Daisy 4123 Series User manual

Make it
Daisy Data Displays, Inc.
2850 Lewisberry Road
York Haven, PA 17370
717.932.9999
www.daisydata.com
Includes Models:
4123: Carbon Fiber, Intel Core i7, 128GB Slim Sata, 16GB RAM, Battery B/U
4123AC: Cast Aluminum, Intel Core i7, 256GB 2.5” SSD, 16GB RAM, WiFi
4123AD: Cast Aluminum, Intel Atom, 128GB Slim Sata, 8GB RAM, Wi-Fi
4123AE: Cast Aluminum, Intel Core i7, 256GB 2.5” SSD, 16GB RAM
4123AF: Machined Aluminum, Intel Core i7, 128GB Slim Sata, 16GB RAM, Wi-Fi
Model 4123 Series Portable PC User Manual
DECEMBER 2018

4123 Series User Manual
ii D004-000017
DISCLAIMER
Daisy Data Displays, Inc. makes no representations or warranties with respect to the contents or use of this manual,
and specically disclaims any express or implied warranties of merchantability or tness for any particular purpose.
Daisy Data Displays, Inc. reserves the right to revise this publication and to make changes to its content, at any
time, without obligation to notify any person or entity of such revisions or changes.
Furthermore, Daisy Data Displays, Inc. makes no representations or warranties with respect to any Daisy Data
Displays manufactured equipment, and specically disclaims any express or implied warranties of merchantability
or tness for any particular purpose. Daisy Data Displays, Inc. reserves the right to make changes to any and all
Daisy Data Displays manufactured equipment, at any time, without obligation to notify any person or entity of such
changes.
FCC WARNING
Computing devices and peripherals manufactured by Daisy Data Displays generate, use, and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions in this manual may cause
interference to radio communications. Such equipment has been tested and found to comply with the limits for
a Class A computing device pursuant to Subpart J of Part 15 of the FCC Rules, which are designed to provide
reasonable protection against radio interference when operated in a commercial environment. Operation of this
equipment in a residential area is likely to cause interference, in which case the user - at his own expense - will be
required to take whatever measures may be required to correct the interference.
Some components may not have been manufactured by Daisy Data Displays, Inc. If not, Daisy has been advised by
the manufacturer of the component that the component has been tested and complies with the Class A computing
device limits as described above.
Daisy Data Displays, Inc.
2850 Lewisberry Road
York Haven, PA 17370
717.932.9999
www.daisydata.com
Copyright ©2018, Daisy Data Displays, Inc. All rights reserved.
Manual: D004-000017
December 2018
Initial Release

4123 Series User Manual
D004-000017 iii
LIMITED WARRANTY AND LIABILITY STATEMENT
To the original purchaser, Daisy Data Displays, Inc., hereinafter referred to collectively as SELLER, warrants each
of its manufactured products, and all components therein contained to be free from defects in materials and/or
workmanship for a period of 12 months from the date of purchase.
Should a malfunction or other indication of defect attributable directly to faulty materials and/or workmanship occur,
Seller will, at its option, and without charge to the customer for labor and parts, repair or replace the defective
product, F.O.B. Seller’s plant, but Seller will not be responsible for freight from Purchaser to Seller’s plant. In no
event shall Seller be liable for any loss, inconvenience or damage, whether direct, incidental, consequential or
otherwise resulting from abuse, misapplication or modication of the product, improper or faulty power, damage
resulting from repairs or alterations performed by unauthorized persons, or conditions resulting from any other
equipment attached to the product.
Seller assumes no liability for damage occurring in transit due to the product not being returned in its original
shipping material.
This warranty is exclusive and is in lieu of any warranty of merchantability or tness for a particular purpose or other
warranty of quality whether expressed or implied, except of title and against patent infringement. Correction of
nonconformities, in the manner and for the period of time provided above, shall constitute fulllment of all liabilities
of the Seller to the Purchaser with respect to, or arising out of the goods, whether based on contract, negligence,
strict tort or otherwise.
LIMITATION OF LIABILITY
The Seller shall not under any circumstances be liable for special or consequential damages, such as, but not limited
to, damage or loss of other property or equipment, loss of prots or revenues, cost of capital, cost of purchased or
replacement goods, or claims of customers of Purchaser for service interruptions. The remedies of the Purchaser
set forth herein are exclusive, and the liability of Seller respect to any contract, or anything done in connection
therewith such as the performance or breach thereof, of from the manufacture, sale, delivery, resale, installation or
use of any goods covered by or furnished under this contract whether arising out of contract, negligence, strict tort
or breach of warranty or otherwise, shall not, except as expressly provided herein, exceed the price of the goods
upon which such liability is based.
This warranty gives you specic legal rights, and you may also have other rights, which vary from state to state.
Seller makes every e󰀨ort to provide clear and accurate technical information on the application of its products in the
Operator’s Manual, and assumes no liability for misuse of the information.

4123 Series User Manual
iv D004-000017
TABLE OF CONTENTS
1.0 Introduction .................................................................................................................1
1.1 Product Description..............................................................................................................1
2.0 Customer Service........................................................................................................2
3.0 Software/Hardware......................................................................................................2
4.0 UnitCertications .......................................................................................................3
4.1 Model 4123 Special Conditon..............................................................................................3
5.0 CerticateofCompliance ........................................................................................... 4
6.0 Specications ..............................................................................................................5
7.0 Models/Components ...................................................................................................5
7.1 BaseModel4123SeriesCongurations ................................................................... 5
7.2 Model 4123(xx) Critical Components...................................................................................6
7.3 Glandplate Components ......................................................................................................8
7.4 Model 4123(xx) Series Field Wiring Diagrams.....................................................................9
7.4.1 Model 4123 Field Wiring Diagram .......................................................................................... 9
7.4.2 Model 4123AC Field Wiring Diagram.................................................................................... 10
7.4.3 Model 4123AD Field Wiring Diagram.....................................................................................11
7.4.4 Model 4123AE Field Wiring Diagram.................................................................................... 12
7.4.5 Model 4123AF Field Wiring Diagram.................................................................................... 13
7.5 Model 4123(xx) Series Block Diagrams.............................................................................14
7.5.1 Model 4123 Block Diagram................................................................................................... 15
7.5.2 Model 4123AC Block Diagram.............................................................................................. 16
7.5.3 Model 4123AD Block Diagram.............................................................................................. 17
7.5.4 Model 4123AE Block Diagram.............................................................................................. 18
7.5.5 Model 4123AF Block Diagram.............................................................................................. 19
7.6 Model 4123(xx) Series Mechanical Drawings....................................................................20
7.6.1 Model 4123 Mechanical Drawings........................................................................................ 20
7.6.2 Model 4123AC Mechanical Drawings................................................................................... 22
7.6.3 Model 4123AD Mechanical Drawings................................................................................... 24
7.6.4 Model 4123AE Mechanical Drawings................................................................................... 26
7.6.5 Model 4123AF Mechanical Drawings ................................................................................... 28
8.0 SupplyPowerConnection(100-240VAC)................................................................ 30
8.1 Bayonet-style Quick Connect/disconnect Power Connection............................................30
8.1.1 Connecting KPT/KPSE Bayonet-style Quick Connect.......................................................... 31
8.2 Sealcon Cord Grip/Internal Power Connection..................................................................31
8.2.1 Installing Internally Connected Power Source Cable............................................................ 32
9.0 KeypadLayout........................................................................................................... 35
10.0InstallationandWarnings.........................................................................................36
11.0BatteryStorageandOperation(Model4123) ......................................................... 36
12.0Repair,MaintenanceandWarnings ......................................................................... 36
12.1 Repairs............................................................................................................................36
12.2 Maintenance....................................................................................................................37
13.04123(xx)GeneralTroubleShooting ......................................................................... 38
14.0 Revisions ...................................................................................................................39

4123 Series User Manual Introduction
D004-000017 1
1.0 Introduction
This manual will detail the the Model 4123 Series Portable PC manufactured by Daisy Data Display, Inc.
1.1 ProductDescription
The Model 4123 Series Portable PC is a mobile HMI PC certied for a Zone 2 (Information
Technology) enviornment. The highly durable, sleek mobile design of the Model 4123 allows for the
unit to be used in a variety of locations.
While adhering to the stringent design parameters to meet the Zone 2 hazardous location rating,
Daisy Data Displays has engineered the core functionality of the Model 4123 around ve (5) base
model congurations, with options. This exibility makes the Model 4123 suitable for a variety of
applications that include: Oil and Gas Industry, the military, pharmeceutical and food processing.
For more information contact
2850 Lewisberry Rd
York Haven, PA 17370
www.daisydata.com
Daisy Data Displays, Inc.
p 717.932.9999
f 717.932.8000
e [e-mail]
:

2D004-000017
Customer Service 4123 Series User Manual
2.0 Customer Service
All Daisy systems pass detailed quality control conguration and inspection before being shipped.
Daisy strives to create the highest quality systems, and chooses top quality parts. However, like most
electronic devices, units may experience issues over time. Should you experience problems, or have
any further inquiries or comments, please contact Daisy’s customer service department:
Business Phone: [phone] x222
Fax: [phone]
Email: [email protected]
Equipment returned to Daisy for service must be accompanied by a valid return merchandise
authorization (RMA) number. Items or products shipped to Daisy without a valid RMA number will be
refused. An RMA will be generated upon receipt of Company Name, Address, Contact, Product Model
and Serial Numbers.
Figure 1 — Daisy Data Product ID Tag
Daisy Data Displays Inc. prides itself on o󰀨ering best in class support for your products. Our technical
support team can help you with installation, conguration, troubleshooting, and other support issues
for all Daisy’s products.
3.0 Software/Hardware
Daisy data should be contacted for any hardware or software questions/issues. Additional SSD’s or
operating systems can be supplied as needed. Be aware that any modications or alterations without
the assistance of Daisy Data could a󰀨ect unit certications and implied warranty.
!! IMPORTANT NOTE ON ORDERING REPLACEMENT PARTS !!
All Daisy Data Display products undergo continual improvement to ensure they meet the
myriad of regulatory standards and codes for equipment operating in hazardous enviornments.
These improvements or modications may e󰀨ect Daisy Data products already in the eld.
With that in mind, as a customer servicing your own product, it is highly reccomended that you
contact your Daisy Data Display customer service representative to conrm any part or part
number you may be looking to replace. Your Daisy representative will ensure you are getting
the correct part, or the possible availability of a suitable replacement part to ensure your
equipment continues to meet the standards and/or codes originally intended.

4123 Series User Manual Unit Certications
D004-000017 3
4.0 Unit Certications
The 4123 Series Portable PCs are third-party certied for ATEX Zone 2 locations as detailed below.
Table 1 — Product Rating Description
Symbol/Rating Description
European Conformity
Manufactured according to applicable EU Directivies
Special Marking
signifying equipment used in explosive atmospheres
II Equipment Group (Gas/Dust)
3Equipment Catagory (Normal Protection)
GHazardous Atmospheres (Gas, Vapour, Mist)
Ex European Hazardous Location Standard Certied
nA Non-incendive
IIC Gas Group
T4 Temperature Class (T4=135ºC max)
Gc Zone 2 Protection Methods
0ºC <Ta <+40ºC Model 4123 (Only) Operating Temperature Range
-20ºC <Ta <+55ºC Models 4123AC, 4123AD, 4123AE, 4123AF
4.1 Model 4123 Special Conditon
Due to the front enclosure on the Model 4123 Portable PC having a carbon ber faceplate, a Daisy
Data Option 821 (Sun Visor) needs to be installed if exposure to ultraviolet light is anticipated. This
Sun Visor (Option 821) Special Condition is specically for the Model 4123 to meet the Resistance to
Light, EN-IEC 60079-0 (clause 7.3) requirement.
When a Model 4123 utilizes the Option 821 Sun Visor in it’s construction to meet the Special
Condition requirement, its product nameplate will denote this with an “X” marking proceeding the
rating nomenclature as shown below:
e.g. Ex nA T4 0ºC < Ta < 40ºC X
Figure 2 — Typical Model 4123 / Product Certication ID

4D004-000017
Certicate of Compliance 4123 Series User Manual
5.0 CerticateofCompliance
EC Declaration of Conformity
Date:Wednesday, November 21, 2018
Company Name: Daisy Data Displays, Inc.
Company Address: 2850 Lewisberry Road, York Haven, PA 17370
The Daisy Data Displays Series 4123(xx) Portable PC fully complies with the following directives:
•EMC Directive 2014/30/EU
•Low Voltage Directive 2014/35/EU
•RoHS Directive 2011/65/EU
•ATEX Directive 2014/34/EU
The following EN/IEC standards were used to verify compliance:
•EN 55032:2012 (EN 61000-3-2, EN 61000-3-3)
•EN 55024:2010 (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-11)
•EN 60950-1:2006+A11(2009)+A12(2011)+A1(2010)+A2(2013)
•EN-IEC 60079-0:2017, EN-IEC 60079-1:2014, EN-IEC 60079-7:2017, EN-IEC 60079-15:2017
•IEC 60529 ed. 2.2 Dated 2013-08
According to information provided, our suppliers do not use in the manufacture of the
components they supply us, hazardous substances as mentioned in the above RoHS
Directive 2011/65/EU. We do not systematically analyze the supplied materials but
require from our suppliers a certificate of compliance for raw materials. This declaration of
conformity is used under the sole responsibility of the manufacturer.
David “Avi” Shefet
President
Daisy Data Displays, Inc.
Model: 4123
Rating:Ex nA IIC T4 Gc 0°C<Ta<+40°C X
Models: 4123AC, 4123AD, 4123AE, 4123AF
Rating:Ex nA IIC T4 Gc -20°C<Ta<+55°C
Figure3—CerticateofCompliance

4123 Series User Manual Specications
D004-000017 5
6.0 Specications
Table2—Model4123xxTechnicalSpecications
MATERIALS All materials comply with IEC 60529 IP66 Standards
Enclosure and Hardware
Model 4123 Carbon Fiber1, 6061-T6 Aluminum
Model4123AC,4123AD,4123AE A356.2 Cast Aluminum
Model 4123AF Machined Aluminum 6061-T6
MECHANICAL
See dimentional drawings - See Section 7.6 Model 4123(xx) Series Mechanical Drawings
ENVIRONMENTAL
Model 41231
Ingress Protection IP66
Operating Temperature (No Heater) -0ºC to 40ºC
Storage Temperature -0ºC to 40ºC
Relative Humidity 5% to 95%
Model 4123AC
Model 4123AD
Model 4123AE
Model 4123AF
Ingress Protection IP66
Operating Temperature (No Heater) -20ºC to 55ºC
Storage Temperature -20ºC to 75ºC
Relative Humidity 5% to 95%
ELECTRICAL
Voltage 100-240VAC 47-63Hz
Current 1.8A
AIR REQUIREMENTS
Air Pressure N/A
DISPLAY
Resolution (max) 1024x768
Viewing Angle 80º x 80º
Typical Brightness 600 nits
Color Depth 24 bit
7.0 Models/Components
The Model 4123 Series Portable PC is based upon ve (5) unique base models incorporating a standard
set of components/options for each model. In addition to the standard components/options, each model has
a specic glandplate designed for it.
7.1 BaseModel4123SeriesCongurations
The Model 4123 Series Portable PCs are designed around ve (5) distinct models with a standard set
of critical components. Each of these models are dened by specic base model congurations as
shown in Table 3 below.
Table3—4123(xx)–ULListed,ATEXZone2CertiedModelCongurations
Model Number Enclosure Material Processor Hard Drive RAM Misc. GlandplateAssembly
4123 Carbon Fiber1Intel Core i7-2610UE 128GB Slim SATA 16GB Battery B/U I640-002303
4123AC Cast Alluminum Intel Core i7-6600U 256GB SSD 16GB WiFi I640-002325
4123AD Cast Alluminum Intel Atom-E3845 128GB SSD 8GB WiFi I640-002322-01
4123AE Cast Alluminum Intel Core i7-6600U 256GB SSD 16GB N/A I640-002323
4123AF Machined Alluminum Intel Core i7-2610UE 128GB SSD 16GB WiFi I640-002325
1-Option821(SunVisor)mustbeusedtomeettheSpecialConditionrequirementtomaintainATEXZone2Certicationif
theModel4123carbonberfaceplateisexposuredtoultraviolentlight.

6D004-000017
Models/Components 4123 Series User Manual
7.2 Model4123(xx)CriticalComponents
Each of the ve (5) Model 4123 Series Portable PCs are constructed around a set of standard critical
components. These components are shown in Table 4.
Table4—4123(xx)ULListed,ATEXZone2CertiedCriticalComponents
MODEL PART NO. DESCRIPTION
4123
P010-000101 110VAC Power Supply
P310-005000 Motherboard – COM Express carrier board
P000-000139 15” LCD Display
P040-000080 15” Glass on Glass Resistive Touch Screen
I301-010005 Nine Button Membrane
I202-700011 Membrane Controller
P040-100030 Touch Screen Controller (GoG Resistive)
P050-200007 Intel i7 2nd gen module
P062-120001 Storage (128GB Slim SATA)
A314-318000 8GB DDR3 Memory (used with 2nd gen i7 module)
E905-000017 14.4V Smart Battery
4123AC
P010-000101 110VAC Power Supply
P310-005000 Motherboard – COM Express carrier board
P000-000139 15” LCD Display
P040-000098 15” Projected Capacitance Touch Screen
I301-010005 Nine Button Membrane
I202-700011 Membrane Controller
P040-100048 Touch Screen Controller (PCAP)
P050-210002 Intel i7 6th gen Module
P060-000099 Storage (256GB 2.5” SSD)
A314-418000 8GB DDR4 Memory (used with 6th gen i7 module)
E907-000001 Antenna
P050-000286 Wireless Card
4123AD
P010-000101 110VAC Power Supply
P310-005000 Motherboard – COM Express carrier board
P000-000139 15” LCD Display
P040-000098 15” Projected Capacitance Touch Screen
I301-010005 Nine Button Membrane
I202-700011 Membrane Controller
P040-100048 Touch Screen Controller (PCAP)
P050-210000 Intel Atom E3845 Module
P062-120001 Storage (128GB Slim SATA)
A314-314003 8GB DDR3L Memory (used with Atom E3845 module)
E907-000001 Antenna
P050-000286 Wireless Card

4123 Series User Manual Models/Components
D004-000017 7
Table4—4123(xx)ULListed,ATEXZone2CertiedCriticalComponents
MODEL PART NO. DESCRIPTION
4123AE
P010-000101 110VAC Power Supply
P310-005000 Motherboard – COM Express carrier board
P000-000139 15” LCD Display
P040-000098 15” Projected Capacitance Touch Screen
I301-010005 Nine Button Membrane
I202-700011 Membrane Controller
P040-100048 Touch Screen Controller (PCAP)
P050-210002 Intel i7 6th gen Module
P060-000099 Storage (256GB 2.5” SSD)
A314-418000 8GB DDR4 Memory (used with 6th gen i7 module)
4123AF
P010-000101 110VAC Power Supply
P310-005000 Motherboard – COM Express carrier board
P000-000139 15” LCD Display
P040-000098 15” Projected Capacitance Touch Screen
I301-010005 Nine Button Membrane
I202-700011 Membrane Controller
P040-100048 Touch Screen Controller (PCAP)
P050-200007 Intel i7 2nd gen module
P062-120001 Storage (128GB Slim SATA)
A314-318000 8GB DDR3 Memory (used with 2nd gen i7 module)
E907-000001 Antenna
P050-000286 Wireless Card
* Shaded parts represent critical components common in ALL Model 4123 Series units

8D004-000017
Models/Components 4123 Series User Manual
7.3 GlandplateComponents
Each 4123 Series Portable PC model is designed with specic user connections. These connections
are pentrations through the enclosure that are specically designed to seal the the internal
components from any possible outside hazardous enviroment that could exist. Each model has a
specic glandplate (1 of 4) designed for it as shown in Table 3. See Table 5 below for the connections
assigned to each glandplate.
Table5—4123(xx)–ULListed,ATEXZone2CertiedGlandplateCongurations
GlandAssembly Includes
I640-002303 Cord grip, 2 USB Ports, 1 RJ45 Port
I640-002322 Cord grip, 2 USB Ports, 1 RJ45 Port
I640-002323 Power Connector, 2 USB Ports, 2 RJ45 Ports
I640-002325 Power Connector, 2 Lemo Connectors, 2 USB Ports, 1 RJ45 Port
Figure4—I640-002303GlandplateConguration
Figure5—I640-002322GlandplateConguration
Figure6—I640-002323GlandplateConguration
Figure7—I640-002325GlandplateConguration

4123 Series User Manual Models/Components
D004-000017 9
7.4 Model4123(xx)SeriesFieldWiringDiagrams
The Model 4123 Series gland plate provides all the recepticles for external connections. Each
recepticle is a standard component provided to meet the hazardous location-rated connection the unit
was designed for.
The customer is responsible obtaining and making all external connections. In addition, care must be
taken when making the external connections to the Model 4123xx. The unit MUST be de-enegized
and/or the location rendered a non-hazardous area beforehand.
The following eld wiring diagrams depict each gland plate and the external connection provided.
These diagrams also show the customer-supplied connector required to make the connection and
where they are to be located within the hazardous and non-hazardous area.
7.4.1 Model4123FieldWiringDiagram
Figure8—Model4123FieldWiringDiagram

10 D004-000017
Models/Components 4123 Series User Manual
7.4.2 Model4123ACFieldWiringDiagram
Figure9—Model4123ACFieldWiringDiagram

4123 Series User Manual Models/Components
D004-000017 11
7.4.3 Model4123ADFieldWiringDiagram
Figure10—Model4123ADFieldWiringDiagram

12 D004-000017
Models/Components 4123 Series User Manual
7.4.4 Model4123AEFieldWiringDiagram
Figure11—Model4123AEFieldWiringDiagram

4123 Series User Manual Models/Components
D004-000017 13
7.4.5 Model4123AFFieldWiringDiagram
Figure12—Model4123AFFieldWiringDiagram

14 D004-000017
Models/Components 4123 Series User Manual
7.5 Model4123(xx)SeriesBlockDiagrams
The Model 4123 Series Portable PC comes in ve standardized conguations as described in “7.1 Base
Model 4123 Series Congurations” on page 5. The following block diagrams detail each of the base
models and the components contained in each.
Model 4123 Block Diagram
Model 4123AC Block Diagram
Model 4123AD Block Diagram
Model 4123AF Block Diagram
Model 4123AF Block Diagram
Figure13—Model 4123 Series Portable PCs

4123 Series User Manual Models/Components
D004-000017 15
7.5.1 Model4123BlockDiagram
Figure14—Model4123BlockDiagram

16 D004-000017
Models/Components 4123 Series User Manual
7.5.2 Model4123ACBlockDiagram
Figure15—Model4123ACBlockDiagram
