Mega Motion ENDEAVOR X User manual

Mega Motion Inc.
P.O. Box 275
Taylor, PA 18517-0275
1-800-MEGA-508
Owner’s Manual
*INFMANU4333*
Mega Motion, Inc.
P.O. Box 275
Taylor, PA 18517-0275
www.mega-motion.com

Mega Motion Service Center:________________________________________________________
Address: ________________________________________________________________________
Phone Number:__________________________
Purchase Date: __________________________ Serial Number:____________________________
SAFETY GUIDELINES
Copyright © 2012
Mega Motion Inc.
INFMANU4333/Rev A/January 2012
WARNING! An authorized Mega Motion Provider or qualified technician must perform the
initial setup of this scooter and must perform all of the procedures in this manual.
The symbols below are used throughout this owner's manual and on the scooter to identify warnings and
important information. It is very important for you to read them and understand them completely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow
designated procedures can cause either personal injury, component damage or
malfunction. On the product, this icon is represented as a black symbol on a yellow
triangle with a black border.
MANDATORY! These actions should be performed as specified. Failure to perform
mandatory actions can cause personal injury and/or equipment damage. On the product,
this icon is represented as a white symbol on a blue dot.
PROHIBITED! These actions are prohibited. These actions should not be performed at
any time or in any circumstances. Performing a prohibited action can cause personal
injury and/or equipment damage. On the product, this icon is represented as a black
symbol with a red circle and a red slash.
Please fill out the following information for quick reference:
NOTE: This owner’s manual is compiled from the latest specifications and product information
available at the time of publication. We reserve the right to make changes as they become necessary. Any
changes to our products may cause slight variations between the illustrations and explanations in this
manual and the product you have purchased.
DO NOT RETURN THIS PRODUCT TO THE
STORE. CALL 1-800-MEGA-508 FIRST.
STOP
Intended Use
The intended use of the Mega Motion device is to provide mobility to persons limited to a seated position
that have the capability of operating a powered scooter.

3Endeavor X www.mega-motion.com
CONTENTS
I. INTRODUCTION .........................................................................................................................4
II. SAFETY...........................................................................................................................................5
III. YOUR SCOOTER ......................................................................................................................19
IV. BATTERIES AND CHARGING ............................................................................................24
V. OPERATION ..............................................................................................................................29
VI. COMFORT ADJUSTMENTS ...............................................................................................31
VII. DISASSEMBLY AND ASSEMBLY ....................................................................................34
VIII. BASIC TROUBLESHOOTING ..........................................................................................36
IX. CARE AND MAINTENANCE ..............................................................................................38
X. WARRANTY ................................................................................................................................42
APPENDIX I - SPECIFICATIONS ................................................................................................44

4www.mega-motion.com Endeavor X
I. INTRODUCTION
SAFETY
Welcome to Mega Motion Inc . The product you have purchased combines state of the art components with
safety, comfort, and styling in mind. We are confident the design features will provide you with the
conveniences you expect during your daily activities. Understanding how to safely operate and care for
this product should bring you years of trouble free operations and service.
Read and follow all instructions, warnings, and notes in this manual before attempting to operate this
product for the first time. You must also read all instructions, warnings, and notes contained in any
supplemental instructional booklets that accompanied your scooter before initial operation. In addition,
your safety depends upon you, as well as your provider, caregiver, or healthcare professional in using good
judgement.
If there is any information in this manual which you do not understand, or if you require additional
assistance for setup or operation, please contact 1-800-MEGA-508. Failure to follow the instructions,
warnings, and notes in this manual and those located on your Mega Motion product can result in
personal injury or product damage and will void Mega Motion’s product warranty.
PURCHASER’S AGREEMENT
By accepting delivery of this product, you promise that you will not change, alter, or modify this product
or remove or render inoperable or unsafe any guards, shields, or other safety features of this product; fail,
refuse, or neglect to install any retrofit kits from time to time provided by Mega Motion to enhance or
preserve the safe use of this product.
SHIPPING AND DELIVERY
Before using your scooter, make sure your delivery is complete as some components may be individually
packaged. If you do not receive a complete delivery, please contact Mega Motion immediately. Where
damage has occurred during transport, either to the packaging or content, please contact the delivery
company responsible.
INFORMATION EXCHANGE
We want to hear your questions, comments, and suggestions about this manual. We would also like to hear
about the safety and reliability of your new scooter, and about the service you received from Mega Motion.
Please notify us of any change of address, so we can keep you apprised of important information about
safety, new products, and new options that can increase your ability to use and enjoy your scooter. Please
feel free to contact us at the address below:
Mega Motion Inc.
P.O. Box 275
Taylor, PA 18517-0275
1-800-MEGA-508
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact
us and we will be glad to send you a new one immediately.

5Endeavor X www.mega-motion.com
Keep tools and other metal objects away from battery terminals. Contact with
tools can cause electrical shock.
Read and follow the information in the owner’s manual.
Explosive conditions exist!
EMI/RFI - This product has been tested and passed at an immunity level of 20 V/m.
Corrosive chemicals contained in battery.
Pinch/Crush points created during assembly.
II. SAFETY
PRODUCT SAFETY SYMBOLS
The symbols below are used on the scooter to identify warnings, mandatory actions, and prohibited
actions. It is very important for you to read and understand them completely.
Fully charge batteries before operating.
Remove key from an unattended scooter.
Do not expose to heat sources such as open flame or sparks. Do not transport
batteries with flammable or combustible items.

6www.mega-motion.com Endeavor X
Maximum seating weight.
Unlocked and in freewheel mode.
Locked and in drive mode.
Place unit on level ground and stand to one side when changing from drive mode
to freewheel mode or freewheel mode to drive mode.
Battery posts, terminals, and related accessories contain lead and lead
compounds. Wear goggles and gloves when handling batteries and wash hand
after handling.
Not a brake.
Front-to-rear plug orientation.
II. SAFETY
Do not place the scooter in freewheel mode when on an incline or decline.

7Endeavor X www.mega-motion.com
Do not connect an extension cord to the AC/DC converter or the battery charger.
Removal of grounding prong can create electrical hazard. If necessary, properly
install an approved 3-pronged adapter to an electrical outlet having 2-pronged
plug access.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible.
Maintain and store in a clean and dry condition.
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while
operating.
Do not remove anti-tip wheels.
II. SAFETY
Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive
conditions.
Manufactured in.
This scooter does not meet ISO 7176-19 requirements for transport of an
occupied scooter in a motor vehicle.

8www.mega-motion.com Endeavor X
Indicates scooter attachment points.
Indicates electrical shock hazard.
Disposal and recycling - Contact your authorized Mega Motion Provider for
information on proper disposal and recycling of your Mega Motion product and its
packaging.
II. SAFETY
Do not allow unsupervised children to play near the scooter while the batteries
are charging.
Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and
new batteries. Always replace both batteries at the same time.
Battery charger for indoor use only.
Keep your hands away from the tires when driving. Be aware that loose fitting
clothing can become caught in drive tires.
Do not mix AGM or Gel-Cell batteries. Always use batteries of the same type and
chemistry.

9Endeavor X www.mega-motion.com
GENERAL
Your scooter is a state-of-the-art life-enhancement device designed to increase mobility. Mega Motion
provides an extensive variety of products to best fit the individual needs of the scooter user. Please be
aware that the final selection and purchasing decision regarding the type of scooter to be used is the respon-
sibility of the scooter user who is capable of making such a decision and his/her healthcare professional
(i.e., medical doctor, physical therapist, etc.).
The contents of this manual are based on the expectation that a mobility device expert has properly fitted
the scooter to the user and has assisted the prescribing healthcare professional and/or the authorized Mega
Motion Provider in the instruction process for the use of the product.
There are certain situations, including some medical conditions, where the scooter user will need to prac-
tice operating the scooter in the presence of a trained attendant. A trained attendant can be defined as a
family member or care professional specially trained in assisting a scooter user in various daily living
activities.
As you begin using your scooter during daily activities, you will probably encounter situations in which
you will need some practice. Simply take your time and you will soon be in full and confident control as
you maneuver through doorways, on and off elevators, up and down ramps, and over moderate terrain.
Below are some precautions, tips, and other safety considerations that will help the user become accus-
tomed to operating the scooter safely.
MODIFICATIONS
Mega Motion has designed and engineered your scooter to provide maximum mobility and utility. A wide
range of accessories is available from your authorized Mega Motion Provider to further customize your
scooter to better suit your needs and/or preferences. However, under no circumstances should you modify,
add, remove, or disable any feature, part, or function of your scooter.
WARNING! Do not modify your scooter in any way not authorized by Mega Motion. Do not
use accessories if they have not been tested or approved for Mega Motion products.
REMOVABLE PARTS
WARNING! Do not attempt to lift or move your scooter by any of its removable parts,
including the armrests, seat, or shroud. Mega Motion recommends use of only solid, non-
removable frame components such as scooter securement points or the front and rear
frame weldments to lift or move your scooter.
WARNING! Lifting the scooter should be accomplished with no fewer than three people,
one at the front and two at the rear of the unit.
PRE-RIDE SAFETY CHECK
Get to know the feel of your scooter and its capabilities. Mega Motion recommends that you perform a
safety check before each use to make sure your scooter operates smoothly and safely.
MANDATORY! Do not operate your new scooter for the first time without completely
reading and understanding this owner’s manual.
II. SAFETY

10 www.mega-motion.com Endeavor X
Perform the following inspections prior to using your scooter:
Check for proper tire inflation. Maintain but do not exceed the psi/bar/kPa air pressure rating indicated
on each tire if equipped with pneumatic tires.
Check all electrical connections. Make sure they are tight and not corroded.
Check all harness connections. Make sure they are secured properly.
Check the brakes.
Check battery charge.
If you discover a problem, contact your authorized Mega Motion Provider for assistance.
TIRE INFLATION
If your scooter is equipped with pneumatic tires, you should check or have the air pressure checked at least
once a week. Proper inflation pressures will prolong the life of your tires and help ensure the smooth
operation of your scooter.
WARNING! It is critically important that the psi/bar/kPa air pressure rating indicated on
each tire be maintained in pneumatic tires at all times. Do not underinflate or overinflate
your tires. Low pressure may result in loss of control, and overinflated tires may burst.
Failure to maintain the psi/bar/kPa air pressure rating indicated on pneumatic tires at all
times may result in tire and/or wheel failure.
WARNING! Inflate your scooter tires from a regulated air source with an available
pressure gauge. Inflating your tires from an unregulated air source could overinflate
them, resulting in a burst tire.
NOTE: If the tires on your scooter list the psi rating only, use the following conversion formulas to find
the bar or kPa rating: bar = psi x 0.06895, kPa = psi x 6.89476
WEIGHT LIMITATIONS
Your scooter is rated for a maximum weight capacity. Refer to the specifications table for information.
Keep in mind that the maximum weight capacity includes the combined weight of the user and any
accessories mounted to the scooter.
MANDATORY! Stay within the specified weight capacity for your scooter. Exceeding the
weight capacity voids your warranty. Mega Motion will not be held responsible for
injuries and/or property damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your scooter. Carrying passengers on your
scooter may affect the center of gravity, resulting in a tip or a fall.
INCLINE INFORMATION
More and more buildings have ramps with specified degrees of inclination, designed for easy and safe
access. Some ramps may have turning switchbacks (180-degree turns) that require you to have good cor-
nering skills on your scooter.
Proceed with extreme caution as you approach the downgrade of a ramp or other incline.
Take wide swings with your scooter around any tight corners. If you do that, the scooter’s rear wheels
will follow a wide arc, not cut the corner short, and not bump into or get hung up on any railing corners.
When driving down a ramp, keep the scooter’s speed adjustment set to the slowest speed setting to
ensure a safely controlled descent.
Avoid sudden stops and starts.
II. SAFETY

11Endeavor X www.mega-motion.com
When climbing an incline, try to keep your scooter moving. If you must stop, start up again slowly, and
then accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial to the
slowest setting and driving in the forward direction only. If your scooter starts to move down the incline
faster than you anticipated or desired, allow it to come to a complete stop by releasing the throttle control
lever. Then push the throttle control lever forward slightly to ensure a safely controlled descent.
WARNING! When on any sort of an incline or decline, never place the scooter in
freewheel mode especially while seated on it or standing next to it.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the
face of the incline. Drive your scooter straight up the incline. This greatly
reduces the possibility of a tip or a fall. Always exercise extreme caution when
negotiating an incline.
WARNING! Do not drive your scooter across the side of an incline or diagonally
up or down an incline; do not stop, if possible, while driving up or down an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e.,
areas covered with snow, ice, cut grass, or wet leaves).
WARNING! Even though your scooter is capable of climbing slopes greater than
those listed in Specifications Appendix, do not, under any circumstances, exceed
the incline guidelines or any other specifications. Doing so could cause instability
in your scooter.
Handicap public access ramps are not subject to government regulation in all countries, and therefore do
not necessarily share the same standard percent of slope. Other inclines may be natural or, if man-made,
not designed specifically for scooters.
Tests were conducted with the scooter’s seat in the highest position and adjusted rearward on the seat base
to its farthest rearward position. Use the specification table information as a guideline. See Section
“Appendix I - Specifications.” Your scooter’s ability to travel up inclines is affected by your weight, your
scooter’s speed, your angle of approach to the incline and your scooter setup.
WARNING! Any attempt to climb or descend a slope steeper than what is listed in the
Specifications Appendix may put your scooter in an unstable position and cause it to tip.
WARNING! Never carry an oxygen tank weighing more than 13 lbs. (6 kg). Never fill the
front or rear basket with contents exceeding 13 lbs. (6 kg).
II. SAFETY

12 www.mega-motion.com Endeavor X
II. SAFETY
CORNERING INFORMATION
Excessively high cornering speeds can create the possibility of tipping. Factors which affect the possibility
of tipping include, but are not limited to, cornering speed, steering angle (how sharply you are turning),
uneven road surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction
(such as passing from a grassy area to a paved area – especially at high speed while turning), and abrupt
directional changes. High cornering speeds are not recommended. If you feel that you may tip over in a
corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your scooter
from tipping.
WARNING! When cornering sharply, reduce your speed and maintain a stable center of
gravity. When using your scooter at higher speeds, do not corner sharply. This greatly
reduces the possibility of a tip or fall.
BRAKING INFORMATION
Your scooter is equipped with these powerful brake systems:
Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the
center/stop position.
Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or
when power is removed from the system for any reason.
When you approach an incline, it is best to lean forward. See figures 1 and 2. This shifts the center of
gravity of you and your scooter toward the front of the scooter for improved stability.
NOTE: When negotiating ramps, if the throttle control lever is released while moving forward, the
powered scooter may "roll back" approximately 3 feet (1 meter) before the brake engages. If the throttle
control lever is released while moving in reverse, the powered scooter may "roll back" approximately
3 feet (1 meter) before the brake engages.
Figure 2. Increased Stability Driving Position
Figure 1. Normal Driving Position

13Endeavor X www.mega-motion.com
II. SAFETY
OUTDOOR DRIVING SURFACES
Your scooter is designed to provide optimum stability under normal driving conditions—dry, level
surfaces composed of concrete or asphalt. However, Mega Motion recognizes that there will be times
when you will encounter other surface types. For this reason, your scooter is designed to perform
admirably on packed soil, grass, and gravel. Feel free to use your scooter safely on lawns and in park areas.
Avoid driving on uneven terrain and/or soft surfaces.
Avoid tall grass that can become tangled in the running gear.
Avoid loosely packed gravel and sand.
Do not use your scooter in fresh or salt water.
Do not use your scooter at the edge of a stream, lake, or ocean.
If you feel unsure about a driving surface, avoid that surface.
PUBLIC STREETS AND ROADWAYS
WARNING! You should not operate your scooter on public streets and roadways. Be
aware that it may be difficult for traffic to see you when you are seated on your scooter.
Obey all local pedestrian traffic rules. Wait until your path is clear of traffic, and then
proceed with extreme caution.
STATIONARY OBSTACLES (STEPS, CURBS, ETC.)
WARNING! Do not drive near raised surfaces, unprotected ledges, and/or drop-offs (curbs,
porches, stairs, etc.).
WARNING! Do not attempt to have your scooter climb or descend an obstacle that is
inordinately high.
WARNING! Do not attempt to have your scooter proceed backward down any step, curb,
or other obstacle. This may cause the scooter to tip.
WARNING! Be sure your scooter is traveling perpendicular to any curb you may be
required to ascend or descend. See figures 3 and 3A.
WARNING! Even though your scooter may be capable of handling greater obstacles,
Mega Motion recommends that you do not attempt to negotiate a curb that has a height
greater than 2 in. (5 cm). Doing so could cause instability in your scooter.
Figure 3. Correct Curb Approach Figure 3A. Incorrect Curb Approach
CURB
CURB

14 www.mega-motion.com Endeavor X
INCLEMENT WEATHER PRECAUTIONS
Exposure of your scooter to inclement weather conditions should be avoided whenever possible. If sud-
denly caught up in rain, snow, severe cold or heat while operating your scooter, proceed to shelter at the
earliest opportunity. Thoroughly dry your scooter before storing, charging, or operating your scooter.
PROHIBITED! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery
surfaces can cause damage to the scooter and electrical system. Maintain and store
your scooter in a dry and clean condition.
WARNING! Prolonged exposure to hot or cold conditions may affect the temperature of
upholstered and non-upholstered items on the scooter, possibly resulting in skin
irritation. Exercise caution when using your scooter in extremely hot or cold conditions
or when exposing your scooter to direct sunlight for prolonged periods of time.
FREEWHEEL MODE
Your scooter is equipped with a manual freewheel lever that, when engaged, allows the scooter to be
pushed. For more information about how to place your scooter into and out of freewheel mode, see III.
“Your Scooter.”
WARNING! When your scooter is in freewheel mode, the braking system is disengaged.
Disengage the drive motors only on a level surface.
Ensure the key is removed from the key switch.
Stand to the side of the scooter to engage or disengage freewheel mode. Never sit
on a scooter to do this.
After you have finished pushing your scooter, always return it to the drive mode to
lock the brakes.
An added feature built into the scooter is “push-too-fast” protection which safeguards the scooter against
gaining excessive speed while in freewheel mode.
“Push-too-fast” operates differently depending on which of two conditions exists:
If the key is switched “off” while in freewheel mode, the scooter’s controller activates regenerative
braking when the scooter is pushed faster than a maximum threshold which has been preprogrammed.
In this case, the controller is acting as a speed governor.
If the key is switched “on” while in freewheel mode, you will encounter considerable resistance at any
speed. This prevents the scooter from gaining unwanted momentum should the manual freewheel lever
inadvertently be released while driving the scooter.
WARNING! Mega Motion recommends that you do not disconnect the batteries when the
scooter is in freewheel mode as this may interfere with the function of the controller.
STAIRS AND ESCALATORS
Scooters are not designed to travel up or down stairs or escalators. Always use an elevator.
WARNING! Do not use your scooter to negotiate steps or escalators.
DOORS
Determine if the door opens toward or away from you.
Use your hand to turn the knob or push the handle or push-bar.
Drive your scooter gently and slowly forward to push the door open. Or drive your scooter gently and
slowly backwards to pull the door open.
II. SAFETY

15Endeavor X www.mega-motion.com
ELEVATORS
Modern elevators have a door edge safety mechanism that, when pushed, reopens the door(s).
If you are in the doorway of a elevator when the door(s) begin to close, push on the rubber door edge
or allow the rubber door edge to contact the scooter and the door will reopen.
Use care that pocketbooks, packages, or scooter accessories do not become caught in elevator doors.
NOTE: If your scooter’s turning radius is greater than 60 in. (152.4 cm), it may be difficult to maneuver
in elevators and building entrances. Use caution when attempting to turn or maneuver your scooter in
small spaces, and avoid areas that might pose a problem.
LIFT/ELEVATION PRODUCTS
If you will be transporting your scooter during travel, you may find it necessary to use a vehicle-mounted
lift system or elevation product to aid in transportation. Mega Motion recommends that you closely review
the warnings, instructions, specifications, and safety information set forth by the manufacturer of the lift/
elevation product before using that product.
WARNING! Not all lift systems/elevation products are rated for use with an occupied
mobility device. Mega Motion recommends that you do not remain seated in your scooter
when it is being used in connection with any type of lift system/elevation product unless:
That product is rated for occupied use by the manufacturer.
You are able to occupy your mobility device in strict conformity with the warnings,
instructions, specifications, and safety guidelines set forth by the manufacturer.
WARNING! Always turn off the power to the unit when you are being transferred via an
elevation product. Failure to do so may result in accidental throttle control lever contact,
resulting in unintended movement and personal injury or product damage.
BATTERIES
In addition to following the warnings below, be sure to comply with all other battery handling information.
MANDATORY! Battery posts, terminals, and related accessories contain lead
and lead compounds. Wear goggles and gloves when handling batteries and
wash hands after handling.
WARNING! Scooter batteries are heavy. See specifications table. If you are
unable to lift that much weight, be sure to get help. Use proper lifting techniques
and avoid lifting beyond your capacity.
WARNING! Always protect the batteries from freezing and never charge a frozen
battery. Charging a frozen battery may result in damage to the battery.
WARNING! Connect the battery harnesses in the proper manner. RED (+) cables
must be connected to positive (+) battery terminals/posts. BLACK (-) cables must
be connected to negative (-) battery terminals/posts. Protective caps should be
installed over all battery terminals. REPLACE cables immediately if damaged.
BATTERY DISPOSAL AND RECYCLING
If you encounter a damaged or cracked battery, immediately enclose it in a plastic bag and contact your
local waste disposal agency or authorized Mega Motion Provider for instructions on disposal and battery
recycling, which is our recommended course of action.
II. SAFETY

16 www.mega-motion.com Endeavor X
PREVENTING UNINTENDED MOVEMENT
WARNING! If you anticipate being seated in a stationary position for an extended period
of time, turn off the power. This will prevent unexpected motion from inadvertent throttle
control lever contact.
MOTOR VEHICLE TRANSPORT
Mega Motion recommends that you do not remain seated in your scooter while traveling in a motor
vehicle. The scooter should be stowed in the trunk of a car or in the back of a truck or van with batteries
removed and/or properly secured. In addition, all removable scooter parts, including the armrests, seat, and
shroud should be removed and/or properly secured during motor vehicle transport.
WARNING! Although your scooter may be equipped with a positioning belt, this belt is not
designed to provide proper restraint during motor vehicle transport. Anyone traveling in
a motor vehicle should be properly secured in the motor vehicle seat with safety belts
fastened securely.
WARNING! Do not sit on your scooter while it is in a moving vehicle.
WARNING! Always be sure your scooter and its batteries are properly secured when it is
being transported. Batteries should be secured in an upright position and protective caps
should be installed on the battery terminals. Batteries should not be transported with any
flammable or combustible items.
GETTING ONTO AND OFF OF YOUR SCOOTER
Getting onto and off of your scooter requires a good sense of balance. Please observe the following safety
tips when getting onto and off of your scooter:
Remove the key from the key switch.
Ensure that your scooter is not in freewheel mode. See III. “Your Scooter.”
Make certain that the seat is fixed into place.
Pivot the armrests up to make getting onto and off of the scooter easier.
WARNING! Position yourself as far back as possible in the scooter seat to prevent the
scooter from tipping.
WARNING! Avoid putting all of your weight on the scooter armrests and do not use the
armrests for weight bearing purposes, such as transfers. Such use may cause the
scooter to tip, resulting in a fall from the scooter.
WARNING! Avoid putting all of your weight on the floorboard. Such use may cause the
scooter to tip.
II. SAFETY

17Endeavor X www.mega-motion.com
REACHING AND BENDING
Avoid reaching or bending while driving your scooter. Bending forward creates the risk of accidental
throttle control lever contact. Bending to the side while seated creates the risk of tipping. It is important to
maintain a stable center of gravity and keep the scooter from tipping. Mega Motion recommends that the
scooter user determine his/her personal limitations and practice bending and reaching in the presence of a
qualified attendant.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the
scooter deck or from either side of the scooter. Movements such as these may change
your center of gravity and the weight distribution of the scooter and cause your scooter
to tip.
PROHIBITED! Keep your hands away from the tires when driving. Be aware that loose
fitting clothing can become caught in drive tires.
POSITIONING BELTS
Your authorized Mega Motion Provider, therapist(s), and other healthcare professionals are responsible
for determining your requirement for a positioning belt in order to operate your scooter safely.
WARNING! If you require a positioning belt to safely operate your scooter, make sure it
is fastened securely. Serious personal injury may result if you fall from the scooter.
PRESCRIPTION DRUGS/PHYSICAL LIMITATIONS
The scooter user must exercise care and common sense when operating his/her scooter. This includes
awareness of safety issues when taking prescribed or over-the-counter drugs or when the user has specific
physical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter
medication or if you have certain physical limitations. Some medications and limitations
may impair your ability to operate your scooter in a safe manner.
ALCOHOL/SMOKING
The scooter user must exercise care and common sense when operating his/her scooter. This includes
awareness of safety issues while under the influence of alcohol or while smoking.
WARNING! Do not operate your scooter while you are under the influence of alcohol, as
this may impair your ability to drive safely.
WARNING! Mega Motion strongly recommends that you do not smoke cigarettes while
seated in your scooter, although the scooter has passed the necessary testing
requirements for cigarette smoking. You must adhere to the following safety guidelines
if you decide to smoke cigarettes while seated in your scooter.
 Do not leave lit cigarettes unattended.
 Keep ashtrays a safe distance from the seat cushions.
 Always make sure cigarettes are completely extinguished before disposal.
II. SAFETY

18 www.mega-motion.com Endeavor X
FLAMMABILITY PRECAUTIONS
WARNING! Even though the plastics used on your scooter have been tested and have
passed the applicable flammability standards, Mega Motion recommends that you do not
expose your scooter to open flames.
WARNING! Replace worn or damaged upholstery immediately to reduce the risk of fire
hazard.
WARNING! Be aware that washing of upholstered items may reduce the resistance to
flammability of the fabric.
ELECTROMAGNETIC AND RADIO FREQUENCY INTERFERENCE (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency
waves can have an adverse effect on the performance of electrically-powered mobility
vehicles.
Electromagnetic and Radio Frequency Interference can come from sources such as cellular phones, mobile
two-way radios (such as walkie-talkies), radio stations, TV stations, amateur radio (HAM) transmitters,
wireless computer links, microwave signals, paging transmitters and medium-range mobile transceivers
used by emergency vehicles. In some cases, these waves can cause unintended movement or damage to
the control system. Every electrically-powered mobility vehicle has an immunity (or resistance) to EMI.
The higher the immunity level, the greater the protection against EMI. This product has been tested and
has passed at an immunity level of 20 V/M.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio
transmitters may cause unintended movement of your electrically-powered mobility
vehicle due to EMI. Exercise caution when using any of these items while operating your
mobility vehicle and avoid coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered
mobility vehicle can increase the susceptibility of the vehicle to EMI. Do not modify your
scooter in any way not authorized by Mega Motion.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance
of other electrical devices located nearby, such as alarm systems.
NOTE: If unintended motion or brake release occurs, turn your scooter off as soon as it is safe to do
so. Call Mega Motion at 1-800-MEGA-508 to report the incident.
II. SAFETY

19Endeavor X www.mega-motion.com
III. YOUR SCOOTER
TILLER CONSOLE
The tiller console houses all of the controls needed to drive your scooter, including the speed adjustment
dial, throttle control lever, battery condition meter, lights switch, hazard lights switch and horn buttons.
See figure 4.
PROHIBITED! Do not expose the tiller console to moisture. In the event that the tiller
console does become exposed to moisture, do not attempt to operate your scooter until
the tiller console has dried thoroughly.
Horn Buttons
These buttons activate a warning horn. Your scooter must be powered up for the horn to be operational.
Do not hesitate to use the warning horn when doing so may prevent accident or injury.
Key Switch
Insert the key into the key switch and turn it clockwise to power up (turn on) your scooter.
Turn the key counterclockwise to power down (turn off) your scooter.
WARNING! If the key is moved to the “off” position while your scooter is in motion, the
electronic brakes will engage and your scooter will come to an abrupt stop!
Battery Condition Meter
When the key is fully inserted and turned clockwise to power up your scooter, this meter indicates the
approximate battery voltage strength. For further information on battery charging, see IV. “Batteries and
Charging.”
Figure 4. Tiller Console
HORN BUTTON
SPEED ADJUSTMENT DIAL
THROTTLE
CONTROL
LEVER
HORN BUTTON
BATTERY CONDITION METER
LIGHTS SWITCH
KEY SWITCH
THROTTLE
CONTROL
LEVER

20 www.mega-motion.com Endeavor X
OFF-BOARD CHARGER PORT
III. YOUR SCOOTER
Lights Switch
This switch controls your scooter’s lights.
Toggle the switch forward to turn on your scooter’s front top light and running lights.
Toggle the switch rearward to turn on all the scooters lights (upper and lower front and running lights).
WARNING! Scooter users are required to use their lights when visibility is restricted—day
or night.
Throttle Control Lever
This lever allows you to control the forward speed and the reverse speed of your scooter up to the
maximum speed you preset with the speed adjustment dial.
To move forward, use your right thumb to push the right side of the throttle control lever.
To move rearward, use your left thumb to push the left side of the throttle control lever.
Release the throttle control lever and allow your scooter to come to a complete stop before engaging the
other side of the lever. When the throttle control lever is completely released, it automatically returns to
the center “stop” position and engages your scooter’s brakes.
Speed Adjustment Dial
This dial allows you to preselect and limit your scooter’s top speed.
The image of the tortoise represents the slowest speed setting.
The image of the hare represents the fastest speed setting.
Off-board Charger Port
The off-board charger power cord plugs into this port when charging the batteries. See figure 5.
Figure 5. Off-board Charger Port
