Dacor DMW2420 Instruction Manual

DMW2420
Page # Sheet Title
2 Oven Parts
4 Control Panel / Door Parts
Technical Service |14425 Clark Avenue |City of Industry, CA 91745 |PH 800-353-2267 |FAX [phone]
Revised 04-04-2011

Technical Service |14425 Clark Avenue |City of Industry, CA 91745 |PH 800-353-2267 |FAX [phone]
DMW2420 - Oven Parts
2-3
4-7
6-10
1-5
4-6
4-8
4-11
7-6
7-2
1-2
4-9
6-4
6-3
7-4
1-11
4-10
7-2
7-2
1-12
1-9
7-3 7-6
7-6
1-8
7-8
7-8
4-2
7-4
1-10
7-1
4-4
1-1
4-12
6-5
4-5
1-13
7-5
7-7
7-5
7-9
7-9
7-7
4-3 1-7
1-7
1-6
1-7
7-5
6-9
6-6
7-5
1-6
1-4
1-3
7-4
6-12
7-1
4-1
2-1
2-2
2-2
2-2
2-2
7-5
7-5
7-5
4-13
4-14
4-15
4-16

Technical Service |14425 Clark Avenue |City of Industry, CA 91745 |PH 800-353-2267 |FAX [phone]
Ref # Part # Description
1-1 105418 High Voltage Assembly
1-2 105419 AH Sensor
1-3 105420 Oven Lamp
1-4 101937 Noise Filter
1-5 86805 Fan Motor
1-6 66179 Monitor Switch & Fuse Assembly
1-7 66236 Secondary Interlock Switch
1-8 86794 Magnetron Temperature Fuse
1-9 86795 Cavity Temperature Fuse
1-10 105421 Magnetron
1-11 66245 Turntable Motor
1-12 105422 Power Transformer
1-13 105423 Power Supply Cord
2-1 105424 Base Plate
2-2 105425 Foot
2-3 105426 Outer Case Cabinet
3-1 105427 CPU Unit
3-2 105428 Control Panel Frame Assy
3-3 66337B Open Button Assy
3-4 76170 Open Button Spring
3-5 86780 Screw, 3mm x 10mm
4-1 105429 H.V. Capacitor Band
4-2 105430 Chassis Support
4-3 105431 Latch Hook
4-4 86824 Switch Lever
4-5 105432 Magnetron Duct
4-6 105433 Fan Blade
4-7 105434 Fan Duct
4-8 N/A Oven Cavity (Not Replaceable)
4-9 105435 Waveguide Cover
4-10 105436 Turntable Motor Packing
4-11 105437 Sensor Duct
4-12 105438 Cushion
DMW2420 - Oven Parts

Technical Service |14425 Clark Avenue |City of Industry, CA 91745 |PH 800-353-2267 |FAX [phone]
DOOR PARTS
MISCELLANEOUS
CONTROL PANEL PARTS
5-5
Actual wire harness may be dierent from illustration.
6-8
6-2
5-1
5-3
5-2
5-4
6-11
3-4
3-2
3-3
3-5
3-1
5-6
3-5
DMW2420 - Control Panel / Door Parts

Technical Service |14425 Clark Avenue |City of Industry, CA 91745 |PH 800-353-2267 |FAX [phone]
DMW2420 - Control Panel / Door Parts
Ref # Part # Description
5-1 105439 Door Frame Assy
5-2 86785 Latch Head
5-3 86786 Latch Spring
5-4 105440 Door Panel
5-5 105441 Choke Cover
5-6 105442 Door Stopper
6-1 N/A Recipe Card
6-2 105443 Main Wire Harness
6-3 105444 Turntable Support
6-4 66344 Turntable Tray
6-5 N/A Monitor Caution Label
6-6 86845 DHHS/Screw Caution Label
6-7 N/A Operation Manual
6-8 86799 High Voltage Wire A
6-9 101273 DHHS/GRD/BIK Caution
6-10 N/A Health Canada Label
6-11 N/A User Caution Label
6-12 N/A Menu Label
7-1 105445 Special Screw
7-2 86820 Special Screw (Latch Hook)
7-3 86902 Screw, 4mm x12mm
7-4 86847 Screw
7-5 86905 Screw, 4mm x 12mm
7-6 101233 Screw, 3mm x 8mm
7-7 66866 Special Screw
7-8 86901 Screw, 4mm x 8mm
7-9 105446 Screw, 4mm x 12mm
