and take it home, yet sll leave
the camera a-eld. When you return, all you need to
do is install the SD card & ARM the camera to transfer
images from internal memory to the SD card.

5
Install SD Card
Insert the SD card into the camera label side down.
Do not force the card. If it does not go in easily check
to make sure you are inserng it correctly. You will
break the card socket if you force the card.
Insert SD card with
label facing down
SD Card Tip
The SD Card reader on this camera is not spring
loaded. We believe a pull out SD socket is more
reliable. You can make your SD card easier to access
by placing electrical tape on the SD card, as shown
below, to create a pull tab.

6
Baery Noce
Remove baeries when the camera is not going to be
used for an extended period of me. Failure to follow
these guidelines may result in baery leakage which
will damage your camera.
 Never mix old and new baeries.
 Never mix dierent types of baeries.
 Never mix lithium and alkaline baeries.
 Replace all baeries at the same me.
 Always remove baeries when the camera is not
going to be used for a period of me.
 Dispose of baeries properly as recommended by
the baery manufacturer.
 Never expose skin or eyes to baery acid. Refer
to baery manufacturer’s precauons.
 This camera can use alkaline D baeries.
DC INPUT. This camera has a baery input
connector. Only use CuddePower baery packs or
cables. Maximum input voltage is 9 volts DC.
DO NOT ATTACH CAMERA TO A 12 VOLT BATTERY!

7
Install Baeries
Install baeries by loosening the 2 baery door
thumb screws and opening the baery door. Insert 4
D baeries as shown then secure the baery door
with the thumb screws. Tighten fully but do not
overghten.
Make sure to observe the correct polarity. Baeries
can explode, leak acid, or ignite if inserted
incorrectly.
We recommend Rayovac, Duracell, or Energizer brand
baeries only. (Choose baeries carefully – there is a
dierence, especially in
cold temperatures).
This camera will not
operate with rechargeable
baeries. The baery
voltage is too low.

8
Zone Control
This camera is equipped with Cuddeback’s patented
Zone Control. The moon sensor can be set to detect
animals in a wide angle or a narrow view.
Wide view will capture more animals but is more
suscepble to triggering by non-target animals (such
as birds) which can lead to blank images and can
result in images of the nose or tail of the animal.
Narrow view is very accurate and generates images
with the animals centered in the image but will not
capture images to the side of the camera.
Slide the Zone Control shuer to the appropriate
posion by placing your thumb as shown in the next
diagrams (be careful not to damage the Fresnel lens).
Important: When changing the Zone Control shuer
posion we recommend you also change the ZONE
seng as explained in the User Interface Manual.
Set the ZONE seng to WIDE if the Zone Control
Shuer is down. Set to CENTERED if the Zone Control
Shuer is up.

9
Push the Zone Control shuer down for wide detecon.
Push the Zone Control shuer up for centered detecon.

10
LIMITED WARRANTY FOR THIS CUDDEBACK CAMERA
1. Limited Warranty. Non Typical, Inc. (“Non Typical”)
warrants the Product to be free from malfuncons
and defects in both materials and workmanship for
the period of the warranty (“Warranty Period”). Non
Typical will repair or replace, at its opon, the Product
if it fails to funcon properly during the Warranty
Period, subject to the condions and/or limitaons
stated herein. Such repair or replacement is your sole
and exclusive remedies under this Limited Warranty.
2. Limitaons. Limited Warranty service will not be
provided unless the Product is returned in the manner
set forth below.
3. Warranty Period. The Warranty Period shall
commence on the date of the product’s purchase and
shall expire on either: (a) the 1st annual anniversary
of the Product’s Acvaon Date*; or (b) the 181st Run
Day of the Product, whichever comes rst.
This Limited Warranty does not cover the following:
a. Any defect in or damage to the Product that
occurs due to mishandling of the Product;
b. Any defect in or damage to the Product that
occurs due to repair, modicaon, or other similar

11
acvity performed by anyone other than Non
Typical;
c. Any defect in or damage to the Product that
occurs due to transport, dropping, shock, or other
similar acvity aer your purchase of the Product;
d. Any defect in or damage to the Product that
occurs due to careless or improper storage, or
improper use or maintenance of the Product;
e. Any defect in or damage to the Product that
occurs due to exhausted baeries;
f. Any defect in or damage to the Product that
occurs due to sand, mud, or other foreign objects
entering the inside of the Product; or
g. Any defect in or damage to the Product related to
accident, misuse, abuse, use with incompable
accessories or aachments, your failure to follow
proper operang instrucons provided by Non
Typical, claims made aer the duraon of the
Warranty Period, or your failure to follow the
instrucons set forth below with respect to return
of the Product to Non Typical.
ALL OTHER EXPRESS AND IMPLIED WARRANTIES FOR

12
THE PRODUCT, INCLUDING THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE ARE HEREBY
DISCLAIMED. NON TYPICAL EXPRESSLY DISCLAIMS ALL
WARRANTIES NOT STATED IN THIS WARRANTY. ANY
IMPLIED WARRANTIES THAT MAY BE IMPOSED BY
LAW ARE LIMITED IN DURATION TO THE TERMS OF
THIS EXPRESS LIMITED WARRANTY. SOME
JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF
IMPLIED WARRANTIES OR LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO
YOU. IN NO EVENT WILL NON TYPICAL BE LIABLE TO
YOU, OR ANY THIRD PARTY, FOR ANY DAMAGES IN
EXCESS OF THE PURCHASE PRICE OF THE PRODUCT.
IN ADDITION, NON TYPICAL SHALL IN NO EVENT BE
LIABLE TO YOU, OR ANY THIRD PARTY, FOR ANY
DIRECT OR INDIRECT DAMAGES OR OTHER SPECIAL,
INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL
DAMAGES ARISING OUT OF THE USE OF OR INABILITY
TO USE THE PRODUCT. SOME JURISDICTIONS DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR
SOME PRODUCTS, SO THE EXCLUSIONS OR
LIMITATIONS MAY NOT APPLY TO YOU. THIS LIMITED

13
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS WHICH MAY
VARY FROM JURISDICTION TO JURISDICTION.
5. Notwithstanding any terms of this Limited
Warranty to the contrary, no warranty coverage shall
be provided for any Product purchased from, through
or with the assistance or involvement of any Internet
aucon web site.
*Acvaon Date is the rst day the baeries are installed and is
automacally set and saved by the camera.
Free Extended Warranty
You can extend this warranty to 2 years by registering
your camera online within 14 days of purchase. Visit
Cuddeback.com and click REGISTER at the top of the
page.
You must register your camera to extend your warranty.
We will only honor requests for extended warranty for
cameras that have been registered.

14
Approvals: FCC, CE, ROHS
This device complies with Part 15 of the FCC Rules.
Operaon is subject to the following two condions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operaon.
Please note that changes or modicaons not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment. NOTE: This equipment has
been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference
in a residenal installaon. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance
with the instrucons, may cause harmful
interference to radio communicaons. However,
there is no guarantee that interference will not occur
in a parcular installaon. If this equipment does
cause harmful interference to radio or television
recepon, which can be determined by turning the
equipment o and on, the user is encouraged to try

15
to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separaon between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.

16
