OWNER’S MANUAL
GUIDE DU PROPRIÉTAIRE
CAUTION:
Read and Follow All Safety Rules and
Operating Instructions Before First
Use of This Product.
ATTENTION :
Avant de faire fonctionner cette
machine, lisez et suivez toutes les
consignes de sécurité de ce guide en
premier lieu.
Table of Contents . . . . . . . . . . . . . . . . . . . . 1
Table des matières . . . . . . . . . . . . . . . . . . . 13
Danby Products Limited, Guelph, Ontario Canada N1H 6Z9
Danby Products Inc., Findlay, Ohio USA 45840
Version 1.01.06
DBC514BLS
R

Important Safety Information
Safety Precautions 3
Grounding Instructions 4
Operating Instructions
Features of Your Beverage Center 5
The Controls of Your Beverage Center 6
Setting the Temperature 6
Wine Storage 7
Shelf Instructions 7
Installation Instructions
Tools You Will Need 8
Preparing the Enclosure 8
Care and Cleaning
Helpfull Hints 9
How to Clean the Inside 9
How to Clean the Outside 9
Trouble Shooting
Before Your Call For Service 10
3
5
9
10
1
TABLE OF CONTENTS
8

2
WELCOME
NEED HELP?
Welcome to the
Danby family. We’re
proud of our quality
products and we
believe in dependable
service.
You’ll see it in this
easy-to-use manual
and you’ll hear it in the
friendly voices of our
consumer service
department.
Tel:1-800-26-
Best of all, you’ll
experience these
values each time you
use your Beverage
Center. That’s impor-
tant, because your
new appliance will be
part of your family for
along time.
Before you call for service,
there are a few things you
can do to help us serve
you better...
Read this manual
It contains instructions to
help you use and maintain
your appliance properly.
If you received a
damaged appliance
Immediately contact the
dealer (or builder) that sold
you the Beverage Center.
Save time and money
Check the Trouble Shooting
section before calling. This
section helps you solve
common problems that may
occur.
If you do need service, you
can relax knowing help is
only a phone call away.
Tel: 1-800-26-
Write down the model and serial
numbers here. They are on a label
located on the back of the unit
.
Model number DBC514BLS
Serial number ______________
Date purchased ____________
Staple your receipt to the inside
back cover of this manual. You will
need it to obtain service under
warranty.
Start Here!…Before using your Beverage Center

READ ALL SAFETY INFORMATION BEFORE USING
3
IMPORTANT SAFETY INFORMATION
WARNING
SAFETY
PRECAUTIONS
•This appliance must be
grounded. Connect only to a
properly grounded outlet.
See “Grounding Instructions”
section on page 4.
•Do not operate this appliance
if it has a damaged power cord
or plug, if it is not working
properly, or if the appliance has
been damaged or dropped.
•Do not splice the power cord
that is equipped with this appli-
ance.
•Keep power cord away from
heated surfaces.
•Do not immerse power cord,
plug or the appliance itself in
water.
•Do not use this product near
water-for example, in a wet
basement, near a swimming
pool or near a sink.
•Do not use corrosive
chemicals or vapors in this
appliance.
•Use this appliance only for
it’s intended use, asdescribed
in this manual.
•Do not store perishable food
items such as (but not limited
to) meats and dairy products
in your Beverage Center.
•Store beverages in sealed
containers only.
•See door surface cleaning
instructions in the Care and
Cleaning section(s) of this
manual.
•Do not cover or block any
openings on the appliance.
•This appliance is intended for
household use only. Do not
attempt to operate or store this
appliance outdoors.
•This appliance should be
serviced only by qualified serv-
ice personnel. Contact nearest
authorized service facility for
examination, repair or adjust-
ment.
SAVE THESE INSTRUCTIONS
DANGER, RISK OF CHILD ENTRAPMENT!
An empty refrigerator is a very dangerous attraction to children. Remove either the gasket,
latches, lids, lock and/or doors from unused or discarded appliances, or take some other action
to guarantee it harmless.
DON’T WAIT, DO IT NOW!
To reduce the risk of fire, burns, electric shock, or injury to persons when using your appliance,
follow basic precautions, including the following sections;

4
This appliance must be
grounded. In the event of an
electrical short circuit, ground-
ing reduces the risk of electric
shock by providing an escape
wire for the electric current.
This appliance is equipped
with a power cord having a
grounding wire with a ground-
ing plug. The plug must be
plugged into an outlet that is
properly installed and ground-
ed.
Consult a qualified electrician
or service technician if the
grounding instructions are not
completely understood, or if
doubt exists as to whether the
appliance is properly ground-
ed.
If the outlet is a standard 2-
prong wall outlet, it is your per-
sonal responsibility and obliga-
tion to have it replaced with a
properly grounded 3-prong
wall outlet.
For best operation, plug this
appliance into its own electri-
cal outlet to prevent flickering
of lights, blowing of fuse or
tripping of circuit breaker.
Do not under any circum-
stances cut or remove the
third (ground) prong from the
power cord.
Do not use an adapter plug
with this appliance.
Do not use an extension
cord with this appliance. If the
power cord is too short, have
a qualified electrician or serv-
ice technician install an outlet
near the appliance.
GROUNDING
INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
WARNING
Improper use of the
grounding plug can result
in a risk of electric shock.

5
Operating Instructions
Features of your
Beverage Centre
1. Tempered Glass Door: Tinted for UV
protection while still allowing for easy interior
viewing.
2. Electronic Display and Controls:
For viewing and regulating the temperature
of the Beverage Center.
3. Magnetic Door Gaskets: Tight fitting
seals retain all the cooling power and humid-
ity levels.
4. Stainless Steel Trim Shelves
5. Child Proof Lock with Key
6. Front Mounted Exhaust: Allows for
integrated (built-in) applications.
7. Leveling Legs
.
8. Interior Light (not shown):Illuminates
the compartment when the door is opened.
9. Interior Light Toggle Switch: To
manually illuminate/extinguish the interior
lights, while door remains closed.
10. Wine Rack: Allows for storage of up to
eleven (11) bottles of wine.
9
6
4
5
1
3
2
7
10

6
Operating Instructions
C
F
C
F
1
2
4
Setting the
Temperature
When you plug in your bever-
age center for the first time,
the temperatures will auto-
matically be set to 45°F (7°C)
and 54°F (12°C) and will be
displayed in the Fahrenheit
scale (°F).
•To switch the display
between the Fahrenheit (°F)
and Celsius (°C) scale,
depress the UP and DOWN
control buttons simultaneous-
ly for approximately five (5)
seconds
•The temperature range can
be set as low as 39°F(4°C)
or as high as 64°F (18°C) to
suit your specific storage
requirements. Each depres-
sion of the UP or DOWN but-
ton will allow you adjust the
temperature in 1°degree
increments within the afore-
mentioned range.
Please note: In the event of
a power failure or interrup-
tion, all modified settings are
lost and the default settings
are used once power
resumes.
The Controls of your
Beverage Center
1. Run
Indicator light illuminates to signify the
cooling mode is currently in operation.
2. Set Temperature Display
Display screen shows the temperature
setting (see ‘Setting the Temperature’ below)
3. Cabinet Temperature Display
Display screen shows the current cabinet
temperature.
3. C° / F°
Adjacent indicator light denotes which
scale of temperature is displayed.
4. ‘UP’ Button
Used to raise (warmer) the temperature
in 1° degree increments.
‘DOWN’ Button
Used to decrease (cooler) the
temperature in 1° degree increments.
3
5

Operating Instructions
In order to achieve the maxi-
mum storage capacity of
eleven (11) wine bottles, it
may be necessary to position
the glass shelves higher (see
Shelf Instructions below).
This will allow for the storage
of six (6) 750 ml bottles in the
storage “cylinders”, and five
(5) bottles on the top of the
rack - one (1) postionned in
between each “cylinder”.
Wine
Storage
The *maximum capacity of
the wine storage rack is 11
(750ml) wine bottles.
*When stocked as per
instructions.
7
6Wine Bottle Storage
11 Wine Bottle Storage
Shelf Instructions
Lock
Screw
Shelf
Stopper
To remove a shelf from it’s
locked position, remove the
shelf stoppers located on
either side of the shelf as
shown in Fig C, and pull out-
ward.
To re-install, ensure the shelf
is resting securely on the
support brackets and push
shelf inward until it locks into
place.
Please Note: The bottom
wine rack is not secured in
place (locked). Do not
attempt to pull on the rack
when it is stocked.
IMPORTANT!
Do not cover any part of the
glass shelves with
aluminum foil or any other
material that will prevent
adequate air circulation
within the cabinet.
Fig C
Lock
Screw
Shelf
Stopper

8
Installation Instructions - Intergrated Application
Preparing the
Enclosure
FOR YOUR SAFETY:
While performing
installations described in
this section, gloves, safety
glasses or goggles should
be worn.
Tools You Will
Need
Carpenters
Square
Measuring
Tape
Level
Drill & Hole Saw set
Gloves
Safety Glasses
Flashlight
Electrical Requirements:
The appliance must be
connected to an individual
properly grounded electrical
outlet, protected by a 15 or
20 ampere circuit breaker or
time delay fuse.
•It is recommended that you de
not install the beverage center
into a corner (i.e. directly beside
awall). This is to allow the
door(s) to have a greater then
90° opening swing. A limited
door swing will prevent the
shelves from sliding out as
intended, and may lead to dam-
aging the door gasket(s).
•The rough cabinet opening
must be on a level floor area
and at least 25” deep by 24”
wide. The opening should also
have a height of at least 35”.
•The electrical oulet may be
positioned from within either
side of the adjacent cabinetry, or
the rear of the shaded area (as
shown in Fig C.).
•If the electrical outlet is located
inside the adjacent cabinetry, cut
a1-1/2” diameter hole to admit
the power cord. If the cabinet
wall is metal, the hole edge
must be covered with a bushing
or grommet.
Electrical Access
Fig C
Cabinets
Square
and
Plumb
35” From
Underside of
Countertop to
Floor
24”
6”
2”
24”
Min.
1-1/2” dia. hole
*if electical outlet
is in adjacent
cabinetry

9
Helpful Hints Allow the beverage center
door to remain open for a few
minutes after manual cleaning
to air out and dry the inside of
the wine cooler cabinet
NOTE: Be certain the
power is off before
cleaning any part of
this appliance.
How to Clean
the Inside Walls, Floor, Inside
Window, and Shelves
Some water deposits and dust
can be removed with a dry
paper towel, others may
require a damp cloth.
Care and Cleaning
How to Clean
the Outside Outer Case
It’s important to keep the area
clean where the door seals
against the cabinet. Clean this
area with a sudsy cloth. Rinse
and then dry.
Door surface
Use only mild, non-abrasive
detergents applied with a
clean sponge or soft cloth.
Rinse well.
Control Panel and
Door
Wipe with a damp cloth and
dry thoroughly. Do not use
cleaning sprays, large
amounts of soap and water,
abrasive or sharp objects on
the panel-they can damage it.
Some paper towels may also
scratch the control panel and
door glass.
Do not use cleaners con-
taining ammonia or alcohol
on the beverage center.
Ammonia or alcohol can
damage the appearance of
the appliance.
Never use any commercial or
abrasive cleaners or sharp
objects on any part of the
beverage center.
