Behringer Ultragraph Pro FBQ6200 User manual

Technical Specications
ULTRAGRAPH PRO FBQ6200
Audiophile 31-Band Stereo Graphic Equalizer with
FBQ Feedback Detection System

2ULTRAGRAPH PRO FBQ6200 Technical Specifications
ULTRAGRAPH PRO FBQ6200
Audiophile 31-Band Stereo Graphic Equalizer with
FBQ Feedback Detection System
Audiophile 31-band stereo graphic equalizer for live and studio applications
Revolutionary FBQ Feedback Detection system instantly reveals critical frequencies and can also be used as audio analyzer
Dedicated Limiters with gain reduction meters for each channel protect your sound system from overload and distortion
Pink noise generator provides test signals to adapt your sound system to any room acoustics
Mono subwoofer output with dedicated level control and adjustable crossover frequency
Additional sweepable high and low-cut lters for each channel remove unwanted frequencies e.g. oor rumble, hiss etc.
Highly accurate 8-segment LED input/output metering and input gain controls for easy level setting
Ultra-low noise audio operational ampliers for highest signal integrity
Relay-controlled hard bypass with an auto-bypass function during power failure (failsafe relay)
Servo-balanced inputs and outputs with 1/4" TRS and gold-plated XLR connectors
Shielded toroidal power transformer for ultra-low noise performance
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Specications
Audio Inputs
INPUTS RF-ltered, servo-balanced XLR and
¼" TRS connectors
Impedance 40 kW balanced and unbalanced
Maximum input level +21 dBu balanced and unbalanced
CMRR typ. 40 dB, >55 dB @ 1 kHz
Audio Outputs
OUTPUTS servo-balanced XLR and
¼" TRS connectors
SUBWOOFER OUT balanced XLR connector,
level variable o to 0 dB
Crossover frequency variable, 30 - 200 Hz
System Specications
Frequency response 10 Hz to 30 kHz, ±3 dB
S/N ratio 22 Hz to 22 kHz >94 dB @ +4 dBu
Distortion (THD) typ. 0.006% @ +4 dBu, 1 kHz, Gain 1
Crosstalk typ. -65 dB @ 1kHz
Roll-O Filter Section
Type 12 dB/oct., Butterworth
Input variable (-15 dB to +15 dB)
Low Cut variable (10 Hz to 400 Hz)
High Cut variable (2.5 kHz to 30 kHz)
Graphic Equalizer
Type analog 31-band equalizer
Frequency range 20 Hz to 20 kHz in 31 1/3-octave bands
(ISO frequencies)
Bandwidth 1/3 octave
Control range ±6 dB or ±12 dB (switchable)
Limiter Section
Attack/Release 20 msec / 90 msec
Threshold variable, -6 dB to +22 dB (o)
LED meter Gain reduction 20/10/3/1 dB
Noise Generator
Type Pink noise, level variable, o to 0 dBu,
LED level meter -24/-12/-6/0 dB

3ULTRAGRAPH PRO FBQ6200 Technical Specifications
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time to time to existing products without prior notice. Specifications and appearance may differ from those
listed or illustrated.
TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER IS PART OF THE MUSIC GROUP (MUSIC-GROUP.COM). ALL TRADEMARKS ARE THE PROPERTY OF THEIR
RESPECTIVE OWNERS. MUSIC GROUP ACCEPTS NO LIABILITY FOR ANY LOSS WHICH MAY BE SUFFERED BY ANY PERSON WHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH OR STATEMENT CONTAINED HEREIN. COLORS AND
SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS ONLY. FULLFILLERS AND RESELLERS ARE NOT AGENTS OF MUSIC GROUP AND HAVE ABSOLUTELY NO
AUTHORITY TO BIND MUSIC GROUP BY ANY EXPRESS OR IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OF THIS MANUAL MAY BE REPRODUCED OR TRANSMITTED IN ANY FORM OR BY ANY MEANS, ELECTRONIC OR
MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE, WITHOUT THE EXPRESS WRITTEN PERMISSION OF MUSIC GROUP IP LTD. ALL RIGHTS RESERVED. © 2012 MUSIC GROUP IP LTD. TRIDENT CHAMBERS,
WICKHAMS CAY, P.O. BOX 146, ROAD TOWN, TORTOLA, BRITISH VIRGIN ISLANDS
Function Switches
FBQ activates the FBQ Feedback Detection
System
Audio In/Out switch to bypass the equalizer
functions
I/O Meter In/Out switches the meter display from input
to output
Range shift of the maximum cut/boost range
for all 31/15 bands
Low Cut —
Limiter activates the limiter
Pink Noise activates the noise generator
Subwoofer activates the subwoofer output
Indicators
Input/output level 8-segment LED display:
-24/-18/-12/-6/0/+6/+12 dB/CLIP
Subwoofer 4-segment LED display:
-18/-12/0/+12 dB
Power Supply
Mains Voltage
USA / Canada 120 V~, 60 Hz
Europe / U.K. / Australia 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
General export model 120/230 V~, 50 - 60 Hz
Power consumption 35 W
Fuse 100 - 120 V~: T 630 mA H
200 - 240 V~: T 315 mA H
Mains connection standard IEC receptacle
Dimensions / Weight
Dimensions (H x W x D) approx. 5 ¼ x 19 x 5 7/8"
approx. 133.5 x 482.6 x 150 mm
Weight approx. 5.95 lbs
approx. 2.70 kg
