D-D The Aquarium Solution TITANIUM User manual

INSTRUCTION MANUAL
TITANIUM HEATER

OVERVIEWOVERVIEW
TECHNICAL DETAIL
1 2 3
4
5
6
1 Cap
2 Marking, minimum
immersion depth (s)
3 Heater/titanium tube
4 Holder
5 Cable
6 Power plug
Voltage 230 V/50 Hz
Power consumption 100 to 600W (depending on the version)
Cable Cable HO3VV-F 3G 0.75mm2
Cable length 1.5m
Heating element length 250mm (at 100 to 300W)
350mm (at 600W)
Heating element diameter 25mm
Protection class IP 68
Maximum water immersion depth 1.20m
Recommended power depending
on the volume of water at a room
temperature of 20°C
100W at 75 - 100L
200W at 150 - 200L
300W at 250 - 300L
600W at 300 - 600L
Fig. 1: Overview

THANK YOU
Thank you for purchasing our titanium heater. The titanium heater is designed to
warm water in aquariums and terrariums. It is unbreakable, resistant to sea water
and it is the ideal supplement to the D-D Temperature Controller TC125.
Symbols on the heating element
CE mark: CE mark: Confirmation of complete compliance with basic
safety requirements specified in the appropriate EC directives
Designed exclusively for use in areas as specified in DIN 30600
Satisfies the standards for electromagnetic compatibility
Symbols in this operating manual
Important instructions for your safety and prevention of damage to the heating
element are specially indicated. Strictly comply with these instructions:
WARNING: Warns of health hazards and indicates possible injury hazards.
ATTENTION: Warns of possible hazards for the heating element or other objects.
Operating manual
Read this operating manual completely through before using the titanium heater.
Keep this manual somewhere safe and accessible. If you make the heating
element available to a third party, provide this operating manual along with the
heating element. Failure to comply with the instructions in this manual can result
in personal injury and material damage. We assume no liability whatsoever for
personal injury and material damage due to failure to comply with the instructions
in this operating manual.

SAFETY INSTRUCTIONS
WARNING
The heating element is operated with electric power and generates high operating
temperatures that can cause burn injuries and material damage if there is contact
with the heating element.
• Prior to performing any work disconnect the heating element from the power
supply. To do this, unplug the power plug (Fig. 1/6) from the socket and allow the
heating element to cool before reaching into the aquarium, terrarium or basin.
• Allow the heating element to cool to ambient temperature and dry before you
touch it.
• Only grasp the heating element on the cap (Fig. 1/1).
• Do not leave the heating element unattended if children or persons who cannot
assess the hazards are in the vicinity.
• The heating element is not designed to be used by persons (including children)
with limited physical, sensory, or mental capacities, or lack of experience and/
or knowledge, unless such persons are supervised by a person responsible for
their safety, or have received instructions on how to operate the device from the
person responsible for their safety.
NOTE:
Use a temperature controller to prevent uncontrolled heating of the heating
element (e.g. the D-D Temperature Controller TC125).
PREPARING
Unpack the heater and ensure that the contents are complete and undamaged.
If you notice any transport damage contact the dealer from whom you purchased
the heating element straight away.

ATTACHING & CONNECTING
THE HEATING ELEMENT
It is possible to attach the heating element in any desired position below the
surface of the water, using the supplied holder (Fig. 1/4).
ATTENTION: The heating element is operated with electrical current. The
connections of the heating element are not designed for outdoor use.
• Only use the heating element in enclosed, dry areas.
• Protect the power plug (Fig. 1/6) from moisture.
• Only operate the heating element in conjunction with a ground fault circuit
interrupter with maximum 30 mA.
1. Ensure that the power of the heating element is appropriate for the volume of
water that will be heated (Page 2).
2. Slide the supplied holder (Fig. 1/4) onto the heating element.
ATTENTION: The heating element is fastened using suction cups that do
not adhere to uneven, dirty surfaces. Surfaces can be damaged if the heating
element falls.
• Select a suitable, smooth surface for fastening the heating element.
• Clean the surface so that it is clean and free of grease.
ATTENTION: The element can be damaged if it is not completely
surrounded by water.
• Pay attention to the minimum immersion depth (Fig. 1/2), when installing
vertically, this is the minimum point to which the heating element must be
immersed in the water.
• For horizontal installation ensure that the heating element is always immersed
in flowing liquid.
3. Press the heating element with the holders into the desired position on the
surface.
ATTENTION: The wrong voltage can damage the heating element.
• Only connect the heating element if the voltage of your socket is 230V
alternating current.
4. Plug the power plug of the heating element into the socket or into a suitable
temperature controller (e.g the D-D Temperature Controller TC125).

REMOVING THE HEATING
ELEMENT
1. Unplug the power plug of the heating element (Fig. 1/6) from the socket or from
the temperature controller.
2. Allow the heating element (fig. 1/3) to cool completely; ensure that it has cooled
before touching the heating element.
WARNING: Chemicals can be harmful and can cause injuries if there is skin
contact.
• Wear personal protective equipment when handling hazardous chemicals.
Comply with the instructions specified on the appropriate safety data sheets.
3. Remove the heating element by detaching the suction cups from the surface.
4. Place the heating element on a non-flammable, moisture-resistant substrate.
MAINTENANCE INSTRUCTIONS
n Regularly remove deposits on the heating element with a suitable brush so
there is no encrustation and damage on the heating element.
n If the cable is damaged (Fig. 1/5) replace the entire heating element. The power
cable cannot be replaced separately.
DISPOSAL
When the device has reached the end of its service life, dispose of
the heating element and all accessories as specified by applicable
environmental regulations. Electrical waste should not be disposed
of together with household waste.

WARRANTY
We provide a guarantee of 24 months from the date of purchase (proof of
purchase receipt required) for the purchased device. Within the guarantee
period we will correct defects of the device or accessories*) at no charge, that
are due to material or manufacturing faults, through repair or replacement at our
discretion. Warranty exchanges do not extend the guarantee period, nor do they
substantiate a claim for a new guarantee! The purchase receipt is verification of
the guarantee. Without this verification a no-charge replacement or no-charge
repair cannot be provided.
*Defects in consumable accessories or parts subject to wear, as well as cleaning,
maintenance or replacement of wear parts do not fall under the guarantee, and
thus are chargeable services!
SPARE PARTS & ACCESSORIES
Spare part/accessory Article no.
Holder (Fig. 1/4) 25 mm x 2 SSCH01
D-D Temperature Controller 1600 W, -40 to +99 °C TC125
