Cybernet
Owner’s Manual
Quartz PLL
Direct-Drive Auto-Return
Turntable CP-300Q

Contents
Designation of parts /3
Installing the Platter /4
Removing the dust cover /4
Assembling the tonearm /5
Connection /5
Adjusting the tonearm /6
Operation /8
Cautions /9
Cartridge stylus replacement /9
Specifications /10
Designation of parts
QQOLHOSSOIGOHSSOHSOO GEOOOOGLO
Rubber mat
Platter
Base
Dust cover
45 RPM adapter
Center spindle
Speed adjustment control
& Quartz ON/OFF switch
Speed selector
Reject button
Main weight
Tracking Force Dial
Anti-skating control
Cueing lever
Tonearm rest
Tonearm rest clamper
Tonearm — Tonearm shaft
Headshell
Manual arm lifter
Lock nut
Cartridge
Stylus
Stylus protective cover
Foot
Stroboscope window

Ajusting the Tonearm
@ Set the ANTI-SKATING @ control to ‘0’. © Release the TONEARM REST CLMPER@. The tonearm ® With the tonearm balanced horizontally, it has a © Adjusting the Tracking Force.
Pull the CUEING-lever @3) down to v . will swing up, down or sideways, so care must be taken to tracking force of “0” gram. Turn the MAIN WEIGHT (rear part) until the
Remove the needle protection (STYLUS COVER ®) from avoid damage of the stylus. To prepare the tracking force adjustment, turn only the TRACKING FORCE DIAL indicates the appropriate
the cartridge. You can hold the tonearm by the MANUAL ARM LIFTER TRACKING FORCE DIAL to read “0” on the reference tracking force for your cartridge.
(hook of the headshell). line of the tonearm shaft. The standard cartridge provided operates best with a
Be sure not to turn the entire MAIN WEIGHT as this will tracking force of 2.5 grams.
spoil the horizontal balance of the tonearm.
Be ss E ;
JUN
We
—
|
l
%
A f :
aia
|
© Balance the entire tonearm, by turning the MAIN © -Adjusting the ANTI-SKATING (2 control.
WEIGHT @ (moving it forward or backward). Leave the As the cartridge tracks a revolving disk (record), the stylus
MAIN WEIGHT (0 where it balances the tonearm horizontally. tends to be pulled toward the center of the disk. This
When the above adjustment is finished, secure the tonearm on inside force’ presses the stylus against the inner wall of the
the
TONEARM
REST
@
with
the
CLAMPER
@)
and
lift
the
record
groove.
The
ability
to
track
the
groove
is
reduced,
CUEING
LEVER
@
to
Vv
.
and
the
reproduced
sound
is
slightly
distorted.
The
ANTI-SKATING 42 control (or inside force canceller)
offsets this harmful force and only needs to be set at the
same indication as the Tracking Force applied.

Operation
Set the VOLUME of your amplifier to minimum.
Turn the POWER switch ON.
Set the INPUT SELECTOR (FUNCTION or SOURCE
switch) to PHONO.
Remove the stylus protective cover.
Release the CLAMPER @ at the TONEARM REST 44) .
@ Depress the SPEED SELECTOR button to play
a 45 RPM record.
Release the SPEED SELECTOR button to pla
a 33-1/3 RPM record. v
® Gently place your finger on the MANUAL ARM
LIFTER 48 (hook of the headshell) and move it to the
beginning of the track you wish to play.
Pull the CUEING @3 lever to Z . The tonearm lowers
gently onto the record and starts playing.
|
@ Liftthe CUEING ®lever to X .
© Adjust the VOLUME of the amplifier.
When the record is finished, the tonearm will return to the
arm rest, and the turntable will shut off automatically.
If you desire to terminate the play before the record is
finished, push the REJECT © button, and the turntable will
shut off the same manner as above.
The orange dots, visible in the STROBOSCOPE
WINDOW @ permit you to adjust the revolving speed of
the turntable, related to the correct speed, chosen by the
SPEED SELECTOR ®. The adjustment is done by the
SPEED ADJUSTMENT CONTROL ®©. The speed is
correct when the dots don’t move.
When pushing the QUARTZ ON/OFF SWITCH ©,
manual speed adjustment is replaced by a precise quartz-
controlled circuit.
Cartridge Stylus Replacement
The life of a diamond stylus is between 800 and 1000
hours.
To replace the stylus, loose the lock nut of the tonearm
and remove the headshell from the tonearm.
The entire stylus holder can be pulled off the cartridge, as
illustrated.
The new replacement stylus can gently be pressed in.
Cautions
While the tonearm is automatically returning to the
armrest, do not manually interfere it.
During playback, do not touch the platter or tonearm.
To prevent possible damage to record or stylus, the
CUEING lever should:always be used to lower the
tonearm onto the record surface.
Cartridge Wiring Diagram
Green (Ground) 2
Right Channel
Red (Hot) Te
CJ Blue (Ground)
Left Channel
9 White (Hot)

Specifications
Turntable
Motor
Drive system
Platter
Platter weight
Wow and Flutter
Signal-to-Noise ratio
Speeds
Speed adjustment range
Tonearm
Type
Effective length
Overhang
Acceptable cartridge weight
Cartridge
Type
Frequency Response
Channel Balance
Crosstalk
Output Voltage
Optimum Load
Tracking Force
Stylus
General
Coreless, slotless, brushless Power Requirement
4-phase 8-pole magnet field
type flat DC motor
Electronically controlled
Direct Drive
310 mm diameter aluminum
diecast
0.9 kg
Less than 0.035% WRMS (JIS)
More than 73 dB (DIN-B)
33-1/3 and 45 RPM
+4%
Dimensions (W x D x H)
Weight
Statically balanced straight
tubular arm
Direct reading Tracking
Force Adjustment
Viscous-damped cueing
mechanism
215mm
16 mm
5~9g
Moving Magnet (MM)
20-20,000 Hz
Within 1 dB at 1 kHz
More than 25 dB at 1 kHz
3.5 mV at 1 kHz (50 mm/s)
47 kOhm
2.5g (+0.5g)
0.7 mil diamond
220 Volt AC (+10%)
50/60 Hz 7W
420 x 375 x 133 mm
5.5 kg Net
7.0 kg Gross

Cybernet Electronics Corporation
Cybernet Europe S.A. Mercure Centre
Raketstraat 100
B-1130 Brussels
Belgium Tel. 02-720, 90, 20
Cybernet International Inc. 7 Powder Horn Drive
Warren, New Jersey 07060
U.S.A.
Tel. [phone]
Head Office 344 Shinsaku
Takatsu-ku
Kawasaki
Kanagawa 213
Japan Tel. [phone]
KTCP300EXX
Printed in Japan
