DAV TECH PDP-005 Product manual

2K VOLUMETRIC PUMPS PDP
015 / 050 / 150 / 500 / 1000
DAV TECH SRL
Via Ravizza, 30 - 36075 Montecchio Maggiore (VI) - ITALY
Tel. [phone] - Fax [phone]
[email protected] - www.davtech.it
Installation and
maintenance guide

Index
1 INTRODUCTION pag. 3
1.1 The manual
1.2 Warranty
1.3 Goods receiving
2 TECHNICAL DESCRIPTION pag. 3
2.1 Pumps operation
2.2 Technical specifications
3 SAFETY RULES pag. 4
4 NAMES FOR PARTS OF PDP PUMP pag. 5
5 PREPARATION PROCEDURE WITH USING PDP PUMPS pag. 6
6. DISASSEMBLY/ASSEMBLY OF A PDP PUMP pag. 7
7. BREAKDOWN PDP-005 A TYPE pag. 8
8. BREAKDOWN PDP-015 A TYPE pag. 12
9. BREAKDOWN PDP-050 A TYPE pag. 16
10. BREAKDOWN PDP-150 A TYPE pag. 20
11. BREAKDOWN PDP-500 A TYPE pag. 24
12. BREAKDOWN PDP-1000 A TYPE pag. 28
13. BREAKDOWN PDPX-150-015 BB TYPE pag. 32
14. BREAKDOWN PDPX-150-050 BB TYPE pag. 34
15. BREAKDOWN PDPX-500-015 BB TYPE pag. 36
16. BREAKDOWN PDPX-500-050 BB TYPE pag. 38
17. BREAKDOWN PDPX-500-150 BB TYPE pag. 40
18. BREAKDOWN PDPX-1000-500 BB TYPE pag. 42
19. BREAKDOWN PDPX-1000-150 BB TYPE pag. 44
Installation and maintenance guide

2K VOLUMETRIC PUMPS PDP
1 INTRODUCTION
1.1 The manual
The user guide is the document that accompanies the pumps from the time of its construction and throughout the period of
use, it is therefore an integral part of the pump. It requires reading the manual before taking any action involving the pump. The
manual must be readily available for use by staff and maintenance of the pump. The user and the attendant use are required to
know the contents of this manual.
Reproduction of any part of this manual, in any form, without the express written permission of DAV Tech. The text and
illustrations in this manual are not binding, the DAV Tech reserves the right, at any time and without notice, the right to make any
changes to improve the product or for reasons of character manufacturing or commercial.
1.2 Warranty
The warranty is valid for a period of 12 months from the date of commissioning and no later than 15 months from the date
delivery. The interventions carried out during the warranty period does not extend in any way the validity period of the guarantee.
The seller is not liable for defects caused by normal wear of parts which by their nature are subject to wear.
1.3 Goods receiving
The original configuration of the pump must never be changed. Upon receipt of the goods, check that:
• The packaging is intact
• The exact correspondence of the material ordered.
2 TECHNICAL DESCRIPTION
2.1 Pumps operation
The PDP volumetric pumps are a innovative, compact, vesartile, precise and reliable 2k dispensing systems.
The specially designed rotary auger pump allow high performances dispensing for 2k material. The system provide an efficient
and consistent dispensing more than any other piston or gear pump system. Mix ratio and dispensing volume can be easily
adjusted through the controller, changing speed and rotation of the rotor. The pumps are drived by a gearmotor with encoder
and allow volumetric dispensing in strips, drops, or filling a determinated volume with the highest accuracy, without be affected
from inlet fluid pressure, viscosity and temperature of the media.
2.2 Technical specification
pag.3
1. A seconda del fluido erogato - 2. Ingresso diverso, come raccordi per siringhe o cartucce disponibili su richiesta - 3. Diversi tipi di miscelatori
possibili su richiesta - 4. Materiali diversi possibili su richiesta.
ITEM PDP-005 PDP-015 PDP-050 PDP-150 PDP-500 PDP-1000
Dimensions 60xL260xØ30mm 60xL260xØ30mm 60xL260xØ30mm 67xL310xØ35mm 67xL310xØ35mm 67xL340xØ35mm
Weight 1.12 Kg 1.12 Kg 1.12 Kg 1.66 Kg 1.66 Kg 1.85 Kg
Input pressure 0~6 bar 0~6 bar 0~6 bar 0~6 bar 0~6 bar 0~6 bar
Max. Dosing pressure 20 bar 20 bar 20 bar 20 bar 15 bar 15 bar
Viscosity 0~500,000 cPs 0~500,000 cPs 0~500,000 cPs 0~500,000 cPs 0~500,000 cPs 0~500,000 cPs
Dosing Volume/Rev. ≈0.01 ml ≈0.03 ml ≈0.1 ml ≈0.3 ml ≈1.0 ml ≈2.0 ml
Motor Speed (rpm) 1~120 rpm 1~120 rpm 1~120 rpm 1~120 rpm 1~120 rpm 1~120 rpm
Dosing Flow Rate
(Max.)1
≈ 1.2 mil/min ≈ 3.6 mil/min ≈ 12 mil/min ≈ 36 mil/min ≈ 120 mil/min ≈ 240 mil/min
(0.02 mil/sec) (0.06 mil/sec) (0.2 mil/sec) (0.6 mil/sec) (2.0 mil/sec) (2.0 mil/sec)
Accuracy of dosing ±1% ±1% ±1% ±1% ±1% ±1%
Mixing Ratio 1:1 ~ 10:1 1:1 ~ 10:1 1:1 ~ 10:1 1:1 ~ 10:1 1:1 ~ 10:1 1:1 ~ 10:1
Stator Material FFKM FFKM FFKM FFKM FFKM FFKM
Material Inlet Port2G 1/4” (STD) 2G 1/4” (STD) 2G 1/4” (STD) 2G 1/4” (STD) 2G 1/4” (STD) 2G 1/4” (STD) 2
Material Outlet Port3Static mixer 3Static mixer 3Static mixer 3Static mixer 3Static mixer 3Static mixer 3
Wetting Part
Material4
AISI 304 / AL /
UHMW - PE / FKM 4
AISI 304 / AL /
UHMW - PE / FKM 4
AISI 304 / AL /
UHMW - PE / FKM 4
AISI 304 / AL /
UHMW - PE / FKM 4
AISI 304 / AL /
UHMW - PE / FKM 4
AISI 304 / AL /
UHMW - PE / FKM 4
Operating Condition 10~40°C 10~40°C 10~40°C 10~40°C 10~40°C 10~40°C

Installation and maintenance guide
Do not use disassemble or remodel. Fire, electric shock or danger of injury. If there is a
problem, please contact us.
Do not close to the fire or clean water. This may cause fire or electric shock.
Make sure the ground connection. Without earth connection, it may cause fire, electric
shock, injury or equipment malfunction.
Do not damage the power cord.
It may cause fire, electric shock or injury.
• Do not insert the power cord between the product,
wall or shelf.
• Do not place a heavy object and pull the power cord .
• Do not plug in or unplug with wet hands.
• When cleaning or moving, be sure to disconnect the
power plug.
• When unplugging the power cord, always grasp the
plug.
Please use the power AC 100V~240V range. It may cause equipment malfunction.
Plug the power cord into an outlet with a ground
terminal and multi-outlet. It may cause electric shock.
Do not use in an area exposed to direct sunlight,
high-temperature place, a place with drastic
temperature changes, humidity and many placed
dust.
It may cause malfunction in internal circuit.
Do not use the air conditioner or the same power line. It may cause malfunction in internal circuit.
Do not impact.
Do not place the heavy object.
Do not reverse or attach the liquid material in the
machine.
If reflux through inside the adapter’s tube, it may
cause malfunction.
Do not use in enclosed space that is poorly ventilated. It may cause malfunction in internal circuit.
It must be at least 15 cm of space between the wall
and do not place any obstacle.
The internal temperature of the device.
There is a risk of burn.
Disconnect all cables before cleaning. It may cause electric shock or malfunction.
If the unit falls down or damaged, then unplug the
power cord and contact us.
There is a risk of electric shock and fire when used in
a broken state.
When in correct handling, this dangerous situation can occur if there is a potential risk of death or serious
injury.
3 SAFETY RULES

pag.5
2K VOLUMETRIC PUMPS PDP
4 NAMES FOR PARTS OF PDP PUMP
Classification of Mixer Shape and Mix Adapter
MIX ADAPTER
A TYPE B TYPE C TYPE
MIXER
MIXER PART
COUPLING
MOTER PART
AIR VENT KNOB
BEARING PART
CHAMBER PART
PUMP MODEL NAME
TWIN BLOCK PART
MIX ADAPTER PART
SEAL PART
BEARING
SEAL
METRIAL SUPPLY
INLET
MIX PART
Specifications for
marked parts are
varied over pump
model.

Installation and maintenance guide
Rotor and stator connection
Do not activate
the pump without
applying the
material to the
stator. If so, even
for a short duration
of time, there might
be a damage on the
stator.
5 PREPARATION PROCEDURE WITH USING PDP PUMPS
5.1 In connecting A(Stator) and B(Rotor).
Use C (fixed tool) to fix the tools and apply solution (material) inside A(stator) and on B(rotor).
Connect A(stator) and B(rotor) and rotate them up to the marked position and rotate C(fixed tool) in
clockwise direction.
5.2 Eliminating bubbles before liquid discharge.
When the pump and the controller’s settings are finished, before applying
the solution to the product, rotate the D(Vent Knob) as the arrow direction
one to two rounds to discharge the bubbles and some liquid(about 5~10
seconds). When it is confirmed that the bubbles are all eliminated, then
close it off again.
When eliminating bubbles, set the motor speed at low (5~10 rpm) to
discharge. Eliminating
bubbles
5.4 Loose the vent knob which is attached to each Pro-Duo resin/hardner.
5.3 Turn on a Controller.
5.5 Select a controller mode upon a ratio and enter the setting values.
• It is an operation for checking whether the supply of materials
can be made smoothly without the operation of a pump and for the
removal of bubbles from a pump.
(Open it for one and a half rotation in counterclockwise.)
• If liquid is flowing out sufficiently (in comparison of the dispensing
volume), turn off a knob completely and then clean it.

pag.7
2K VOLUMETRIC PUMPS PDP
6 DISASSEMBLY/ASSEMBLY OF A PDP PUMP
PDP Pump Disassembly order:
1. In case of MIX-CAP(C TYPE), turn it
counterclockwise to disassemble it.
2. Separate four WRENCH BOLTS to
separated a MIX-ADAPTER.
3. Turn a STATOR LOCK NUT
counterclockwise to separate it. .
4. Separate a WRENCH BOLT to separate it
from TWIN BLOC. .
5. Separate a WRENCH BOLT to separate
it from CHAMBER PART and MOTOR
HOUSING.
6. Turn a STATOR counterclockwise to
separate it. (With a REPAIR TOOL)
7. Separate a WRENCH BOLT to separate it
from a CHAMBER.
8. Separate a SEAL BLOCK.

1
2
9
19
11
12
13
PDP-005
PART A
PDP-005
3
4
8
15
17
18
14
10
6
Dedicated to pump
model/body Pump
PCPM extension
5
16
7
20
22
21
Installation and maintenance guide

pag.9
Ref. Description Code Additional description
1 ROTOR ASSY
1.1 PCP-005-ROTOR STAINLESS STEEL ROTOR ASSYPCP-005
1.2 PCP-005-ROTOR-PP POLYPROPYLENE ROTOR ASSY PCP-005
2 SMALL PCP MOTOR ASSY - PCP-MOTOR-S -
3 SMALL COLLAR RING PCP - PCP-NUT-S -
4 TWINBLOCK SLEEVE ADAPTER - TWINADAPTER-BUSH STATOR SLEEVE PCP-005
5 STATOR ASSY
5.1 PCP-005-STATOR STATOR ASSY FFKM PCP-005
5.2 PCP-005-STATOR-EP STATOR ASSY EPDM PCP-005
6 SMALL PCP/ PCPM PUMP BODY
6.1 PCP-BODY-S STANDARD THREADED SMALL BODY PCP (SX)
6.2 PCPM-BODY-S INLET MODULE SMALL BODY PCP (SX)
7 SMALL INLET ADAPTER PCPM
7.1 PCPM-SYRINGE3055CC-S SMALL INLET ADAPTER PCP SYRINGE 30CC and 55CC
7.2 PCPM-310-S SMALL INLET ADAPTER PCP CARTRIDGE 310CC
7.3 PCPM-SEMCO-S SMALL INLET ADAPTER PCP SEMCO 6 OZ
8 PCP PURGE VALVE
8.1 PCP-PURGE PCP MANUAL PURGE VALVE
8.2 PCP-PURGE-UV PCP MANUAL PURGE VALVE FOR UV
9 SMALL ROTARY SEAL BLOCK BODY PCP - PCP-SEALBLOCK-S SMALL ROTARY SEAL BLOCK PCP
10 TWINBLOCK ADAPTER FOR MANIFOLD - TWINBLOCK-S WITH PCP MASTER PCP-005 / PCP-015 / PCP-050
11 ROTARY SEAL BODY PCP (x 1 pcs) - PCP-ROTARYSEAL -
12 SLEEVE MOTOR JOINT FOR SMALL MOTOR PCP - PCP-JOINT-S -
13 SMALL MOTOR CONNECTOR PCP - PCP-CONNECTOR-S -
14 O-RING FKM - PCP-A -
15 O-RING FKM - PCP-B -
16 SCREW SET (x2 pcs) - PCP-1 -
17 O-RING FKM - PCP-C -
18 O-RING (x1 pcs) FKM - PCP-D -
19 O-RING FKM - PCP-E -
20 O-RING (x1pcs) FKM
20.1 PCP-F -
20.2 PCP-F-FFKM -
21 SCREW SET (x2 pcs) - PCP-2 -
22 SCREW SET (x2 pcs) - PCP-3 -
-KIT O-RING PCP-005 - GASKETKIT-PCP005 -
PDP-005 - Components list PART A
2K VOLUMETRIC PUMPS PDP

PDP-005
PART B
1
2
9
18
20
19
10
11
12
PDP-005
3
4
7
8
14
17
16
13
21
6
5
15
Dedicated to pump
model/body Pump
PCPM extension
Installation and maintenance guide

pag.11
Ref. Description Code Additional description
1 ROTOR ASSY
1.1 PCP-005-ROTOR STAINLESS STEEL ROTOR ASSYPCP-005
1.2 PCP-005-ROTOR-PP POLYPROPYLENE ROTOR ASSY PCP-005
2 SMALL PCP MOTOR ASSY - PCP-MOTOR-S -
3 SMALL COLLAR RING PCP - PCP-NUT-S -
4 SMALL PCP TWINBLOCK SLEEVE ADAPTER ASSY - TWINADAPTER-BUSH STATOR SLEEVE PCP-005
5 STATOR ASSY
5.1 PCP-005-STATOR STATOR ASSY FFKM PCP-005
5.2 PCP-005-STATOR-EP STATOR ASSY EPDM PCP-005
6 SMALL PCP/ PCPM PUMP BODY
6.1 PCP-BODY-S-R STANDARD THREADED SMALL BODY PCP (DX)
6.2 PCPM-BODY-S-R INLET MODULE SMALL BODY PCP (DX)
7 SMALL INLET ADAPTER PCPM
7.1 PCPM-SYRINGE3055CC-S SMALL INLET ADAPTER PCP SYRINGE 30CC and 55CC
7.2 PCPM-310-S SMALL INLET ADAPTER PCP CARTRIDGE 310CC
7.3 PCPM-SEMCO-S-R SMALL INLET ADAPTER PCP SEMCO 6 OZ
8 PCP PURGE VALVE
8.1 PCP-PURGE PCP MANUAL PURGE VALVE
8.2 PCP-PURGE-UV PCP MANUAL PURGE VALVE FOR UV
9 SMALL ROTARY SEAL BLOCK BODY PCP - PCP-SEALBLOCK-S SMALL ROTARY SEAL BLOCK PCP
10 ROTARY SEAL BODY PCP (x 1 pcs) - PCP-ROTARYSEAL -
11 SLEEVE MOTOR JOINT FOR SMALL MOTOR PCP - PCP-JOINT-S -
12 SMALL MOTOR CONNECTOR PCP - PCP-CONNECTOR-S -
13 O-RING FKM - PCP-A -
14 O-RING FKM - PCP-B -
15 SCREW SET (x2 pcs) - PCP-1 -
16 O-RING FKM - PCP-C -
17 O-RING (x1 pcs) FKM - PCP-D -
18 O-RING FKM - PCP-E -
19 O-RING (x1 pcs) FKM
19.1 PCP-F -
19.2 PCP-F-FFKM -
20 SCREW SET (x2 pcs) - PCP-2 -
21 SCREW SET (x2 pcs) - PCP-3 -
-KIT O-RING PCP-005 - GASKETKIT-PCP005 -
PDP 005 - Components list PART B
2K VOLUMETRIC PUMPS PDP

1
2
9
19
21
11
12
13
PDP-015
PART A
PDP-015
3
4
7
8
15
17 18
14
10
6
Dedicated to pump
model/body Pump
PCPM extension
5
16
20
22
Installation and maintenance guide

pag.13
Ref. Description Code Additional description
1 ROTOR ASSY
1.1 PCP-015-ROTOR STAINLESS STEEL ROTOR ASSYPCP-015
1.2 PCP-015-ROTOR-PP POLYPROPYLENE ROTOR ASSY PCP-015
1.3 PCP-015-ROTOR-TC CARBIDE ROTOR ASSY PCP-015
1.4 PCP-015-ROTOR-ZC CERAMIC ROTOR ASSY PCP-015
2 SMALL PCP MOTOR ASSY - PCP-MOTOR-S -
3 SMALL COLLAR RING PCP - PCP-NUT-S -
4 SMALL PCP TWINBLOCK SLEEVE ADAPTER ASSY - TWINADAPTER-BUSH STATOR SLEEVE PCP-015
5 STATOR ASSY
5.1 PCP-015-STATOR STATOR ASSY FFKM PCP-015
5.2 PCP-015-STATOR-EP STATOR ASSY EPDM PCP-015
6 SMALL PCP/ PCPM PUMP BODY
6.1 PCP-BODY-S STANDARD THREADED SMALL BODY PCP (SX)
6.2 PCPM-BODY-S INLET MODULE SMALL BODY PCP (SX)
7 SMALL INLET ADAPTER PCPM
7.1 PCPM-SYRINGE3055CC-S SMALL INLET ADAPTER PCP SYRINGE 30CC and 55CC
7.2 PCPM-310-S SMALL INLET ADAPTER PCP CARTRIDGE 310CC
7.3 PCPM-SEMCO6-S SMALL INLET ADAPTER PCP SEMCO 6 OZ
8 PCP PURGE VALVE
8.1 PCP-PURGE PCP MANUAL PURGE VALVE
8.2 PCP-PURGE-UV PCP MANUAL PURGE VALVE FOR UV
9 SMALL ROTARY SEAL BLOCK BODY PCP - PCP-SEALBLOCK-S SMALL ROTARY SEAL BLOCK PCP
10 TWINBLOCK MANIFOLD ADAPTER - TWINBLOCK-S WITH PCP MASTER PCP-005 / PCP-015 / PCP-050
11 ROTARY SEAL BODY PCP (x 1 pcs) - PCP-ROTARYSEAL -
12 SLEEVE MOTOR JOINT FOR SMALL MOTOR PCP - PCP-JOINT-S -
13 SMALL MOTOR CONNECTOR PCP - PCP-CONNECTOR-S -
14 O-RING FKM - PCP-A -
15 O-RING FKM - PCP-B -
16 SCREW SET (x2 pcs) - PCP-1 -
17 O-RING FKM - PCP-C -
18 O-RING (x1 pcs) FKM - PCP-D -
19 O-RING FKM - PCP-E -
20 O-RING (x1 pcs) FKM
20.1 PCP-F -
20.2 PCP-F-FFKM -
21 SCREW SET (x2 pcs) - PCP-2 -
22 SCREW SET (x2 pcs) - PCP-3 -
-KIT O-RING PCP-015 - GASKETKIT-PCP015 -
PDP 015 - Components list PART A
2K VOLUMETRIC PUMPS PDP

PDP-015
PART B
PDP-015
3
4
7
14
16
17
13
21
6
Dedicated to pump
model/body Pump
PCPM extension
5
15
8
1
2
9
18
20
19
10
11
12
Installation and maintenance guide

pag.15
Ref. Description Code Additional description
1 ROTOR ASSY
1.1 PCP-015-ROTOR STAINLESS STEEL ROTOR ASSYPCP-015
1.2 PCP-015-ROTOR-PP POLYPROPYLENE ROTOR ASSY PCP-015
1.3 PCP-015-ROTOR-TC CARBIDE ROTOR ASSY PCP-015
1.4 PCP-015-ROTOR-ZC CERAMIC ROTOR ASSY PCP-015
2 SMALL PCP MOTOR ASSY - PCP-MOTOR-S -
3 SMALL COLLAR RING PCP - PCP-NUT-S -
4 SMALL PCP TWINBLOCK SLEEVE ADAPTER ASSY - TWINADAPTER-BUSH STATOR SLEEVE PCP-015
5 STATOR ASSY
5.1 PCP-015-STATOR STATOR ASSY FFKM PCP-015
5.2 PCP-015-STATOR-EP STATOR ASSY EPDM PCP-015
6 SMALL PCP/ PCPM PUMP BODY
6.1 PCP-BODY-S-R STANDARD THREADED SMALL BODY PCP (DX)
6.2 PCPM-BODY-S-R INLET MODULE SMALL BODY PCP (DX)
7 SMALL INLET ADAPTER PCPM
7.1 PCPM-SYRINGE3055CC-S SMALL INLET ADAPTER PCP SYRINGE 30CC and 55CC
7.2 PCPM-310-S SMALL INLET ADAPTER PCP CARTRIDGE 310CC
7.3 PCPM-SEMCO-S-R SMALL INLET ADAPTER PCP SEMCO 6 OZ
8 PCP PURGE VALVE
8.1 PCP-PURGE PCP MANUAL PURGE VALVE
8.2 PCP-PURGE-UV PCP MANUAL PURGE VALVE FOR UV
9 SMALL ROTARY SEAL BLOCK BODY PCP - PCP-SEALBLOCK-S SMALL ROTARY SEAL BLOCK PCP
10 ROTARY SEAL BODY PCP (x 1 pcs) - PCP-ROTARYSEAL -
11 SLEEVE MOTOR JOINT FOR SMALL MOTOR PCP - PCP-JOINT-S -
12 SMALL MOTOR CONNECTOR PCP - PCP-CONNECTOR-S -
13 O-RING FKM - PCP-A -
14 O-RING FKM - PCP-B -
15 SCREW SET (x2 pcs) - PCP-1 -
16 O-RING FKM - PCP-C -
17 O-RING (x1 pcs) FKM - PCP-D -
18 O-RING FKM - PCP-E -
19 O-RING (x1 pcs) FKM
19.1 PCP-F -
19.2 PCP-F-FFKM -
20 SCREW SET (x2 pcs) - PCP-2 -
21 SCREW SET (x2 pcs) - PCP-3 -
-KIT O-RING PCP-015 - GASKETKIT-PCP015 -
PDP 015 - Components list PART B
2K VOLUMETRIC PUMPS PDP

16
PDP-015-005
3
4
7
8
15
17
18
22
14
10
6
Dedicated to pump
model/body Pump
PCPM extension
5
1
2
9
19
21
11
12
13
PDP-015-005
PART A
20
Installation and maintenance guide

pag.17
Ref. Description Code Additional description
1 ROTOR ASSY
1.1 PCP-015-ROTOR STAINLESS STEEL ROTOR ASSYPCP-015
1.2 PCP-015-ROTOR-PP POLYPROPYLENE ROTOR ASSY PCP-015
1.3 PCP-015-ROTOR-TC CARBIDE ROTOR ASSY PCP-015
1.4 PCP-015-ROTOR-ZC CERAMIC ROTOR ASSY PCP-015
2 SMALL PCP MOTOR ASSY - PCP-MOTOR-S -
3 SMALL COLLAR RING PCP - PCP-NUT-S -
4 SMALL PCP TWINBLOCK SLEEVE ADAPTER ASSY - TWINADAPTER-BUSH STATOR SLEEVE PCP-015
5 STATOR ASSY
5.1 PCP-015-STATOR STATOR ASSY FFKM PCP-015
5.2 PCP-015-STATOR-EP STATOR ASSY EPDM PCP-015
6 SMALL PCP/ PCPM PUMP BODY
6.1 PCP-BODY-S STANDARD THREADED SMALL BODY PCP (SX)
6.2 PCPM-BODY-S INLET MODULE SMALL BODY PCP (SX)
7 SMALL INLET ADAPTER PCPM
7.1 PCPM-SYRINGE3055CC-S SMALL INLET ADAPTER PCP SYRINGE 30CC and 55CC
7.2 PCPM-310-S SMALL INLET ADAPTER PCP CARTRIDGE 310CC
7.3 PCPM-SEMCO-S SMALL INLET ADAPTER PCP SEMCO 6 OZ
8 PCP PURGE VALVE
8.1 PCP-PURGE PCP MANUAL PURGE VALVE
8.2 PCP-PURGE-UV PCP MANUAL PURGE VALVE FOR UV
9 SMALL ROTARY SEAL BLOCK BODY PCP - PCP-SEALBLOCK-S SMALL ROTARY SEAL BLOCK PCP
10 TWINBLOCK MANIFOLD ADAPTER - TWINBLOCK-S WITH PCP MASTER PCP-005 / PCP-015 / PCP-050
11 ROTARY SEAL BODY PCP (x 1 pcs) - PCP-ROTARYSEAL -
12 SLEEVE MOTOR JOINT FOR SMALL MOTOR PCP - PCP-JOINT-S -
13 SMALL MOTOR CONNECTOR PCP - PCP-CONNECTOR-S -
14 O-RING FKM - PCP-A -
15 O-RING FKM - PCP-B -
16 SCREW SET (x2 pcs) - PCP-1 -
17 O-RING FKM - PCP-C -
18 O-RING (x1 pcs) FKM - PCP-D -
19 O-RING FKM - PCP-E -
20 O-RING (x1 pcs) FKM
20.1 PCP-F -
20.2 PCP-F-FFKM -
21 SCREW SET (x2 pcs) - PCP-2 -
22 SCREW SET (x2 pcs) - PCP-3 -
-KIT O-RING PCP-015 - GASKETKIT-PCP015 -
PDP 015-005 - Components list PART A
2K VOLUMETRIC PUMPS PDP

PDP-015-005
3
4
7
8
14
16
17
13
21
6
Dedicated to pump
model/body Pump
PCPM extension
5
15
PDP-015-005
PART B
1
2
9
18
20
19
10
11
12
Installation and maintenance guide

pag.19
Ref. Description Code Additional description
1 ROTOR ASSY
1.1 PCP-005-ROTOR STAINLESS STEEL ROTOR ASSY PCP-005
1.2 PCP-005-ROTOR-PP POLYPROPYLENE ROTOR ASSY PCP-005
2 SMALL PCP MOTOR ASSY - PCP-MOTOR-S -
3 SMALL COLLAR RING PCP - PCP-NUT-S -
4 SMALL PCP TWINBLOCK SLEEVE ADAPTER ASSY - TWINADAPTER-BUSH STATOR SLEEVE PCP-005
5 STATOR ASSY
5.1 PCP-005-STATOR STATOR ASSY FFKM PCP-005
5.2 PCP-005-STATOR-EP STATOR ASSY EPDM PCP-005
6 SMALL PCP/ PCPM PUMP BODY
6.1 PCP-BODY-S-R STANDARD THREADED SMALL BODY PCP (DX)
6.2 PCPM-BODY-S-R INLET MODULE SMALL BODY PCP (DX)
7 SMALL INLET ADAPTER PCPM
7.1 PCPM-SYRINGE3055CC-S SMALL INLET ADAPTER PCP SYRINGE 30CC and 55CC
7.2 PCPM-310-S SMALL INLET ADAPTER PCP CARTRIDGE 310CC
7.3 PCPM-SEMCO-S-R SMALL INLET ADAPTER PCP SEMCO 6 OZ
8 PCP PURGE VALVE
8.1 PCP-PURGE PCP MANUAL PURGE VALVE
8.2 PCP-PURGE-UV PCP MANUAL PURGE VALVE FOR UV
9 SMALL ROTARY SEAL BLOCK BODY PCP - PCP-SEALBLOCK-S SMALL ROTARY SEAL BLOCK PCP
10 ROTARY SEAL BODY PCP (x 1 pcs) - PCP-ROTARYSEAL -
11 SLEEVE MOTOR JOINT FOR SMALL MOTOR PCP - PCP-JOINT-S -
12 SMALL MOTOR CONNECTOR PCP - PCP-CONNECTOR-S -
13 O-RING FKM - PCP-A -
14 O-RING FKM - PCP-B -
15 SCREW SET (x2 pcs) - PCP-1 -
16 O-RING FKM - PCP-C -
17 O-RING (x1 pcs) FKM - PCP-D -
18 O-RING FKM - PCP-E -
19 O-RING (x1 pcs) FKM
19.1 PCP-F -
19.2 PCP-F-FFKM -
20 SCREW SET (x2 pcs) - PCP-2 -
21 SCREW SET (x2 pcs) - PCP-3 -
-KIT O-RING PCP-005 - GASKETKIT-PCP005 -
PDP 015-005 - Components list PART B
2K VOLUMETRIC PUMPS PDP

PDP-050
3
4
7
8
15
17
18
14
10
6
Dedicated to pump
model/body Pump
PCPM extension
5
16
1
2
9
19
21
11
12
13
PDP-050
PART A
22
20
Installation and maintenance guide
