Damon Astoria 2006 User manual

Owners Manual

[phone]
Congratulations on your recent purchase of a Damon Motor Coach Recreational Ve-
hicle. We sincerely thank you for choosing and putting your faith in Damon, and we
would like you to know that your satisfaction is of great importance to us. Our major
goal is to provide you with a quality recreational vehicle at a reasonable price.
Your unit has been designed to provide you with many years of carefree, comfort-
able travel and vacationing. We hope that it will bring you that, along with many years
of enjoyment and pleasant memories.
This manual will help you better understand the features and operating perfor-
mances of your recreational vehicle. Please read it and keep it in your vehicle for
future reference.
Our customers are extremely important to us, and we want to assure you that we will
always strive to do everything possible to continue to earn your trust and goodwill.
Welcome to the wonderful world of RVing and the Damon family.
Happy Travels!
Damon Motor Coach

The purchaser of a Damon Vehicle should complete and promptly return to Damon this registration
form. This form is not necessary in order to obtain warranty service. However, a purchase receipt or
other proof of date of original consumer purchase will be required before warranty service is rendered.
Federal law requires that Damon maintain records of the names and addresses of the owners of its
Vehicles and the respective identication numbers of such Vehicles. The information contained in this
and other forms will assist Damon in the prompt servicing of such Vehicles.
I have read, understand, and am fully aware of the terms, conditions and requirements of the Damon
Limited Warranty, and how to obtain warranty service under this Limited Warranty. I also have re-
ceived and read a copy of the Damon Owner’s Manual for this RV with a copy of the Limited Warranty.
Last Name _______________________________ First____________________________Mi
Address _________________________________________________________________
City ____________________________________ State Zip
Telephone ( ) __________________________ E-Mail _________________________
Damon Serial Number:_____________________________________________________
Chassis VIN: ______________________________________________________________
Date of Purchase: _________________________________________________________
Mileage or Kilometers (circle one) on Odometer: ___________________________________________
________________________________________ Signature of Purchaser: _________________________
________________________________________ Signature of Purchaser: _________________________
Selling Dealer:
City ____________________________________ State Zip
PERFORATED - TEAR HERE
DAMON MOTOR COACH
CUSTOMER SERVICE DEPARTMENT
P.O. BOX 2888
ELKHART, IN. USA 46515-2888

FOLD HERE
FOLD HERE
DAMON MOTOR COACH
CUSTOMER SERVICE DEPARTMENT
PO BOX 2888
ELKHART, IN. USA 46515-2888
TAPE-PLEASE DO NOT STAPLE
TAPE-PLEASE DO NOT STAPLE
PLACE
STAMP
HERE

I
INTRODUCTION
Introduction.....................................................................................1
How to use this manual..................................................................2
Reporting Safety Defects................................................................2
Major Equipment Suppliers............................................................3
WARRANTY – Chapter 1
Damon Limited Warranty................................................................5
Owner Responsibility......................................................................6
Owner Responsibility Checklist............................ ...........8
PLANNINGAND PREPARATION – Chapter 2
License and Insurance.................................................................11
Inspect and Maintain....................................................................11
Loading and Weight......................................................................11
Controlling the Motorhome...........................................................11
Pre–Travel Checklist.....................................................................12
Opening Checklist........................................................................13
Weights.........................................................................................14
Federal Certification Label............................................................14
Weight Ratings.............................................................................15
Capacity........................................................................................15
Weighing Your Motorhome...........................................................16
Weight Distribution .......................................................................17
Trailer Hitches and Towing...........................................................17
Towing and GCWR.......................................................................18
ON THE ROAD SAFETY– Chapter 3
Safety Belts..................................................................................19
Fuel System..................................................................................19
Driving..........................................................................................19
Parking.........................................................................................20
Changing tires..............................................................................20
Tire Care.......................................................................................21
Air Pressure..................................................................................21
SAFETY PROVISIONS – Chapter 4
Smoke Detector............................................................................23
Fire Extinguisher...........................................................................23
LP Gas Detector...........................................................................23
CO Detector..................................................................................24
Carbon Monoxide Precautions.....................................................24
LightingAppliances.......................................................................24
Emergency Exit Locations............................................................24
PLUMBING SYSTEMS - Chapter 5
Water Pump and Filter..................................................................25
Fresh Water Fill/Tank....................................................................25
City Water Hook – up....................................................................25
Low Point Drains..........................................................................26
Sanitizing the Fresh Water System..............................................26
Heated Holding Tanks ..................................................................27
Dumping the Holding Tanks..........................................................27
How to Prevent Blockage.............................................................27
Termination Compartment Fixtures ..............................................28
TECHNICALSYSTEMS - Chapter 6
Chassis Electrical.........................................................................29
Coach Electrical............................................................................29
DC System...................................................................................29
Converter / Inverter.......................................................................30
AC System....................................................................................30
GFCI.............................................................................................30
Battery Control Center (BCC).......................................................31
Generator.....................................................................................31
Monitor Panel...............................................................................32
RoofAir Conditioner.....................................................................32
LP Gas..........................................................................................33
LP Gas Tank.................................................................................34
LP Gas Regulator.........................................................................34
Home Theater Programming........................................................35
Home Theater Operation..............................................................36
Home Theater Trouble Shooting ..................................................38
INTERIOR SYSTEMS – Chapter 7
Automotive Dash..........................................................................39
Gear Selector...............................................................................39
Engine Block Heater.....................................................................39
Fuel Selection...............................................................................39
Dash Board Controls....................................................................40
Symbols of Switches....................................................................40
Steering Wheel.............................................................................41
Engine Brake Switch....................................................................42
Air Suspension.............................................................................42
Backup Monitor.............................................................................42
Heating and Cooling Controls.......................................................42
Parking Brakes.............................................................................42
Leveling System...........................................................................42
Storage above Cockpit.................................................................43
Front Television ............................................................................44
Interior StorageAreas...................................................................44
Entry Storage and Step Cover......................................................44
Under Bed Storage.......................................................................44
EngineAccess Panel ..................................................................... 44
Extending the Room.....................................................................44
Retracting the Room.....................................................................45
Hide-A-Bed Sofa...........................................................................46
Sofa Bed ........................................................................................ 46
Sliding Door and Latch.................................................................46
Day/Night Shade..........................................................................46
Furnace Thermostat.....................................................................46
Water Heater Switch.....................................................................46
Cabinets.......................................................................................46
Galley Drawers.............................................................................47
Pantry...........................................................................................47
Range...........................................................................................47
Refrigerator...................................................................................47
Microwave....................................................................................47
Sink...............................................................................................47
Faucet................................................................... .....................47
Dinette Bench Conversion............................................................48
Bath Vent......................................................................................48
Shower Head and Hose...............................................................48
Toilet.............................................................................................48
Washer/Dryer Combination Machine ............................................. 48
EXTERIOR SYSTEMS - Chapter 8
Main Entrance..............................................................................49
EntryAssist Handle......................................................................49
Electric Step.................................................................................49
Table of Contents

II
Compartment Doors.....................................................................49
Rear Ladder..................................................................................49
Awning..........................................................................................49
TV Cable and Telephone Hookup.................................................50
120 Volt Outlet..............................................................................50
120 Volt Cord................................................................................50
Generator Compartment...............................................................50
Furnace Door................................................................................50
Water HeaterAccess Panel..........................................................50
Refrigerator Panel........................................................................51
Automotive Fuse Block.................................................................51
Satellite Dish .................................................................................. 51
Dual Stage Gas Support Pistons .................................................... 51
Fantastic Power Vent ..................................................................... 51
CAREAND MAINTENANCE - Chapter 9
Batteries.......................................................................................53
Waste Water System....................................................................54
Fresh Water System.....................................................................54
Electrical System..........................................................................54
Generator Power Plant System....................................................54
LP Gas System.............................................................................55
ABS Plastic Parts.........................................................................55
MotorhomeAlignment...................................................................55
Awning..........................................................................................55
Motorhome Chassis......................................................................56
Doors and Door Locks..................................................................56
Exterior Lights...............................................................................56
Fiberglass Exterior........................................................................57
Wax...............................................................................................57
Graphics.......................................................................................58
Sidewalls......................................................................................58
Roof..............................................................................................58
Roof Vents....................................................................................59
Seals andAdhesives....................................................................59
Slide-Out.......................................................................................60
Tires..............................................................................................60
TVAntenna...................................................................................60
Satellite Dish.................................................................................61
Underbody....................................................................................61
Windows.......................................................................................61
Hydraulic Fluid .............................................................................. 61
Appliances....................................................................................62
Bath Fixtures................................................................................62
Bathtub Seal.................................................................................62
Bedspread / Draperies / Valance / Headboards...........................62
Carpet...........................................................................................62
Ceramic Tile .................................................................................. 62
Carbon Monoxide Detector...........................................................62
High Pressure Laminates.............................................................62
Hardware /Accessories / Light Fixtures.......................................63
Kitchen Fixtures ............................................................................. 63
Mini Blinds / Day Night Shades....................................................63
Table of Contents Sinks.............................................................................................63
Solid Surface Countertops............................................................63
Upholstery and Fabrics.................................................................64
Vinyl Cabinetry .............................................................................64
Wall Coverings..............................................................................64
Windows (Interior)........................................................................64
Wood Cabinetry............................................................................64
WINTER USEAND STORAGE - Chapter 10
Water Systems.............................................................................65
Food Storage................................................................................65
LP Gas System.............................................................................65
Heating.........................................................................................65
Condensation...............................................................................65
Winterization Procedures.............................................................66
Water Heater Bypass....................................................................67
Storage and Winterization Checklist.............................................68
MAINTENANCE SCHEDULE...........................................................71
TRAVEL PREPARATION CHECKLIST ............................................. 72
SERVICE / MAINTENANCE RECORD............................................73
FUEL/ OIL RECORD..................................................................74-75
NOTES.............................................................................................77
TROUBLESHOOTING
RoofAir Conditioner.....................................................................81
Battery Control Center (BCC).......................................................81
Electrical Power............................................................................82
Electric Step.................................................................................82
Furnace........................................................................................82
Generator.....................................................................................83
Interior Lights................................................................................83
Leveling Jacks..............................................................................83
LP Gas..........................................................................................84
Microwave Oven...........................................................................85
Monitor Panel...............................................................................85
Outside Receptacle......................................................................85
Oven.............................................................................................85
Power Inverter..............................................................................86
Slide-Out Room............................................................................86
Water Systems.............................................................................87
Water Pumps................................................................................87
Refrigerator...................................................................................87
Coach Battery...............................................................................88
Running Lights..............................................................................88
Termination Valve.........................................................................88
TVAntenna .................................................................................... 88
Satellite Dish.................................................................................89
Waste Tanks.................................................................................89
Water Heater................................................................................90
ELECTRICALDIAGRAMS...............................................................92
INDEX.............................................................................................107

Introduction
This manual describes many features of your motorhome and provides a guide to operating procedures so that you can
obtain the best performance from those features. Your motorhome has been designed to conform with, or exceed, the
American National Standards Institute A 119.2, NFPA 1192, CANADIAN CAN/CSA-Z240 RV SERIES-99 (Canadian-
built or units built for Canada), and applicable motor vehicle safety standards. These standards establish the plumbing,
heating, electrical and other requirements for quality and safety. The seal attached just outside the entry door indicates
compliance with these standards. This seal is the outward sign of internal quality.
Like all automotive equipment, your motorhome will require care and regular maintenance in order to retain its maxi-
mum performance characteristics. This manual, along with the specific instructions provided by the leading appliance
manufacturers, are in your Owner’s Information Kit. The Chassis Operator’s Manual outlines important areas of service
and provides a maintenance schedule. Please follow them carefully to ensure a safe trouble-free service. Study these
instructions carefully. A good working knowledge of your unit and how to care for it will help you enjoy many miles and
years of recreational living.
If you have any questions regarding operation, maintenance, or service, please contact your dealer immediately so they
can assist you. Your dealer’s Service or Sales Department is equipped to handle most any problem that may occur.
Customer service is of the utmost importance to your dealer and is just as important to the manufacturer. This manual
contains a section outlining the warranty and explaining your rights and obligations, as well as the rights and obligations
of the dealer and manufacturer, under the terms of the warranty. Please read this section carefully. You will be better
informed in case you have a warranty related problem and your dealer will be better able to get you back on the road
again in a timely manner.
We sincerely believe that your dealer and the factory representative will be able to solve any problem which may arise. If
their combined efforts are not satisfactory, please send a letter describing the circumstances to:
Damon Motor Coach
Customer Service Department
PO Box 2888
Elkhart IN 46515-2888
You must include the dealer’s name, model and serial number of your motorhome. The Damon serial number is located
on the bottom of the federal sticker, which is located in the driver’s compartment area. Thank you for choosing our
product. Your dealer and we, the manufacturer, will continually strive to merit your confidence.
Some equipment and features described or shown in this manual may be optional on your model. This
instructional manual is of a general nature only. Because of the continuous process of product im-
provement conducted by Damon Motor Coach, it is possible that recent product changes
may not be included in this manual. Specifications may change without notice. This manual is accurate as of the date
of publication. The instructions included in this manual are intended as a guide, and in no respect extend the responsi-
bilities of the manufacturing subsidiary, parent company or affiliates beyond the standard written warranty as
presented in this manual.
Photographs or illustrations in this manual are representative of function and may or may not be specific in
their depiction of actual equipment, fabrics, interior or exterior decor, or design options as installed on or in your
motorhome.
This product is designed to provide temporary living quarters for recreational, camping, or travel. Use of this
product for long term or permanent occupancy may lead to premature deterioration of interior finishes, fabrics,
carpeting, drapes, or components. Damage or deterioration due to long term occupancy may not be
considered normal, and may under the terms of the warranty, constitute misuse, abuse, or neglect, and may therefore
reduce or void certain warranty protection.

Introduction
HOW TO USE THIS MANUAL
Your motorhome has been thoroughly inspected before shipment to the dealer. Your selling dealer is responsible for
performing a complete pre-delivery inspection of all motorhome components as specified in the pre-delivery checklists
supplied by the manufacturer. You should receive a copy of these completed checklists from your dealer when the mo-
torhome is delivered to you.
Should a problem arise, your first step is to contact your selling Damon dealer who will be glad to handle your situation.
This Owner’s Manual is not intended for use as a service manual, but rather as a guide to help you become familiar with
your motorhome.
This manual is not model specific, which means that it is used for a variety of different models that Damon manu-
factures. It is of a general nature, so the illustrations and descriptions may not be exactly as they are in your particular
motorhome.
If you are unclear or unfamiliar with any procedure that is described in this manual, see your Damon dealer for further
clarification before proceeding.
Damon Corporation uses the following notations to warn the user of possible safety concerns and to provide infor-
mation that will prevent personal injury to the user and/or damage to the motorhome.
A WARNING INDICATES AN INSTRUCTION OR PROCEDURE THAT YOU
MUST FOLLOW TO AVOID SERIOUS PERSONAL INJURY.
A CAUTION INDICATES AN INSTRUCTION OR PROCEDURE THAT YOU MUST
FOLLOW TO AVOID DAMAGING EQUIPMENT OR COMPONENTS.
SERIOUS PERSONAL INJURY COULD ALSO OCCUR.
A NOTICE INDICATES AN INSTRUCTION OR PROCEDURE THAT IS
IMPORTANT FOR PROPER SERVICE. A NOTICE CAN ALSO SUPPLY
INFORMATION THAT WILL HELP TO MAKE YOUR CAMPING
EXPERIENCE MORE PLEASANT.
REPORTING SAFETY DEFECTS
If you believe that your vehicle has a defect, which could cause an accident, injury, or death, you should immediately
inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Damon Motor Coach.
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of
vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems
between you and your dealer or Damon Motor Coach.
To contact NHTSA, you may either call the Auto Safety Hotline toll free at 888-327-4236 (or 202-366-0123 in the
Washington DC area), TTY: 800-424-9153, or write to: US Department of Transportation, NHTSA, 400 Seventh Street
SW, Washington DC, USA 20590. You can go to the NHTSA website, www.nhtsa.gov. You can also obtain other in-
formation about motor vehicle safety from the Hotline.

Introduction
MAJOR EQUIPMENT SUPPLIERS
Please read your recreational vehicle warranty carefully. It is very important to know what Damon Motor Coach war-
rants, and what is warranted by other suppliers’ warranties. Damon Motor Coach does not warrant some items within
your vehicle. Below you will find a list of manufacturers who can help you with these components. Please contact them
should a need arise.
ACME / Dash Air Conditioning ..............................................................................800-522-2263
ASA / Audiovox / Backup Monitor & Radio ............................................................800-688-3135
Atwood / Water Heater & Furnace .........................................................................815-877-5700
Bob Gunn / Velvac / Exterior Mirrors & Backup Monitor & Camera .........................574-262-2518
Bristol Laminating / Corian / Countertops ...............................................................574-848-4461
Carrier Transport / Roof Air Conditioning ................................................................800-450-2211
Coachstep / Electric Step ...................................................................................800-451-9245
Dometic / Awning & Refrigerator ..........................................................................574-294-2511
Flair International / Furniture ..................................................................................574-295-5688
Freightliner / Chassis ...........................................................................800-FTL-HELP(385-4357)
Generac / Generator ............................................................................................574-293-6503
Hehr / Windows ...................................................................................................517-845-3061
Lippert Components / Slideout & Leveling Jacks ..................................................574-537-8900
Magnum Energy / 2000W Inverter .........................................................................425-353-8833
Midwest Sales / Microwave ..................................................................................574-287-3385
Norco / Slideouts ................................................................................................574-262-3400
Odyssey Group / TV’s .........................................................................................574-848-2277
Onan / Generator .................................................................................................800-888-6626
Progressive Dynamics / 80amp Converter ............................................................269-781-4241
Putnam / Hitch .....................................................................................................517-369-2165
Sealand / Toilet ..................................................................................................800-321-9886
Shaw Industries / Carpet .......................................................................................574-264-9687
Shurflo / Water Pump ...........................................................................................800-762-8094
Thetford / Toilet (Michigan Residents 313-769-6000) ...............................................800-521-3032
Trico (Alta) / Wipers .............................................................................................888-421-5874
Tristar / Microwave ...............................................................................................800-456-3340
Ventline / Range Vent & Monitor Panel ..................................................................574-848-4491
Westland Sales / Washer/Dryer ...........................................................................800-356-0766
Williamsburg / Furniture ........................................................................................574-773-7711
Winegard / TV Antenna & Satellite Dish .................................................................319-753-0121
This list may not be all inclusive. If you have any questions regarding other components, call Damon Customer Service
at 574-264-2900. A complete listing of all your unit’s appliances along with their corresponding serial numbers is located
on the wall inside your wardrobe. Please refer to this list if you need to contact the manufacturer regarding the ap-
pliance.

Introduction

5
Chapter 1 - Warranty
LIMITED WARRANTY
When purchased from an authorized Damon Corporation (“Damon”) dealer and used for its intended
purpose of recreational travel and camping, Damon warrants your recreation vehicle (“RV”) will be free
from defects in material and workmanship attributable to Damon for a period of twelve (12) months
or 12,000 miles, whichever occurs rst. However, Damon further warrants the steel or aluminum frame
structure of the roof, front and rear walls, and sidewalls (excluding slide-outs), for twenty four (24) months
or 24,000 miles, whichever comes rst.
The warranty period shall begin on the date that the RV is delivered to the rst retail purchaser or the
date that the RV is rst placed in service by the dealer for personal use prior to sale at retail, whichever
occurs rst. This Limited Warranty is not transferable and covers only materials, components or parts of
the RV manufactured and nally assembled by Damon, and does not replace or extend, the warranties
provided by the independent manufacturers which have issued warranties attributable to their products
separately for materials, components, or parts used in the manufacture of this RV. For additional limita-
tions on this Limited Warranty, please refer to the section entitled “What is Not Covered” below.
In the event that a defect in materials or workmanship is found to exist, Damon at its option, will provide
for the repair or replacement of such defective material or workmanship at no charge to the RV owner
in accordance with the terms, conditions and limitations of this Limited Warranty. To obtain warranty
service, the RV owner must do all of the following:
(a) complete and return to Damon the Owner Registration Form in the Owner’s Manual within ten (10)
days of delivery
(b) notify in writing Damon or one of its authorized, independent dealers of the claimed defect within
ten (10) days of the date that the claimed defect is or should have been discovered; and
(c) promptly return the RV to Damon or an authorized dealer for such repairs. All costs incurred in trans-
porting the RV for warranty service shall be the responsibility of the RV owner.
Damon’s obligation to repair or replace defective materials is the sole obligation of Damon under this
Limited Warranty. Damon specically makes no warranty as to the future performance of this RV or
any of its materials, components, or parts.
Please inspect your RV at the time of delivery and make sure you accept it as delivered to you. This RV has
been sold to an independent dealer, and not an agent of Damon, for resale in the ordinary course of the
dealer’s business on terms and conditions and equipped as he and you determine, and your agreement
is solely with the dealer, not Damon. Damon does not participate in the retail sales agreement other
than by the terms of this Limited Warranty.
The RV owner’s obligation to notify Damon or one of its authorized, independent dealers of a claimed
defect does not replace, alter, or modify the obligations, if any, placed on the RV owner to contact Da-
mon directly when pursuing remedies under applicable state or federal laws. If, after two attempts, any
required repair that substantially impairs the value, use or safety of your RV has not been addressed by
the authorized Damon dealer, it is the RV owner’s responsibility to contact Damon in writing so Damon
can become directly involved in performing the repair. Damon may, at its option, request the vehicle be
returned to Elkhart, Indiana for repair. If the RV owner refuses to allow repairs to be performed at the
Elkhart, Indiana repair facility, the warranty on that repair will be voided.
Damon does not control the scheduling of service work at an authorized repair facility. Delays in sched-
uling or completion of work may be unavoidable. If you need assistance in obtaining the benet of
this Limited Warranty, please contact Damon at the telephone number below.
WHAT IS NOT COVERED

6
Chapter 1 - Warranty
This Limited Warranty does not apply to and Damon will not be responsible for the following:
1. Normal wear and usage;
2. Items added or changed after the RV leaves the possession of Damon or any damage caused by these
additions or changes;
3. Any RV used for rental or other commercial purposes (a conclusive presumption that your RV has been
used for commercial purposes arises if you have taken a business related tax deduction on any federal
or state tax return, or it is titled or has been titled to a sole proprietorship, partnership or corporation) ;
4. Minor imperfections, including paint imperfections which do not aect the suitability of the RV for
its intended purpose of recreational camping.
5. Damage, even to otherwise warranted components or parts, due to accident, misuse whether or
not foreseeable (including failure to maintain and use the RV in accordance with the owner’s manual),
abuse, hail, earthquake, water or ood, windstorm, lightning, hurricane, other acts of nature, collision,
re, explosion, damage from foreign objects striking the RV, damage or corrosion due to environment,
road salt, chemicals, or theft, vandalism or other intervening acts not attributable to Damon;
6. Scratches, dents, chips or defacing of any surface or fabric of this RV not caused by Damon or which
constitute normal wear and tear;
7. Wheel alignment, tire wear, or damage due to tire failure or battery failure;
8. Periodic maintenance, including but not limited to re-caulking the body of the RV, tightening screws,
adjusting doors, lubricating, cleaning or polishing the RV or chassis, replacement or repair of items as a
result of RV use, wear or exposure, such as oil, lters, brake pads, and linings;
9. Minor adjustments such as adjustments to the interior or exterior doors, drawers, latches etc. will be
performed by the dealer for the rst 90 days of warranty coverage. Thereafter, such adjustments are the
owners’ responsibility as normal maintenance.
10. Items that are working as designed but you are unhappy with because of the design;
11. Any material, component, or part of the RV that is warranted separately by its manufacturer, including
but not limited to tires, batteries, microwave, generator, VCR, CB radio, CD player, DVD player, tape player,
radio, speakers, television, home theater, satellite dish, dryer, washer, water pump, converter, inverter,
refrigerator, range, hot water heater, stove, LP detector, carbon monoxide detector, smoke detector, fur-
nace, roof air conditioners, dash air conditioner, leveling jack system, and the chassis and other items
supplied by the chassis manufacturer. The chassis includes any components of the chassis frame, power
train, brake systems, air cleaning system, cooling system, portions of the dash air system, chassis electrical
system, gauges, exhaust systems, shocks, struts, and steering system, or any other components supplied
by the chassis manufacturer. The written warranty provided by any component manufacturer is a direct
responsibility of that manufacturer; please refer to that manufacturer’s warranty for any pertinent terms
and conditions. Damon makes no warranty as to any of the components separately warranted by another
manufacturer; and
12. Damage due to overloading the RV or any of its components.
13. Damon shall not be liable for incidental or consequential damages including, but not limited to, lost
wages, lost time, commercial loss, legal expense, payments on any installment loan, towing, vehicle rental
or temporary living expenses.
RV OWNER MAINTENANCE AND USE OBLIGATIONS
This RV requires proper care and maintenance by the owner. The accessories and appliances must be
properly used. Failure to provide proper care and maintenance or to observe the proper handling and
use of accessories and appliances my result in damage to the RV or its components.
It is the responsibility of the owner to take such preventive measures as are necessary to maintain the
exterior caulking and sealer of the RV. It is the responsibility of the owner to use reasonable, prudent
care to prevent foreseeable secondary damage from rainwater, plumbing leaks, condensation and the
natural accumulation of moisture in the RV, such as a delaminated oor; stained upholstery, carpet-
ing, or drapes; mold formation and growth; furniture damage, etc. Mold and mildew are natural growths

7
Chapter 1 - Warranty
given certain environmental conditions and are not covered by the terms and conditions of this
Limited Warranty.
Damon will not pay for the cost of repairing or replacing items that are damaged as a result of lack of care,
prevention or improper use, nor for damage to other parts of the RV that result from such lack of care,
prevention or improper use. By design, these products are not intended or equipped to meet the needs of
a permanent or semi-permanent home; therefore, any such use shall void Damon’s Limited Warranty.
LIMITATION AND DISCLAIMER OF IMPLIED WARRANTIES
ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR OTHER IM-
PLIED WARRANTIES APPLICABLE TO THIS RV ARE LIMITED TO THE DURATION OF DAMON’S EXPRESS
WRITTEN LIMITED WARRANTY OF TWELVE (12) MONTHS OR TWELVE THOUSAND (12,000) MILES,
WHICHEVER COMES FIRST; OR IN THE CASE OF THE STEEL OR ALUMINUM FRAME STRUCTURE OF THE
ROOF, FRONT AND REAR WALLS AND SIDEWALLS (EXCLUDING SLIDE-OUTS), FOR TWENTY FOUR (24)
MONTHS OR 24,000 MILES, WHICHEVER OCCURS FIRST. PERFORMANCE OF REPAIRS OR NEEDED ADJUST-
MENTS ISTHE EXCLUSIVE REMEDY UNDER THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRAN-
TY. DAMON SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, LOST WAG-
ES, LOST TIME, COMMERCIAL LOSS, LEGAL EXPENSE, PAYMENTS ON ANY INSTALLMENT LOAN, TOWING,
VEHICLE RENTAL OR TEMPORARY LIVING EXPENSES) RESULTING FROM BREACH OF THIS WRITTEN LIM-
ITED WARRANTY OR ANY IMPLIED WARRANTY.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY WILL LAST OR THE
EXCLUSION OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITA-
TIONS MAY NOT APPLY TO YOU.
Damon makes no warranty or other representation with respect to the condition of the RV beyond that
contained in this warranty. Any opinions or representations contained in any promotional literature with
respect to the RV or any other Damon product are strictly the opinion of Damon, and do not constitute
a warranty of any kind, including any warranty of performance or quality. No person, including without
limitation any independent, authorized dealer, has the authority to enlarge, amend, or modify this Lim-
ited Warranty.
JURISDICTION AND APPLICABLE LAW
Exclusive jurisdiction for deciding any claims, demands or causes of action for defects or representations
of any nature or damages due from such defects or representations shall be in the courts in the state
of manufacture. The laws applicable to any litigation, dispute, mediation, arbitration or any claim what-
soever arising from the sale, purchase or use of the RV shall be those of the state of manufacture. Any ac-
tion to enforce the terms of Damon’s Limited Warranty shall be commenced not more than three (3)
months after expiration of the applicable warranty period. Any performance of repairs shall not suspend
this three month limitation from expiring. Any performance of repairs after the warranty coverage period
has expired, or performance of repairs regarding anything excluded from coverage under this Limited
Warranty shall be considered “good will” repairs, and they will not alter the express terms of this limited
warranty, or extend the warranty coverage period or this limitation period.
CALIFORNIA ARBITRATION CERTIFICATION PROGRAM
Damon Corporation participates in the Consumer Arbitration Program for Recreation Vehicles (CAP-RV).
This third-party dispute resolution program is available, at no charge to you, to settle unresolved warran-
ty disputes for recreation vehicles. This dispute resolution program reviews eligible product and service
related complaints involving warranty covered components.

8
To nd out more about the program, or to request an application/bro-
chure, please call the Arbitration Administration oce toll-free 800-279-
5343.
For recreation vehicles purchased in the State of California: The CAP-RV
program operates as a certied mechanism under the review of the Cali-
fornia Arbitration Certication Program. You must utilize the arbitration
program before claiming rights conferred by 15 USC section 2310 (Uni-
form Commercial Code) or Civil Code section 1793.22(b) (Son-Beverly
Warranty Act). You are not required to use the program if you choose to
seek redress by pursuing rights and remedies not created by those laws.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY
HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
Damon reserves the right to make changes in Vehicles built and/or sold by
it at any time without incurring any obligations to make the same or similar
changes on Vehicles previously built and/or sold by Damon.
As the proud owner of a Damon Motor Coach, you want to trust that your
unit will continue to perform at its peak. To ensure this Damon has pro-
vided you this checklist of the responsibilities of the Damon owner.
Please make sure that this list is carefully observed and adhered to in order
to maintain your Limited Warranty.
Please refer to the Maintenance Schedule (p. 71) to determine when your
inspections should take place.
Check both house batteries and chassis battery and tighten connections
if necessary. Clean the terminals if necessary. Check to make sure that
the batteries have the proper water levels in them, and ll if necessary.
Check the charge and recharge if necessary. Keep connections clean and
covered with a light coat of grease.
There is a certain danger involved when working with batteries. If you
are unfamiliar with these dangers, contact a Damon dealer.
Just as in your home, it is the owner’s responsibility to periodically check
the batteries in the smoke detector, LP detector and carbon monoxide
detector when applicable. We recommend that you change the batteries
every six months to ensure proper working order.
Chapter 1 - Warranty
PRODUCTION CHANG-
ES
OWNER RE-
SPONSIBILITY
CHECKLIST
BATTERIES
BATTERY
REPLACEMENT
CONDENSATION

9
Chapter 1 - Warranty
EXTERIOR/
INTERIOR
FRONT END
ALIGNMENT
POTABLE TANK
PROPER LOAD
BALANCE
SEALANTS
SERVICE CALLS
The owner is responsible for checking to ensure that the vehicle has as
little condensation in it as possible.The condensation in a motorhome
is much greater than in most houses because the insulated walls of the
vehicle are much thinner than house walls, and the small size and tight
construction of the vehicle allow a quick buildup of high moisture levels
in the inside air.
This can be reduced by always keeping the bathroom door closed and
the window or vents open when bathing, and for a period of time when
you have nished bathing to allow for dissipation of all the moisture. Use
your vent hood and fan when cooking. Don’t hang wet clothes in your
unit to dry. When left for prolonged periods of time, condensation can
cause considerable damage to your vehicle.
Most exterior parts of your motorhome are made of berglass, which is
a very durable material, but not indestructible. Exposure to the ele-
ments can cause premature deterioration without routine mainte-
nance, especially in hotter climates. The eects may be; fading,
yellowing, or chalking, however these are surface cosmetic changes,
which do not aect the strength of your unit. Simple maintenance
through cleaning by washing and waxing will ensure lasting beauty.
The same fading may occur to carpeting and upholstering. Be sure to
keep your shades down in extremely sunny locations and maintain
proper cleaning techniques for both carpet and upholstery.
The front suspension and steering system of this vehicle was factory
aligned using highly accurate equipment prior to delivery to the deal-
ership. We recommend that the alignment is checked after you
have fully loaded the motorhome according to your personal needs. If
necessary, adjust alignment for the loaded motorhome. Thereafter,
the alignment should be inspected yearly to help prevent uneven tire
wear.
Sanitize the fresh water system at least once per year or whenever the
motorhome is unused for prolonged periods of time (see p. 26).This will
help keep your water system fresh and discourage the growth of bacte-
ria that can contaminate the water supply. Make sure that the tanks are
properly treated with the right chemicals for disinfection.
Your motorhome is built to withstand a certain maximum load. Check
the amount listed on the Federal Certication Label in the driver’s area
of your motorhome to determine safe load limits. NEVER OVERLOAD
THE MOTORHOME. Reference pages 11, 16 and 17 for proper loading
and weight distribution.

10
Chapter 1 - Warranty
TIRE PRESSURE
TRAVEL BARS
WINDSHIELDS
WINTERIZATION
STEP LUBRICATION
SLIDE OUT
LUBRICATION
Damon Corporation
Customer Service Department
PO Box 2888
Elkhart IN USA, 46515-2888
[phone]
Weatherproong sealants are used around the doors, windows, vents, and
joints during construction of your motorhome. These sealants are subject
to the same deterioration from exposure as the berglass components,
and must be checked periodically to assure the weatherproof integrity of
your unit. If evidence of cracking or voids in the sealants is apparent,
have your dealer reseal these areas. Proper sealant coverage should be
checked and resealed at least once every six months. Please see Chapter
9 - “Care and Maintenance” for instructions on properly sealing the
roof area. Failure or neglect of proper sealant maintenance could result
in leakage, and may reduce or void your warranty protection.
It is important that the owner realize that Damon’s Limited Warranty covers
warrantable repairs that are performed by an authorized Damon dealer at
their service center or facility only. If you are unable to bring your unit
in for repairs, Damon is not responsible for the cost of the actual service
call charged to come out to your unit.
If your slide-out system becomes squeaky or makes any noises while
operating, it is permissible to apply a coat of lightweight oil to the drive
shaft and roller areas located below the main oor. Remove any excess oil
so dirt and debris cannot build up.
To maintain the integrity of the retractable step in your motorhome, you
must periodically inspect it for rust or damage, also see that it is
lubricated to function safely and to ensure proper working order.
The owner is responsible for maintaining proper tire pressure in the
vehicle’s tires. Check the tire specications on the Federal Certication
Label located in the driver’s area for the proper pressure. You will ensure
optimum driving standards by keeping your vehicle maintained.

Chapter 2 - Planning and Preparation
Athoroughworkingknowledgeofyourmotorhomeisimportantifyouare go-
ing to get the most out of the convenience and safety items built into your unit.
Be as familiar with it as you are with your personal car or truck. Study all the
booklets included in your Owner’s Information Kit.These booklets cover details
of operation for the major appliances and equipment built into your motorhome
foryourcomfort,convenienceandsafety.Yoursellingdealershouldprovideyou
with a complete walk through of your vehicle at the time of purchase. Any
questions and concerns should be addressed at that time.
Thevehiclelicensing laws vary fromstate-to-state.Check with your state li-
cense bureau or nearest branch office for the requirements of your state. Be
sure to renew your license if it has expired or will expire during your trip. Your
motorhome is considerably larger and heavier than your car, therefore certain
precautionsshouldbeexercised. ACDLlicensemaynotberequiredtooperate
yourmotorhome,butDamonMotorCoachrecommendsyouattendaCDLclass
to better understand the motorhomes driving and handling character-
istics.DamonMotorCoach wants your drivingexperiencetobe pleasant and
enjoyable.
Talktoyourinsuranceagentabouttheappropriatecoveragesforyourmotorhome.
Always carry your policy card.
Followaconsistentscheduleofinspectionandmaintenanceforyourmotorhome.
Yourcontinuingsafetyandcomfortdependonit.Thismanualincludes recom-
mendedmaintenanceintervalsandinstructions.Adherencetothese schedules
will minimize the possibility of failure of any important system or part of your
motorhome. The time spent inspecting and maintaining your motorhome will
provide you with many years of recreational pleasure. Improper inspections or
maintenance neglect may invalidate your Limited Warranty.
Proper loading is one of the most important considerations when traveling in
a motorhome. Your motorhome is built to withstand a certain maximum load.
Check the Federal Certification Label located in the driver’s area to determine
thesafeloadlimits.Forsafety’ssake,NEVEROVERLOADTHEMOTORHOME.
This chapter contains information about proper loading and weighing of your
motorhome.
Know how to control your motorhome on the highway. Be familiar with pass-
ing and stopping requirements, and problems that can develop. Know how to
brake properly, how to back up and how to turn. Practice in a secluded place
until you become familiar with the handling characteristics and techniques of
your motorhome. Don’t overlook the laws of your state that govern driving a
motorhome. Your state Motor Vehicle Department office can provide you with
the applicable vehicle codes that spell out your rights and responsibilities as a
motorhome owner.
READ THE BOOK
LICENSES
INSURANCE
INSPECT AND MAINTAIN
LOADING AND WEIGHT
DISTRIBUTION
CONTROL OF THE
MOTORHOME

Whenever you depart, be it from your home, rest area, or campsite. You should
perform these pre-travel checks:
Shouldbeinspected beforeeachtrip forunevenwear,roaddamage, foreign ob-
jects,peelingorbulging,andcorrecttirepressure.Heatgeneratedbysurfacefriction
willincrease thetire’sairpressure,therefore donot bleedairout ofahot tire.Check
tire pressure after the vehicle has been parked for at least one hour. Inflate tires to
recommendedpressureasindicatedontheFederalCertificationLabellocatedabove
the Drivers area. (See maintenance schedule on page 71.)
Proper tire inflation is extremely important.
When purchasing a new tire, be certain it is the same size and has
the sameply rating and load rangeas the original tire.
DO NOT mix radial ply with bias or bias-belted
tires.
Must be tightened to the specifications in the Chassis Manufacturer’s Owner’s
Manual.
Should be clean, wiper blades inspected, and windshield washer reservoir filled.
Shouldbetested,includingbrakelights,warningflashers,clearancelights,taillights,
turn signals and headlights. Clean all lens covers.
Should be adjusted so the driver can see to the rear on both the right and left side
of the unit.
(120Voltshoreline)mustbeunpluggedfromtheexternalsourceandproperlystored
for transit, also making sure the cord hatch is secured.
Hosesmustbedisconnected,properlydrainedandstored,andthecapsandhatches
secured. Fill the fresh water tank as required prior to storing hoses.
Shouldbeemptied from theholdingtanks before traveling.Termination valvesmust
be closed and locked. The sewer hose must be removed from the termination
valve outlet and stored. Termination cap must be securely fastened to the termina-
tion outlet.
Must be returned to its travel position. Pay special attention to this every time you
move your unit. Severe damage may result if not retracted during transit.
Levels at the monitor panel should be checked, and gas line connections should be
checked for leaks.
Some states prohibit vehicles equipped with LP gas tanks from using
tunnels. A few other states prohibit traveling with the service valve
open and the pilot lights lit. Check the regulations of the
states through which you intend to travel.
Chapter 2 - Planning and Preparation
TIRES
WHEEL LUGS
LIGHTS
REARVIEW MIRRORS
POWER CORD
WATER FILL
SEWAGE
ENTRY STEP
LP GAS TANK
WINDSHIELD
PRE-TRAVEL CHECK

Should be closed and secured. Loose items should be secured or stored
away.
Be sure all loose items are secured or properly
stored while the vehicle is in motion. Possible
overlooked items may include canned goods, small
appliances (on countertop), cooking pans (on range), or free standing furniture. These
items could become dangerous projectiles during a sudden stop.
For storage and equipment should be closed and locked, also making sure that
loose items are secured or stored for transit.
Door should be secured with the travel latch, and the items inside made ready
for transit.
Should be closed and secured or adjusted as desired.
If the motorhome was properly and carefully prepared for storage, taking it out
of storage will not be difficult. The following checklist assumes that you stored
your RV with care. If you didn’t, and extensive freeze damage or other serious
deteriorationhasoccurred,consultyourdealeroranauthorizedservice center
for advice.
 ThoroughlyinspecttheoutsideofyourRV. Lookforanimal’snestsinwheel
wells,inengine,aircleaner,orinotheroutofthewayplaces.Cleanallappliance
exhaust vents, ceiling vents and air conditioning covers.
 Changing the wiper blades on your motorhome is similar to your
car. Remove the screw, take o the old blade, and replace with a similar
style and length blade. Lubricating pivot points with thin lubricating
oil is also recommended.
 Check that all furnace, water heater and refrigerator openings are free of
debris, insect nests, webs, etc.
 Openalldoorsandcompartments.Checkforanimalorinsectintrusion,water
damage, or other deterioration.
 Check charge level in batteries. Refill with distilled water and recharge if
necessary. Reinstall batteries if necessary. Be sure cable ends and terminals
are clean and free of corrosion.Turn the Battery Disconnect Switch off if
applicable.
 Check tire pressure. Inflate to the specified cold pressure.
 Remove coverings from windows if necessary.
 Open vents and windows for ventilation.
 Drain,flushandsanitizethefreshwatersystem.(seeChapter5- “Plumb-
ing Systems”) Inspect drain lines for leaks. Replace if necessary. Do not try to
repair, as this is usually ineffective.
 Install a new water filter (if your unit is equipped with this).
 Operate all faucets and fixtures in the fresh water system. Check for leaks
at all joints and fittings. Repair if necessary.
Chapter 2 - Planning and Preparation
OPENING CHECKLIST
DOORS AND DRAWERS
COMPARTMENT
DOORS
REFRIGERATOR
DOOR
WINDOWS AND VENTS
Remove Screw to Re-
place Blades.
Lubricate Pivot Points

Chapter 2 - Planning and Preparation
FEDERAL
CERTIFICATION
LABEL
WEIGHTS
 Check 12 Volt circuit breakers and inspect all fuses.
 Operate all 12 Volt lights and accessories.
 Install new batteries in battery operated devices.
 Test LP gas, smoke and carbon monoxide detectors. Replace the batteries if
necessary.
 Check the monitor panel operation.
 Open and operate all vents and vent fans. Remove any outside coverings if
applicable.
 Inspect 120 Volt electrical system which includes power cord, converter, all
outlets and exposed wiring. If defects are found, consult your servicing dealer or
an authorized service center.
 Operate 120 Volt appliances and air conditioner(s). Be sure to uncover air
conditioner shroud(s).
 Inspectthe LPgassystemand checkfor leaks.IfLPtank showssigns ofrustor
corrosion, have it inspected by a qualified LP technician. Refill if necessary.
 Operateeach LPgasappliance. Observeall burner/pilotflamesforpropercolor
and size.
 If necessary, have LP gas regulator adjusted for proper pressure by a quali-
fied technician.
 Checksealantsaroundallroofandbodyseamsandwindows.Resealif nec-
essary.
 Lubricate all exterior locks, hinges, and latches.
 Wash and wax exterior. Inspect body for scratches or other damage. Touch up
or repair as necessary. Flush underside of the motorhome thoroughly.
 Check all the chassis fluid levels including engine oil, coolant, power steering
fluid, brake fluid, transmission, rear axle oil and washer fluid. Top off if necessary.
 Check windshield wiper blades. Replace if necessary.
 Check all exterior lights; clearance, brake, turn, and reverse should be fully
functional.
Your motorhome should be ready for a new traveling season. Your dealer can check
your preparation and correct any defects or make any necessary adjust-
ments.
These items are the absolute minimum requirements necessary for pre-travel.
A motorhome chassis (springs, wheels, tires, axles, and frame) is designed to carry
a certain maximum load. This load includes everything; the weight of the empty mo-
torhome itself, occupants, your belongings, fuel, fresh water, waste water and any-
thing else that may be in or attached to the motorhome.
The Federal Certification Label, found in the driver’s area, is installed in the ve-
hicle as required by federal standards. It contains information that will be helpful
in determining proper loading. The label will also list the date of manufacture,
(GCWR), (GVWR), (GAWR) (Front and Rear), tire size, rim size, tire pressure (PSI),
Vehicle Identification Number (VIN), and the type of unit.
