Danacoid DY-M1 Plus User manual

!1!/!6!
!
Cloud Platform Control
Center
DY-M1 Plus
Instruction
Manual
Danacoid International Pte Ltd.

!2!/!6!
!
I. Product Appearance and
Description
! Power indicator: The indicator of power
supply, which becomes on when the device is
electrified
" Standby indicator: The indicator of status
# RUN indicator: The indicator of device
running, which becomes on during signal
transmission
$ LAN indicator: The indicator of internet
access, which becomes on when the cable is
well-connected
! Ground terminal: Used for connection of
device shell and grounding wire terminal or
bolt
" RESET key: Use a long and thin object to
press the key for 10 seconds to reset the
device
# Internet port: For network access and
backup
$ RS-232 interface: RS-232 control interface
% Power switch: Touch-tone switch

!3!/!6!
!
& Power port: Connect to the power cable for
power supply
II. Product Features
n Strengthened cloud platform control center
adopts embedded hardware development, and
operate optimized embedded Linux system
n Free of virus infection, high security
n Conduct concentrated management on all
interface machines, scan automatically to
identify the interface machines within the
network range and complete auto configuration
n Support Web access, and the user may complete
full system management through the browser
n Conduct unified management and dispatching on
diverse display screens of different types with
different splicing scales, and achieve multiple
display modes of multi-screen linkage and
multi-screen mirroring
n Conduct accurate sync control over integrated
spliced screens, and carry out unified
synchronous management on all splicing display
units within the network
n Set up the position, size and hierarchy of the
window for the input signal source node, and

!4!/!6!
!
achieve the cross-screen, roaming and stacking
of windows on the large screen wall
n Achieve access management of seas of signals
and real-time preview and echo
n Save the combination and layout of the displayed
contents as the prearranged plans for rapid
retrieval
n Support hierarchical management of user
permissions, and allow online sync management
and operation of multiple users
n Support dual-server backup; synchronous
redundancy mechanism guarantees that even if
there is any fault with any server, the control
center will automatically switch to another server
and continue to work, avoiding any possible
mistakes in the special industries
n Support DM-700LK/DE-7000HD/DE-SDI2I
/DE-BNC8I, achieve dual-network backup
n Support DM-700LK captions and dynamic base
III. Product Specifications
Product Model
DY-M1 Plus; 19-inch industrial
standard 1U rack-mount server
Processor
1 ARM-A8 chip, 1G main
frequency
Memory
≥1.6GB 64-bit DDR3
Front Panel
Indicators: POWER indicator; LAN

!5!/!6!
!
indicator; RUN indicator
OLED Front
Screen
Dual OLED screen, used for display
of server IP, running state and other
information
Rear Panel
Power switch: Touch-tone switch
Serial
Communication
Equipped with 1 D-sub9
independent serial port, used for
reading of working log and system
codes
Internet Port
High-precision synchronous
calibration, with a sync error of
distributed node less than 1ms;
adopt embedded pure hardware
architecture, without Windows
operating system, free of virus
infection, with a startup time less
than 5 seconds
Power Supply
AC90V~260V
Power
Consumption
20W
Operating
Temperature
0~ +40
Operating
Humidity
10% ~ 90%, non-condensing
Dimensions
482.6*285.75*43.6mm

!6!/!6!
!
IV. System Architecture
1) Confirm that there is DHCP server or router with
DHCP functions in the network, so as to allocate
legitimate IP addresses to all network devices in the
system
2) Set the IP address of MICS server as static, such as
192.168.1.80, which will be beneficial to client login
and IIS setting
3) Conduct system connection and construction in
accordance with the above architecture
4) Connect the decoding device to the display device
(DLP/LCD or projector) through DVI or HDMI cable,
and connect the internet interface of decoding node to
the exchange through Cat5e or Cat6
5) Connect the signal source (computer, DVD, analog
camera, Blu-ray DVD, high-definition camera etc.) to
the coding nodes of MICS system through respective
dedicated cable, and connect the internet interface of
coding node to the exchange through Cat5e or Cat6
cable
6) All devices are electrified for operation
