Daikin FTX20JV1B User manual

Service
Manual
Inverter Pair
Wall Mounted Type J-Series
SiBE041010EA
[Applied Models]
zInverter Pair : Heat Pump

SiBE041010EA
iTable of Contents
Inverter Pair
Wall Mounted Type
J-Series
zHeat Pump
Indoor Unit
FTX20JV1B ATX20JV1B
FTX25JV1B ATX25JV1B
FTX35JV1B ATX35JV1B
FTX20J2V1B ATX20J2V1B
FTX25J2V1B ATX25J2V1B
FTX35J2V1B ATX35J2V1B
Outdoor Unit
RX20JV1B ARX20JV1B
RX25JV1B ARX25JV1B
RX35JV1B ARX35JV1B
RX20J3V1B ARX20J3V1B
RX25J3V1B ARX25J3V1B
RX35J3V1B ARX35J3V1B
The removal procedure for each model is separately bound. Refer to page 103 for the booklet number of
applicable model.

SiBE041010EA
Table of Contents ii
1. Introduction .............................................................................................v
1.1 Safety Cautions ........................................................................................ v
1.2 Used Icons ...............................................................................................x
Part 1 List of Functions ................................................................ 1
1. Functions.................................................................................................2
Part 2 Specifications .................................................................... 4
1. Specifications ..........................................................................................5
Part 3 Printed Circuit Board Connector Wiring Diagram ...........13
1. Indoor Unit.............................................................................................14
2. Outdoor Unit..........................................................................................16
Part 4 Function and Control........................................................ 18
1. Main Functions......................................................................................19
1.1 Temperature Control ..............................................................................19
1.2 Frequency Principle................................................................................19
1.3 Airflow Direction Control.........................................................................21
1.4 Fan Speed Control for Indoor Unit .........................................................22
1.5 Program Dry Operation ..........................................................................23
1.6 Automatic Operation...............................................................................24
1.7 Thermostat Control.................................................................................25
1.8 NIGHT SET Mode ..................................................................................26
1.9 ECONO Operation .................................................................................26
1.10 Inverter POWERFUL Operation .............................................................27
1.11 Clock Setting ..........................................................................................27
1.12 Other Functions......................................................................................28
2. Function of Thermistor ..........................................................................29
3. Control Specification .............................................................................30
3.1 Mode Hierarchy ......................................................................................30
3.2 Frequency Control..................................................................................30
3.3 Controls at Mode Changing / Start-up....................................................32
3.4 Discharge Pipe Temperature Control.....................................................33
3.5 Input Current Control..............................................................................34
3.6 Freeze-up Protection Control .................................................................35
3.7 Heating Peak-cut Control .......................................................................35
3.8 Outdoor Fan Control...............................................................................36
3.9 Liquid Compression Protection Function................................................36
3.10 Defrost Control .......................................................................................37
3.11 Electronic Expansion Valve Control .......................................................38
3.12 Malfunctions ...........................................................................................41
Part 5 Remote Controller ............................................................ 42
1. Remote Controller .................................................................................43

SiBE041010EA
iii Table of Contents
Part 6 Service Diagnosis............................................................. 45
1. Troubleshooting with LED .....................................................................46
1.1 Indoor Unit..............................................................................................46
1.2 Outdoor Unit ...........................................................................................46
2. Problem Symptoms and Measures .......................................................47
3. Service Check Function ........................................................................48
4. Troubleshooting ....................................................................................51
4.1 Error Codes and Description ..................................................................51
4.2 Indoor Unit PCB Abnormality .................................................................52
4.3 Freeze-up Protection Control or Heating Peak-cut Control....................53
4.4 Fan Motor (DC Motor) or Related Abnormality.......................................54
4.5 Thermistor or Related Abnormality (Indoor Unit)....................................56
4.6 Refrigerant Shortage ..............................................................................57
4.7 Low-voltage Detection or Over-voltage Detection..................................59
4.8 Signal Transmission Error (between Indoor Unit and Outdoor Unit) ......61
4.9 Unspecified Voltage (between Indoor Unit and Outdoor Unit) ...............63
4.10 Outdoor Unit PCB Abnormality...............................................................64
4.11 OL Activation (Compressor Overload) ...................................................65
4.12 Compressor Lock ...................................................................................67
4.13 DC Fan Lock ..........................................................................................68
4.14 Input Overcurrent Detection ...................................................................69
4.15 Four Way Valve Abnormality..................................................................70
4.16 Discharge Pipe Temperature Control.....................................................72
4.17 High Pressure Control in Cooling ...........................................................73
4.18 Compressor System Sensor Abnormality ..............................................74
4.19 Position Sensor Abnormality ..................................................................75
4.20 DC Voltage / Current Sensor Abnormality..............................................77
4.21 Thermistor or Related Abnormality (Outdoor Unit).................................78
4.22 Electrical Box Temperature Rise............................................................80
4.23 Radiation Fin Temperature Rise ............................................................81
4.24 Output Overcurrent Detection ................................................................83
5. Check ....................................................................................................85
5.1 Thermistor Resistance Check ................................................................85
5.2 Fan Motor Connector Output Check ......................................................86
5.3 Power Supply Waveforms Check...........................................................87
5.4 Electronic Expansion Valve Check.........................................................87
5.5 Four Way Valve Performance Check .....................................................88
5.6 Inverter Units Refrigerant System Check ...............................................88
5.7 Inverter Analyzer Check .........................................................................89
5.8 Rotation Pulse Check on the Outdoor Unit PCB ....................................90
5.9 Installation Condition Check...................................................................91
5.10 Discharge Pressure Check.....................................................................91
5.11 Outdoor Fan System Check ...................................................................92
5.12 Main Circuit Short Check........................................................................92
5.13 Power Module Check .............................................................................93
Part 7 Tips for Servicing ............................................................. 94
1. Tips for Servicing ..................................................................................95
1.1 Pump Down Operation ...........................................................................95
1.2 Forced Cooling Operation ......................................................................95

SiBE041010EA
Table of Contents iv
2. Trial Operation ......................................................................................96
3. Field Settings ........................................................................................97
3.1 When 2 Units are Installed in 1 Room....................................................97
3.2 Jumper Settings .....................................................................................97
4. Silicon Grease on Power Transistor / Diode Bridge..............................98
Part 8 Appendix........................................................................... 99
1. Piping Diagrams..................................................................................100
1.1 Indoor Unit............................................................................................100
1.2 Outdoor Unit .........................................................................................101
2. Wiring Diagrams..................................................................................102
2.1 Indoor Unit............................................................................................102
2.2 Outdoor Unit .........................................................................................102
3. Removal Procedure (Booklet No.) ......................................................103

Introduction SiBE041010EA
v
1. Introduction
1.1 Safety Cautions
Cautions and
Warnings
Be sure to read the following safety cautions before conducting repair work.
The caution items are classified into “ Warning” and “ Caution”. The “ Warning”
items are especially important since they can lead to death or serious injury if they are not
followed closely. The “ Caution” items can also lead to serious accidents under some
conditions if they are not followed. Therefore, be sure to observe all the safety caution items
described below.
About the pictograms
This symbol indicates the item for which caution must be exercised.
The pictogram shows the item to which attention must be paid.
This symbol indicates the prohibited action.
The prohibited item or action is shown in the illustration or near the symbol.
This symbol indicates the action that must be taken, or the instruction.
The instruction is shown in the illustration or near the symbol.
After the repair work is complete, be sure to conduct a test operation to ensure that the
equipment operates normally, and explain the cautions for operating the product to the
customer.
1.1.1 Cautions Regarding Safety of Workers
Warning
Do not store the equipment in a room with successive fire sources (e.g., naked
flame, gas appliance, electric heater).
Be sure to disconnect the power cable plug from the plug socket before
disassembling the equipment for repair.
Working on the equipment that is connected to the power supply may cause an
electrical shock.
If it is necessary to supply power to the equipment to conduct the repair or
inspecting the circuits, do not touch any electrically charged sections of the
equipment.
If the refrigerant gas is discharged during the repair work, do not touch the
discharged refrigerant gas.
The refrigerant gas may cause frostbite.
When disconnecting the suction or discharge pipe of the compressor at the
welded section, evacuate the refrigerant gas completely at a well-ventilated
place first.
If there is gas remaining inside the compressor, the refrigerant gas or
refrigerating machine oil discharges when the pipe is disconnected, and it may
cause injury.
If the refrigerant gas leaks during the repair work, ventilate the area. The
refrigerant gas may generate toxic gases when it contacts flames.
The step-up capacitor supplies high-voltage electricity to the electrical
components of the outdoor unit.
Be sure to discharge the capacitor completely before conducting repair work.
A charged capacitor may cause an electrical shock.

SiBE041010EA Introduction
vi
Do not start or stop the air conditioner operation by plugging or unplugging the
power cable plug.
Plugging or unplugging the power cable plug to operate the equipment may
cause an electrical shock or fire.
Be sure to wear a safety helmet, gloves, and a safety belt when working at a
high place (more than 2 m). Insufficient safety measures may cause a fall
accident.
In case of R-32 / R-410A refrigerant models, be sure to use pipes, flare nuts
and tools for the exclusive use of the R-32 / R-410A refrigerant.
The use of materials for R-22 refrigerant models may cause a serious accident
such as a damage of refrigerant cycle as well as an equipment failure.
Do not mix air or gas other than the specified refrigerant (R-32 / R-410A / R-
22) in the refrigerant system.
If air enters the refrigerating system, an excessively high pressure results,
causing equipment damage and injury.
Warning
Caution
Do not repair the electrical components with wet hands.
Working on the equipment with wet hands may cause an electrical shock.
Do not clean the air conditioner by splashing water.
Washing the unit with water may cause an electrical shock.
Be sure to provide the grounding when repairing the equipment in a humid or
wet place, to avoid electrical shocks.
Be sure to turn off the power switch and unplug the power cable when cleaning
the equipment.
The internal fan rotates at a high speed, and may cause injury.
Be sure to conduct repair work with appropriate tools.
The use of inappropriate tools may cause injury.
Be sure to check that the refrigerating cycle section has cooled down enough
before conducting repair work.
Working on the unit when the refrigerating cycle section is hot may cause
burns.

Introduction SiBE041010EA
vii
1.1.2 Cautions Regarding Safety of Users
Use the welder in a well-ventilated place.
Using the welder in an enclosed room may cause oxygen deficiency.
Caution
Warning
Do not store the equipment in a room with successive fire sources (e.g., naked
flame, gas appliance, electric heater).
Be sure to use parts listed in the service parts list of the applicable model and
appropriate tools to conduct repair work. Never attempt to modify the
equipment.
The use of inappropriate parts or tools may cause an electrical shock,
excessive heat generation or fire.
If the power cable and lead wires have scratches or deteriorated, be sure to
replace them.
Damaged cable and wires may cause an electrical shock, excessive heat
generation or fire.
Do not use a joined power cable or extension cable, or share the same power
outlet with other electrical appliances, since it may cause an electrical shock,
excessive heat generation or fire.
Be sure to use an exclusive power circuit for the equipment, and follow the local
technical standards related to the electrical equipment, the internal wiring
regulations, and the instruction manual for installation when conducting
electrical work.
Insufficient power circuit capacity and improper electrical work may cause an
electrical shock or fire.
Be sure to use the specified cable for wiring between the indoor and outdoor
units. Make the connections securely and route the cable properly so that there
is no force pulling the cable at the connection terminals.
Improper connections may cause excessive heat generation or fire.
When wiring between the indoor and outdoor units, make sure that the terminal
cover does not lift off or dismount because of the cable.
If the cover is not mounted properly, the terminal connection section may cause
an electrical shock, excessive heat generation or fire.
Do not damage or modify the power cable.
Damaged or modified power cable may cause an electrical shock or fire.
Placing heavy items on the power cable, and heating or pulling the power cable
may damage the cable.

SiBE041010EA Introduction
viii
Do not mix air or gas other than the specified refrigerant (R-32 / R-410A / R-
22) in the refrigerant system.
If air enters the refrigerating system, an excessively high pressure results,
causing equipment damage and injury.
If the refrigerant gas leaks, be sure to locate the leaking point and repair it
before charging the refrigerant. After charging refrigerant, make sure that there
is no refrigerant leak.
If the leaking point cannot be located and the repair work must be stopped, be
sure to perform pump-down and close the service valve, to prevent the
refrigerant gas from leaking into the room. The refrigerant gas itself is
harmless, but it may generate toxic gases when it contacts flames, such as fan
and other heaters, stoves and ranges.
When relocating the equipment, make sure that the new installation site has
sufficient strength to withstand the weight of the equipment.
If the installation site does not have sufficient strength and if the installation
work is not conducted securely, the equipment may fall and cause injury.
Check to make sure that the power cable plug is not dirty or loose, then insert
the plug into a power outlet securely.
If the plug has dust or loose connection, it may cause an electrical shock or fire.
Be sure to install the product correctly by using the provided standard
installation frame.
Incorrect use of the installation frame and improper installation may cause the
equipment to fall, resulting in injury.
For unitary type
only
Be sure to install the product securely in the installation frame mounted on the
window frame.
If the unit is not securely mounted, it may fall and cause injury.
For unitary type
only
When replacing the coin battery in the remote controller, be sure to dispose of
the old battery to prevent children from swallowing it.
If a child swallows the coin battery, see a doctor immediately.
Warning
Caution
Installation of a leakage breaker is necessary in some cases depending on the
conditions of the installation site, to prevent electrical shocks.
Do not install the equipment in a place where there is a possibility of
combustible gas leaks.
If the combustible gas leaks and remains around the unit, it may cause a fire.

Introduction SiBE041010EA
ix
Check to see if the parts and wires are mounted and connected properly, and
if the connections at the soldered or crimped terminals are secure.
Improper installation and connections may cause excessive heat generation,
fire or an electrical shock.
If the installation platform or frame has corroded, replace it.
Corroded installation platform or frame may cause the unit to fall, resulting in
injury.
Check the grounding, and repair it if the equipment is not properly grounded.
Improper grounding may cause an electrical shock.
Be sure to measure the insulation resistance after the repair, and make sure
that the resistance is 1 MΩor higher.
Faulty insulation may cause an electrical shock.
Be sure to check the drainage of the indoor unit after the repair.
Faulty drainage may cause the water to enter the room and wet the furniture
and floor.
Do not tilt the unit when removing it.
The water inside the unit may spill and wet the furniture and floor.
Be sure to install the packing and seal on the installation frame properly.
If the packing and seal are not installed properly, water may enter the room and
wet the furniture and floor.
For unitary type
only
Caution

SiBE041010EA Introduction
x
1.2 Used Icons
Icons are used to attract the attention of the reader to specific information. The meaning of each
icon is described in the table below:
Icon Type of
Information
Description
Note:
Note A “note” provides information that is not indispensable, but may
nevertheless be valuable to the reader, such as tips and tricks.
Caution
Caution A “caution” is used when there is danger that the reader, through
incorrect manipulation, may damage equipment, loose data, get
an unexpected result or has to restart (part of) a procedure.
Warning
Warning A “warning” is used when there is danger of personal injury.
Reference A “reference” guides the reader to other places in this binder or
in this manual, where he/she will find additional information on a
specific topic.

SiBE041010EA
1List of Functions
Part 1
List of Functions
1. Functions.................................................................................................2

SiBE041010EA Functions
List of Functions 2
1. Functions
Category Functions
FTX20/25/35JV1B RX20/25/35JV1B FTX20/25/35J2V1B RX20/25/35J3V1B
Category Functions
FTX20/25/35JV1B RX20/25/35JV1B FTX20/25/35J2V1B RX20/25/35J3V1B
Basic
Function
Inverter
(with inverter power control) zz
Health &
Clean Air-purifying filter — —
Operation limit for cooling (°CDB) 10
~46
10
~46 Photocatalytic deodorizing filter — —
Operation limit for heating (°CWB) –15
~18
–15
~18
Air-purifying filter with photocatalytic
deodorizing function ——
PAM control zz Titanium apatite photocatalytic
air-purifying filter zz
Standby electricity saving zz
Compressor Oval scroll compressor — — Air filter (prefilter) zz
Swing compressor zz Wipe-clean flat panel zz
Rotary compressor — — Washable grille — —
Reluctance DC motor zz MOLD PROOF operation — —
Comfortable
Airflow
Power-airflow flap zz Heating dry operation — —
Power-airflow dual flaps — — Good-sleep cooling operation — —
Power-airflow diffuser — — Timer WEEKLY TIMER operation — —
Wide-angle louvers zz 24-hour ON/OFF TIMER zz
NIGHT SET mode zz
Vertical auto-swing (up and down) zz Worry Free
“Reliability &
Durability”
Auto-restart (after power failure) zz
Horizontal auto-swing (right and left) — — Self-diagnosis (digital, LED) display zz
3-D airflow — —
COMFORT AIRFLOW operation zz Wiring error check function — —
Comfort
Control Auto fan speed zz Anti-corrosion treatment of outdoor heat
exchanger zz
Indoor unit quiet operation zz
Flexibility Multi-split / split type compatible indoor
unit zz
NIGHT QUIET mode (automatic) — — Flexible power supply correspondence — —
OUTDOOR UNIT QUIET operation
(manual) — — High ceiling application — —
INTELLIGENT EYE operation — — Chargeless 10 m 10 m
Quick warming function
(preheating operation) zz Either side drain (right or left) zz
Hot-start function zz Power selection — —
Automatic defrosting zz
Remote
Control 5-room centralized controller (option) — —
Operation Automatic operation zz
Program dry operation zz Remote control adaptor
(normal open pulse contact) (option) ——
Fan only zz
Lifestyle
Convenience
New POWERFUL operation
(non-inverter) —— Remote control adaptor (normal open contact) (option) ——
Inverter POWERFUL operation zz DIII-NET compatible (adaptor) (option) — —
Priority-room setting — — Remote
Controller
Wireless zz
COOL / HEAT mode lock — — Wired (option) zz
HOME LEAVE operation — —
ECONO operation zz
Indoor unit [ON/OFF] button zz
Signal receiving sign zz
R/C with back light — —
Temperature display — —
Note: z: Available
— : Not available

Functions SiBE041010EA
3List of Functions
Category Functions
ATX20/25/35JV1B ARX20/25/35JV1B ATX20/25/35J2V1B ARX20/25/35J3V1B
Category Functions
ATX20/25/35JV1B ARX20/25/35JV1B ATX20/25/35J2V1B ARX20/25/35J3V1B
Basic
Function
Inverter
(with inverter power control) zz
Health &
Clean Air-purifying filter — —
Operation limit for cooling (°CDB) 10
~46
10
~46 Photocatalytic deodorizing filter — —
Operation limit for heating (°CWB) –15
~18
–15
~18
Air-purifying filter with photocatalytic
deodorizing function ——
PAM control zz Titanium apatite photocatalytic
air-purifying filter zz
Standby electricity saving zz
Compressor Oval scroll compressor — — Air filter (prefilter) zz
Swing compressor zz Wipe-clean flat panel zz
Rotary compressor — — Washable grille — —
Reluctance DC motor zz MOLD PROOF operation — —
Comfortable
Airflow
Power-airflow flap zz Heating dry operation — —
Power-airflow dual flaps — — Good-sleep cooling operation — —
Power-airflow diffuser — — Timer WEEKLY TIMER operation — —
Wide-angle louvers zz 24-hour ON/OFF TIMER zz
NIGHT SET mode zz
Vertical auto-swing (up and down) zz Worry Free
“Reliability &
Durability”
Auto-restart (after power failure) zz
Horizontal auto-swing (right and left) — — Self-diagnosis (digital, LED) display zz
3-D airflow — —
COMFORT AIRFLOW operation zz Wiring error check function — —
Comfort
Control Auto fan speed zz Anti-corrosion treatment of outdoor heat
exchanger zz
Indoor unit quiet operation zz
Flexibility Multi-split / split type compatible indoor
unit zz
NIGHT QUIET mode (automatic) — — Flexible power supply correspondence — —
OUTDOOR UNIT QUIET operation
(manual) — — High ceiling application — —
INTELLIGENT EYE operation — — Chargeless 10 m 10 m
Quick warming function
(preheating operation) zz Either side drain (right or left) zz
Hot-start function zz Power selection — —
Automatic defrosting zz
Remote
Control 5-room centralized controller (option) — —
Operation Automatic operation zz
Program dry operation zz Remote control adaptor
(normal open pulse contact) (option) ——
Fan only zz
Lifestyle
Convenience
New POWERFUL operation
(non-inverter) —— Remote control adaptor
(normal open contact) (option) ——
Inverter POWERFUL operation zz DIII-NET compatible (adaptor) (option) — —
Priority-room setting — — Remote
Controller
Wireless zz
COOL / HEAT mode lock — — Wired (option) zz
HOME LEAVE operation — —
ECONO operation zz
Indoor unit [ON/OFF] button zz
Signal receiving sign zz
R/C with back light — —
Temperature display — —
Note: z: Available
— : Not available

SiBE041010EA
Specifications 4
Part 2
Specifications
1. Specifications ..........................................................................................5

Specifications SiBE041010EA
5Specifications
1. Specifications
50 Hz, 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTX20JV1B FTX25JV1B
Outdoor Unit RX20JV1B RX25JV1B
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.6) 2.5 (1.3 ~ 3.5) 2.5 (1.3 ~ 3.0) 2.8 (1.3 ~ 4.0)
Btu/h 6,800 (4,400 ~ 8,900) 8,500 (4,400 ~ 11,600) 8,500 (4,400 ~ 10,200) 9,600 (4,400 ~ 13,600)
kcal/h 1,720 (1,120 ~ 2,240) 2,150 (1,120 ~ 3,010) 2,150 (1,120 ~ 2,580) 2,410 (1,120 ~ 3,440)
Running Current (Rated) A 2.7 3.0 3.7 3.2
Power Consumption
Rated (Min. ~ Max.) W 550 (310 ~ 720) 590 (250 ~ 950) 730 (310 ~ 1,050) 690 (250 ~ 1,110)
Power Factor (Rated) % 88.6 91.6 85.8 93.8
COP Rated (Min. ~ Max.) W/W 3.64 (4.19 ~ 3.61) 4.24 (5.20 ~ 3.68) 3.42 (4.19 ~ 2.86) 4.06 (5.20 ~ 3.60)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ9.5 φ9.5
Drain mm φ 18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 15 15
Max. Interunit Height Difference m 12 12
Chargeless m 10 10
Amount of Additional Charge
of Refrigerant g/m 20 20
Indoor Unit FTX20JV1B FTX25JV1B
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
9.1 (321) 9.4 (331) 9.2 (325) 9.7 (342)
M7.4 (261) 7.8 (276) 7.6 (268) 8.0 (283)
L5.9 (208) 6.3 (222) 6.0 (212) 6.3 (222)
SL 4.7 (166) 5.5 (194) 4.8 (169) 5.5 (194)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 16 16
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 283 × 770 × 198 283 × 770 × 198
Packaged Dimensions (H × W × D) mm 263 × 840 × 344 263 × 840 × 344
Weight (Mass) kg 7 7
Gross Weight (Gross Mass) kg 11 11
Sound
Pressure
Level H / M / L / SL dB(A) 39 / 33 / 25 / 22 39 / 34 / 28 / 25 40 / 33 / 26 / 22 40 / 34 / 28 / 25
Sound Power Level dB 55 55 56 56
Outdoor Unit RX20JV1B RX25JV1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD
Motor Output W 750 750
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant Type R-410A R-410A
Charge kg 0.74 0.74
Airflow Rate H m³/min
(cfm) 29.2 (1,030) 26.2 (927) 29.2 (1,030) 26.2 (927)
Fan Type Propeller Propeller
Motor Output W 33 33
Running Current (Rated) A 2.52 2.62 3.52 3.02
Power Consumption (Rated) W 510 550 690 650
Power Factor % 88.0 91.3 85.2 93.6
Starting Current A 2.7 3.7
Dimensions (H × W × D) mm 550 × 658 × 275 550 × 658 × 275
Packaged Dimensions (H × W × D) mm 616 × 788 × 359 616 × 788 × 359
Weight (Mass) kg 28 28
Gross Weight (Gross Mass) kg 31 31
Sound Pressure Level (H) dB(A) 46 47 46 47
Sound Power Level (H) dB 60 61 60 61
Drawing No. 3D065930 3D065931
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 5 m

SiBE041010EA Specifications
Specifications 6
50 Hz, 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTX35JV1B
Outdoor Unit RX35JV1B
Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 3.3 (1.3 ~ 3.8) 3.5 (1.3 ~ 4.8)
Btu/h 11,300 (4,400 ~ 13,000) 11,900 (4,400 ~ 16,400)
kcal/h 2,840 (1,120 ~ 3,270) 3,010 (1,120 ~ 4,130)
Running Current (Rated) A 5.2 4.7
Power Consumption
Rated (Min. ~ Max.) W 980 (290 ~ 1,300) 930 (290 ~ 1,290)
Power Factor % 81.9 86.0
COP Rated (Min. ~ Max.) W/W 3.37 (4.48 ~ 2.92) 3.76 (4.48 ~ 3.72)
Piping
Connections
Liquid mm φ 6.4
Gas mm φ9.5
Drain mm φ 18.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 15
Max. Interunit Height Difference m 12
Chargeless m 10
Amount of Additional Charge
of Refrigerant g/m 20
Indoor Unit FTX35JV1B
Front Panel Color White
Airflow Rate
H
m³/min
(cfm)
9.3 (328) 10.1 (356)
M7.7 (272) 8.4 (295)
L6.1 (215) 6.7 (235)
SL 4.9 (173) 5.7 (201)
Fan
Type Cross Flow Fan
Motor Output W 16
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 283 × 770 × 198
Packaged Dimensions (H × W × D) mm 263 × 840 × 344
Weight (Mass) kg 7
Gross Weight (Gross Mass) kg 11
Sound
Pressure
Level H / M / L / SL dB(A) 41 / 34 / 27 / 23 41 / 35 / 29 / 26
Sound Power Level dB 57 57
Outdoor Unit RX35JV1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23AEXD
Motor Output W 750
Refrigerant
Oil
Type FVC50K
Charge L 0.375
Refrigerant Type R-410A
Charge kg 1.0
Airflow Rate H m³/min
(cfm) 27.6 (975) 24.5 (865)
Fan Type Propeller
Motor Output W 33
Running Current (Rated) A 5.02 4.52
Power Consumption (Rated) W 940 890
Power Factor % 86.0 85.6
Starting Current A 5.0
Dimensions (H × W × D) mm 550 × 658 × 275
Packaged Dimensions (H × W × D) mm 616 × 788 × 359
Weight (Mass) kg 30
Gross Weight (Gross Mass) kg 34
Sound Pressure Level (H) dB(A) 48 48
Sound Power Level (H) dB 62 62
Drawing No. 3D065932
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 5 m

Specifications SiBE041010EA
7Specifications
50 Hz, 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTX20J2V1B FTX25J2V1B
Outdoor Unit RX20J3V1B RX25J3V1B
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.6) 2.5 (1.3 ~ 3.5) 2.5 (1.3 ~ 3.0) 2.8 (1.3 ~ 4.0)
Btu/h 6,800 (4,400 ~ 8,900) 8,500 (4,400 ~ 11,900) 8,500 (4,400 ~ 10,200) 9,600 (4,400 ~ 13,600)
kcal/h 1,720 (1,120 ~ 2,240) 2,150 (1,120 ~ 3,010) 2,150 (1,120 ~ 2,580) 2,410 (1,120 ~ 3,440)
Running Current (Rated) A 2.7 3.0 3.7 3.2
Power Consumption
Rated (Min. ~ Max.) W 550 (310 ~ 720) 590 (250 ~ 950) 730 (310 ~ 1,050) 690 (250 ~ 1,110)
Power Factor (Rated) % 88.6 85.5 85.8 93.8
COP Rated (Min. ~ Max.) W/W 3.64 (4.19 ~ 3.61) 4.24 (5.20 ~ 3.68) 3.42 (4.19 ~ 2.86) 4.06 (5.20 ~ 3.60)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ9.5 φ9.5
Drain mm φ 18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 15 15
Max. Interunit Height Difference m 12 12
Chargeless m 10 10
Amount of Additional Charge
of Refrigerant g/m 20 20
Indoor Unit FTX20J2V1B FTX25J2V1B
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
9.1 (321) 9.4 (331) 9.2 (325) 9.7 (342)
M7.4 (261) 7.8 (276) 7.6 (268) 8.0 (283)
L5.9 (208) 6.3 (222) 6.0 (212) 6.3 (222)
SL 4.7 (166) 5.5 (194) 4.8 (169) 5.5 (194)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 16 16
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 283 × 770 × 198 283 × 770 × 198
Packaged Dimensions (H × W × D) mm 266 × 846 × 345 266 × 846 × 345
Weight (Mass) kg 7 7
Gross Weight (Gross Mass) kg 11 11
Sound
Pressure
Level H / M / L / SL dB(A) 39 / 33 / 25 / 22 39 / 34 / 28 / 25 40 / 33 / 26 / 22 40 / 34 / 28 / 25
Sound Power Level dB 55 55 55 55
Outdoor Unit RX20J3V1B RX25J3V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD
Motor Output W 750 750
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant Type R-410A R-410A
Charge kg 0.74 0.74
Airflow Rate H m³/min
(cfm) 29.2 (1,030) 26.2 (927) 29.2 (1,030) 26.2 (927)
Fan Type Propeller Propeller
Motor Output W 33 33
Running Current (Rated) A 2.52 2.82 3.52 3.02
Power Consumption (Rated) W 510 550 690 650
Power Factor % 88.0 84.8 85.2 93.6
Starting Current A 3.0 3.7
Dimensions (H × W × D) mm 550 × 658 × 275 550 × 658 × 275
Packaged Dimensions (H × W × D) mm 612 × 769 × 350 612 × 769 × 350
Weight (Mass) kg 28 28
Gross Weight (Gross Mass) kg 31 31
Sound Pressure Level (H) dB(A) 46 47 46 47
Sound Power Level (H) dB 60 61 60 61
Drawing No. C: 3D080673 C: 3D080674
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 5 m

SiBE041010EA Specifications
Specifications 8
50 Hz, 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTX35J2V1B
Outdoor Unit RX35J3V1B
Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 3.3 (1.3 ~ 3.8) 3.5 (1.3 ~ 4.8)
Btu/h 11,300 (4,400 ~ 13,000) 11,900 (4,400 ~ 16,400)
kcal/h 2,840 (1,120 ~ 3,270) 3,010 (1,120 ~ 4,130)
Running Current (Rated) A 5.2 4.7
Power Consumption
Rated (Min. ~ Max.) W 980 (290 ~ 1,300) 930 (290 ~ 1,290)
Power Factor % 81.9 86.0
COP Rated (Min. ~ Max.) W/W 3.37 (4.48 ~ 2.92) 3.76 (4.48 ~ 3.72)
Piping
Connections
Liquid mm φ 6.4
Gas mm φ9.5
Drain mm φ 18.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 15
Max. Interunit Height Difference m 12
Chargeless m 10
Amount of Additional Charge
of Refrigerant g/m 20
Indoor Unit FTX35J2V1B
Front Panel Color White
Airflow Rate
H
m³/min
(cfm)
9.3 (328) 10.1 (356)
M7.7 (272) 8.4 (295)
L6.1 (215) 6.7 (235)
SL 4.9 (173) 5.7 (201)
Fan
Type Cross Flow Fan
Motor Output W 16
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 283 × 770 × 198
Packaged Dimensions (H × W × D) mm 266 × 846 × 345
Weight (Mass) kg 7
Gross Weight (Gross Mass) kg 11
Sound
Pressure
Level H / M / L / SL dB(A) 41 / 34 / 27 / 23 41 / 35 / 29 / 26
Sound Power Level dB 58 58
Outdoor Unit RX35J3V1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23AEXD
Motor Output W 750
Refrigerant
Oil
Type FVC50K
Charge L 0.375
Refrigerant Type R-410A
Charge kg 1.0
Airflow Rate H m³/min
(cfm) 27.6 (975) 24.5 (865)
Fan Type Propeller
Motor Output W 33
Running Current (Rated) A 5.02 4.52
Power Consumption (Rated) W 940 890
Power Factor % 81.4 85.6
Starting Current A 5.2
Dimensions (H × W × D) mm 550 × 658 × 275
Packaged Dimensions (H × W × D) mm 612 × 769 × 350
Weight (Mass) kg 30
Gross Weight (Gross Mass) kg 34
Sound Pressure Level (H) dB(A) 48 48
Sound Power Level (H) dB 62 62
Drawing No. C: 3D080675
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 5 m

Specifications SiBE041010EA
9Specifications
50 Hz, 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit ATX20JV1B ATX25JV1B
Outdoor Unit ARX20JV1B ARX25JV1B
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.6) 2.5 (1.3 ~ 3.5) 2.5 (1.3 ~ 3.0) 2.8 (1.3 ~ 4.0)
Btu/h 6,800 (4,400 ~ 8,900) 8,500 (4,400 ~ 11,600) 8,500 (4,400 ~ 10,200) 9,600 (4,400 ~ 13,600)
kcal/h 1,720 (1,120 ~ 2,240) 2,150 (1,120 ~ 3,010) 2,150 (1,120 ~ 2,580) 2,410 (1,120 ~ 3,440)
Running Current (Rated) A 2.7 3.0 3.7 3.2
Power Consumption
Rated (Min. ~ Max.) W 550 (310 ~ 720) 590 (250 ~ 950) 730 (310 ~ 1,050) 690 (250 ~ 1,110)
Power Factor (Rated) % 88.6 91.6 85.8 93.8
COP Rated (Min. ~ Max.) W/W 3.64 (4.19 ~ 3.61) 4.24 (5.20 ~ 3.68) 3.42 (4.19 ~ 2.86) 4.06 (5.20 ~ 3.60)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ9.5 φ9.5
Drain mm φ18.0 φ 18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 15 15
Max. Interunit Height Difference m 12 12
Chargeless m 10 10
Amount of Additional Charge
of Refrigerant g/m 20 20
Indoor Unit ATX20JV1B ATX25JV1B
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
9.1 (321) 9.4 (331) 9.2 (325) 9.7 (342)
M7.4 (261) 7.8 (276) 7.6 (268) 8.0 (283)
L5.9 (208) 6.3 (222) 6.0 (212) 6.3 (222)
SL 4.7 (166) 5.5 (194) 4.8 (169) 5.5 (194)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 16 16
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 283 × 770 × 198 283 × 770 × 198
Packaged Dimensions (H × W × D) mm 263 × 840 × 344 263 × 840 × 344
Weight (Mass) kg 7 7
Gross Weight (Gross Mass) kg 11 11
Sound
Pressure
Level H / M / L / SL dB(A) 39 / 33 / 25 / 22 39 / 34 / 28 / 25 40 / 33 / 26 / 22 40 / 34 / 28 / 25
Sound Power Level dB 55 55 56 56
Outdoor Unit ARX20JV1B ARX25JV1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD
Motor Output W 750 750
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant Type R-410A R-410A
Charge kg 0.74 0.74
Airflow Rate H m³/min
(cfm) 29.2 (1,030) 26.2 (927) 29.2 (1,030) 26.2 (927)
Fan Type Propeller Propeller
Motor Output W 33 33
Running Current (Rated) A 2.52 2.62 3.52 3.02
Power Consumption (Rated) W 510 550 690 650
Power Factor % 88.0 91.3 85.2 93.6
Starting Current A 2.7 3.7
Dimensions (H × W × D) mm 550 × 658 × 275 550 × 658 × 275
Packaged Dimensions (H × W × D) mm 616 × 788 × 359 616 × 788 × 359
Weight (Mass) kg 28 28
Gross Weight (Gross Mass) kg 31 31
Sound Pressure Level (H) dB(A) 46 47 46 47
Sound Power Level (H) dB 60 61 60 61
Drawing No. 3D065933 3D065934
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 5 m
