Cuisinart DGB650BCU Installation and operation manual

Grind &Brew Automatic
DGB650BCU

Important Safeguards
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. The appliance is not intended to be operated by means of external
timer or separate remote-control system.
2. This appliance is not intended for use by persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
3. Children should always be supervised to ensure that they do not play
with this product.
4. Not for use by children. Keep out of reach of children during and
after use.
5. Always inspect the appliance before use for noticeable signs of
damage. Do not use if damaged, or if the appliance has been dropped.
Do not use this appliance if the lead is damaged. In the event of
damage, or if the appliance develops a fault, contact the Cuisinart
Customer Care Line (refer to “UK After Sales Service“ section for
further information).

3
Congratulations on your purchase of the Cuisinart Grind & Brew Automatic
For over 30 years Cuisinart’s aim has been to produce the very finest kitchen
equipment.
All Cuisinart products are engineered for exceptionally long life, and
designed to be easy to use as well as to give excellent performance day
after day.
To learn more about Cuisinart products, visit our website www.cuisinart.co.uk

4
Contents
Product Description........................................................................................................... 5
Safety Cautions.................................................................................................................. 6
Instructions for Use...........................................................................................................9
A Control Panel.................................................................................................................................... 9
B Setting the Clock .........................................................................................................................10
C Setting the Program Time ..........................................................................................................10
D Inserting Charcoal Water Filter ................................................................................................10
E Preparing to Brew ........................................................................................................................ 11
Adding Water ................................................................................................................................ 11
Adding Coffee................................................................................................................................12
Using Pre-ground Beans.............................................................................................................12
Preparing the Carafe ...................................................................................................................13
F Brewing Coffee .............................................................................................................................14
Cleaning &Maintenance ................................................................................................15
UK Guarantee &After Sales Service .............................................................................17

5
Product Description
Control Panel
Water Reservoir Cover with Release Button
Water Reservoir with Water Level
Indicator
Resting Plate
Coffee Filter Compartment
10 Cup Thermal Carafe
Coffee Filter Compartment Release Button
(not shown)
Grind Chamber

6
Safety Cautions
Read all the instructions before using the appliance and keep in a safe place for
future reference.
Always follow these safety cautions when using this appliance to avoid personal injury
or damage to the appliance. This appliance should be used only as described within this
instruction book.
Do not immerse the housing unit in water or any other liquid or put it in a dishwasher.
Never pull the plug out of the mains socket by the lead.
Do not allow the lead to overhang the edge of the table or work surface.
Do not allow lead to touch hot surfaces.
This appliance should not be used by adults or children whose lack of experience,
product knowledge or disability might cause a hazard, unless they have been correctly
instructed and are adequately supervised.
Children should always be supervised to ensure that they do not play with this product.
Not for use by children. Keep out of reach of children during and after use.
Do not use this appliance if the lead is damaged. In the event of damage the lead must
be replaced by a specialist lead available from the manufacturer or its service agent
(see “UK After Sales Service” section).
Do not use the appliance if it has fallen or shows signs of damage. Discontinue use
immediately (see “UK After Sales Service” section).
No repair can be carried out by the user. (see “UK After Sales Service” section).
Use this appliance for grinding coffee beans as described within the instructions for
use which accompany it. Please retain these for future reference.
For indoor and domestic use only.
Always ensure that your hands are dry before removing the plug from the mains outlet.
This appliance complies with the basic requirements of Directives 2004/108/EC
(Electromagnetic Compatibility) and 2006/95/EC (Safety of domestic electrical
appliances).
Do not use any accessory or attachment other than those recommended by Cuisinart.
Allow to cool before cleaning the appliance.
Do not place the appliance on or near a hot gas or electric burner or in a heated oven.
WARNING: Polythene bags over the product or packaging may be dangerous.
To avoid danger of suffocation, keep away from babies and children. These bags
are not toys.

7
Safety during use
Do not touch hot surfaces. Use handles and knobs.
Always fill water reservoir first, then plug into a suitable power outlet. To disconnect
push the ‘On/Off’ button to switch off the appliance, then remove the plug from the
wall outlet.
Never open the filter basket during the brew cycle, extremely hot water/coffee can
spill and cause injury.
Ensure the lid is securely attached to the carafe before serving any beverages.
Liquids will reach to approximately 90°C. Be careful when pouring beverages.
The thermal carafe is designed for use with this appliance only.
Do not use the carafe if cracked or if the handle is loose.
Do not clean the carafe or resting plate with cleansers, steel wool pads, or other
abrasive materials.
Avoid contact with moving parts.
Check grinder basket before use for presence of foreign objects.
Use the coffee grinder to grind roasted coffee beans only. Do not use to grind other
substances, e.g nuts, spices or un-roasted beans as this may damage the blades or
cause injury.
Do not place cloth or otherwise restrict airflow beneath coffeemaker.
Use only the Cuisinart Gold Tone® Commercial Style Filter with this unit. These are
available to purchase by contacting the Cuisinart Helpline (see “UK After Sales Service”
section). Other Gold Tone® permanent filters or normal paper filters may cause the unit
to overflow.
Do not place the hot carafe on a cold or wet surface.
WARNING: Scalding may occur if the lid is removed during the brewing cycle.

8
UK Wiring Instructions
Your Cuisinart Grind and Brew Automatic includes a BS 1363 moulded (13A fused) mains
plug on the supply cord.
Should it be necessary at any stage to remove this moulded plug and replace it with a
re-wireable BS 1363 moulded (13A fused) mains plug, the re-wiring should be completed
as follows: (NB The moulded plug should be disposed of safely)
Class I (1) Earthed Appliance
The wires in the mains lead are coloured in accordance with the following code:
GREEN & YELLOW = EARTH
BLUE = NEUTRAL BROWN = LIVE
The wire which is coloured GREEN & YELLOW must be connected to the terminal in the plug
which is marked with the letter E or symbol.
The wire which is coloured BLUE must be connected to the terminal which is marked with
the letter N.
The wire which is coloured BROWN must be connected to the terminal which is marked
with the letter L.
With this appliance, if a 13 amp plug is used, a 13 amp fuse should be fitted.
WARNING: A cut off plug inserted into a 13 amp socket is a serious safety (shock) hazard.
Ensure that the cut off plug is disposed of safely.
The symbol on the product or on its packaging indicates that this product may not be
treated as household waste. Instead it should be handed over to an appropriate collection
point for the recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriate waste handling of this product. For more detailed information about the
recycling of this product, please contact your local council office or your household waste
disposal service.

9
Instructions for use
A Control Panel
1. ON/OFF button with LED Indicator
Press the On/Off button to start the machine.
The machine features an audible tone which beeps 5 times after the coffee has finished
brewing.
2. Clock/LCD Display
Displays time of day and program setting (when program button is pressed).
3. Hour and Minute Buttons
Use to set the clock and set program time function.
4. 1-4 Cup Setting
Improves coffee extraction, flavour and temperature when brewing fewer than 5 cups.
5. Grind Off Button with LED Indicator
Turns off the grinder when using pre-ground coffee.
6. Program Button with LED Indicator
Press to display or set program.
ON/OFF
1-4 CUPS
GRIND OFF
HR MIN
PROGRAM
1 3365
42

10
B Setting the Clock
When the unit is plugged in, the screen will show 12:00.
Press and hold either the ‘HR’ or the ‘MIN’ button until the numbers start to flash.
Then press the ‘HR’ and ‘MIN’ buttons to scroll through the numbers. When the numbers
stop flashing, the time has been set.
N.B. When you go past the number 12, the letters ‘PM’ will appear to adjust the time from
12 noon to midnight. When ‘PM’ is not shown, the time indicated corresponds to the AM
hours, from 12 midnight to 12 noon. Always make sure that the time is set according the
correct period so that the programming is correct.
C Setting the Program Time
Press and hold the ‘Program’ button. The numbers and the indicator light will flash.
To set the desired start time, press and hold either the ‘HR’ and ‘MIN’ buttons until the
numbers start to flash. Then press and hold the ‘HR’ and ‘MIN’ to scroll through the
numbers. When the numbers stop flashing, the scheduled time is programmed and the
display will revert back to the current time.
To check the programmed start time press and hold the programme button, the
programmed start time will display. The green light beside the programme button
must be illuminated.
To cancel the programed start time, press the programme button and the green light
will go out.
CAUTION! You will not be able to program the start time while the coffee machine
is running.
D Inserting Charcoal Water Filter
Your appliance comes with two charcoal water filters that eliminate chlorine, bad tastes
and odors from tap water. It is recommended that you change your water filter every 90
days or after 90 uses and more often if you have hard water. Replacement filters can be
purchased directly from the manufacturer, (see “UK After Sales Service” section).
Remove the water filter from its packaging and soak in cold tap water for 15 minutes.
To remove the water filter holder, simply lift it out from its opening on the inner wall
of the reservoir. This can be accessed by lifting the water reservoir lid.

11
Hold stem in one hand. With your other hand, gently press the compartment door
down and pull outwards to flip open as shown above..
Place the filter in the holder and close the compartment cover; you will hear a snap
indicating filter is in place.
N.B. Caution must be used when inserting the charcoal filter. Improper placement in
the holder can cause tearing of the filter skin.
Hold the filter under cold running tap water for 10 seconds to flush. Hold the water
filter holder vertically, directly under the water stream so that the water flows through
the filter compartment.
Allow the filter to drain completely.
Replace the water filter holder into its opening on the inner wall of the reservoir,
pushing it all the way down to the base of the unit.
E Preparing to Brew
Before making coffee for the first time, we recommend operating the appliance once,
using only water, to remove any dust or residue that may remain in the system from the
manufacturing process.
Adding Water
Open the reservoir cover at the top of the appliance and pour in the desired amount of
water using the water level indicator . Close the reservoir cover ensuring not to exceed
the 10 cup capacity.
N.B. Do not exceed the 10 cup line. Doing so could cause the carafe to overflow.
N.B. Be careful to add only the amount of water for the number of cups you wish to
brew. The machine will use all of the water added regardless of the amount of coffee
used.

12
Adding Coffee
There are 2 ways to add coffee when using this machine. You can use fresh coffee beans
and allow the machine to grind the beans before brewing the coffee, or you can simply
use pre-ground coffee beans.
Adding Coffee Beans
Lift the grinder basket lid using the recess on either side.
Fill the basket with the desired quantity of coffee beans.
N.B. Use 1 level scoop of whole beans per cup. For 1 to 4 cups, use 1½ level scoops per
cup. Do not add more than 14 scoops. This could cause the grinder to malfunction and/
or the coffeemaker to overflow.
N.B. Be careful to add only the amount of beans for the number of cups you wish to brew.
The machine will use all of the coffee regardless of the amount of water used.
Replace grinder basket lid.
Press down reservoir cover to lock.
Using Pre-ground beans
You can use pre-ground coffee beans with this appliance. We recommend using 1 level
scoop of ground coffee per cup. The maximum capacity for ground coffee is 16 scoops.
Exceeding this may cause the filter compartment to overflow.
N.B. Be careful to add only the amount of coffee for the number of cups you wish to
brew. The machine will use all of the coffee regardless of the amount of water used.
To add coffee, press the filter compartment release button which can be found on the
left side of the housing.
Grinder basket lid
Reservoir cover
Grinder basket
Water filter holder
Water reservoir

13
Remove the filter basket cover.
Scoop the desired amount of coffee into the Gold Tone® Filter. Ensure the handle of
the gold tone filter is facing away from the main body of the appliance. If the handle
is not facing away, it may interfere with the flow of ground coffee into the filter
basket.
Replace the filter basket cover, ensuring the ‘GRIND’ arrow is matching the ‘LIFT’
arrow and then close the filter compartment door. The door will click when closed
properly.
N.B. If the filter basket cover is not in place or the filter door is not properly closed a
safety interlock system will prevent operation. If you try and turn the unit on when
parts are not in place, the unit will beep continuously until the missing parts are
installed and the filter door is closed.
Preparing the Carafe
Remove the lid of the thermal carafe by turning in the direction of the ‘unlock’ arrow.
N.B. For best results, pre warm the carafe by rinsing it out with hot water. This will help
to keep the coffee hotter for longer.
Replace the carafe lid. To lock, align the arrows on the lid and the carafe body and
turn in a clockwise direction until the lid fits tightly onto the carafe and the arrow is
lined up in the centre of the spout. This ensures the lid is locked into place and in the
correct position for brewing and pouring.
Replace the thermal carafe in its position on the resting plate.
Filter basket cover
Filter basket
Gold Tone® Filter

14
F Brewing Coffee
Now the machine is ready to use. Ensure the machine is plugged into the mains.
Immediate Brewing
To start the appliance immediately, press ‘ON/OFF’ button. The Red LED will illuminate
and brewing will begin.
Press the ‘GRIND OFF’ button if you are intending to use pre ground beans
Press the 1-4 cup selector if you are planning to brew only 1-4 cups and have only
added sufficient water and coffee for 1-4 cups, this will improve the extraction and
flavour. Once 1-4 cups is selected the orange light will illuminate.
Programmed Brewing
To set the appliance to start at a programmed time, refer to ‘Setting the Program Time’
page 10.
Press the ‘GRIND OFF’ button if you are intending to use pre-ground coffee beans.
Press the 1-4 cup selector if you are planning to brew only 1-4 cups and have only
added sufficient water and coffee for 1-4 cups, this will improve the extraction and
flavour. Once 1-4 cups is selected the orange light will illuminate.
Brewing will begin at the programmed time.
Brewed Coffee
When the brewing cycle has completed, 5 beeps will sound. Coffee will continue to
stream from the filter for several seconds afterwards.
When the coffee is ready, stir before serving, to blend the flavours. The coffee at the
bottom of the carafe will be stronger than that at the top.
The brew-through, pour-through lid allows coffee to drip from the appliance through
the closed lid. When brewing is complete, the lid seals itself so air stays out and coffee
freshness and temperature are maintained. No need to turn or adjust the lid before
pouring.
After brewing, the appliance will automatically shut off. The thermal carafe will keep
the coffee hot for hours.
The ‘Automatic Brew Pause’ feature allows you to remove the carafe during mid-brew.
The brewing process does not stop during this period, only the flow of coffee from the
basket to the carafe stops.

15
N.B. Whilst we offer this feature for your convenience, we do not recommend that you
pour coffee before the cycle has reached completion, since the coffee brewed at the
beginning of the cycle has a very different flavour profile to that made at the end of
the cycle. Removing a cup during the cycle will alter the flavour of the finished pot.
WARNING! Do not remove the carafe for longer than 20 seconds or the coffee may
overflow the basket.
CAUTION! The bottom of the thermal carafe is hot to touch for several minutes after
brewing.
Cleaning &Maintenance
Completely clean and dry all parts after every use.
Always turn coffee maker off and remove the plug from the electrical outlet before
cleaning.
Do not use scouring agents or harsh cleaning agents on any part of the appliance.
Never immerse the main housing unit in water or other liquid. To clean the base, simply
wipe with a clean damp cloth and dry before storing.
Wipe resting plate with a clean, damp cloth. Never use rough, abrasive materials or harsh
cleaning agents to clean the resting plate.
Do not dry the inside of the water reservoir with a cloth as lint may remain.
Cleaning the Coffee Filter
After every use, ensure the appliance has cooled down, open filter basket door by pressing
filter basket door release button. Remove filter basket cover, filter basket and Gold Tone®
1. Filter Basket Cover
3. Filter Basket Door
2. Gold Tone® Filter
4. Filter Basket

16
filter. Discard ground coffee.
The Gold Tone® filter, filter basket and filter basket cover can be washed in warm soapy
water and rinsed thoroughly, or cleaned in the upper rack of the dishwasher. Dry all parts
thoroughly after every use.
Once clean, replace the filter basket followed by the Gold Tone® filter then the filter
basket cover. Close the filter basket door by pushing firmly until it clicks into place.
Cleaning the Carafe
Remove the carafe from the resting plate. Discard any remaining coffee. The carafe
and lid can be washed in warm soapy water and rinsed thoroughly, or placed in a
dishwasher, on the upper rack only.
Coffee contains oils that can build up on the carafe. For best performance, wash
carafe and wipe pour spout after each use.
Descaling
Descaling refers to removing the calcium deposits which form over time on the metal
parts of the coffee maker. For best performance from your coffee maker, de-scale the
base unit from time to time.
The frequency depends upon the hardness of your tap water and how often you use the
coffee maker.
Fill the water reservoir completely with a mixture of 1/3 white vinegar and 2/3 water
and switch the appliance on. One cycle should be sufficient to descale the appliance.
Once the cycle has been completed and 5 beeps sound, switch the appliance off.
Repeat the cycle once more using cold tap water.

17
UK Guarantee
This Cuisinart appliance is guaranteed for consumer use for 3 years. This guarantee
covers defects under normal use from date of purchase and ceases to be valid in the
event of alteration or repairs by unauthorised persons. If the appliance does not perform
satisfactorily due to defects in materials or manufacture, it will be repaired or replaced
through Conair UK After Sales Service. No responsibility will be accepted for any
damage caused in transit. The Conair Group Ltd reserves the right to amend terms and
specifications without prior notice.
This guarantee in no way affects your statutory rights.
UK After Sales Service
For further advice on using the appliance, contact the Conair Customer Care Line on
0370 240 6902 (09:00 to 17:00 Monday to Friday) or email your enquiry to
[email protected]
If you should need to return your appliance to us please send it to the following address:
Customer Care Centre
Conair Logistics
Unit 4
Revolution Park
Buckshaw Avenue
Buckshaw Village
Chorley
PR7 7DW
Please enclose your name and address, together with a copy of proof of purchase and
details of the fault.

www.cuisinart.co.uk
N IB-9/039D
