DAEWOO ELECTRONICS KOC-8HAFR User manual

Customer Helpline Number : 01189 252577
Spare Parts : 0844 557 0290 or www.4daewoo.co.uk / DAEWOO ELECTRONICS Web Site www.daewooelectronics.co.uk
COMBI MICROWAVE OVEN WITH
AIR-FRYER FUNCTION
USER MANUAL
HOW TO TURN ON THE OVEN AT FIRST
MODEL NO. KOC-8HAFR
money
money
money
money
money
DESUK_KOC-8HAF7R.indd 3 2014-01-02 오전 10:28:39

Customer Helpline Number : 01189 252577
Spare Parts : 0844 557 0290 or www.4daewoo.co.uk / DAEWOO ELECTRONICS Web Site www.daewooelectronics.co.uk
COMBI MICROWAVE OVEN WITH
AIR-FRYER FUNCTION
USER MANUAL
HOW TO TURN ON THE OVEN AT FIRST
DESUK_KOC-8HAF7R.indd 2 2014-01-02 오전 10:28:39

KOC-8HAFR_2
KOC-8HAFR_3
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not aempt to operate this oven with the door open since open-
door operaon can result in harmful exposure to microwave energy. It
is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or
allow soil or cleaner residue to accumulate on sealing surfaces.
(c) WARNING : If the door or door seals are damaged, the oven must not
be operated unl it has been repaired by a competent person : (1) door
(bent), (2) hinges and latches(broken or loosened), (3) door seals and
sealing surfaces.
(d) WARNING : It is hazardous for anyone other than a competent person
to carry out any service or repair operaon that involves the removal of
a cover which gives protecon against exposure to microwave energy.
(e) WARNING : Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
(f) WARNING : This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be
made by children unless they are aged from 8 years and above and
supervised.
(g) WARNING : When the appliance is operated in the combinaon mode,
children should only use the oven under adult supervision due to the
temperature generated. ( if provided )
DESUK_KOC-8HAF7R.indd 4 2014-01-02 오전 10:28:40

KOC-8HAFR_2
KOC-8HAFR_3
About Your Microwave
Introduction.................................................................................................................................. 04
Before first use ............................................................................................................................. 04
What is a function, STANDBY POWER “0”? ................................................................................ 05
FIRST SET UP................................................................................................................................. 05
Description ................................................................................................................................... 06
How to use the Home Fryer bowl ............................................................................................... 08
Operation
General ......................................................................................................................................... 10
Stand-By Power "0"...................................................................................................................... 10
Microwave Cooking ..................................................................................................................... 11
Grill Cooking ................................................................................................................................. 12
Convection Cooking(With Pre-Heat)........................................................................................... 13
Convection Cooking(Traditional Cooking)................................................................................... 14
Combination Cooking ( Microwave + Convection + Upper Grill ).............................................. 16
Deodorization............................................................................................................................... 17
Steam Cleaning (With Microwave Feature) ............................................................................... 17
Weight Defrost ............................................................................................................................. 18
Time Defrost................................................................................................................................. 18
Home Fryer................................................................................................................................... 19
Auto Cook..................................................................................................................................... 22
+30sec........................................................................................................................................... 23
Stop............................................................................................................................................... 23
ARCING ......................................................................................................................................... 23
Safety
Oven Utensils And Accessories Guide......................................................................................... 24
Safety information........................................................................................................................ 25
Electrical Connection ................................................................................................................... 27
Cleaning.....................................................................................................................28
Trouble Shooting.......................................................................................................29
Question And Answer ...............................................................................................30
Technical Data
Specifications................................................................................................................................ 31
Disposal of used electrical & electronic equipment..................................................31
Table of contents
DESUK_KOC-8HAF7R.indd 5 2014-01-02 오전 10:28:40

KOC-8HAFR_4
KOC-8HAFR_5
About Your Microwave
You have chosen a Daewoo Combi- Microwave Oven with Air-Fryer funcon.
Daewoo oers a variety of quality products that would make your life more comfortable.
This Combi-Microwave Oven combines the properes of a microwave with those of a tradional oven. The wide
range of programmig opons makes it possible to choose your preparaon method precisely.
The display provides informaon and helps you with seng.
Please read the user manual very carefully before starng to use the appliance.
Just for your informaon, the manual also serves as cooking recipy.
Enjoy cooking!
»INTRODUCTION
• Put the microwave on a solid, at surface.
• Ensure that there is adequate venlaon around the microwave. Keep 30 cm of space free at the top. At the back and sides,
keep at least 7.5 cm free.
• Do not cover the venlaon openings.
• The adjustable feet may not be removed.
• Do not place the microwave in the vicinity of heat sources.
• Broadcasng and transming equipment such as radios and TVs can aect the working of the microwave.
• Remove the accessories from the microwave and clean them with a mild cleaning agent. Then put the frame back on the sha.
»Before first use
7.5 cm
7.5 cm
30 cm
7.5 cm
When you heat the microwave to a high temperature for the rst me, you will noce a ‘new-oven smell’.
Don’t worry, this is normal. If desired, switch on the cooker hood or open a window.
The minimum height of free space necessay above the top surface of the
oven is minimum 170mm.
NOTE
Please note
: Always use the microwave with the frame on the shaft together with a turntable!
Put a heat-resistant dish with 200 ml of water in the microwave. Turn the function dial and select ‘oven’. Set the time to 5 minutes and press
the Start button. This will remove any protective grease used during manufacture. When the 5 minutes are nished, allow the microwave to
cool down, and clean the microwave with warm water. The microwave is now ready for use.
DESUK_KOC-8HAF7R.indd 6 2014-01-02 오전 10:28:40

KOC-8HAFR_4
KOC-8HAFR_5
»What is a function, STANDBY POWER “0”?
• Standby power is the electric power consumed by electronic appliances without operang on inserng the plug into a socket.
• STANDBY POWER “0” is a funcon reducing standby power consumpon.
• This product can save energy in a standby mode, by seng the STANDBY POWER "O" mode.
To turn on the oven, press and hold ECO buon unl display is turned on and beep sounds aer plugging in.
The oven goes to STANDBY POWER “0” mode automatically after 10minutes without using or press and hold STOP/CLEAR
buon unl display is turned o.
Press and hold ECO (ZERO-ON) buon again unl display is turned on and beep sounds, you can use the oven.
• If you insert plug into a socket, the oven is STANDBY POWER “0” mode. So the display shows nothing. To cancel STANDBY
POWER “0” mode, press and hold ECO (ZERO-ON) buon unl display is turned on and beep sounds. (Because the oven
is turned power o automacally aer 10 minutes without using. The display shows nothing.)
»FIRST SET UP
1. Connect the plug into the socket.
4. Ten minutes aer cooking is nished the oven will
automacally go into Zero Standby and use no power.
2. Zero Standby mode is selected automacally.
(The display will be turned o.)
5. To use oven again repeat step 3.
3. • Press and hold ECO buon unl LED display is turned on
and a beep sounds.
• The oven is now ready for use.
6. Save energy and money without the hassle of unplugging
the appliance..
money
money
money
money
money
DESUK_KOC-8HAF7R.indd 7 2014-01-02 오전 10:28:40

KOC-8HAFR_6
KOC-8HAFR_7
»Descripon
① Display
②Control panel
③ Door handle
①
②
③
④ Frame for turntable (only remove for cleaning)
⑤ Sha ④
⑤
⑧ Metal rack, low: use this rack together with a
turntable
⑨
Home Fryer Bowl : Center the kit on the metal
tray when using the Home fryer cooking.
⑥Glass turntable
⑦Metal turntable
⑦
⑥
⑧
⑨
About Your Microwave
DESUK_KOC-8HAF7R.indd 8 2014-01-02 오전 10:28:41

KOC-8HAFR_6
KOC-8HAFR_7
↘HOW TO USE THE ACCESSORIES OF COOKING
Glass Turntable MetalTray Metal rack Home Fryer bowl
• Microwave cooking • Convection cooking
• Combination cooking
• Auto cooking menu 5
• Grill cooking
• Auto cooking menu 1,2,3,4
• Convection cooking
(cake,pizza.pie)
• Home fryer cooking.
NOTE
Metal Tray must not be used in microwave cooking.
DESUK_KOC-8HAF7R.indd 9 2014-01-02 오전 10:28:41

KOC-8HAFR_8
KOC-8HAFR_9
»How to use the Home Fryer bowl.
↘ Composion of Home Fryer bowl.
↘ How to use the Home Fryer bowl.
• Please put the Fryer fan on the Fryer
support solidly.
• Please put the foods on the Fryer fan
evenly.
• Please use the Home Fryer bowl after
putting on the Metal tray.
• Cauons while using the Home Fryer bowl.
①
Please always use the Home Fryer bowl aer pung on the Metal tray.
- Never use this bowl with other dish and other tray. Home Fryer and Home Fryer bowl can be damaged.
② Please put the Fryer fan on the Fryer support solidly.
③ Please put the foods on the Fryer fan evenly.
④ Please use the kitchen gloves while taking out the Home Fryer bowl because it is very hot.
⑤ Please be careful when you taking out the Home Fryer bowl aer cooking is done.
CAUTION: : Please be clean the Home Fryer bowl. Spark can occur if there is foreign substances on it. Home Fryer bowl can be
used only for "Home Fryer". When it is used for a gas range or other products, it may cause a malfunction or re.
CAUTION: : Please wash up the Home Fryer bowl immediately after cooking. Please use a neutral detergent and soft sponge.
CAUTION: : Please ensure cavity is kept clean and free of food deposits. If left they can carbonize and damage the cavity.
Fryer fan
Fryer support
Metal Tray
Glass Turntable
Roller Guide
CAUTION: : • Please use the kitchen gloves while taking
out the Home Fryer bowl because it is very
hot.
About Your Microwave
DESUK_KOC-8HAF7R.indd 10 2014-01-02 오전 10:28:41

KOC-8HAFR_8
KOC-8HAFR_9
↘ DISPLAY WINDOW
Cooking me, power level and indicators are displayed.
: When blinking, the oven is operang in MICROWAVE COOK.
: When blinking, the oven is operang in GRILL.
: When blinking, the oven is operang in COMBI.
: When blinking, the oven is operang in CONVECTION.
: When blinking, the oven is operang in AUTO DEFROST.
: When blinking, the oven is operang AUTO COOK and HOME
FRYER COOK.
: When blinking, the oven is operang DEODORIZATION.
: When blinking, the oven is operatng STEAM CLEANING.
: When blinking, the oven is operang in weight input mode.
↘ BUTTONS
① Home fryer : Used to select Home fryer.
②Auto cook : Used to select Auto cook
③Dial knob : Used to set me, weight and quanty.
④M/W : Used to set power level of microwave.
⑤Combi : Used to select combi.
⑥Convecon : Used to select convecon and selected
temperature.
⑦ Grill : Used to select grill.
⑧Defrost : Used to defrost foods for weight or me.
⑨Deodor. / Steam cleaning : Used to deodorize oven or to clean
oven.
⑩START/+30sec : Used to start a programmed, also for speedy
start(each press adds 30 seconds microwave
cooking me).
⑪STOP/Clear : Used to stop the oven operaon or to delete the
cooking data.
①
④
⑥
⑧
③
⑩
⑤
⑨
⑪
⑦
②
DESUK_KOC-8HAF7R.indd 11 2014-01-02 오전 10:28:42
