Daewoo RN-331DPS Installation instructions

8VHU,QVWUXFWLRQ
&RPEL)ULGJH)UHH]HU
1R)URVW
Content
1. Safety Information Page 1~5
2. Overview Page 6
3. Installation Page 7~13
4.User interface Page 14~16
5. Daily Use Page 17~19
Моdel: RN-331DPS
RN-331NPT
RN-331DPW














 

!
"

"

#


$%



$%





#
&
'


'
1

' 

$)*++%


'


&
&

,-



&
.
&
.
&.
&&
'$
%

,$
%
/

1
21
(%
2
(%
'
(%

2

'
'
(%
!&!
&!!
(%
 

, 
)
'!!!
 
(%


(%


(%!
0%&

3

'4
'45
(%

) 

0%


7
8/
,/

8
'


9
"
'!
-
-!
, 
3


,/
/
!"


'.
'.
8$%.
$%.
'$%/.
'$%.
' .






5'
)



,/


;
$&
%

8

4


!

<

,
 


'

7
'

('
0"



/3

/




5

2YHUYLHZ
Note: Above picture is for reference only. Real appliance probably is different.
FridgeShelves Fridge
Balconies
Crisper
Crisper Cover
Fresh convertible box
Freezer Drawers
Leveling Feet
6

,QVWDOODWLRQ
SpaceRequirement
ySelect a location without direct exposure to sunlight;
ySelect a location with enough space for the refrigerator doors to open
easily;
ySelect a location with level (or nearly level) flooring;
yAllow sufficient space to install the refrigerator on a flat surface;
yAllow clearance to the right, left, back and top when installing. This
will help reduce power consumption and keep your energy bills lower.
yKeep at lest 50mm gap at two sides and back.
Positioning
Install this appliance at a location where the ambient temperature corresponds to the climate class
indicated on the rating plate of the appliance:
Climate class Ambient temperature
SN
N
ST
T
+10 C to +32
oo
C
+16 C to +32
oo
C
+16 C to +38
oo
C
+16 C to +43
oo
C
Location
The appliance should be installed well away from sources of heat such as radiators, boilers, direct sunlight
etc. Ensure that air can circulate freely around the back of the cabinet. To ensure best performance, if the
appliance is positioned below an overhanging wall unit, the minimum distance between the top of the cabi-
net and the wall unit must be at least 100 mm. Ideally, however, the appliance should not be positioned
below overhanging wall units. Accurate leveling is ensured by one or more adjustable feet at the base of
the cabinet.
Warning! It must be possible to disconnect the appliance from the mains power supply; the plug must
therefore be easily accessible after installation.
Electrical connection
Before plugging in, ensure that the voltage and frequency shown on the rating plate correspond to your
domestic power supply. The appliance must be earthed. The power supply cable plug is provided with a
contact for this purpose. If the domestic power supply socket is not earthed, connect the appliance to a
separate earth in compliance with current regulations, consulting a qualified electrician.
The manufacturer declines all responsibility if the above safety precautions are not observed.
This appliance complies with the E.E.C. Directives.
7

,QVWDOODWLRQ
-$D&*.
Door Reversibility
'&)!8!%!,&)%!8
%!8!),!!)&
Left Aid-Closer on Upper Door x 1 Left Aid-Closer on Lower Door x 1
nscrew top hinge cover and disconnect connectors of door switch and harness.
2.Unscrew top hinge
3.Remove the pin with a screwdriver and filp the hinge bracket. Then refit the pin to hinge bracket
VOscrew
screw
8

,QVWDOODWLRQ
5.Detach cover in top of upper door and move harness from right side to left side, then replace the cover.
6.Move top left cover to right side
7.Take off the upper door, take out the screw from the middle hinge by cross screwdriver,
then take off the lower door.
4.Move door switch from right hinge cover to left hinge cover in accessary bag.
9

,QVWDOODWLRQ
8 .
9. Unscrew bottom hinge. Then remove the adjustable feet from both side.
10. Unscrew and remove the bottom hinge pin, turn the bracket over and replace it.
unscrew screw
10

,QVWDOODWLRQ
13.Detach the Fridge and the Freezer door gaskets and then attach them after rotating.
11.Refit the bracket fitting the bottom hinge pin. Replace both adjustable feet.
12.Remove aid-closers from bottom of upper and lower doors, then take new aid-closers from
accessary bag and install them to left side.
11

,QVWDOODWLRQ
15.Replace upper door, please ensure the door align with the cabinet to make sure door gasket seal
the cabinet tightly. Then connect door with cabinet by tightly fixed top hinge.
16.Connect harnesses from door and cabinet. Then replace top hinge cover. Before screw the cover,
connect terminals of door switch.
14. Install the lower door, adjust and fix the middle hinge onto the cabinet.
12

y
y
,QVWDOODWLRQ
,QVWDOOGRRUH[WHUQDOKDQGOH(if external handle is present)
1007NN
1071NN
6SDFH5HTXLUHPHQW
Keep enough space of door open.
Keep at least 50mm gap at two sides.
To do this adjust the two levelling feet at front of the unit.
If the unit is not level, the doors and magnetic seal
alignments will not be covered properly.
/HYHOOLQJWKHXQLW
13

8VHULQWHUIDFH
Using the Control Panel
A.Temperature Control of Fridge Compartment
B.Temperature Control of Freezer Compartment
C.Mode/ Locking / Unlocking
1.1 BUTTON OPERATION
2.1.1The panel will be lit up for 2 minutes once the door of fridge compartment is opened.
2.1 DISPLAY
1.Temperature of Fridge Comparment
2.Temperature of Freezer Comparment
3.ECO Mode
4.Holiday Mode
5.Super Mode
6.Locking / Unlocking
1.2 LED DISPLAY
a.The control panel is 100% lit up for 3 seconds, which operates exactly as per the setting
(mode and temperature) before the poweroff. The system will be automatically locked 25
seconds after the last button operation. After locking, the light of the panel would be out 30
seconds after the last button operation.
b.Both preset temperatures of fridge compartemnt and freezer compartment would be shown
on the display.
2.0 OPERATING CONDITION
1
2
A
B
C
34
56
14

8VHULQWHUIDFH




2.1.2 The panel will be lit up by any button operation whereas the light would be out 2 minutes
after the last operation.
2.1.3 Display during normal operation
Temperature Display of the Fridge Compartment: Indicating the temperature of the
current setting.
Temperature Display of the Freezer Compartment: Indicating the temperature of the
current setting.
3.0 ILLUSTION OF THE BUTTON
3.1 Temperature Control of the Fridge Compartment
Temperature Control of the Fridge Compartment:
This button is workable both in User Defined Mode as well as Super Mode. After entering
the temperature control of the fridge compartment, this button flashes.
By touching the key consecutively, the temperature would change in a circle of “2°C, 3°C,
4°C, 5°C, 6°C, 7°C, 8°C, after which 5-second flashing means the selection of temperature
is settled.
3.2 Temperature Control of the Freezer Compartment
This button is workable both in User Defined Mode as well as Holiday Mode. After entering the
temperature control of the freezer compartment, the button flashes.
By touching the button consecutively, the temperature would change in a circle from -14°C to -22°C,
after which a 5-second flashing means the selection of temperature is settled.
3.3 Mode
By touching this button consecutively, the operation mode of the refrigerator will change in a
circle of “ECO Mode-Holiday Mode-Super Mode-User Defined Mode. A 5-second flashing means the
selection of temperature is settled.
3.4 Press Button
Short beep after per press button
All buttons will only valid under unlock mode.
3.5 Lock / Unlock
Press MODE button and hold for 3 seconds to lock other two buttons,
then the LOCK icon will be at lock situation after a beep.
To unlock, press MODE button and hold for 3 seconds, then LOCK icon
will be at unlock situation after a beep. In unlock situation, all buttons are
workable.
If no any operation in 25 seconds, the display will be locked
automatically. Keep press “MODE” button to unlock the display.
15

8VHULQWHUIDFH
4.1 Holiday Mode
4.2 Super mode
4.0 ECO mode
Press MODE bottom to choose ECO mode. After 5 seconds of flash, ECO icon will keep bright
and ECO mode is confirmed.
In ECO mode, the refrigerator will automatically set temperature of fridge compartment at 5°C,
as temperature of freezer compartment at -18°C. Except MODE button, other buttons will not
response any press.
Press MODE button to exit ECO mode.
Press MODE button to choose Holiday mode. After 5 seconds of flash, Holiday mode icon will keep
bright and Holiday mode is confirmed.
In Holiday mode, temperature of fridge will be set at 17°C. “FRIDGE” button will not response any
press.
Press “MODE” button to exit Holiday mode.
Press MODE button to select Super mode. And it will be confirmed after 5 seconds of flash of
Super icon.
In Super mode, “FREEZER” button will not response any press.
To exit Super mode,
- Adjust mode by MODE button,
- Or after 50 hours of Super mode, the refrigerator will automatically stop it and enter to
previous setting.
Helpful hint:
If you plan to freeze a large number food in one time, please set Super mode 24 hours ahead.
Warning:
In Super mode, the refrigerator will work hard. So the noise of refrigerator will be slightly
higher than normal running.
16
5.0 Door Open Alarm
if fridge (upper) door keeps open for 90 seconds, periodical alarm will be arisen until the door is
closed.

'DLO\8VH'DLO\8VH
First use
Cleaning the interior
Before using the appliance for the first time, wash the interior and all internal accessories with lukewarm
water and some neutral soap so as to remove the typical smell of a brand new product, then dry thoroughly.
Important! Do not use detergents or abrasive powders, as these will damage the finish.
Daily use
Freezing fresh food
yThe freezer compartment is suitable for freezing fresh food and storing frozen and deep-frozen food for
a long time.
yPlace the fresh food to be frozen in the bottom compartment.
yThe maximum amount of food that can be frozen in 24 hours is specified on the rating plate.
yThe freezing process lasts 24 hours: during this period do not add other food to be frozen.
Storing frozen food
When first starting-up or after a period out of use. Before putting the product in the compartment let the
appliance run at least 2 hours on the higher settings.
Important! In the event of accidental defrosting, for example the power has been off for longer than the
value shown in the technical characteristics chart under “rising time”, the defrosted food must be
consumed quickly or cooked immediately and then re-frozen (after cooked).
Thawing
Deep-frozen or frozen food, prior to be used, can be thawed in the freezer compartment or at room
temperature, depending on the time available for this operation.
Small pieces may even be cooked still frozen, directly from the freezer. In this case, cooking will take
longer.
Helpful hints and tips
Hints for freezing
To help you make the most of the freezing process, here are some important hints:
ythe maximum quantity of food which can be frozen in 24 hrs. is shown on the rating plate;
ythe freezing process takes 24 hours. No further food to be frozen should be added during this period;
yonly freeze top quality, fresh and thoroughly cleaned, foodstuffs;
yprepare food in small portions to enable it to be rapidly and completely frozen and to make it possible
subsequently to thaw only the quantity required;
ywrap up the food in aluminium foil or polythene and make sure that the packages are airtight;
ydo not allow fresh, unfrozen food to touch food which is already frozen, thus avoiding a rise in
temperature of the latter;
ylean foods store better and longer than fatty ones; salt reduces the storage life of food;
ywater ices, if consumed immediately after removal from the freezer compartment, can possibly cause
the skin to be freeze burnt;
yit is advisable to show the freezing in date on each individual pack to enable you removal from the
freezer compartment, can possibly cause the skin to be freeze burnt;
yit is advisable to show the freezing in date on each individual pack to enable you to keep tab of the
storage time.
Hints for storage of frozen food
To obtain the best performance from this appliance, you should:
make sure that the commercially frozen foodstuffs were adequately stored by the retailer;
be sure that frozen foodstuffs are transferred from the food store to the freezer in the shortest possible
time;
not open the door frequently or leave it open longer than absolutely necessary.
Once defrosted, food deteriorates rapidly and cannot be refrozen.
Do not exceed the storage period indicated by the food manufacture.
Hints for fresh food refrigeration
To obtain the best performance:
yDo not store warm food or evaporating liquids in the refrigerator
yDo cover or wrap the food, particularly if it has a strong flavour
17

'DLO\8VH'DLO\8VH
Cleaning
For hygienic reasons the appliance interior, including interior accessories, should be cleaned regularly.
Caution! The appliance may not be connected to the mains during cleaning. Danger of electrical
shock! Before cleaning switch the appliance off and remove the plug from the mains, or switch off or
turn out the circuit breaker or fuse. Never clean the appliance with a steam cleaner. Moisture could
accumulate in electrical components, danger of electrical shock! Hot vapors can lead to the damage
of plastic parts. The appliance must be dry before it is placed back into service.
Important! Ethereal oils and organic solvents can attack plastic parts, e.g. lemon juice or the juice form
orange peel, butyric acid, cleanser that contain acetic acid.
yDo not allow such substances to come into contact the appliance parts.
yDo not use any abrasive cleaners
yRemove the food from the freezer. Store them in a cool place, well covered.
ySwitch the appliance off and remove the plug from the mains, or switch off or turn out the circuit breaker
of fuse.
yClean the appliance and the interior accessories with a cloth and lukewarm water. After cleaning wipe
with fresh water and rub dry.
yAfter everything is dry place appliance back into service.
Hints for refrigeration
Useful hints:
yMake (all types): wrap in polythene bags and place on the glass shelves above the vegetable drawer.
yFor safety, store in this way only one or two days at the most.
yCooked foods, cold dishes, etc...: these should be covered and may be placed on any shelf.
yFruit and vegetables: these should be thoroughly cleaned and placed in the special drawer(s) provided.
ybutter and cheese: these should be placed in special airtight containers or wrapped in aluminum foil or
polythene bags to exclude as much air as possible.
yMilk bottle: these should have a cap and should be stored in the balconies on the door.
yBananas, potatoes, onions and garlic, if not packed, must not be kept in the fridge.
Fresh Zone Temperature Control
y
7HPSHUDW UHRIWKHIUHVKFDQEHDGM VWHGDFFRUGLQJWRWKHW\SHRIVWRUDJHIRRG
y3 VKWKHNQRE SZDUGIURPWKHERWWRPWHPSHUDW UHLQWKHIUHVK]RQHZLOOEHJUDG DOO\GHFUHDVHG
y:KHQWKHNQRELVSODFHGDWWKH&5,63(5SRVLWLRQWKHIUHVK]RQHFDQEHI QFWLRQHGDVD
FULVSHU]RQHDQGPDLQWDLQWKHDSSURSULDWHWHPSHUDW UHDQGK PLGLW\IRUIU LWVDQGYHJHWDEOH
y:KHQWKHNQRELVSODFHGDWWKH&+,//(5SRVLWLRQLWLVV LWDEOHIRUVKRUWWHUPVWRUDJHRIILVKRURWKHU
IUHVKIRRG7KHIRRGZLOONHHSIUHVKE WQRWIUR]HQZKLFKPDNHVLWWKHEHVWFKRLFHIRUVWRULQJIUHVKIRRG
y7LSV:KHQ\R FKRRVH&+,//(5I QFWLRQLWLVUHFRPPHQGHGWRVHWWKHUHIULJHUDWRUWHPSHUDW UH
EHORZ&DQGSUHVHUYHGOHDGWLPHQRPRUHWKDQGD\VLQRUGHUWRNHHSWKHEHVWIUHVKQHVV
18

'DLO\8VH'DLO\8VH

*
,A
Troubleshooting
Caution! Before troubleshooting, disconnect the power supply. Only a qualified electrician of
competent person must do the troubleshooting that is not in this manual.
Important! There are some sounds during normal use (compressor, refrigerant circulation).
Appliance dose not
work
Mains plug is not plugged in
or is loose
Check fuse, replace if necessary.
Socket is defective
Mains malfunctions are to be
corrected by an electrician.
Problem Solution
Fuse has blown or is defective
Insert mains plug.
Appliance freezes or
cools too much
Turn the temperature regulator to a
warmer setting temporarily.
Unusual noises
Appliance is not level.
The appliance is touching the
wall or other objects.
Re-adjust the feet.
Move the appliance slightly.
A component, e.g. a pipe, on
the rear of the appliance is
touching another part of the
appliance or the wall.
If necessary, carefully bend the
component out of the way.
Door seal is not air tight.
Heavy build up of
frost on the door
seal.
Carefully warm the leaking sections of
the door seal with a hair dryer (on a cool
setting). At the same time shape the
warmed door seal by hand such that it
sits correctly.
Temperature is not properly
adjusted.
Please look in the initial Temperature
Setting section.
Door was open for an extended
period.
Open the door only as long as
necessary.
A large quantity of warm food
was placed in the appliance
within the last 24 hours.
Turn the temperature regulation to
a colder setting temporarily.
The food is not frozen
enough.
Please look in the installation
location section.
The appliance is near a heat
source.
Temperature is set too cold
or the appliance runs at Super
modes.
Possible cause
If the malfunction shows again, contact the Service Center.
These data are necessary to help you quickly and correctly.Write the necessary data here, refer to the
rating plate.
;
<9 
.
19
