PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 11.2
42” & 48” Wide
Built-In Refrigerator
EF42BDCB, EF42BNDB, IF42BDCB, IF42BNDB,
EF48BDCB, EF48BNDB, IF48BDCB, IF48BNDB
112905 1/3
Model Rough-In Width “A”
42-Inch 41 1/2”” (1054mm)
48-Inch 47 1/2”” (1207mm)
Door swinG DimEnsions
The area to the left and the right of the appliance must permit
both doors to open to a minimum of 90°. Allow a minimum of 2
1/2” (64mm) space between the side of the refrigerator doors and
a corner wall.
NOTE: More clearance may be required if using an overlay panel
or custom handles.
proDuct DimEnsions
◊ The depth from the front of the top grill (w/o decorator panel)
to the back of the refrigerator chassis is 25 1/4” (641mm).
◊ The depth from the rear of the top grill to the back of the
refrigerator chassis is 23 13/16” (605mm).
◊ The power cord is 40” (1016mm) long.
◊ The height from the top of the top grill to floor with the
leveling legs in the down position is 83 3/8” (2118mm)
◊The height from the top of the top grill to floor with the
leveling legs in the fully extended position is 84 5/8”
(2149mm)
◊The chassis width from the chassis edge to the chassis edge
for 42-inch is model 41 1/4” (1048mm), 48-inch is model 47
1/4” (1200mm).
◊The overall width from the trim edge to the trim edge for 42-
inch model is 42 1/16” (1068mm), 48-inch model is 48 1/16”
(1221mm).
ElEctrical rEquirEmEnts
A 115VAC, 60 Hz, 15 Amp circuit breaker and electrical supply are
required. A separate dedicated non-GFCI circuit, servicing only
this appliance, is required.
Your Dacor®Built-In refrigerator is equipped with a 40” (1016mm)
3-prong grounded power cord, which must be plugged into a
3-prong grounding-type non-GFCI wall receptacle. Follow the
National Electrical Code and local codes and ordinances when
installing the receptacle. See “Rough-In Dimensions” for location
of the electrical supply.
IMPORTANT: A ground fault circuit interrupter (GFCI) is not
recommended and may cause interruption of operation.
◊All installations must meet local plumbing code
requirements.
◊Connect to 1/4” (6mm) copper line to the house cold fresh
water supply.
◊Use a shut off valve between the refrigerator and supply.
The shut off valve should be a drilled saddle valve.
◊Do not use a self-tapping valve which reduces water flow
and clogs more easily.
◊Route the water line within 3-1/2” (89mm) of the rear wall
and no higher than 3” (76mm) from the floor.
◊Allow a minimum of 24” (610mm) dimeter service loop of
copper tubing outside the wall or floor for easy connection to
the water supply.
Cold water supply
Connect the ice maker to a cold water line with water pressure
between 30 and 120 PSI. If you have any questions about your
water pressure, call your utility company.
IMPORTANT:
◊In homes with a Reverse Osmosis water treatment system,
remove the water inlet connector from the “yellow” valve
and attached to the “blue” valve. Make sure the water filter
bypass plug is in place.
watEr supply rEquirEmEnts
7”
4”
2”
6”
3”
75 1/2”
“A”
83 3/4”
Water Supply
Electrical
24”

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 11.3
42” & 48” Wide
Built-In Refrigerator
EF42BDCB, EF42BNDB, IF42BDCB, IF42BNDB,
EF48BDCB, EF48BNDB, IF48BDCB, IF48BNDB
112905 2/3
custom ovErlay panEls
The decorator panels for overlay models cover the door trim for an
attractive, seamless look that flows into the overall design of the
room. This application is often accomplished by using three panels:
the decorative front panel, a spacer panel of .10-inch thickness,
and a 1/4-inch backer panel. (see page 11.4)
H
(A)
Grille Panel H
W
(C)
Non-Dispenser
Freezer Panel
W
(D)
Refrigerator
Panel
W
H
W
H1
H2
W1
W2
(B)
Dispenser
Freezer
Panel

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 11.4
42” & 48” Wide
Built-In Refrigerator
EF42BDCB, EF42BNDB, IF42BDCB, IF42BNDB,
EF48BDCB, EF48BNDB, IF48BDCB, IF48BNDB
112905 3/3
Overlay Panel Specifications
(See Illustrations on page 11.3)
42-Inch Model 48-Inch Model
BACKER PANEL
(A) Grille Panel
WWidth 40 1/4” (1022mm) 46 1/4” (1175mm)
HHeight 8 3/4” (222mm) 8 3/4” (222mm)
(B) Freezer Dispenser Panel
WWidth 16 1/4” (413mm) 18 1/2” (470mm)
W1 Width 2” (51mm) 2” (51mm)
W2 Width 14 1/2” (368mm) 14 1/2” (368mm)
HHeight 69 1/8” (1756mm) 69 1/8” (1756mm)
H1 Height 34 1/16” (865mm) 34 1/16” (865mm)
H2 Height 48 1/8” (1222mm) 48 1/8” (1222mm)
(C) Freezer Non-Dispenser Panel
WWidth 16 1/4” (413mm) 18 1/2” (470mm)
HHeight 69 1/8” (1756mm) 69 1/8” (1756mm)
(D) Refrigerator Panel
WWidth 23 1/2” (597mm) 27 1/4” (692mm)
HHeight 69 1/8” (1756mm) 69 1/8” (1756mm)
SPACER PANEL
(A) Grille Panel
WWidth 39 1/4” (997mm) 45 1/4” (1149mm)
HHeight 7 3/4” (197mm) 7 3/4” (197mm)
(B) Freezer Dispenser Panel
WWidth 15 1/4” (387mm) 17 1/2” (445mm)
W1 Width 1 1/2” (38mm) 1 1/2” (38mm)
W2 Width 14” (356mm) 14” (356mm)
HHeight 68 1/8” (1730mm) 68 1/8” (1730mm)
H1 Height 34 1/16” (865mm) 34 1/16” (865mm)
H2 Height 48 1/8” (1222mm) 48 1/8” (1222mm)
(C) Freezer Non-Dispenser Panel
WWidth 15 1/4” (387mm) 17 1/2” (445mm)
HHeight 68 1/8” (1730mm) 68 1/8” (1730mm)
(D) Refrigerator Panel
WWidth 22 1/2” (572mm) 26 1/4” (667mm)
HHeight 68 1/8” (1730mm) 68 1/8” (1730mm)
Overlay Panel Specifications
(See Illustrations on page 11.3)
42-Inch Model 48-Inch Model
FRONT DECORATOR PANEL
(A) Grille Panel
WWidth 40 1/4” (1022mm) 46 1/4” (1175mm)
HHeight 8 3/4” (222mm) 8 3/4” (222mm)
(B) Freezer Dispenser Panel
WWidth 16 7/16” (418mm) 18 3/4” (476mm)
W1 Width 2 1/4” (572mm) 2 1/4” (572mm)
W2 Width 14 1/4” (362mm) 14 1/4” (362mm)
HHeight 69 1/4” (1759mm) 69 1/4” (1759mm)
H1 Height 34 5/16” (872mm) 34 5/16” (872mm)
H2 Height 47 13/16” (1214mm) 47 13/16” (1214mm)
(C) Freezer Non-Dispenser Panel
WWidth 16 7/16” (418mm) 18 3/4” (476mm)
HHeight 69 1/4” (1759mm) 69 1/4” (1759mm)
(D) Refrigerator Panel
WWidth 23 3/4” (603mm) 27 1/2” (699mm)
HHeight 69 1/4” (1759mm) 69 1/4” (1759mm)
Custom Handle Specifications
Before installing the custom panel assembly, the custom handle
hardware must be installed. It is recommended that handles with
larger D-style pulls be used. If the screws that are used have
thick heads, the screws will need to be countersunk into the panel
before it is put into place.
IMPORTANT: Dacor®advises not using single pull knobs on Built-
In Refrigerator.
20" (508mm)
