D Light D LIGHT 360 User manual

User Manual
Pleasereadtheoperatinginstructionscarefully,particularly
the safety precautions, before using the appliance.

7
6
8
1
25
4
31. Status Display
2. Flash Button
3. Power Socket
4. Rear Air Outlet
5. Outlet Fan
6. Power Connector
7. Power Cable 180cm
8. Power Supply 110~220v
ILLUSTRATED GUIDE
12
9
13
10
11
9. Energy Ignition
9. Energy Level Button +
9. Energy Level Button -
10. Contact Sensor
11. Flash Window
12. HR Lamp
13. SR Lamp (optional)
14. AC Lamp (optional)
14
ENGLISH ENGLISH

D LIGHT 360 USER MANUAL
Dear Light 360 Customer thank you for purchasing this product. We are certain
that you will appreciate the quality and reliability of this device, designed and
manufactured by putting customer satisfaction in the foreground.
Please read the operating instructions carefully, particularly
the safety precautions, before using the appliance. Keep this
manual along with the relative illustrative guide, for the entire
life span of the appliance, for consultation purposes. In case
the appliance is transferred to a third party, also consign the
entire documentation. Should certain parts of this booklet
be difcult to understand or should doubts arise, contact
the company before using the product, at the address indicated on the last
page.
Safety Warnings
Contraindications
Other Safety Precautions
Installation
Operating Modes
How to Prepare Treatments
Epilation Treatment Procedure
Photorejuvenation Treatment Procedure
Acne Treatment Procedure
Possible Side Effects
Treatment Areas
Patch Test
Maintenance
Problems and Solutions
Technical and Environmental Specications
Pag. 2-3
Pag. 4-5-6
Pag. 6-7
Pag. 8
Pag. 9
Pag. 10
Pag. 11
Pag. 12
Pag. 13
Pag. 14-15
Pag. 16
Pag. 17
Pag. 18
Pag. 19
Pag. 20
INDEX
1
SAFETY WARNINGS
This appliance is not intended for use by anyone under the age of 16; by persons
with reduced physical, sensory, mental capabilities, or by inexperienced persons.
Unless they have been given supervision or instruction concerning safe and
proper use of the device by a person responsible for their safety. Children should
not use, play with, maintain or clean the devise.
If you are using the appliance in bathroom premises, disconnect the plug from
the socket after use, proximity to water is also dangerous even the appliance is
switched off.
In order to ensure better protection, it is advisable to install the power circuit
feeding the bathroom a residual current device, the residual current should not
exceed 30 ma (Ideal 10 ma). Ask your installer for advice.
CAUTION! Do not use this appliance in the vicinity
of bathtubs, showers, sinks or other containers
containing water! Do not immerse the appliance in
the water!
After removing the appliance from the packaging, make sure that the product is complete
and in perfect condition. Check the integrity of the supply, the design and any presence of
transport damages. In case of doubt, contact the authorized service department.
Before connecting the appliance, ensure that the power supply voltage corresponds with the
rating quoted on the equipment identication nameplate. The nameplate is located on the
appliance’s power supply.
Do not expose the appliance to moisture or atmospheric agents (rain, sun).
Always disconnect appliance from the power supply when not in use and before cleaning or
servicing.
This appliance must be used only for the purpose for which it has been designed as a pulsed
light xture for home use. Any other use is considered improper and therefore dangerous.
This device is not suitable for use in the presence of ammable anesthetic mixture with air or
oxygen or nitrous oxide.
Do not use the appliance with wet hands, damp or bare feet.
2
ENGLISH ENGLISH

Do not pull the power cord or the appliance to unplug it from the power socket.
In case of appliance failure or malfunction, switch it off and do not tamper with it. For repairs,
please contact the D Light technical support center.
If the power cord is damaged, it must be replaced by an authorized technical service center,
in order to prevent any risk.
The appliance can be used only on human hair. Do not use it on animals.
Do not obstruct the ventilation holes.
Do not use appliance if it is cracked or broken..
Do not use the appliance if the light is damaged, or the surface treatment is cracked, chipped
or missing.
Never look directly at the light coming from the treatment area.
Never point the treatment surface by trying to emit a light impulse from an open space.
In case of side effects or complications, it is advisable to contact your doctor or dermatologist.
Protective eyewear is highly recommended when using the appliance.
3
CONTRAINDICATIONS
Important Safety Information
Read before use
This appliance is not intended to be used by anyone. Read and take into account the information
included on the following paragraph before use. For more information and personal advice you
can visit the website www.dlight-ipl.com
If you are unsure if the appliance is safe for you to use, please ask your doctor or dermatologist
DO NOT USE DEVICE IF ANY OF THE FOLLOWING CONDITIONS IS PRESENT AT THE TIME
OF TREATMENT:
Pregnant or breast-feeding
If you were exposed to strong sunlight or an articial tanning machine during the past 28 days.
If you have a tattoo or permanent makeup on the area to be treated.
If you have dark brown or black spots, such as large freckles, birth marks, or warts on the
area to be treated.
If you have eczema, psoriasis, lesions, open wounds or active infections, such as cold sore in
the area to be treated. Wait for the affected area to heal before using the appliance.
If you have a history of keloidial scar formation, a known sensitivity to light (photosensitivity)
or are taking medication that makes the skin more sensitive to light, including anti-
inammatory agents (such as aspirin, ibuprofen, paracetamol, acetaminophen), tetracyclines,
phenothiazines,thiazide, diuretics, sulphonylureas, sulfonamides, DTIC, uorouracil,
vinblastine, griseofulvin, Alpha-Hydroxi Acids (AHAs), Beta-Hydroxi Acid (BHA), Retin-A ®,
Accutane ® and/or topical retinoids.
If you have abnormal skin conditions, such as vitiligo or albinism.
If you have varicose veins in the treatment area.
If you are currently or have recently been treated with Alpha-Hydroxi acids (AHA), Beta-Hydroxi
acids (BHA), Retin-A ,topical retinoids or azelaic acidH.
If you have abnormal skin conditions, caused by diabetes, for example, or other systematic or
metabolic diseases
4
ENGLISH ENGLISH

If you have been treated with Accutane ® (isotretinoin) within the past 6 months..
If you have been taking on steroid regimen within the past 3 months.
If you have a history of herpes outbreaks in the area of treatment, unless you have consulted
your physician and received preventive treatment before using the appliance.
If you suffer from epilepsy.
If you have an active implant, such as a pacemaker, an incontinence device, insulin pump,
etc.
If you have a disease related to photosensitivity, such as porphyria, polymorphic light eruption,
solar urticaria, lupus, etc..
If you have a history of skin cancer or areas of potential skin malignancies.
If you have received radiation therapy or chemotherapy treatments within the past 3 months.
If you have any other condition which in your physician’s opinion would make it unsafe for you
to be treated. In case of doubt, consult with your physician.
The appliance removes unwanted hair by selectively addressing hair pigment. Varied quantities
of pigment (melanin) are also present in the surrounding tissue of. The quantity of pigment in a
particular person’s skin, which is manifested by their complexion, determines the degree of the
risk they are exposed to using any method of light-based epilation.
SKIN TONE
Before using the appliance, compare your complexion
with the skin tone chart shown on the product packaging
Do not use the appliance on a naturally dark
complexion!
Treating the dark skin with the appliance may cause sunburn, blisters and skin
color changes (hyper or Hypo-pigmentation).
5
TANNED SKIN
Tanned skin particularly following sun exposure, contains large amounts of melanin. This applies
to all skin types and all complexion, including those who do not seem to tan quickly. The presence
of large quantities of melanin exposes the skin to higher risk when using any method of light
based treatment.
Avoid exposure to sun and/or tanning lights for 4 weeks before using the appliance!
Never use the appliance around or near the eyes!
The appliance can be used for the treatment of facial area.
Extra caution should be taken during the treatment to avoid
eye area.
EYE CAUTION
Do not use the appliance on nipples or genital
organs (male or female) and on the lips.
NIPPLES GENITALS AND LIPS
OTHER SAFETY PRECAUTIONS
ENERGY LEVEL
Choose your energy levels CAREFULLY! Energy level refers to the light pulse that is projected on
the skin during use, from the lower level to the highest level. The notches on the status display (1)
indicate the energy level at which the machine is set. As the energy level increases, it improves
results as well as the risk of side effects (See “Possible Side Effects” below).
Always begin treatment using the lowest
energy level!
6
ENGLISH ENGLISH

Only if you experience little or no discomfort during and after use of the devise energy at the
lowest energy setting, you can increase the energy level, and so on for each subsequent session.
For detailed instructions on energy level setting, see “Energy Level”.
Always shave the area to be treated and make sure the skin is clean and dry before using the
appliance.
Cover tattoos, lips and nipples before applying the appliance.
Cover dark brown or black spots, such as large freckles, birth marks, moles or warts before
using the appliance.
Never use ammable liquids such as alcohol (including perfumes, sanitizers, or other
applications containing alcohol), or acetone to clean the skin before using the appliance.
Do not use the appliance on any body part where you might later want hair.
PATCH TEST
Before you begin the treatment, it is recommended that you perform a patch test to identify
your skin’s highest level of tolerance to the pulsed light. For instructions on how to perform a
patch test, see “Inspection before use” section.
DURING TREATMENT
If blisters are formed on the skin, or if the skin burns, IMMEDIATELY STOP USING THE
APPLIANCE.
Always make sure that the treatment surface points toward the skin, and is completely in
contact with it.
Remove the surface treatment (11) from the skin if it becomes excessively hot.
7
INSTALLATION
1) Assembling the Lights
A
B
CD
A
B
DC
8
Pay attention to the direction of insertion. There are 3 plastic pivot hinges (A C D) found
behind the light and an electronic card (B). During installation of the light, be careful to match
these elements with their corresponding housings on the machine’s attachment. Installation
and removal of the light does not require equipment and is hand-made when the Machine is
off and disconnected from the power socket, note
that the lights are dismantled by pulling outward on
one side as indicated in the drawing on the side, do
not remove the light by pulling horizontally because
it would risk damaging the plastic.
2) Insert the Power Connector (6) in the power socket (3)
ENGLISH ENGLISH
Not treat the same area of skin more than once per
session! Do not repeat the spots.

TYPES OF TREATMENT
Depending on the type of light mounted, the appliance automatically selects the correct functional
mode.
HR for Epilation Mode (Hair Removal)
SC for Photo Rejuvenation Mode (Skin Care)
RA for Acne Mode (Remove Acne)
1) HR MODE - EPILATION
Inserting the HR Light (yellow optical lter color), D Light 360 automatically activates the
Epilation mode and shows HR on the status display. In HR mode, you can choose between
5 power levels and whether to operate a single or sliding ash. The wavelength of
this light is between 510nm ~ 1200nm and specically hits hair follicles.
2) SC MODE - PHOTO REJUVENATION (SR)
Inserting the SR light (orange optical lter color),D light 360 automatically activates
photorejuvenation mode and shows SC on the status display. In SR mode, you can choose
between 5 power levels and whether to operate a single or sliding ash. The wavelength of
this light is 560nm, specically treats blemishes such as skin discoloration, small thin wrinkles,
grayish/off color and stimulates the production of new collagen that replenish the skin, improves
texture and overall tone.
3) RA MODE - ACNE (AC)
Inserting the AC light (Red optical lter color), D Light 360 is automatically activated in
Acne mode and shows RA on the status display. In AC mode, you can choose between 5 power
levels and whether to operate with single or sliding ash. The wavelength of this light is 430mm,
specically kills bacteria causing acne, also dried heat of the pulsed light accelerates healing.
9
3
2
1
Do not use the appliance on naturally dark
complexion or on tanned skin!
HOW TO PREPARE THE TREATMENTS
Before starting treatments, prepare the treatment area by thoroughly cleaning the skin and remove
makeup. Hair must be shaved with a razor or a hair clipper, it is preferable to use a clipper as you
immediately obtain an optimal length of 1mm, and maximizes the absorption of pulsed light (in
epilation treatment), using the clipper will also avoid any skin irritation.
Given that the pulsed light is absorbed by dark colors, it is necessary to protect small, dark
birthmarks and tattoos, cover it with white eyepencil makeup, or with a specic product like the D
Light Patch Pro.
Do not let the pulsed light pass on large or irregular areas! In
the presence of doubt, ask your dermatologist before initiating
treatments!
Do not use the pulsed light on varicose veins and any type of skin
lesions
It is always advisable to begin at the lowest energy level and gradually increase to nd the right
intensity according to your own tolerance. The energy level is selected by repeatedly pressing the
ignition button (9) after the machine has been started.
As the enegry level increases, so does the results, as well as the risk of possible side effects.
SELECT ENERGY LEVEL
10
ENGLISH ENGLISH
If blistering occurs on the skin, or if you feel burning,
IMMEDIATELY STOP using the device.

EPILATION TREATMENT
The D Light 360 epilation treatment is suitable for all body areas that have hair except the scalp,
male beard, eyebrows, genital and perianal areas.
Any birthmarks or tattoos on the area to be treated must be covered before starting the treatment,
to protect them, you can use an opaque white makeup pencil or a specic product like the D light
Patch Pro. Before starting the treatment, it is advisable to wear certied laser safety glasses or
pulsed light safety eyewear, as an alternative, you can close your eyes when the ash is emitted.
Dene the area to be treated (can also help by drawing a grid with a white makeup pencil) and
select the appropriate energy level of the skin type when you are ready.
It is always advisable to start at the lowest energy level and depending on your tolerance, if
you experience no discomfort, you can increase the energy level, treatment is more effective
at highest energy level, but the ash takes longer to load. You can choose between two modes
of operation: single ash or scroll. Using the single ash mode, a ash is emitted everytime the
Flash button (2) is pressed. The scroll mode is activated by holding the Flash button (2) down for
3 seconds, then you can release it and the device will emit ash repeatedly whenever the Flash
window will come into contact with the skin. To turn off scroll mode, just press the Flash button (2)
once and the appliance resumes to function on single ash mode.
When the Flash window is correctly in contact with the skin and the machine is ready for the
Flash, the display starts ashing. It is recommended to radiate 1, maximum 2 times on each
treated area then proceed and move to the next area.
11
EPILATION TREATMENT CYCLE
For the rst 3 months, it is advisable to proceed with 1 treatment per week or every 2 weeks if
you are also doing photorejuvenation or acne treatments on the same area, it is important to
spend at least one week between other treatments by alternating Epilation to the others. The skin
should be hairless after nishing the rst 3 month cycle, therefore there will only be maintenance
sessions needed when the hairs begin to reappear (usually a session every 2 or 3 months,
depends on the of individual growth rhythm).
PHOTO REJUVENATION TREATMENT
The typical areas of photorejuvenation treatment with D Light 360 are the face, the neckline and
back of the hands. With photorejuvenation treatment (SR) it is possible to attenuate the rst signs
of aging by stimulating the production of new collagen, which renews, rms and replenishes
the skin, it is also be possible to lighten discolorations, overall skin texture and brighten the
complexion in case of a grayish or washed tone.
Any birthmarks or tattoos on the area to be treated must be covered before starting the treatment,
to protect them, you can use an opaque white makeup pencil or a specic product like the D light
Patch Pro. Before starting the treatment, it is advisable to wear certied laser safety glasses or
pulsed light safety eyewear, as an alternative,you can close your eyes when the ash is emitted.
Dene the area to be treated (can also help by drawing a grid with a white makeup pencil) and
select the appropriate energy level of the skin type when you are ready.
You can choose between two modes of operation: single ash or scroll. Using the single ash
mode, a ash is emitted everytime the Flash button (2) is pressed. The scroll mode is activated
by holding the Flash button (2) down for 3 seconds, then you can release it and the device will
emit ash repeatedly whenever the Flash window will come into contact with the skin. To turn off
scroll mode, just press the Flash button (2) once and the appliance resumes to function on single
ash mode.
When the Flash window is correctly in contact with the skin and the machine is ready for the
Flash, the display starts ashing. It is recommended to radiate once, maximum 2 times on each
treated area then proceed move to the next area.
PHOTOREJUVENATION TREATMENT CYCLE
12
It is advisable to have 1 treatment per week until the results are achieved.
If you are taking epilation or acne treatments on the same area, it is important to spend at least
one week between photo rejuvenation treatment and other treatments. Once you have reached
the desired results you can suspend the weekly treatments and schedule maintenance treatments
according to individual needs.
ENGLISH ENGLISH

ACNE TREATMENT
13
The D Light 360 Acne treatment can be used in all areas of the body where blemishes are
present, pay particular attention and wear protective glasses when treating areas near the eyes.
The acne light works on a specic wavelength to kill bacteria that causes acne (Propionibacterium
acnes), also the heat dry pulsed light boils accelerandone the healing and narrowing the pores by
preventing the new problem to arise.
It is advisable to avoid treatment on birthmarks or tattoos, if these are present on the area to be
treated, you can use an opaque white makeup pencil or a specic product like the D light Patch
Pro to protect them. Before starting the treatment, it is also advisable to wear certied laser safety
glasses or pulsed light safety eyewear, as an alternative, you can close your eyes when the ash
is emitted. When ready, dene an area to be treated (can also help by drawing a grid with a white
makeup pencil) and select the appropriate energy level of the skin type.
You can choose between two modes of operation: Single ash or scroll.
To use the single ash mode, a ash is emitted every press of the Flash button (2). Holding the
ash button (2) down for 3 seconds activates the scroll mode.
When you release it, the device will emit a ash then the Flash window enters into contact with
the skin; To turn off scroll mode, just press the Flash button (2) once and the appliance resumes
to operate in single ash mode.
When the Flash window is in correct contact with the skin and the machine is ready for the Flash,
the display starts ashing. It is advisable to radiate once, maximum 2 times each, then proceed
and move to the next area.
CYCLE OF ACNE TREATMENTS
It is advisable to take 1 treatment per week until the desired results are achieved, if you are
also taking epilation or photorejuvenation treatments, it is important to spend at least one
week between treatment and other treatments by alternating acne treatment. Once you have
reached the desired results you can suspend weekly treatments and schedule maintenance
treatments according to individual needs.
AFTER TREATMENT
After treatment, do not expose the skin to the sun and/or tanning
lights. For the following two weeks after each treatment session, in
case of exposure to the sun, protect the treated skin with a minimum
of SPF30 cream.
POSSIBLE SIDE EFFECTS
When used in accordance with the instructions, side effects and complications associated with
the use of the appliance are rare. However, any cosmetic procedure, including those intended
for household use, involve some risk. Consequently, it is important to understand and accept the
risks and complications that may occur with designed pulsed light epilation systems for household
use.
NEGATIVE
OCCURENCE
PROBABILITY
OF OCCURENCE
NEGATIVE
EFFECT
PROBABILITY
OF EFFECT
Multiple pulses
accumulated
one over the other
or overlapped
on the same skin
area.
Minimum
Minimal Skin
Discomfort
Minimum
Skin Redness Minimum
Increased Skin
Sensitivity
Minimum
Wounds and Burns Rare
Scars Rare
Pigmentation
Disorder
Rare
Excessive swelling
and redness
Rare
Infection Negligible
Bruises Negligible
14
ENGLISH ENGLISH

Minimal Skin Discomfort
Despite the domestic pulsed light treatments are generally tolerated very well, most users try a
annoyance during use, generally described as a slight warm sensation or a pinch in the treated
skin areas. This sensation can be an alert during application or for a few minutes after application.
Any sensation beyond this minimal annoyance is not normal and it means that you need to
interrupt the use because your skin is not able to tolerate epilation treatment, or the energy level
is too high.
Skin Redness
Skin may be reddened immediately after using appliance or during the following 24 hours. Redness
generally disappears within 24 hours. Consult your physician if the redness does not disappear
within 2 or 3 days..
Increased Skin Sensitivity
The skin of the treated area becomes more sensitive and can be dry or scaly.
Skin wounds and burns
Burns or wounds may occur after application. They may take a few weeks to heal, and, in very
rare cases, may leave a visible permanent scar.
Scars
Although it is very rare, permanent scars may be formed. Generally when scars are formed, they
have a at lesion and white skin (hypertrophic). However, the scar may be very large and red
(hypertrophic) or large and extends beyond the margins of the wound itself (keloid). Subsequent
aesthetic treatments can be necessary to improve the appearance of the scar.
Pigmentation Changes
In some rare cases there is a risk of temporary pigmentation (greater pigment or
Brown bleaching) or IPO-pigmentation (whitening) in the surrounding skin area leeping. The risk
of skin pigmentation change is higher for people with dark skin complexion.
Redness and excessive swelling
In some rare cases the skin can become very red and swollen. This is more common in sensitive
areas of the body. Redness and swelling should decrease between 2 and 7 days later, it must be
cured with frequent applications of ice. You can gently wipe the area, but avoid exposing to the
sun.
Infection
Infection of the skin is very rare but it is a possible risk due to scalding or injury caused by the
device.
Bruises
Very seldom use of the device may cause blue-violet bruises that may last from 5 to 10 days.
15
NOTE:
Treating the same body part more frequently than recommended does not improve results. Due
to hormonal and physiological changes or other type, hair follicles, latents can become active.
Hair removal sessions or occasional maintenance treatment can therefore be necessary.
Individual reaction depends on hair type and biological factors that can affect the hair growth
cycle. Compared to the recommended epilation program, some people may react faster or
slower.
The appliance is not effective on very clear hair, on naturally white, gray, light blond and red hair
(see color scale on the packaging). If the hairs of your body are one of these colors, the device
will not be effective.
INSPECTION BEFORE USE
ENERGY LEVEL
he appliance can be set to 5 energy levels, from 1 (the
lowest) to 5 (the highest), represented by the 5 triangles
arranged like a fan on the status display (1). The energy
increases and decreases repeatedly pressing energy level
button (9) Increasing the power of treatment increases the
effectiveness of the CIA, but also possible side effects, it is
advisable to perform a patch test to identify the appropriate
energy level according to proper tolerance.
16
NUMEBER OF DISPOSABLE SPOTS
The meter reads the number of disposable spots available
to the light inserted. Spot counting is stored in an internal
chip in the light, then dismantling and reassembling the light,
the count is never lost, but reparts from the point where it
was left. Each light has its own count, when the light is 0, it
must be replaced.
ERROR MESSAGE
When the counter displays the message “error” instead of
the number of disposable spots, it means that the machine
cannot detect the light inserted. The problem may occur if
the light is not properly inserted, or if it is extracted while the
machine is running. If the light has been inserted correctly
and the message persists, it means that it is defective and
must be replaced.
f
f
f
ENGLISH ENGLISH
