CZEM Drill One User manual

USER MANUAL

3
Welcome
Thank you for purchasing Czech Electric Motorcycle Drill. We appreciate your trust in our product.
Adhering to the guidelines in this manual is important in order to enjoy your Drill experience. Read the manual carefully before the rst use.
Also refer to the manual if there occur any problems or uncertainties using Drill.
Drill is a powerful and entertaining machine with which you can enjoy every moment of your ride. However, ill-treatment can endanger your
health or your life. Always drive carefully, wear the protection helmet, gloves, goggles and other proper clothing and safety equipment. Be
aware that you will drive a fast and quiet machine. Be considerate to your surroundings and pay attention not only to your safety but to others
too.
This manual shall advise you how to keep the motorcycle in perfect condition. We recommend that you purchase only original spare parts
exclusively from your Drill dealer. Pay special attention to the safety instructions. If you are still unsure after reading this manual, do not
hesitate to contact your Drill dealer.
The User’s Manual contains important technical and safety information about the Drill. This machine is designed for private recreational use, it
is not intended for professional sport.
All information in this manual is non-binding. Drill manufacturer reserves the right to make changes without prior notice and without giving
reasons to make changes to the technical specications, such as color, construction, equipment and use of materials. Furthermore, the
company acquires the right to adapt motorcycles to local conditions, market requirements and possibly stop the production of certain models
without prior review.
Drill manufacturer is not responsible for the availability of vehicles, the dierences between pictures or machine descriptions, or for errors or
omissions in this manual. The models shown include some special equipment, which is not included in the standard equipment.

INDEX
1.1. General information
2.1. Location of basic components
2.2. Controls placed on handlebars and battery
2.3. Vehicle identication numbers
2.4. Technical Specications
3.1. Check or adjust before each ride
3.2. Battery and charger, electrical components
3.2.1. Basic instructions
3.2.2. Battery charging
3.2.3. Battery capacity indicator
3.3. Starting and changing the driving mode
3.4. Stopping the motorcycle
3.5. Motorcycle range
3.6. Driving instructions
3.7. Instructions for parking the vehicle
3.8. Motorcycle suspension
3.9. Rear shock-absorber functions and settings
3.10. Fork functions and settings
3.11. Brakes
4.1. Brake maintenance
4.2. Rims, tires, hubs
4.3. Wheels disassembly
4.3.1. Removing of the front wheel
4.3.2. Removing of the rear wheel
4.4. Gears, chain
4.5. Adjustments and periodic maintenance
4.6. Washing
5.1. Problem solving
6.1. Warranty
6.2. Warranty Exceptions
6.3. Warranty on selected components
6.3.1. Battery and controller
6.3.2. Engine
6.3.3. Brakes
6.3.4. Chassis components
6.3.5. Transmission components
6.4. Complaint form
6.5. Warranty management
4
5
6
8
9
10
11
11
11
12
12
13
13
13
14
15
15
15
16
16
18
18
19
19
19
20
21
23
25
26
27
29
29
30
31
31
31
31
31
1. Safety
2. Description of the machine
4. Maintenance
5. Problems solving
6. Warranty
3. Operation

5
1.1. General information
Any changes made by the user to the machine may not only aect your safety, but also endanger the health of those around you.
Changes made without the approval of the authorized dealer or the manufacturer may void your warranty.
Always use your Drill in accordance with local regulations and laws that restrict the use of electric vehicles. Drill is not intended for use on
public roads.
If you have any questions, please contact your Drill dealer. Do not allow others to use your Drill until they have received all of the essential
instructions for operating and using the Drill or have read this manual. The manufacturer is not responsible for incorrect operation and use of
the Drill machine. Drill is not a racing machine and is not intended for such use. Racing use will void the machine's warranty. Regular inspec-
tions and maintenance at an authorized dealer along with responsible driving will help you to enjoy a safe and reliable ride. Remember that
only authorized personnel authorized by the manufacturer may operate electrical parts. Always remember that in addition to voiding your
warranty, you can also endanger yourself and your surroundings.
Basic safety precautions
Always check all key machine components before driving. Whenever you do not use the machine or when pushing or moving it, switch o the
engine as instructed! Electrical components are under voltage, which can reach up to 54 V. They can cause you serious injuries and even
endanger your life.
They must be handled (except for battery charging) only through a Drill dealer. Any damage to the electrical components must be repaired by
a Drill dealer before driving again. These components remain energized for some time after switching o. Never break any cables.
1. Safety

High capacity batteries - 55 Ah
Primary transmission
provided with a cover
Adjustable
footrests
Optional rear wheel set
90-100-16” / 70-100-19”
Changing of modes (maps)
Seat
Optional front wheel set
70-100-19” / 26 x 2,6”
Breaks
6
2. Description of the machine
2.1. Location of basic components

Aluminum frame
Rear hydraulic
4-piston brakes
Front hydraulic
4-piston brakes
Fully adjustable fork
Manitou Dorado
Electric drive
disconnector (tear o / tug)
Controller
Fully adjustable
absorbing suspension unit Elka
Durable rear swing
fork with repacking
7
2. Description of the machine

8
2. Description of the machine
2.2. Controls placed on handlebars and battery
Electric drive disconnector (tear o / tug) and main
battery switch (On / O).
Digital battery status indicator and indicator light for
selected driving modes (maps).
Switching of modes (maps) is located on the right side
of handlebars.
Fully adjustable rear fork damping with adjustable
repacking.
Tensioning of the chain by means of eccentrics on the
swinging fork on the rear wheel axle.
Fully adjustable air front fork Manitou Dorado.

9
2. Description of the machine
2.3. Vehicle identification numbers
The identication numbers contain a lot of information related to the production of the motorcycle.
Vehicle identication number VIN (Serial Number): VIN is a 17-digit number that is axed on the frame, battery, and charger of the
motorcycle.
Control unit identication number (controller): this number is located on the top of the controller.
IN CASE OF LOSS OR DAMAGE OF THE GUARANTEE SEAL, THE WARRANTY DISCLAIMS. DO NOT REMOVE THE SEAL FROM THE MOTOR
CYCLE AND PROTECT IT FROM DAMAGE!
VIN on motorcycle charger.VIN on motorcycle battery.VIN on motorcycle frame.

CHASSIS
Length
1.780 mm
Width
430 mm (steps)
820 mm (handlebars)
Seat height
880 mm
Wheelbase
1.240 mm
Headroom
320 mm
Weight
52 kg (according to used tires)
Weight distribution
26 kg : 26 kg (front : rear wheel)
Maximum load
100 kg
Frame
Aluminium
Drive
Chain 420
Front shock absorber - stroke
Manitou Dorado Expert / 200 mm
Rear shock absorber - stroke
Elka / 180 mm
Front tires
70-100-19 / 26 x 2,6” (downhill bike)
Rear tires
90-100-16 / 70-100-19
Front rim
559 x 33 Remerx Super Jumbo
Rear rim
19 x 2,15 32H DID
Front brake
4-piston hydraulic
Rear brake
4-piston hydraulic
Recuperation.
Yes
Charging time
3,5 hours
Homologation
No
Range in terrain
60 km depending on speed
and mode selected / 2.5 hours
o-road / 1 hour in Racing
mode)
10
2. Description of the machine
2.4. Technical Specifications
Power
11 kW Nominal / 15 kW Peak
Maximum torque
40 Nm
Maximal speed
60 - 90 km/h
Engine speed
6.000 rpm
Driving modes
3 modes (Eco, Sport, Racing)
Usable battery capacity
2,25 kWh (Lithium-Ion)
Cooling
Forced rotor cooling
Angle of rise
69°
Type and transmission ratio
7:1 / 10:1
ENGINE AND POWER

311
3. Operation
3.1. Check or adjust before each ride
1/ All fastening components, make sure they are OK, fastened or tightened and show no signs of damage.
2/ Position and function of the brake levers. Make sure you know where and on which side the front and rear brakes are located.
3/ Tires pressure.
4/ With the engine o, if the gas returns to its starting position after adding gas.
5/ Condition of gears and chain lubrication.
6/ All electrical components on the machine, all cables and components must be in perfect condition and in the correct position.
7/ Charging the battery.
After any fall it is always necessary to completely revise the condition of the vehicle. To be completely sure visit any Drill dealer.
3.2. Battery and charger, electrical components
3.2.1. Basic instructions
The battery is provided with a safety seal, the battery can only be opened by a Drill dealer. If this seal is damaged, you will lose your warranty.
Fully charge the battery before the rst use. The battery is equipped with BMS, which constantly evaluates the current status of the battery and
optimizes its performance. If the battery charge falls below 25% while driving, the control unit automatically reduces engine power. The system
is deactivated before the battery is completely discharged. Battery life may vary depending on the conditions in which the machine drives and
the riding style.

12
3. Operation
3.2.2. Battery charging
1/ Connect the charger to a 220V power supply.
2/ LED No. 1 on the charger lights up red to indicate that it is energized.
3/ LED No. 2 lights up green until the motorcycle charging connector is connected.
4/ Remove the protection cap on the motorcycle charging connector.
5/ Switch the main battery switch on the handlebars of the motorcycle to the ON position and disconnect the tug.
6/ Connect the charging connectors between the charger and the motorcycle.
7/ LED No. 2 on the charger turns red and the charger activates and starts charging the battery.
8/ The charger fan is active during charging and cools the charger.
9/ As soon as the battery is charged, the charger automatically switches o the cooling and LED No. 2 lights up. The LED is green when the
battery is charged.
10/ Turn the main battery switch to OFF.
11/ Disconnect the connectors between the motorcycle and the charger and attach the protective cap to the charging connector on the
motorcycle.
12/ Charging a fully discharged battery takes about 4 hours.
13/ Start the motorcycle according to the chapter "Starting the motorcycle and changing the driving mode".
3.2.3. Battery capacity indicator
The motorcycle is equipped with a central display, which shows the current state of charge of the battery in volts and at the same time via the
graphic symbol of the battery with 4 cells. To determine the battery capacity more accurately, it is better to monitor the voltage in volts. When
the battery is fully charged, the display shows 53, 7 V. If the voltage drops below 42 V, the motorcycle's control system begins to reduce power.
When the 39 V voltage is reached, the control system switches o the entire motorcycle to protect the battery. Further start-up of the motorcy-
cle after full discharge is only possible after recharging.

313
3. Operation
3.3. Starting and changing the driving mode
1/ Turn the main battery switch to ON.
2/ Attach the “tug”(put magnetic protection switch on wrist). The driving mode control indicator illuminates white and the motorcycle
acoustically signals readiness to drive.
3/ Carefully turn the gas handle. The motorcycle does not start and does not react to the gas.
4/ Press the drive mode switch. After the rst press, the weakest economy mode is activated. The motorcycle works at 50% of its own
maximum power. The LED indicates the ECO mode in green. After the second press, the LED lights up blue and signals the middle perfor-
mance level. In this SPORT mode, the motor power is set to 75% of the maximum power. The third press activates the motor at its maximum
RACING power and the LED is red. When pressed again, the motorcycle switches back to the "green" economy mode.
In case of a fall and pulling out of the "tug", check all elements of the motorcycle. Connect the tug magnets. The performance map status LED
lights up white. The motorcycle acoustically announces readiness to ride. Switch on the selected driving mode and continue driving.
3.4. Stopping the motorcycle
1/ Disconnect the "tug" when you stop driving. The map indicator LED goes out.
2/ Then disconnect the battery with the main switch by turning it to the OFF position. The battery indicator turns o when the battery is
turned o.
3.5. Motorcycle range
The range is inuenced by many factors, especially by terrain, rider’s weight, gear selection, outside temperature and riding style.
O-road travel is 60 km depending on speed and selected mode / 2,5 hours in terrain / 1 hour in Racing mode.

14
3. Operation
3.6. Driving instructions
1/ Avoid incorrect and dangerous driving style. Always operate the machine with sucient respect.
2/ Never drive while under the inuence of alcohol, drugs or other addictive substances.
3/ Always use the right equipment including helmet, shoes, gloves, etc.
4/ Do not hang any objects on the handlebars or other parts of the motorcycle while driving.
5/ Don't bring anyone else with you. Drill is designed for one rider only.
6/ Please respect the laws and the natural environment.
7/ The motorcycle may overheat if the maps are selected incorrectly or if the driving direction is unsuitable. To prevent damage to the motor,
it is equipped with a temperature sensor directly inside the motor. When the temperature inside the engine reaches 75°C, the engine
control unit will limit its performance. Full engine power will not return to its original level until the engine temperature drops below that
level. If you park the motorcycle in hot weather at the moment when the temperature inside the engine reaches 75°C, the engine tempera-
ture can rise further, because the engine stops being cooled by the air supply.
If the temperature rises above 80°C in this situation, the motorcycle will be switched o completely. It starts to react only when the
temperature drops below 75°C. If the engine shuts down due to overheating, take o the tug, turn the switch to the OFF position, and start
the motorcycle as usual after cooling down.
8/ Use all performance maps while riding the motorcycle. Use the green map to drive slowly and save energy. Use blue map when driving
o-road and especially on long rides. When driving at full speed, do not drive on the blue map for more than 60 seconds. The red map is
intended primarily for the purpose of fast acceleration, short steep rides, overcoming obstacles, where you need to have maximum power
and engine torque. The red map is not suitable for continuous driving, especially at full throttle. If you use the red map, do not drive at full
throttle for more than 20 seconds.

315
3. Operation
3.7. Instructions for parking the vehicle
Drill is built to work in all nature conditions, but hot or extreme cold can aect it when standing or driving. Drill operating temperature is
between -5°C and 35°C. When batteries are exposed to low temperatures, performance and range may be reduced. Do not leave the vehicle
parked outdoors for long periods of time when the outside temperature is below 0°C. Do not charge the battery if it is super-cooled or at
temperatures above 40°C (for example, in direct summer sunlight). You can damage the battery and reduce its battery life. If you are not using
the Drill in winter, it is recommended that you fully charge the Drill at least once within 30 days.
3.8. Motorcycle suspension
Suspension ensures comfort, safety and handling when driving. Always have the suspension serviced or repaired by an authorized service
center. Do not remove the shock absorber or the fork yourself. Damage caused by improper handling will void your warranty. Never use
pressurized water to clean components.
3.9. Rear shock-absorber functions and settings
At the rear of the machine you nd a central suspension and damping unit, in short and commonly used silencer. The shock absorber is
compressed under load and extended again after release.
The squeezing of the spring is called compression. Compression can be set. It is thus possible to set the force by which the spring must be
compressed. This force can be increased or decreased. After compression (compression of the spring), the compressed spring begins to return
to its original position. This is called rebound.
By adjusting the bounce it is possible to change the time how long it will take for the spring to return to its original position after compression.
.

16
3. Operation
Depending on the weight of the driver, it is also possible to adjust the spring preload and thus aect the so-called rear shock absorber, or the
length by which the rear shock absorber drops below the rider's weight. Each driver must adjust the sag in relation to his weight by changing
the preload settings. It is recommended to set the sag to 10 - 20 mm depending on the driving style. Longer sags are more comfortable, while
smaller sags allow for more aggressive driving. Correct sag, preload, compression and rebound settings are essential for this machine to
function properly.
3.10. Fork functions and settings
The fork is compressed under the load and lengthened again when released. The front fork behaves in the same way as the above-described
shock absorber. The squeezing is called compression. Fork compression can be adjusted according to the rider's style and weight by adjusting
the spring preload. After compression, the compressed fork begins to return to its original position. This is called rebound.
By adjusting the bounce it is possible to change the time how long it will take for the fork to return to its original position after compression.
The fork is also equipped with so-called air chamber and control valve. Do not handle the valve. The new fork needs approximately 20 hours of
use to function properly. Regular maintenance, cleaning and adjustments are required for the fork to function properly.
3.11. Brakes
Check the condition and functioning of the brakes before each use. Always have the brakes serviced or repaired by an authorized service
center. Always test the brakes visually and functionally before driving, also again on a at and non-slippery surface several times. Brand new
brakes need to be driven to achieve the highest braking force. This means, in practice, starting the vehicle at least 20 times to 30 km/h and then
brake fully.

17
3. Operation
The pressure must be steady when the brake levers are pressed. The brake levers must not decrease further under pressure. If this occurs, it may
show a serious malfunction. In such case visit your Drill dealer immediately.
Moisture reduces braking eciency. The stopping distance is longer when it is wet and slippery. Dirty or greasy brake pads and discs can
signicantly reduce braking force. Therefore, make sure that no oil or other similar uid gets into the brakes, for example when lubricating the
chain. Never wash the brake pads impure by oil and always replace them with new ones. On contrary, the discs may be washed with a special
brake cleaner, or hot water and a conventional cleaner.
Contact an authorized service center to adjust the brake levers correctly.
Continuous braking can reduce braking eciency and even lead to extreme brake failure in extreme situations due to overheating. Do not
touch the disc or the brake caliper after a long downhill run to avoid burns. Learn to brake with both brakes at the same time! Stop at the rst
signs of overheating, i.e. when the brakes appear to be defective or when more force is required to brake, or smell or hear strange noise. Allow
the brakes to cool before continue riding.

18
4. Maintenance
4.1. Brake maintenance
1/ Check the brake pads for wear before each ride (min. thickness 2,5 mm).
2/ Always check for wear and damage (min. thickness 1,8 mm) before each ride.
3/ The thickness of the discs should not be less than stated value. If this happens, replace the discs immediately.
4/ Check the connections of hydraulic brake hoses before each ride (there should be no cracks in the cable, the brake uid must never leak).
5/ Wash the brakes if they are very dirty.
6/ Always have the brake serviced by an authorized service center.
4.2. Rims, tires, hubs
1/ Always check the condition of rims, tires and hubs before driving.
2/ Before driving, check the tires for cracks, cuts, bumps or bulges.
3/ If you notice any damage or abnormalities on the tire, replace it immediately.
4/ Check the tire pressure and condition before each ride.
5/ Check the minimum tread depth and, if smaller, replace the tire. The recommended tire pressure is 1,2 - 3,5 bar.
6/ Check the condition of the wheel hub regularly. Focus on runout and any cracks or other mechanical damage.
7/ Check the wheel wires for tightness. Loose wires can negatively aect vehicle behavior and stability.

19
4. Maintenance
4.3. Wheels disassembly
4.3.1. Removing of the front wheel
1/ Place Drill on the mounting stand.
2/ Unscrew the central nut of the wheel axle using an Allen key.
3/ Loosen the 4 screws from the bottom of the fork with the Allen key. Do not unscrew the screws completely.
4/ Lift the wheel slightly upwards so that it does not rest with its full weight on the wheel axis, pull out the wheel axle.
- Before each operation, make sure the vehicle is switched o.
- Be careful, the wheel is released when the wheel axle is removed.
- To replace the wheel, perform this process in reverse order.
- Never press the front brake lever unless the front wheel is tted.
- When retting the wheel, be careful to insert the brake disc back between the pads.
4.3.2. Removing of the rear wheel
1/ Place Drill on the mounting stand.
2/ Loosen the rear wheel axle nut bolt.
3/ Release the chain from the rosette.
4/ Remove the rear wheel axle nut bolt and pull out the rear wheel axle.
- Before each operation, make sure the vehicle is switched o.
- Be careful, the wheel is released when the wheel axle is removed.
- To replace the wheel, perform this process in reverse order.
- Never press the rear brake lever unless the rear wheel is tted.
- When retting the wheel, be careful to insert the brake disc back between the pads.

20
4. Maintenance
4.4. Gears, chain
1/ Check all gears regularly for wear! If the primary or secondary gears are in poor condition, visit your Drill dealer for replacement.
2/ Check the chain for wear.
3/ Clean and lubricate the chain after each ride.
4/ Use products designed for this purpose.
5/ Check the chain tension regularly as shown on the illustration. The gearwheel is located in the oscillation axis, thus the chain tension can be
higher than in other constructions, because the chain does not stretch during the springing. The chain tension should be within 1 cm.
Perform the tension as follows:
1/ Place Drill on the mounting stand.
2/ Loosen the rear wheel axle nut bolt.
3/ Rotate the tensioner symmetrically at both ends of the wheel to tighten the chain.
4/ Check the rear wheel symmetry from the rear and tighten the retaining screw.
