DAYCO DM0906 User manual

INSTALLATION
+ First measure out where the lid dispenser will
be placed, mark four holes and drill into the wall.
+ Insert the provided wall plugs and screw in the
top two screws, leaving a slight gap for the dispenser
to slot onto.
+ Open the dispenser lock before mounting
the dispenser to the wall.
+ Slot the dispenser onto the two previously
fixed screws and then screw final two screws.
+ Once the dispenser is secure, you can close the lid.
MOUNTING TEMPLATE
Should be minimum 60 cm high from the floor.
100
100
DM0906
Mini Interpull Toilet Paper Dispenser
DM0906
1/2
TECHNICAL DATA SHEET
DM0906
GENERAL DESCRIPTION
+ Mini interpull toilet paper dispenser made with
stainless steel 304 S.S. 0.70 thickness.
+ Available in only one finish (satine)
+ Useful for the public areas
+ It is mounted with four steel 4 mm screws
(provided in the box) with their 8 mm plastic plugs
(also provided)
+ Metal lock sytem is exist to protect the paper inside
clean and safe.
COMPONENTS AND MATERIAL
+ DM0906 -Stainless Steel 304 satine finish
11 cm
Max Ø 16 cm

2/2
TECHNICAL DATA SHEET
DM0906
20 cm
7,874"
13 cm
5,1181"
Kg Kg
X
Y
Z
X
Y
Z
X
Y
Z
PRODUCT PRODUCT CARTON CARTON INBOX PALLET GROSS PALLET GROSS PALLET
CODE DIMEN. DIMEN. WEIGHT QUANTITY QUANTITY DIMEN. WEIGHT
DM0906 20x20x13 cm 65x45x35 cm 13,5 kg 12 156 80x120x195 cm 190 kg
DISPENSER REPLACEMENT REQUIREMENTS
AND RECOMMENDATIONS
e following recommendations are intended to
provide guidelines on the best possible placement of
the dispensers. Because every location a dispenser is
to be mounted is different, depending on customer
site, physical size limitations, and available space,
these recommendations may not always be entirely
possible to follow.However, when placing a dispenser
installation must meet ADA requirements and should
promote ease of use and be in union with its
surroundings.Upon installation, the dispenser should
be level and the job results professional, presentable
and fully functional.
AFTERCARE INSTRUCTIONS
+ Regular cleaning with a soft cloth will keep the
surface of your product looking new. Soapy water can
be used to remove stubborn marks. Dont use abrasive
or chemical cleaners as thsese may damage the surface
finish over time.
+ Don’t expose to sunlight.
+ Don’t respond to the product with force against
the possibility of damnification, deformation.
+ Don’t throw any cigarettes and flammable materials
into the product.
