Dacor In-A-Drawer MMD24 Technical manual

PLANNING
GUIDE
www.Dacor.com
Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 12.6
30” Microwave In-A-Drawer
MMD30, MMDV30
4"
5"
Electrical outlet
location Anti-tip
block
(6")
ELECTRICAL UTILITY LOCATION
4"
5"
Electrical outlet
location Anti-tip
block
(6")
ANTI-TIP BLOCK LOCATION
NOTE: Open top cabinet illustrated
48" (1219mm)
3-prong
120 Vac power cord
A. 6"
B. Electrical outlet location
C. Anti-tip block
D. 5"
E. 3 1/2"
F. 4"
G. 28 1/2" opening
H. 14 3/4" to bottom of anti-tip block
I. Allow 3/4" minimum overlap
J. 23 1/2" minimum depth
K. Allow 1/4" minimum overlap
L. 36" nominal countertop height
M. Allow 7/16" minimum overlap
N. Floor must support 100 lbs. minimum
O. 19" to top of floor (recommended)
P. 30" cabinet minimum
Q. 15 3/16" ± 1/16" opening
A
B
C
DE
F
GH
I
I
J
K
L
M
N
O
P
Q
A
B
C
F
I
D
H
G
E
A. 28 5/16"
B. 4 11/16"
C. 2"
G. 15 1/16"
H. 1" door thickness
I. 15 1/4" auto drawer opening
D. 23 3/8"
E. 30"
F. 15 5/8"
OVERALL DIMENsIONs
™
CUTOUT DIMENsIONs
NOTE: Open top cabinet illustrated
48" (1219mm)
3-prong
120 Vac power cord
A. 6"
B. Electrical outlet location
C. Anti-tip block
D. 5"
E. 3 1/2"
F. 4"
G. 28 1/2" opening
H. 14 3/4" to bottom of anti-tip block
I. Allow 3/4" minimum overlap
J. 23 1/2" minimum depth
K. Allow 1/4" minimum overlap
L. 36" nominal countertop height
M. Allow 7/16" minimum overlap
N. Floor must support 100 lbs. minimum
O. 19" to top of floor (recommended)
P. 30" cabinet minimum
Q. 15 3/16" ± 1/16" opening
A
B
C
DE
F
GH
I
I
J
K
L
M
N
O
P
Q
A
B
C
F
I
D
H
G
E
A. 28 5/16"
B. 4 11/16"
C. 2"
G. 15 1/16"
H. 1" door thickness
I. 15 1/4" auto drawer opening
D. 23 3/8"
E. 30"
F. 15 5/8"
NOTES:
1. Spacing between appliances
and doors/drawers is minimum
required to allow for ventilation
and to prevent scraping.
Additional space may be required
for appearance.
Dedicated Circuit Required Total Connected Load
120 Vac, 60 Hz, 15 Amp. 3-wire
grounded, electrical outlet 13 Amp. @ 120 Vac, 60 Hz
ELECTRICAL sPECIfICATIONs
All tolerances: +1/16”, -0, (+1.6mm, -0) unless otherwise stated
Document # PG12-003 Revised 04/06/09 Page 1/1
WARNING
Observe all governing codes and ordinances◊
during planning and installation. Contact
your local building department for further
information.
This appliance must be installed in accordance◊
with the accompanying installation instructions.
