DAS Action Series User manual

action series
User Manual
Antes de utilizar el equipo, lea la sección
“Precauciones de seguridad” de este manual.
Conserve este manual para futuras consultas.
Before operating the device, please read the
“Safety precautions” section of this manual.
Retain this manual for future reference.

CONTENTS
INTRODUCTION
RIGGING SYSTEM
6 to 7
8 to 13
3
4
5
14 to 15
16
17
LINE DRAWINGS
SPECIFICATIONS
2x action 8
2x action 12 (action 15) + 1x action 18
2x action 12 (action 15) + 2x action 18
2x action 12 (action 15) + 2x action 218
2x action 215
4x action M12
CONFIGURATIONS
SAFETY PRECAUTIONS
WARRANTY
DECLARATION OF CONFORMITY
Manual del Usuario / action passive series / User’s Manual

3
action series Precauciones de Seguridad
Safety Precautions
Cajas acústicas pasivas / Passive loudspeaker enclosures
Conserve y lea todas estas instrucciones.
Siga todas las advertencias.
El signo de exclamación dentro de un triángulo indica la
existencia de componentes internos cuyo reemplazo puede
afectar a la seguridad.
Keep these instructions.
Heed all warnings. Follow all instructions.
The exclamation point inside an equilateral triangle indicates the
existence of internal components whose substitution may affect
safety.
El doble cuadrado indica equipo de Clase II. The double square indicates Class II device.
Limpie con un paño seco. No use limpiadores con disolventes.
Las especificaciones se encuentran en la etiqueta de la parte
posterior del producto. The specifications can be found on the rear label of the product.
Clean only with a dry cloth. Do not use any solvent based
cleaners.
No existen partes ajustables por el usuario en el interior de este
equipo. Cualquier operación de mantenimiento o reparación
debe ser realizada por personal cualificado. Es necesario el
servicio técnico cuando el aparato se haya dañado de alguna
forma, tal como que haya caído líquido o algún objeto en el
interior del aparato, haya sido expuesto a lluvia o humedad, no
funcione correctamente o haya recibido un golpe.
No user serviceable parts inside. Refer all servicing to qualified
service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally or has been dropped.
action-8- ------------->125 cm
action-12 ------------->115 cm
action-15 ------------->105 cm
action-8- ------------->125 cm
action-12 ------------->115 cm
action-15 ------------->105 cm
Equipo diseñado para funcionar entre 15ºC y 35ºC con una
humedad relativa máxima del 75%. Working temperature ranges from 15ºC to 35ºC with a relative humidity of 75%.
No exponga este equipo a la lluvia o humedad. No exponga el
equipo a salpicaduras ni coloque sobre él objetos que
contengan líquidos, tales como vasos y botellas. Equipo IP-20.
Do not expose this device to rain or moisture. Do not place any
objects containing liquids, such as bottles or glasses, on the top
of the unit. Do not splash liquids on the unit. IP-20 equipment.
No emplace altavoces en proximidad a equipos sensibles a
campos magnéticos, tales como monitores de televisión o
material magnético de almacenamiento de datos.
Do not place loudspeakers in proximity to devices sensitive to
magnetic fields such as television monitors or data storage
magnetic material.
Este símbolo indica que el presente producto no puede ser
tratado como residuo doméstico normal, sino que debe
entregarse en el correspondiente punto de recogida de equipos
eléctricos y electrónicos.
This symbol on the product indicates that this product should
not be treated as household waste. Instead it shall be handed
over to the appicable collection point for the recycling of
electrical and electronic equipment.
El cableado exterior conectado al equipo requiere de su
instalación por una persona instruida o el uso de cables flexibles
ya preparados.
The outer wiring connected to the device requires installation by
an instructed person or the use of a flexible cable already
prepared.
El equipo cuenta con dos conectores de entrada en paralelo
para facilitar la conexión de varias cajas en paralelo. Note that the two Speakon input connectors are wired in parallel to provide easy parallel connection of several enclosures.
El colgado del equipo sólo debe realizarse utilizando los herrajes
de colgado recomendados y por personal cualificado. No
cuelgue la caja de las asas.
The appliance should be flown only from the rigging points and
by qualified personnel. Do not suspend the box from the
handles.
Para las cajas con vaso para trípode, la altura máxima de
seguridad desde el suelo a la base de la caja montada sobre
trípode modelo TRD-2, con pies a 55 cm del eje del trípode, es:
For enclosures with tripod socket, the maximum safety height
from floor to bottom of enclosure when mounting on a TRD-2
tripod, with legs spread 55cm from the central pole, is:
55 cm
Manual del Usuario / action passive series / User’s Manual

GARANTÍA
WARRANTY
Todos nuestros productos están garantizados por un periodo de 24
meses desde la fecha de compra.
Las garantías sólo serán válidas si son por un defecto de
fabricación y en ningún caso por un uso incorrecto del producto.
Las reparaciones en garantía pueden ser realizadas,
exclusivamente, por el fabricante o el servicio de asistencia técnica
autorizado.
Otros cargos como portes y seguros, son a cargo del comprador
en todos los casos.
Para solicitar reparación en garantía es imprescindible que el
producto no haya sido previamente manipulado e incluir una
fotocopia de la factura de compra.
All D.A.S. products are warrantied against any manufacturing defect
for a period of 2 years from date of purchase.
The warranty excludes damage from incorrect use of the product.
All warranty repairs must be exclusively undertaken by the factory
or any of its authorised service centers.
To claim a warranty repair, do not open or intend to repair the
product.
Return the damaged unit, at shippers risk and freight prepaid, to
the nearest service center with a copy of the purchase invoice.
4Manual del Usuario / action passive series / User’s Manual

DECLARACIÓN DE CONFORMIDAD
DECLARATION OF CONFORMITY
D.A.S. Audio, S.A.
C/ Islas Baleares, 24 - 46988 - Pol. Fuente del Jarro - Valencia. España
(Spain).
Declara que la serie action:
Declares that action series:
Cumple con los objetivos esenciales de las Directivas:
Abide by essential objectives relating Directives:
lDirectiva de Baja Tensión (Low Voltage Directive) 2006/95/CE
lDirectiva de Compatibilidad Electromagnética (EMC) 2004/108/CE
lDirectiva RoHS 2002/95/CE
lDirectiva RAEE (WEEE) 2002/96/CE
Y es conforme a las siguientes Normas Armonizadas Europeas:
In accordance with Harmonized European Norms:
lEN 60065:2002 Audio, video and similar electronic
apparatus. Safety requirements.
lEN 55103-1:1996 Electromagnetic compatibility.
Product family standard for audio, video, audio-
visual and entertainment lighting control apparatus
for professional use. Part 1:Emission.
lEN 55103-2:1996 Electromagnetic compatibility.
Product family standard for audio, video, audio-
visual and entertainment lighting control apparatus
for professional use. Part 2:Immunity.
5
Manual del Usuario / action passive series / User’s Manual

action 12
- Two-way full-range system
- 12" bass loudspeaker
- Compression driver with titanium diaphragm
- Asymmetric enclosure design for stage monitor use
- Built-in rigging points (eyebolt based)
- Stand mountable
The action 12 is a 2-way passive full-range loudspeaker that utilizes a
12” low frequency transducer and a 1” exit compression driver. The
multi-angle cabinet is constructed of Birch plywood protected by an
environmentally friendly black paint finish. Two bar handles and a steel
grille are provided. A 35mm tripod socket allows for stand mounting.
action 8
- 2-way, full-range system
- 8″ bass loudspeaker
- Compression driver
- Asymmetric enclosure design for stage monitor use
- Built-in rigging points
- Stand mountable
The action 8 is a compact 2-way passive full-range loudspeaker that
utilizes a 8” low frequency transducer and a full compression driver. The
multi-angle cabinet is constructed of Birch plywood protected by an
enviormentally friendly ISO-flex black paint finish. A rear located handle
and a robust steel grille are provided. A 35 mm tripod socket allows for
stand mounting.
action M12
- Dedicated stage monitor
- 12" bass loudspeaker
- Compression driver with titanium diaphragm
- Low profile enclosure design for minimum visual impact
- Black paint finish
- Stand mountable
The action M12 is a dedicated stage monitor designed for use with
external amplification. The enclosure is constructed from Birch plywood
and is protected with a black paint finish. Two side located handles
facilitate handling and a steel grille protects the components. A pole
mount socket adds versatility to the action M12.
6Manual del Usuario / action passive series / User’s Manual
INTRODUCTION
Features
The action series inherits the exceptional sound quality and rugged build that have made D.A.S.
professional systems an internacional sound reinforcement standard. Designed from “real-world” experience,
they offer users outstanding performance, absolute reliability, and unparalleled convenience. Whether it is in a
high-profile venue or on the stage of a major event, the action series will provide the power and definition
needed to make your performance a success.

7
action 215
- 2-way, full-range system
- 2 x 15" bass loudspeaker
- Compression driver with titanium diaphragm
- Two steel-reinforced handles
The action 215 is a 2-way passive full range loudspeaker utilizes two
15” bass loudspeakers for extra low frequency punch and higher SPL.
High frequencies are handled by a 1” compression driver with titanium
diaphragm. The trapezoidal cabinet is constructed using Birch plywood
and protected with a hard-wearing black paint finish. Two bar handles
and a steel grille sealed against corrosion using a polyamide powder
coat finish are provided. Rigging points provide a safe and simple way to
fly the action 215 cabinets.
action 18
- Bass-reflex subwoofer system
- 18" low frequency transducer
- Precise and powerful bass reproduction
- Top located pole mount socket
The action 18 bass system incorporates a 18” low frequency
transducer with a 4 " voice coil mounted as a direct radiator into a bass-
reflex cabinet. The loudspeaker is protected by a perforated steel grille,
sealed against corrosion using a powder coat finish. The action 18 is
designed for use in biamped systems. A top located pole-mount socket
permits mounting full-range systems above the action 18 and two bar
handles makes moving easy.
action 218
- High output bass-reflex subwoofer system
- Twin 18" loudspeakers
- Durable black paint finish
- Side located bar handles
This high power bass-reflex subwoofer system uses dual 18" bass
loudspeakers equipped with 4" voice coils. The exceptional power
handling capacity and efficiency provide high sound pressure levels of
powerful bass. Two hand locations facilitate handling. The cabinet is
designed to be stacked in the vertical position in order to reduce the
units "on-stage" footprint.
Manual del Usuario / action passive series / User’s Manual
action 15
- Two-way, full-range system
- 15" bass loudspeaker
- Compression driver with titanium diaphragm
- Asymmetric enclosure design for stage monitor use
- Built-in rigging points (eyebolt based)
- Stand mountable
This 2-way passive full-range loudspeaker utilizes a 15” low
frequency transducer and a 1” exit compression driver with titanium
diaphragm. The cabinet is constructed of Birch plywood and finished
with an environmentally friendly black paint finish. Two bar handles are
provided and a steel grille protects components. A 35 mm tripod socket
allows for stand mounting. Rigging points provide a safe and simple
solution for suspending the action 15.

CONFIGURATIONS
8Manual del Usuario / action passive series / User’s Manual
TRD-2
action 8
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
300 W
150 W
8 W
60 Hz - 20 kHz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 8
TRD-2
action 8
PS-400
Output B Output A
Mixer
Input B
LR
Input A
DSP-26
INPUTS
AB
STEREO 0.775V ON
N1918
CH B INPUT
CHA INPUT
PARALLEL
1.0V
SENSITIVI TY
BRIDGE 1.44V OFF
CH A CH B
BRIDGE
GROUND
GND
GND
COLD
COLD
HOT
HOT 2
31
FORCONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLYWITH THE SAME FUSE TYPE
SPEAKER OUTPUT

9
Manual del Usuario / action passive series / User’s Manual
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
600 W
300 W
8 W
50 Hz - 20 kHz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 12
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
1200 W
600 W
8 W
33 Hz - 160 Hz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 18
22000001
CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TO REDUCE RISK OF FIREOR ELECTRICSHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARA LA CONEXIÓN
REFE
R TO IN STR UCTIONS MANUA L FOR CO NNECTION
ANSCH LUS
SWEISE BITTE D
ER ANLE
ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC TION S POUR LA CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TO REDUCE RISK OF FIREOR ELECTRICSHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARA LA CONEXIÓN
REFE
R TO IN STR UCTIONS MANUA L FOR CO NNECTION
ANSCH LUS SWEISE BITTE D
ER ANLE ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC TION S POUR LA CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
PS-800
PS-800
Mixer
Output B
Output Bridge
Input B Input A
Input A
Output A
action 18
TRD-2
TRD-2
DSP-26
INPUTS
AB
action 12 (or action 15)action 12 (or action 15)
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
700 W
350 W
8 W
47 Hz - 20 kHz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 15
22000001
LR
CONFIGURATIONS (cont’d)

10 Manual del Usuario / action passive series / User’s Manual
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
600 W
300 W
8 W
50 Hz - 20 kHz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 12
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
1200 W
600 W
8 W
33 Hz - 160 Hz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 18
22000001
Output B
Output B
Output A
Output A
TRD-6
action 18
TRD-6
action 18
action 12 (or action 15)
action 12 (or action 15)
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
700 W
350 W
8 W
47 Hz - 20 kHz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 15
22000001
CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TOREDUCE RISKOF FIREOR ELECTRIC SHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARA LA CONEXIÓN
REFE
R TO IN
STR UCTIONSMANUA
L FOR
CO
NNECTION
ANSCH LUS SWEISE BITTE D
ER ANLE
ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC
TION
S POUR LA
CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
PS-800
Mixer
Input B
Input B
Input A
Input A
DSP-26
INPUTS
AB
FORCONTINUED PROTECTION AGAINST RISK
OFFIRE REPLACE ONLY WITH THE SAME TYPE
PS-2400
CHBCH A
BRIDGE
CHA
CHB
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKEROUTPUT
CHA INPUT
CHB INPUT
D.A.S.AUDIO S.A. (VALENCIA)SPAIN
MADEIN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
CHB 1+ 1-
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
LR
CONFIGURATIONS (cont’d)

LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
600 W
300 W
8 W
50 Hz - 20 kHz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 12
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
700 W
350 W
8 W
47 Hz - 20 kHz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 15
22000001
CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TOREDUCE RISKOF FIREOR ELECTRIC SHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARA LA CONEXIÓN
REFE
R TO IN
STR UCTIONSMANUA
L FOR
CO
NNECTION
ANSCH LUS SWEISE BITTE D
ER ANLE ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC
TION
S POUR LA
CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
PS-800
Mixer
Output B
Output B
Input B
Input B
Input A
Input A
Output A
Output A
DSP-26
INPUTS
AB
FORCONTINUED PROTECTION AGAINST RISK
OFFIRE REPLACE ONLY WITH THE SAME TYPE
PS-2400
CHBCH A
BRIDGE
CHA
CHB
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKEROUTPUT
CHA INPUT
CHB INPUT
D.A.S.AUDIO S.A. (VALENCIA)SPAIN
MADEIN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
CHB 1+ 1-
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
TRD-6
action 218
action 15 (or action 12)
TRD-6
action 218
action 15 (or action 12)
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
2400 W
1200 W
4 W
29 Hz - 160 Hz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 218
22000001
11
Manual del Usuario / action passive series / User’s Manual
LR
CONFIGURATIONS (cont’d)

12 Manual del Usuario / action passive series / User’s Manual
CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TO REDUCE RISK OF FIREOR ELECTRIC SHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARA LA CONEXIÓN
REFE
R TO IN
STR UCTIONS MANUA
L FOR
CO
NNECTION
ANSCH LUS SWEISE BITTE D
ER ANLE ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC
TION
S POUR LA
CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
action 215 action 215
PS-1400
Output B Output A
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
1400 W
700 W
4 W
47 Hz - 20 kHz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 215
22000001
Mixer
Input B
LR
Input A
DSP-26
INPUTS
AB
CONFIGURATIONS (cont’d)

13
Manual del Usuario / action passive series / User’s Manual
action M12
action M12
action M12
action M12
Output B Output A
CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TO REDUCE RISK OF FIREOR ELECTRIC SHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARA LA CONEXIÓN
REFE
R TO IN STR UCTIONS MANUA L FOR CO NNECTION
ANSCH LUS SWEISE BITTE D
ER ANLE
ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC TION S POUR LA CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
PS-1400
LINKED INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
600 W
300 W
8 W
63 Hz - 20 kHz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action M12
22000001
Mixer
Input B
LR
Input A
DSP-26
INPUTS
AB
CONFIGURATIONS (cont’d)

RIGGING
This manual contains needed information for
flying D.A.S. Audio line array systems, description
of the elements and safety precautions. To perform
any operations related to flying the system, read
the present document first, and act on the
warnings and advice given. The goal is to allow the
user to become familiar with the mechanical
elements required to fly the acoustic system, as
well as the safety measures to be taken during
set-up and teardown.
Only experienced installers with adequate
knowledge of the equipment and local safety
regulations should fly speaker boxes. It is the
user's responsibility to ensure that the systems to
be flown (including flying accessories) comply with
state and local regulations.
The working load limits in this manual are the
results of tests by independent laboratories. It is
the user's responsibility to stay within safe limits. It
is the user's responsibility to follow and comply
with safety factors, resistance values, periodical
supervisions and warnings given in this manual.
Product improvement by means of research and
development is on going at D.A.S. Specifications
are subject to change without notice.
To this date, there is no international standard
regarding the flying of acoustic systems. However,
it is common practice to apply 5:1 safety factors
for enclosures and static elements. For slings and
elements exposed to material fatigue due to
friction and load variation the following ratios must
be met; 5:1 for steel cable slings, 4:1 for steel
chain slings and 7:1 polyester slings. Thus, an
element with a breaking load limit of 1000 kg may
be statically loaded with 200 kg (5:1 safety factor)
and dynamically loaded with 142 kg (7:1 safety
factor).
When flying a system, the working load must
be lower than the resistance of each individual
flying point in the enclosure, as well as each box.
Hanging hardware should be regularly inspected
and suspect units replaced if in doubt. This is
important to avoid injury and absolutely no risks
should be taken in this respect. It is highly
recommended that you implement an inspection
and maintenance program on flying elements,
including reports to be filled out by the personnel
that will carry out the inspections. Local
regulations may exist that, in case of accident,
may require you to present evidence of inspection
reports and corrective actions after defects were
found.
Warnings
Absolutely no risks should be taken with
regards to public safety. When flying enclosures
from ceiling support structures, extreme care
should be taken to assure the load bearing
capabilities of the structures so that the installation
is absolutely safe. Do not fly enclosures from
unsafe structures. Consult a certified professional if
needed. All flying accessories that are not supplied
by D.A.S. Audio are the user's responsibility. Use
at your own risk.
Flyable action series models feature 6 internal
steel angles, with 2 mounting threads each, so
that 12 flying points are available (2 on each side,
3 on the top panel and 3 on the bottom panel and
2 on the rear panel). Eyebolt flying points are
factory sealed with M10 screws, which are
replaced with eyebolts on the flying points as
required. Flying with eyebolts is very economical
and safe, and is specially recommended for fixed
installations where the boxes are permanently
fixed.
The illustration shows the internal metal
hardware of an enclosure with eyebolt flying.
Introduction
14 Manual del Usuario / action passive series / User’s Manual

The Allen-head screws must be removed and
replaced by M10 eyebolts on one side of the
enclosure. Each rigging point has 200 kg (440 lb)
working load limit. Then choose the slings or
chains of required load resistance and length,
bearing in mind that the length difference between
the front and back slings or chains will determine
the vertical orientation. Alternatively, the back
bottom eyebolt points can be used to provide
vertical orientation.
The ANL-2 set is an optional set of three
eyebolts and three carabiners. (Dimensions are in
milimetres).
Flying with eyebolts
Each ANL-2 eyebolt has a rated working load
of 200 kg. (440 lb). Each ANL-2 carabiner has a
working load of 330 kg (726 lb). If using other
hardware, make sure it is rated to handle the
required load.
When using eyebolts it is important to bear in
mind that the rated working load is only true for a
load applied in the plane of the eye, and is
significantly reduced for other angles. The drawing
illustrates the concept. The table shows the
variation of the working load as a function of the
load angle. In the case of the ANL-2 eyebolt, this
means that the 200 kg working load becomes 60
kg at 45 degrees. Do not use eyebolt flying if the
load angle is higher than 45 degrees.
The following illustrations show different views
on eyebolt flying for a single box. The length of the
back cables or chains determines the vertical
angle of the box.
ANL-2
15
Manual del Usuario / action passive series / User’s Manual
100% 65% 30% 25%
0 Degrees
% Working
load
30 Degrees 45 Degrees More than 45
Degrees

LINE DRAWINGS
ALL DIMENSIONS IN MILIMETERS
16 Manual del Usuario / action passive series / User’s Manual
action M12action 15action 215action 18action 218 action 12
Bottom View
324
Right ViewFront View
378
653
Rear View
624
Rear View
650
Top View Right View
540
Front View
Rear View
1067
Right View
540
Front View
Top View
670
Rear View
474
Bottom View
1154
Right View
447
Front View
436
Bottom View
774
Right View
446
Front View Rear View
645
420
316
Bottom View Right View
Front View Rear View

SPECIFICATIONS
(1) Based on a 2 hour test continuosly applying 6 dB crest factor pink noise (IEC shaped).
Model
RMS Power Handling (1)
Peak Power Handling (-10 dB)
HF Horn Coverage Angles(-6dB)
On-axis Sensitivity 1 W / 1m
Rated Maximum Peak SPL (2)
Transducers/Replacement Parts
Nominal Impedance
Enclosure Material
Color/Finish
Connectors
Dimensions (H x W x D)
Weight
Accessories
action M12
300 W
95 dB SPL
130 dB
8 ohms
LF: 12Mi / GM 12Mi
HF: M-34 / GM M-34
Birch Plywood
Black Paint
2 x NL4 Speakon
42 x 64.5 x 31.6 cm
16.6 x 25.4 x 12.5 in
17.5 kg (38.5 lb)
Frequency Range (-10 dB)
1200 W
80º x 50º
63 Hz - 20kHz
TRD-2, TRD-6
action 12
1200 W
96 dB SPL
131 dB
8 ohms
LF: 12Mi / GM 12Mi
HF: M-34 / GM M-34
Birch Plywood
Black Paint
2 x NL4 Speakon
65.3 x 37.8 x 32.4 cm
25.7 x 14.9 x 12.8 in
18.5 kg (40.7 lb)
300 W
80º x 50º
50 Hz - 20kHz
ANL-2, TRD-2, TRD-6
Model
RMS Power Handling (1)
Peak Power Handling (-10 dB)
HF Horn Coverage Angles(-6dB)
On-axis Sensitivity 1 W / 1m
Rated Maximum Peak SPL (2)
Transducers/Replacement Parts
Nominal Impedance
Enclosure Material
Color/Finish
Connectors
Dimensions (H x W x D)
Weight
Accessories
action 8
action 15
600 W
1400 W
150 W
350 W
80º x 80º
80º x 50º
92 dB SPL
96 dB SPL
120 dB
131 dB
8 ohms
8 ohms
LF: 8B / 8B
LF: 2 x 15Mi / GM 15Mi
HF: M-26 / GM M-26
HF: M-34 / GM M-34
Birch Plywood
Birch Plywood
Black Paint
Black Paint
2 x NL4 Speakon
2 x NL4 Speakon
AXW-1, TRD-2, TRD-6
ANL-2, TRD-2, TRD-6
47.5 x 27.9 x 25.5 cm
77.4 x 44.6 x 43.6 cm
18.7 x 11 x 10 in
30.5 x 17.6 x 17.2 in
8.4 kg (18.5 lb)
24.5 kg (53.9 lb)
action 215
4 ohms
LF: 2 x 15Mi / GM 15Mi
HF: M-44 / GM M-44
Birch Plywood
Black Paint
2 x NL4 Speakon
115.4 x 44.7 x 47.4 cm
45.5 x 17.6 x 18.7 in
38.5 kg (83.6 lb)
action 18
96 dB SPL
133 dB
8 ohms
LF: 18H / GM 18G
Birch Plywood
Black Paint
2 x NL4 Speakon
62.4 x 54 x 65 cm
24.6 x 21.3 x 25.6 in
34.5 kg (75.9 lb)
Frequency Range (-10 dB)
60 Hz - 20kHz
47 Hz - 20kHz
80º x 50º
47 Hz - 20kHz
ANL-2
33 Hz - 160 Hz
TRD-6
action 218
4800 W
99 dB SPL
139 dB
4 ohms
LF: 2 x 18H / GM 18G
Birch Plywood
Black Paint
2 x NL4 Speakon
106.7 x 54 x 67 cm
42 x 21.3 x 26.4 in
61 kg (134.2 lb)
1200 W
29 Hz - 160 Hz
TRD-6
2800 W
700 W
2400 W
600 W
99 dB SPL
134 dB
17
Manual del Usuario / action passive series / User’s Manual
LINE DRAWINGS (cont’d)
ALL DIMENSIONS IN MILIMETERS
Bottom View Right View
Front View Rear View
action 8
475
279

UM_ACT_02_EN
www.dasaudio.com
D.A.S. AUDIO OF AMERICA, INC.
Sunset Palmetto Park
6816 NW 77th Court.
Miami, FL. 33166 - U.S.A.
TOLL FREE: 1-888DAS4USA
Tel. [phone]
Fax [phone]
D.A.S. AUDIO ASIA PTE. LTD.
25 Kaki Bukit Crescent #01-00/02-00
Kaki Bukit Techpark 1
Singapore 416256
Tel. [phone]
Fax [phone]
D.A.S. AUDIO, S.A.
C/. Islas Baleares, 24
46988 Fuente del Jarro
Valencia, SPAIN
Tel. [phone]
Tel. Intl. [phone]
Fax [phone]
Fax Intl. [phone]
