CYP RE-11HS User manual

RE-11HS
RE-11HS
HDMI to HDMI equalizer
Operation Manual

1. Introduction................................................................................
2. Features......................................................................................
3. Package Contents.....................................................................
4. Operation Controls and Functions..........................................
4.1 Front Panel...........................................................................
4.2 Rear Panel............................................................................
5. Connection and Installation.....................................................
6. Specifications............................................................................
TABLE OF CONTENTS
1
1
1
1
1
2
2
2

1. Introduction
The RE-11HS is perfect for placing at the end of a HDMI cable to boost the
signal by up to 40dB to improve the HDMI signal quality to the display. The
RE-11HS Equaliser uses v1.3 HDMI specifications, supporting ‘Deep Colour’
together with High Definition Audio with a high bandwidth up to 225MHz.
2. Features
v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant
HDMI to HDMI Equaliser
Resolutions Support: Output resolution follows Input.
PC: VGA,SVGA,XGA,SXGA, UXGA (1600 x 1200) and WUXGA (1920x1200).
HDTV: 480i, 576i, 480p, 576p, 720p, 1080i & 1080p + 1080P 24fps
High Definition Audio supported: Dolby TrueHD, Dolby Digital Plus and
DTS-HD Master Audio plus LPCM
Corrects digital error and automatically provides equalisation up to 40dB
Automatic equalisation up to 40dB
Supports cable up to 40 metres from the source to the equaliser plus up
to 10 metres from the equaliser to the display
Support xvYCC
Supports Deep Colour (10 & 12 bit)
Supports 3D signals







3. Package Contents
HDMI to HDMI equalizer
5V DC power supply adaptor.
Operation Manual.
4. Operation Controls and Functions
4.1 Front Panel
1 HDMI output: Connect the HDMI output port to the HDMI input port of
your display.
1
1
HDMI OUTPUT
HDMI v1.3 Equalizer



2
1 HDMI input: Connect the HDMI input port to the HDMI output port of
your source equipment such as DVD player or set-top-box.
2 Power: Plug the 5VDC power supply into the unit and connect the
adaptor to AC wall outlet.
4.2 Rear Panel
Input Port
Output Port
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Operating Temperature
1 x HDMI
1 x HDMI
5V/1A DC (US/EU standards, CE/FCC/UL certified)
72(W) x 76(D) x 30(H)
150
Aluminum
Black
0°C ~ 40°C
6. Specifications
1 2
DC 5V
HDMI INPUT
5. Connection and Installation
HDMI
HDMI
HDMI Cable
DVD or Set-Top-Box
HDMI
HDMI
HDMI Cable
HDTV HDMI display LCD TV
OR OR
