DAPAudio DRX-8 User manual

Productcode:
D3630
D3631
D3632
D3633
D3643
D3644
D3645
Productname:
DRX-8
DRX-10
DRX-12
DRX-15
DRX-10B
DRX-12B
DRX-15B
DRX Passive Series
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
MANUAL
ENGLISH

1
DRX Passive Series
Table of contents
Warning ...............................................................................................................................................................................2
Unpacking Instructions .....................................................................................................................................................2
Safety Instructions..............................................................................................................................................................2
Connection with the mains .............................................................................................................................................4
Return Procedure ..............................................................................................................................................................4
Claims ..................................................................................................................................................................................4
Features...............................................................................................................................................................................5
Accessories .........................................................................................................................................................................5
Rear Panel Description .....................................................................................................................................................6
DRX-1OB/12B/15B SUB ..................................................................................................................................................6
DRX-8/10/12/15 .............................................................................................................................................................7
Connection Examples ......................................................................................................................................................8
Two Passive Subwoofers & Two Passive Satellite Speakers ...................................................................................8
One Passive Subwoofer & Two Passive Satellite Speakers....................................................................................9
Two Passive Satellite Speakers..................................................................................................................................10
Frequency Response Diagram .....................................................................................................................................11
DRX-10B/12B/15B.........................................................................................................................................................11
DRX-8/10/12/15 ...........................................................................................................................................................12
Connection Cables ........................................................................................................................................................13
Technical Specifications ................................................................................................................................................14
DRX-10B......................................................................................................................................................................14
DRX-12B......................................................................................................................................................................14
DRX-15B......................................................................................................................................................................15
DRX-8 ..........................................................................................................................................................................15
DRX-10........................................................................................................................................................................16
DRX-12........................................................................................................................................................................16
DRX-15........................................................................................................................................................................17
Troubleshooting ...............................................................................................................................................................17
Notes..................................................................................................................................................................................18

2
DRX Passive Series
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device have to:
-be qualified
-follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty. This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT!
The manufacturer will not accept liability for any resulting damages caused by the non-
observance of this manual or any unauthorized modification to the system.
Avoid flames and do not put close to flammable liquids or gases.
Before changing your grounds around, always turn your amplifiers down.
Before switching on or off make certain the sound system’s amplifiers are off or turned down: this will
avoid signal peaks, which are annoying and sometimes dangerous (particularly for speaker
enclosures).
Do not drive the inputs with a signal level bigger, than required to drive the equipment to full output.
Do not open this device.
Extreme frequency boosts in connection with a high input signal level may lead to overdriving your
equipment. Should this occur, it is necessary to reduce the input signal level by using the INPUT
control.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
In system setup, the amplifier's output power must be 50%-100% more than the loaded loudspeakers
rated power.
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION! Be careful with your operations.
With a dangerous voltage you can suffer
a dangerous electric shock when touching the wires!

3
DRX Passive Series
Keep this user’s manual for future consultation. Also remember that the crossover will get a better
price on the secondhand market if (as well as being in good condition) it has its original
documentation and packaging.
Make sure that there is sufficient room on all sides of the system for air circulation.
Make sure you don’t use the wrong kind of cables or defective cables.
Never remove warning or informative labels from the unit.
Only use device indoor, avoid contact with water or other liquids.
Please turn off the power switch, when changing the power cord or signal cable, or select the input
mode switch.
Prevent distortion! Make sure that all components connected to the DRX-series have sufficient power
ratings. Otherwise distortion will be generated because the components are operated at their limits.
Repairs, servicing and electric connection must be carried out by a qualified technician.
The best way (even if not always feasible) to avoid ground loops is to connect the electric ground of
all the equipment to a single central point (“star” system). In this case, the central point can be the
mixer.
To avoid or solve hum and buzzing troubles, try different combinations of lifting grounds on units that
are supplied with ground lift switches or make sure all chassis are connected to earth ground, either
through the A.C. power cord ground or by the front panel rack mount screws.
WARRANTY: Till one year after date of purchase.
When connecting the other parts of your sound system, watch out for the so-called “ground loops”.

4
DRX Passive Series
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
FASE
N
BLUE
BLACK
SILVER
NUL
YELLOW/GREEN
GREEN
GREEN
EARTH
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
1) Your name
2) Your address
3) Your phone number
4) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

5
DRX Passive Series
Features
These series products include active speaker cabinets and subwoofer.
ACTIVE SPEAKERS:
1. DRX-8
2. DRX-10
3. DRX-12
4. DRX-15
SUBWOOFER:
1. DRX-10B
2. DRX-12B
3. DRX-15B
These products are design to provide a cost effective high grade solution, and they can be used for all
kinds of applications, such as churches, conference center, disco, etc. You can select right model
according to your request.
Accessories
Speaker hanging eye
Ø 8mm
Ordercode: D8435
Distance stand
Ø 35mm
Ordercode: D8450

6
DRX Passive Series
Rear Panel Description
DRX-1OB/12B/15B SUB
INPUT: Receive the power coming from an external power amplifier (SPK +1/-1
connected; +2 -2 not connected)
THRU: Direct LINK for connecting in parallel a second speaker cabinet (SPK
+1/-1 connected; +2 -2 not connected).

7
DRX Passive Series
DRX-8/10/12/15
INPUT: Receive the power coming from an external power amplifier (SPK +1/-1
connected; +2 -2 not connected)
THRU: Direct LINK for connecting in parallel a second speaker cabinet (SPK
+1/-1 connected; +2 -2 not connected).

8
DRX Passive Series
Connection Examples
Two Passive Subwoofers & Two Passive Satellite Speakers
Make your initial connections with all the equipment powered off and ensure that all the main
volume controls are turned completely down.
1) Connect one side of the speaker cable to the Output CH 1 / CH 2 to Binding Post of your stereo
power amplifier and the other side to the Input socket of your speaker cabinet.
2) Complete other connections as illustrated.
3) Turn on your mixer first, then the stereo power amplifier.
4) Use PFL function to get the proper input level for the mixer and adjust the Main Mix Level control
to manipulate the output level.
5) After using your equipment, turn off your stereo power amplifier first, then the mixer.

9
DRX Passive Series
One Passive Subwoofer & Two Passive Satellite Speakers
Make your initial connections with all the equipment powered off and ensure that all the main
volume controls are turned completely down.
1) Connect one side of the speaker cable to the Output CH 1 / CH 2 to Binding Post of your stereo
power amplifier and the other side to the Input socket of your speaker cabinet.
2) Complete other connections as illustrated.
3) Turn on your mixer first, then the stereo power amplifier.
4) Use PFL function to get the proper input level for the mixer and adjust the Main Mix Level control
to manipulate the output level.
5) After using your equipment, turn off your stereo power amplifier first, then the mixer.

10
DRX Passive Series
Two Passive Satellite Speakers
Make your initial connections with all the equipment powered off and ensure that all the main
volume controls are turned completely down.
1) Connect one side of the speaker cable to the Output CH 1 / CH 2 to Binding Post of your stereo
power amplifier and the other side to the Input socket of your speaker cabinet.
2) Complete other connections as illustrated.
3) Turn on your mixer first, then the stereo power amplifier.
4) Use PFL function to get the proper input level for the mixer and adjust the Main Mix Level control
to manipulate the output level.
5) After using your equipment, turn off your stereo power amplifier first, then the mixer.

11
DRX Passive Series
Frequency Response Diagram
DRX-10B/12B/15B

12
DRX Passive Series
DRX-8/10/12/15

13
DRX Passive Series
Connection Cables
Take care of your cables, always holding them by the connectors and avoiding knots and twists when
coiling them: This gives the advantage of increasing their life and reliability.
Periodically check your cables. A great number of problems (faulty contacts, ground hum, discharges,
etc.) are caused entirely by using unsuitable or faulty cables.
Unbalanced
Balanced
For these applications the unit provides 1/4" TRS and XLR connectors to easily interface with
most professional audio devices. Follow the configuration examples below for your particular
connection.

14
DRX Passive Series
Technical Specifications
Model
DRX-10B
System Type
10" Reflex Subwoofer
Continuous Power
250W
Peak Power
500W
Transducer Low
10" Woofer, 2.5"voice coil, with double ventilation
SPL at 1m Max
121dB
Impedance
8Ω
Frequency Response
55Hz-500Hz (-6dB)
Connector
2*Speakon 1+,1- (2+,2- N/C)
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One metal standard pole-mount
Dimensions (H x W x D)
325 x 465 x 421mm
Net Weight
15.03kg
Model
DRX-12B
System Type
12" Reflex Subwoofer
Continuous Power
300W
Peak Power
600W
Transducer Low
12" Woofer, 2.5"voice coil, with double ventilation
SPL at 1m Max
123dB
Impedance
8Ω
Frequency Response
50Hz-400Hz (-6dB)
Connector
2*Speakon 1+,1- (2+,2- N/C)
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One metal standard pole-mount
Dimensions (H x W x D)
370 x 530 x 480 mm
Net Weight
17.95kg

15
DRX Passive Series
Model
DRX-15B
System Type
15" Reflex Subwoofer
Continuous Power
300W
Peak Power
600W
Transducer Low
15" Woofer, 2.5"voice coil, with double ventilation
SPL at 1m Max
124dB
Impedance
8Ω
Frequency Response
45Hz-400Hz (-6dB)
Connector
2*Speakon 1+,1- (2+,2- N/C)
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One metal standard pole-mount
Dimensions (H x W x D)
450x 580 x 480mm
Net Weight
21.3kg
Model
DRX-8
System Type
2-Way Vented Passive Speaker cabinet
Continuous Power
100 Watts
Peak Power
200 Watts
Horn Coverage
50°H x 50°V
Speaker Sensitivity (1W.1m)
90 dB SPL ±3dB Max SPL: 113dB at 1m
Frequency Response
68Hz~20kHz (- 6dB)
Impedance
8Ω
Crossover Frequency
3.2KHz
Protection
High Frequency Protection
Low Frequency
8" Woofer - 1.5" Voice Coil
High Frequency
1" Driver - 1" Voice Coil
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One ABS plastic standard pole-mount
Connectors
2 x SPK4
Dimensions (H x W x D)
542 x 360 x 352mm

16
DRX Passive Series
Model
DRX-10
System Type
2-Way Vented Passive Speaker cabinet
Continuous Power
120 Watts
Peak Power
240 Watts
Horn Coverage
50°H x 50°V
Speaker Sensitivity (1W.1m)
95 dB SPL ±3dB Max SPL: 118dB at 1m
Frequency Response
58Hz~20kHz (- 6dB)
Impedance
8Ω
Crossover Frequency
3.2KHz
Protection
High Frequency Protection
Low Frequency
10" Woofer - 2" Voice Coil
High Frequency
1" Driver - 1" Voice Coil
Connectors
2 x SPK4
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One ABS plastic standard pole-mount
Dimensions (H x W x D)
550 x 328 x 320mm
Model
DRX-12
System Type
2-Way Vented Passive Speaker cabinet
Continuous Power
150 Watts
Peak Power
300 Watts
Horn Coverage
50°H x 50°V
Speaker Sensitivity (1W.1m)
95.6 dB SPL ±3dB Max SPL: 120.3dB at 1m
Frequency Response
55Hz~20kHz (- 6dB)
Impedance
8Ω
Crossover Frequency
2.8KHz
Protection
High Frequency Protection
Low Frequency
12" Woofer - 2" Voice Coil
High Frequency
1" Driver - 1" Voice Coil
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One ABS plastic standard pole-mount
Connectors
2 x SPK4
Dimensions (H x W x D)
650 x 440 x 435mm

17
DRX Passive Series
Model
DRX-15
System Type
2-Way Vented Passive Speaker cabinet
Continuous Power
200 Watts
Peak Power
400 Watts
Horn Coverage
50°H x 50°V
Speaker Sensitivity (1W.1m)
96 dB SPL ±3dB Max SPL: 122dB at 1m
Frequency Response
50Hz~20kHz (- 6dB)
Impedance
8Ω
Crossover Frequency
2.8KHz
Protection
High Frequency Protection
Low Frequency
15" Woofer - 2" Voice Coil
High Frequency
1" Driver - 1" Voice Coil
Enclosure Construction
15mm plywood cabinet, glued and reinforced, resistant
black paint; metal grille, rubber foot.
Mounting
One ABS plastic standard pole-mount
Connectors
2 x SPK4
Dimensions (H x W x D)
522 x 486 x 736mm
Troubleshooting
This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps
below in sequence until a solution is found. Once the unit operates properly, do not carry out following
steps.
1. If the device does not operate properly, unplug the device.
2. Check the fuse, power from the wall, all cables, etc.
3. If all of the above appears to be O.K., plug the unit in again.
4. If you are unable to determine the cause of the problem, do not open the device, as this may
damage the unit and the warranty will become void.
5. Return the device to your Dap Audio dealer.

18
DRX Passive Series
Notes

©2013 DAP Audio
