Dahua Technology DHIH1C User manual

Network Attached Storage User’s Manual
V 1.0.0

Table of Contents
1
General Introduction ............................................................................................................................4
1.1
1.2
1.3
1.4
Overview........................................................................................................................................4
Front Panel/Rear Panel/Side Panel ..........................................................................................4
Packing List ...................................................................................................................................5
Open the Box to Check ...............................................................................................................5
2 WEB .......................................................................................................................................................7
2.1
2.2
2.3
2.4
2.5
2.6
Login...............................................................................................................................................7
Photo ..............................................................................................................................................9
Music ............................................................................................................................................10
Video ............................................................................................................................................12
File ................................................................................................................................................12
Download.....................................................................................................................................14
2.6.1
2.6.2
2.6.3
New Task ..............................................................................................................................15
Delete Task ...........................................................................................................................17
Restore Task ........................................................................................................................17
2.7 Surveillance.................................................................................................................................18
2.7.1
2.7.2
2.7.3
2.7.4
Initialization Settings ...........................................................................................................18
Remote Device Manager....................................................................................................25
Video .....................................................................................................................................29
Alarm .....................................................................................................................................32
2.8 Version .........................................................................................................................................33
3
4
5
ConfigTool............................................................................................................................................35
Appendix-Specifications ....................................................................................................................36
Appendix-Download Modes..............................................................................................................37
i

Welcome
Thank you for purchasing our device!
This user’s manual is designed to be a reference tool for your system.
Please open the accessory bag to check. Contact your local retailer ASAP if something is missing or
damaged in the bag.
1

Important Safeguards and Warnings
1．Electrical safety





All installation and operation here should conform to your local electrical safety codes.
An apparatus with CLASS I construction shall be connected to a MAINS socket outlet with a
protective earthing connection.
Use a power supply which meets the requirements for SELV (Safety Extra Low Voltage) and
complies with Limited Power Source according to IEC 60950-1. Refer to the device label for detailed
information.
The product must be grounded to reduce the risk of electric shock.
We assume no liability or responsibility for all the fires or electric shock caused by improper handling
or installation.
2．Transportation security

Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation



Keep upwards. Handle with care.
Do not apply power to the device before completing installation.
Do not place objects on the device.
4．Qualified engineers needed


All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment


The device should be installed in a cool, dry place away from direct sunlight, inflammable, explosive
substances and etc.
This series product shall be transported, storage and used in the specified environments.
6. Accessories



Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Attention that changes or modification not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
2

Icon
Note
DANGER
Indicates a hazard with a high level of risk, which if not avoided, will
result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which if not avoided,
could result in serious device damage or person injury.
CAUTION
Indicates a potentially hazardous situation, which if not avoided,
could result in device damage, data loss, performance degradation,
or unexpected results.
Anti-static
Indicates it is the static sensitive device.
Eletric shock
risk
Indicates presence of dangerous high voltage. There is a risk of
electric shock to persons.
High power
laser radiation risk
Indicates presence of high power laser radiation.
Tips
It is intended to help you to fix a problem or save your time.
Note
Provides additional information to emphasize or supplement
important points of the main text.
Note: This product has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This product generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this product does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
Safety Instruction
3

1 General Introduction
1.1 Overview
NAS (network attached storage) is a private network storage device for private data backup, sharing and
storage.
NAS provides the storage function (unit: TB) based on the Android OS. It supports 4K HDMI video output,
HIFI (High-Fidelity) audio output. It supports cell phone APP remote management and data access, view,
and downloads the record file and image remotely.
After connected NAS to the network camera, it supports real-time preview, record playback, alarm event
push and etc. It can provide total solutions for home security.
1.2 Front Panel/Rear Panel/Side Panel
The front panel is shown as in Figure 1-1.
Figure 1-1
The front panel is shown as in Figure 1-2.
Figure 1-2
The front panel is shown as below. See Figure 1-3.
Figure 1-3
4

SN
Indicator
Light/Port
Function
1
Power
indicator light
Power indicator light.
The light is off if it has not connected to the power sourcing.
The orange light is on during the system boot up process or press
RESET button for a long time to reset the system.
The white light is on when system is working properly after
initialization.
2
Signal
inductor
It is to receive the IR signal from the remote control.
3
HDD indicator
light
HDD status indicator light.
The light is off when there is no HDD or system cannot detect the
HDD.
The orange light is on when HDD is error.
The white light is on when HDD is running properly.
4
Network port
100/1000Mbpsself-adaptive Ethernet port. Connect to network cable.
5
HDMI port
High definition audio and video signal output port. It transmits
uncompressed high definition video and multiple-channel data to the
HDMI port of the display device.
6
USB2.0 port
USB2.0 port. Connect to mouse, keyboard, USB device and etc.
7
Audio output
port
Audio output port. It is to output the analog audio signal to the devices
such as the sound box.
8
Power port
Power input port. Input 12V/1.5A power.
9
RESET
Reset button.
Press REST button for 8 seconds. The power indicator light becomes
orange and device automatically begins reboot. Device restores
factory default setup after reboot.
10
SD card port
Micro SD card port. Max 128G storage space.
11
USB3.0 port
USB3.0 port. Connect to mouse, keyboard, USB device and etc.
Name
Quantity
Name
Quantity
NAS device
1
Power adapter
1
IR remote control
1
Network connation
cable
1
7# battery
1
HDMI cable
1
Quick Start Guide
1
-
-
SN
Indicator
Light/Port
Function
1
Power
indicator light
Power indicator light.
The light is off if it has not connected to the power sourcing.
The orange light is on during the system boot up process or press
RESET button for a long time to reset the system.
The white light is on when system is working properly after
initialization.
2
Signal
inductor
It is to receive the IR signal from the remote control.
3
HDD indicator
light
HDD status indicator light.
The light is off when there is no HDD or system cannot detect the
HDD.
The orange light is on when HDD is error.
The white light is on when HDD is running properly.
4
Network port
100/1000Mbpsself-adaptive Ethernet port. Connect to network cable.
Please refer to the following table for detailed information.
1.3 Packing List
Please check the accessories according to the packing list.
1.4 Open the Box to Check
Refer to the following table to check the device. Contact the local retailer or our service engineer if there
is any problem.
5

SN
Name
Contents
1
Whole
package
Appearance
There is any visible damage or not.
Package
There is any accidental clash during
transportation or not.
Accessories
Check all accessories are included in
the bag or not.
2
Front
panel and
rear
panel
The model on the front
panel
Check the model with the purchase
order.
The label on the rear
panel.
It is neat and clean or not.
Note
Do not tear off, or discard the label.
Usually we need you to represent the
serial number when we provide the
service after sales.
3
Case
Appearance
There is any visible damage or not.
Check the data cable,
power cable, fan cable,
main board and etc.
Check the connection is secure or not.
Note
Contact your local retailer or our service
engineer if the connection is loosened.
6

2 WEB
Use PC (personal computer) to access the device WEB to manage it.
Note


Check the PC and device connection before login the WEB.
Right now the browser supports Chrome and FireFox.
2.1 Login
Use browser to access the device WEB, it is to access and manage the device remotely.
Steps:
Step 1
Step 2
Step 3
Open browser and input the device IP address in the address column.
Click Enter button.
Enter WEB login interface. See Figure 2-1.
Figure 2-1
Enter user name and password.
Note
 The device default user name is admin and the password is admin.

Click to display the input password contents.
Step 4 Click Login.
Enter main interface. See Figure 2-2.
7

SN
Name
Function
1
Main menu
Click , enter main menu interface. See Figure 2-3. It is to view
system applications and installed applications.
2
Task bar
It is to display current running APP icon. Right click APP icon to restore,
maximize, minimize, close the APP.
3
Logout
Click to logout current user.
Click to select reboot or shut down. It is to reboot or shut down
the device.
4
Home
Click to display main interface.
5
Time pane
It is to display system current time and date.
6
Function
pane
It is to display current installed APP.
Figure 2-2
Please refer to the following table for detailed information.
8

Figure 2-3
2.2 Photo
It is to upload the photo to the device to storage and use the photo applications to play online.
Steps:
In the main interface, click
, enter photo interface. See Figure 2-4.




Right click Photo or click any photo in the list, it is to create a new photo or delete an old one.
Select an album and then click Upload, or select photo(s) and then click open, it is to upload the
image(s) on the local PC to the corresponding album.
Select an album and then click Play slide, system play all images from the album in full-screen. Click
any position in the image; it switches to the next image. Click ESC to exit full screen.
Right click any image, it can view, add to the favorites, delete.
9

Figure 2-4
2.3 Music
It is to upload the video to the device to storage and use the player to play online. \
Steps:
On the main interface, click
, enter music interface. See Figure 2-5.


Click Play all, device plays all songs in current list.
Click Add song, and then select a music file to upload, click Open, it is to upload the local PC music
file to the corresponding list.

Input the search key words in
corresponding search results.
, device can display the

Click the on the right of the playlist, it is to create a new playlist.

The music play control pane is at the bottom of the interface.
10

Icon
Function
Click to play the previous song.
Select a song in the list and then click the icon to play. Now the icon
becomes ,click to pause paly.
Click to switch to the next song.
Click to change to lyric mode, it is to view the lyric. Click the icon again
to go back to the list mode.
Display current music play process, play time and total period.
Click to add current music to the My favorites.
Click to adjust volume.
Click to select music play mode.
=Repeat play list.
=Randon play.
=Sequenc play.
=Repeat current song.
Figure 2-5
Please refer to the following table for detailed information.
11

Icon
Function
Click to view current play music list. Click Clear to clear play list.
Display current played music amount. Click to view the played music
list.
2.4 Video
Upload the video file to the device to storage and use player to play online.
Steps:
In the main interface, click
, enter audio/video interface. See Figure 2-6.


Input key words in
corresponding search results.
Move the mouse to the video file, device pops up
and click Enter button, device displays the
. Click the icon, it is to play the video file.
Figure 2-6
2.5 File
It is to view the data file storage on the device.
12

Icon
Function
Click to go back to the previous path.
Click to cancel go back to the previous path
Click to refresh file list.
Input search key words, device displays
corresponding file list.
Click to select file(s) to be uploaded, click Open to
upload local PC to the device.
Click to add a new folder.
Steps:
In the main menu, click
, enter file interface. See Figure 2-7.


Right click the file name in the file list on the right pane, it is to download, copy/paste/cut, delete,
rename the file, or view the file properties.
Right click file, click download, it is to download the file to the local PC.
Figure 2-7
Please refer to the following table for detailed information.
13

Icon
Function
Click to select file display mode. It includes list,
small icon, medium icon and large icon.
Click to select file sequence. It includes name, size,
type and time modified.
2.6 Download
System supports BT（BitTorrent）, magnet-uri ,HTTP/HTTPS, FTP/FTPS to download file. It max supports
5 download tasks at the same time.
Refer to appendix for Download Mode for BT（BitTorrent）, magnet-uri ,HTTP/HTTPS, FTP/FTPS detailed
information.
Steps:
In the main menu, click
to enter download interface. See Figure 2-8.
Figure 2-8
Please refer to the following table for detailed information.
14

SN
Function
1
Download catalog bar.
Downloading: Display downloading, pause, to be downloaded or error task
information.
Finished: Display finished task information.
Recycle: The deleted task information from the downloading list or the finished
list.
2
Task operation bar
Click to add new download task. Refer to chapter 2.6.1 New task for
detailed information.
Pause task in the downloading list, click the icon or right click mouse
and then select start to resume download process.
Select a download task in the downloading list and then click the
icon or right click mouse to pause current task.
Delete download task. Refer to chapter 2.6.2 Delete task for
detailed information.

In the recycle select the deleted download task, and then click
the icon or right click mouse to restore the task.
Input the search key words, system displays the
corresponding results.
3
Download main window. It is to display download task detailed information.
Name/size: Display download file name, size.
Transmit Speed: Display download speed and remaining time. If the download
failed, system pops up failed to download dialogue box. The download process
bar is grey.
Operation: Click to begin download, click to pause download.
4
View download state. Display current selected task amount and download total
speed.
2.6.1 New Task
System downloads new task by default after you created it. The state is downloading. If current download
tasks have exceeded 5 (system max download threshold), the new task state is to be downloaded.
Steps:
Step 1
In the main interface, click .
15

Enter download interface. See Figure 2-9.
Step 2
Click .
Enter Add task interface.
Figure 2-9
Step 3
Input download link or add BT file.


BT download: Add BT task and select corresponding .torrent file.
Other download: Input download path. Different download modes have different download
links. Please refer to the actual situation to set.
Step 4 Select save path.
Click
to select path interface. See Figure 2-10. Click to select saved path.
Note
System save file to the previous path by default if you do not set new path here.
Figure 2-10
16

Step 5
Click Download Now.
Enter downloading list to view new task state and download process.
2.6.2 Delete Task
Select a task in the list (download task, finished task or the task deleted in the recycle) and then click
, or right click mouse and then select delete, enter delete interface.
Note
Check the box to select delete download file, system can delete the downloaded file at the same time.
2.6.3 Restore Task
Go to the recycle to restore the download task.
Steps:
Step 1
In the main interface, click .
Enter download interface. See Figure 2-8.
Step 2 Click Recycle bin.
Enter recycle interface. See Figure 2-11.
Note
The speed here displays deleting speed.
Figure 2-11
17

Step 3
Select a task to be restored and then click
，
System restore the task. Go to the downloading interface to view the download task.
Step 4
Click the of the corresponding download task.
System begins downloading task again.
2.7 Surveillance
Click
, enter preview and monitor interface. See Figure 2-12.
Connect to the camera, system can display real-time monitor video, playback record file, set camera
parameters remotely.
Note
If it is your first time to enter the preview interface, the window prompts you to install plugins. Please
follow the prompts to install.
Figure 2-12
2.7.1 Initialization Settings
The initialization settings include add remote device and enable remote device record function.
2.7.1.1 Register Camera
It is to manage camera such as add, edit, upgrade camera and etc. It supports to change channel name,
bit rate parameters and etc.
Note
System max supports 4 cameras.
Steps:
There are many ways to register the camera such as search and then add, add by IP address, batch add,
18
