Currys Essentials CFSEWH17 User manual

INSTRUCTION MANUAL
SINgLe OveN
CFSeWH17/CFSeSv17

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 7
Product Overview......................................................................................................................... 8
Front View ...................................................................................................................................................................8
Control Panel..............................................................................................................................................................8
Before Using the Cooker .............................................................................................................. 9
Using the Hotplates...................................................................................................................... 9
First Time Use of the Hotplates............................................................................................................................9
Controlling the Hotplates......................................................................................................................................9
Choosing the Right Cookware.............................................................................................................................9
Shelf Positions.........................................................................................................................................................10
Using the Oven ........................................................................................................................... 10
First Time Use of the Oven .................................................................................................................................10
Oven Function Selector Control.......................................................................................................................12
Temperature (Thermostat) Control.................................................................................................................12
Using the Grill ............................................................................................................................. 13
First Time Use of the Grill....................................................................................................................................13
Cooking Using the Grill .......................................................................................................................................13
Attaching the Grill Pan Handle.........................................................................................................................13
Cleaning Instructions ................................................................................................................. 14
Cleaning the Hotplates........................................................................................................................................14
Cleaning the Outside of the Cooker...............................................................................................................14
Cleaning the Oven Door Glass..........................................................................................................................14
Cleaning the Inside of the Oven ......................................................................................................................14
Removing the Oven Door .......................................................................................................... 15
Removing the Oven Door Glass for Easier Cleaning................................................................ 16
Replacing the Oven Lamp.......................................................................................................... 16
Installation .................................................................................................................................. 17
Adjusting the Feet ...................................................................................................................... 18
Moving the Cooker ..................................................................................................................... 18
Stability Bracket ......................................................................................................................... 18
Electrical Connection ................................................................................................................. 19
Energy Saving Tips and Energy Label ....................................................................................... 20
Product Fiche and Specications .............................................................................................. 21

4
Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
• It is recommended that this appliance is installed by a qualied electrical
engineer. The manufacturer is not responsible for any damage caused by
incorrect installation.
• Check whether there is any damage to the appliance after you have
unpacked it. If any damage is found, do not use the appliance and
contact the store where you purchased it.
• This appliance is for indoor domestic use only.
• For disconnection from the mains supply you must have a switch with
a contact separation of at least 3.0 mm in all poles and suitably rated that
provides full disconnection, this must be incorporated in the xed wiring
in accordance with the local wiring rules.
• If your mains cable gets damaged, it should be replaced by an authorized
service agent or qualied electrician in order to avoid a hazard.
• The oven must be used in a well ventilated location and installed on
at/level ground.
• Only operate your appliance in a dry atmosphere.
• Keep the electrical cables of your other appliances away from hot areas;
do not let them touch the appliance.
• Ensure that the appliance is switched o at the mains supply switch
and allowed it to completely cool down before cleaning, replacing the
oven lamp or performing any maintenance to avoid the possibility of an
electric shock or burns.
• Use of your appliance creates moisture in the room in which it is placed,
make sure that your kitchen is well ventilated. Maintain the natural
ventilation ducts properly.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
• Cleaning and user maintenance shall not be made by children without
supervision.

5
• Children should be supervised to ensure that they do not play with
the appliance.
• During use the appliance becomes hot. Care should be taken to avoid
touching the heating elements inside the oven or the hotplates.
• The appliance and its accessible parts become hot during use. Young
children should be kept away.
• Unattended cooking on a hob with fat or oil can be dangerous and may
result in re. NEVER try to extinguish a re with water, but switch o the
appliance and then cover the ame e.g. with a lid or a re blanket.
• Danger of re: Do not store items in, on or near the oven other than the
accessories supplied.
• When the oven is hot never touch the oven glass or any other parts that
get hot. Allow the oven to cool before touching these parts.
• Do not use harsh abrasives cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
the glass shattering.
• Before starting to use your appliance, keep curtains, tulle, paper
or ammable materials away from your appliance. Do not keep
combustible or ammable things in or on the appliance.
• This appliance is for cooking purposes only. It must not be used for other
purposes, for example room heating.
• Do not use steam cleaners for cleaning the appliance.
• Do not rest any items on or stand on the open door.
• If the hob surface is cracked, switch o the appliance to avoid possibility
of electric shock.
• Take care when handling parts with glass, knocks, chips, heavy handling
and dropping could cause the glass to shatter.
• The glass oven door uses toughened glass and is designed to break into
many‘nugget’ size pieces if it breaks. These pieces will still have sharp
edges, please handle broken glass with care.
• The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
• The supplied stability bracket or a recognized cooker stability device
must be tted.

6
• This appliance is not designed to be used with hob guards. Use of
inappropriate hob guards can cause accidents.
• To prevent the appliance tipping, the stabilizing
bracket must be installed.

7
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to local regulations.
The following items are included:
Grill Pan x 1
Grill Rack x 1
Grill Pan Handle x 1
The Main Unit
* All images are for indication only; please refer to your individual unit for actual item.
Wire Shelf x 2
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Stability Device
Wall plug x 1
Eyelet x 1Stability Chain x 1
Fixing Screw x 1

8
Product Overview
Front View
Control Panel
1
3
4
5
6
6
2
3 4 5
1 2
6 7 8
1. Thermostat lamp
2. Oven/hob active lamp
3. Front left hot plate control
4. Rear left hot plate control
5. Temperature control
6. Oven function selector
7. Rear right hot plate control
8. Front right hot plate control
* All images are for indication only; please refer to your individual unit for actual item.
1. Hot plates
2. Control panel
3. Oven shelf
4. Front ap
5. Oven door
6. Levelling feet

9
Before Using the Cooker
Before using your new cooker, please:
• Make sure all the controls are turned o.
• Read this Instruction/Installation Manual, taking special note of the “Safety Warnings”section.
• Turn the mains power on.
This appliance is for cooking purposes only.
It must not be used for other purposes, for example
room heating.
Using the Hotplates
First Time Use of the Hotplates
• Heat the appliance on maximum, making sure the room is well ventilated as there may be a little smoke and
odour. This is normal, and is due to the protective substance on the appliance which protects it during shipping
from the factory. Switch the appliance o once the smoke and odour has stopped. This can take up to
30 minutes.
The chrome rings may discolour, this is normal
and not a fault with the cooker
Controlling the Hotplates
1. Rotate the control on the selected hotplate clockwise or anti-clockwise
to the heat level you require. The yellow hotplate warning light will
illuminate to show a hotplate is turned on.
2. When you have nished cooking rotate the control back to the “0”
position. The hotplate warning lamp will turn o.
Choosing the Right Cookware
• Do not use cookware with jagged edges or a curved base.
• Make sure that the base of your pan is smooth, sits at, and is the same size as the cooking zone.
Always centre your pan on the cooking zone.
0
1
2
3
* All images are for indication only; please refer to your individual unit for actual item.

10
Using the Oven
First Time Use of the Oven
• Ensure that nothing has been left in the oven. Remove
any insert cards, packaging, labels or plastic bags and
the grill pan handle.
• Before connecting the power, carefully wipe the inner
cavity wall and housing with a damp cloth and hot
water containing a little washing-up liquid.
• Clean all the detachable parts in hot water containing a
little washing-up liquid before using.
• Heat the appliance on maximum, making sure the room is well ventilated as there may be a little smoke and
odour. This is normal, and is due to the protective substance on the appliance which protects it during shipping
from the factory. Switch the appliance o once the smoke and odour has stopped. This can take up to
30 minutes.
50
100
150
200
250
00
* All images are for indication only; please refer to your individual unit for actual item.
Shelf Positions
1. On the wall of the inner cavity there are 5 dierent
shelf guide slots. You can place the shelf at dierent
heights to achieve the best cooking performance
depending on the temperature setting and the size
of food. Position 1 is the highest grill position. The
smallest distance allowed between the food and the
upper heating element is 30 mm
2. Always monitor the food during operation to
ensure that you are not overcooking it.
3. For heavy food, use a baking pan rather than the
oven shelf.
Grill position
1
2
3
4
5
• Under no circumstances should the oven be lined with aluminium foil as overheating may occur.
• Do not place dishes or baking trays directly onto the base of the oven as it becomes very hot and damage
may occur.
• Bread may catch re if the toasting time is too long. Close supervision is necessary during toasting.
• During use, this appliance becomes hot. Care should be taken to avoid touching hot surfaces,
e.g., oven door, heating elements.
• Accessible parts may become hot when in use. Children should be kept away.

11
• Insert the shelf with the back stop to the back as show. Make sure it is pointing upwards. This will prevent
dishes falling o the back of the shelf.
• You will notice that about half way along each shelf, it has a curve on each side. This is the rest position of the
shelf when pulling the shelf out of the oven. It will rest in the recess on the oven side wall. This prevents the
shelf from tilting forward when removing cooking pots and trays.
Rest point
recess
Rest point

12
Oven Function Selector Control
This control is used to select the cooking functions. Turn the control clockwise or anti-clockwise to select the
required function.
1. Turn the control to the required setting. The yellow operation light will illuminate.
2. To switch o the oven, turn the control anti-clockwise to the ”O“ position. The operation light will go out.
Switches on the oven lamp independently of all other functions.
The oven’s thermostat, indicator lamp and upper and lower heating
elements will be switched on.
The oven’s thermostat, indicator lamp and the lower heating element
will be switched on.
The oven’s thermostat, indicator lamp and the upper heating element
will be switched on.
The oven’s indicator lamp and grill heating element will be switched on.
Temperature (Thermostat) Control
This control is used to select the cooking temperature. Turn the control clockwise to select the required
temperature.
1. Turn the control to the required temperature. The red thermostat light will illuminate.
2. The thermostat light will go out once the set temperature is reached. The oven is ready to use.
3. Turn the control anti-clockwise to the ”O“ position when switching the oven o. The thermostat light
will go out.
The temperature can be set from 50°C - 250°C. Select the desired temperature, as follows:
To keep food warm 50 - 100°C position
For traditional oven cooking 50 - 250°C position
For all types of grilling The grill temperature can’t be adjusted
If accurate temperatures are required then this should be checked using an oven thermometer available
at most cookware shops.
* All images are for indication only; please refer to your individual unit for actual item.

13
Using the Grill
First Time Use of the Grill
• Ensure that nothing has been left in the oven. Remove
any insert cards, packaging, labels or plastic bags and
the grill pan handle.
• Before connecting the power, carefully wipe the inner
cavity wall and housing with a damp cloth and hot
water containing a little washing-up liquid.
• Clean all the detachable parts in hot water containing a
little washing-up liquid before using.
• Heat the appliance on maximum, making sure the room is well ventilated as there may be a little smoke and
odour. This is normal, and is due to the protective substance on the appliance which protects it during shipping
from the factory. Switch the appliance o once the smoke and odour has stopped. This can take up to
30 minutes.
Cooking Using the Grill
1. Turn the Oven control to the Grill position .
2. Preheat the grill element for approximately 5 minutes before use.
3. Insert an oven shelf into your desired grilling position, this would normally be position one. Slide the grill pan
onto the oven shelf, making sure to use the handle provided, then remove the handle.
The food being cooked must be placed on the grill pan rack within the grill pan. Ensure there is at least
30 mm between the food and the elements, if necessary use a lower shelf guide slot.
4. Close the door.
5. Check the food regularly to ensure you do not overcook the food. If slower cooking is required use a lower
shelf guide slot.
* All images are for indication only; please refer to your individual unit for actual item.
50
100
150
200
250
00
Attaching the Grill Pan Handle
The grill pan handle must be used when you slide the grill pan in and out of the oven.
1. Locate the recess on either side of the grill pan.
2. Tilt the pan handle up and slid over the recess.
3. Let the pan handle fold down until its horizontal with the grill pan. The handle is now attached.
4. To remove the handle once the grill pan is under the grill, tilt the handle upwards and slide it o the grill pan.
• Never cover the grill pan or grill rack with foil as this can lead to grill res.
• Bread may catch re if the toasting time is too long. Close supervision is necessary during toasting.
• The handle must be removed once the grill pan is inserted into the oven.

14
Cleaning Instructions
Before you start cleaning your cooker, please:
Read the cleaning instructions and the ‘Safety Warnings’ sections.
Turn the cooker o at the wall.
Allow the cooker to cool fully before cleaning.
Do not use a steam cleaner.
• Wipe the oven clean after every use.
• Wipe up spills. Avoid leaving alkaline or acidic substances (such as lemon juice or vinegar) on the
oven surfaces.
• Do not use cleaning products with a chlorine or acidic base.
• Never clean the interior, panel, lid, trays and all other parts of the oven by using tools like hard brush, cleaning
mesh or knives. Do not use abrasive, scratching agents or detergents.
• After cleaning the interior parts of the oven with a soapy cloth, rinse it and then dry thoroughly with
a soft cloth.
• Never use ammable agents like acid, thinner or petrol when cleaning your oven.
• Do not wash any part of your oven in a dishwasher.
Cleaning the Hotplates
• Wipe the hotplates using warm water and a mild household detergent.
• The chrome rings around the outside of the hob plates can be polished using a soft cloth.
• To avoid rust spots appearing use only completely dry pans and do not allow wet lids to be placed on the
hotplates. Avoid salt coming into contact with the hotplate as it can also cause rust.
• Do not use abrasive cleaners/cloths as these can damage the appearance of the appliance.
Cleaning the Outside of the Cooker
Wipe the outside surfaces often, using warm water and a mild household detergent. Any stainless steel parts may
be cleaned with a suitable cleaner.
Cleaning the Oven Door Glass
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they may scratch the
surface, which could result in the glass shattering.
Take care when handling parts with glass, knocks, chips, heavy
handling and dropping could cause the glass to shatter.
Cleaning the Inside of the Oven
• Do not use abrasive cleaners, cloths or pads to clean the enamel.
• Clean the enamel on the inside of the oven when it has cooled down, using household detergents
or an ammonia-based cleaner. You may use ‘o the shelf’ oven cleaners, if you carefully follow the
manufacturers’instructions. After cleaning, wipe dry.
• The oven door can be removed to allow easier access to the inside of your oven. (Please refer to the
“Removing the Oven Door” section)

15
Removing the Oven Door
The oven door can easily be removed as follows:
1. Open the door completely.
2. The swivel retainers of the right hand and left hand hinges
are hooked onto the metal bar above them. Lift the retainers
as shown.
3. Close the oven door gently until it meets the open retainer.
4. Support the door by holding both sides at the same time. Continue
to close the door further then lift to disengage the hinge from the
bottom.
5. Pull the oven door towards you to remove the hinges from
their slots.
6. To replace the door, repeat the above steps in reverse order ensuring
the hinge slot engages over the edge of the door frame.
* All images are for indication only; please refer to your individual unit for actual item.

16
Removing the Oven Door Glass for Easier Cleaning
1. Remove the oven door.
2. Use a at headed screwdriver to remove the plastic vent panel
from the top edge of the door. Gently insert the screwdriver into
the side of the strip and prise it out.
3. Lift the glass out of the frame, noting which side of the glass
faces outwards (the outer side should have a shiny surface).
Clean it using appropriate glass cleaning products.
4. To replace the glass, place it back in position under the two
locating tabs at the bottom.
5. To replace the vent panel rst insert the left side, then insert the
right side and press until it clicks into position. Press in the left
side until it clicks.
6. Ensure the glass is not damaged in any way.
Replacing the Oven Lamp
1. Turn the cooker o at the wall.
2. Let the oven cavity and the heating elements cool down.
3. Remove the cover by turning anti-clockwise. This can be cleaned if required in hot soapy water and allowed
to fully dry before replacing.
4. Unscrew and replace the bulb with a new one suitable for high temperatures (300°C).
5. Ret the cover by turning clockwise.
Bulb specications: Voltage: 230V Power: 25W Thread: SES/E14
* All images are for indication only; please refer to your individual unit for actual item.

17
Installation
• The cooker must be installed by a competent person, if in doubt consult a qualied technician,
and in compliance with local electrical, safety and building regulation standards.
• If the cooker is installed adjacent to furniture which is higher than the hob, a gap of at least 100 mm must be
left between the side of the cooker and the furniture unless non-combustible materials (ceramic tiles, metal
splashback, etc.) are used which then allows this distance to be reduced to 20 mm.
• Your furniture must be heat resistant to 100˚C or above. If you are unsure of the heat resistance of the furniture
that your cooker is installed between, then allow an extra 40 mm of space around the cooker (20 mm each side).
• The furniture walls adjacent to the cooker must be made of heat resistant material (check with your furniture
supplier). The veneered synthetic material and the glue used must be resistant to a temperature of 100°C in
order to avoid ungluing or deformations.
• The cooker may be located in a kitchen, a kitchen/diner or bed-sitting room but not in a room containing a bath
or shower.
• Flammable materials such as curtains, wood, wallpaper, etc. must not be tted immediately behind the
appliance or within 500 mm of the sides.
• Do not place next to a refrigerator.
• This cooker must NOT be placed on a pedestal or base.
• It is essential that the cooker is positioned as stated or freestanding taking into account the distances of any
combustible materials detailed above.
• Any cooker hoods must be installed according to the requirements of the cooker hood instruction/installation
manual but no less than 650 mm away from the cooker.
• Any cupboards placed directly above the cooker must be no less than 700 mm away.
500 mm
420 mm
700 mm
X
Cupboard
500 mm
420 mm
650 mm
X
Cupboard
Cooker Hood
For all dimensions marked “X”, please refer to the information below:
X : 100 mm for combustible materials
20 mm for non-combustible materials.
* All images are for indication only; please refer to your individual unit for actual item.

18
Adjusting the Feet
Your oven has 2 adjustable feet at the front and 2 at the back. When the oven is placed where it will be used,
check if the oven is level. If it is not level, you can adjust the feet by turning the feet if required. It is possible to raise
the appliance a maximum of 10 mm using the feet. DO NOT move the appliance by dragging; lift it into place.
Using the tted adjustable feet is MANDATORY. For safety reasons
and to ensure adequate ventilation, the cooker chassis MUST NOT
sit directly on the oor, a plinth, or other support surface.
1. Open the front ap to access the adjustable feet.
2. Your cooker has 4 adjustable feet, 2 at the front and
2 at the rear of the cooker.
3. Use a at blade screwdriver to adjust the feet. Turn clockwise
to raise the cooker. Turn anti-clockwise to lower the cooker.
4. Close the ap once level.
* All images are for indication only; please refer to your individual unit for actual item.
Moving the Cooker
• Two people must always raise the cooker, as shown, to prevent
damaging the adjustable feet.
• Do not lift the cooker by the door handles.
• DO NOT DRAG the cooker. Lift the feet clear of the oor.
Stability Bracket
The supplied stability device or a recognized cooker stability device must be tted to the back of the cooker as
shown.
Wall Plug
1. Adjust the feet to make sure
the appliance is level before
tting the stability device.
2. Screw the chain to the back of
the cooker as shown above.
3. Screw the eyelet into the wall at a height of 750mm from
the oor level.
4. Clip the chain onto the eyelet.

19
Electrical Connection
Your cooker is designed to operate on an electricity supply which conforms to the electrical data shown on
the Rating Plate. The cooker can be connected to the mains only after you complete the connections in the
terminal box.
The following installation procedure must be carried out by a competent person. If in doubt consult a
qualied electrician. The electrical installation must comply with local regulations and By Laws.
How your cooker is supplied 230V~ 50Hz
* All images are for indication only; please refer to your individual unit for actual item.
• The power supply cable must have these minimum requirements:
– Type: H05VV-F (PVC insulated and sheathed exible cable)
– 3 cores x 4 mm2minimum.
This appliance must be earthed.
• The cooker must be connected to the mains supply with a switched (double pole) cooker outlet providing
full disconnection correctly fused with a capacity appropriate to that shown on the cooker Rating Plate
and incorporated in the xed wiring in accordance with the latest wiring regulations. All electrical wiring
from the consumer unit to the cooker, via the switched double pole cooker outlet, must be of the
correct rating.
• The supply cable must be positioned away from any hot parts of the rear of the cooker. If this cannot
be done then another method of protecting the supply cable from the hot parts must be used
i.e. Heat resistant sleeving or high temperature cables.
This appliance must be earthed
Green / Yellow (Earth) to the PE ( ) terminal
Brown (Live) wire to the terminal marked L
Blue (Neutral) wire to the terminal marked N
Ensure the cable exits through the cable grip
clamping on the outer sheath of the cable
and x in place by tightening the xing screw.
Ensure all screws are adequately tightened.
Do not over tighten as you may risk damaging
the screw threads.
Minimum cable
H05VV- F4 mm2
8061424
Minimum cable
H05VV- F4 mm2
8061424
Grounding lead must be connected
to screw with symbol.

20
Energy Saving Tips and Energy Label
Main Oven
• Cook the meals together, if possible.
• Keep the pre-heating time short.
• Do not elongate cooking time.
• Do not forget to turn o the oven at
the end of cooking.
• Do not open the oven door during
cooking.
Hob
• Use cookware that has a at base.
• Use the correct sized cookware for
the cooking zone being used.
• Use a lid on your cookware.
• Minimize the amount of liquid or
fat used.
• When liquids start boiling reduce
the heat.
