modway MOD-5808 User manual

MOD-5808 /MOD-5812 QUEEN BED
Customer Service 908-368-1025︱www.modway.com
Page 1 of 4
Thank you for purchasing the MODWAY QUEEN BED!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
2.Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components
and hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
and environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten
the components from time to time, so please save the tools that have been provided.
6.Please keep all fitting out of reach of children.
Hardware:
Components:
1. Headboard x1 2. Bed rail x2 3. Footboard x1 4.Center rail x1 5. Center Support leg x3
6. Center Plastic Cover x13 7. Side Plastic Cover x26 8. Slat x26 9. Leg x4
1
2
23
4
7
5
MOD-5808 MOD-5812
Bolt M8x25mm x8
Bolt M8x20mm x10
Flat Washer x22
Lock Washer x22
Allen Wrench x1
Leg Plug x4
B.
Bolt M8x70mm x4
C.
D.
E.
F.
G.
A.

MOD-5808 /MOD-5812 QUEEN BED
Customer Service 908-368-1025︱www.modway.com
Page 2 of 4
STEP 1:
1. Attach the Leg (9) to Headboard (1) & Footboard (3) by using 4 pieces of Bolts (A), 4 pieces of Lock
washer (E) and 4 pieces of Flat washers (D). Tighten Bolts (A) by using Allen wrench (F) fully as
shown.
2. Insert 4 pieces of Leg Plugs (G) into Legs (9) after tighten all bolts in the leg as shown.
STEP 2:
Attach one end of Bed rail (2) to Headboard (1) by using 2 pieces of Bolts (B), 2 pieces of Lock washers (E)
and 2 pieces of Flat washers (D). Do not fully tighten Bolts (B) at this step.
Repeat the same steps for the other end of Bed rail (2) to the Footboard (3).
Repeat the same steps for the other Bed rail (2) to Headboard (1) and Footboard (3).
Finally tighten all the Bolts (B) fully.
FA
D
FA
D
1
3
1
3
B
x 8
x 8
E
x 8
DF
x 1
A
x 4
x 4
E
x 4
DF
x 1 x 4
G
9
9
9
9

MOD-5808 /MOD-5812 QUEEN BED
Customer Service 908-368-1025︱www.modway.com
Page 3 of 4
STEP 3:
1. Attach the Center support leg (5) to Center rail (4) by using 6 pieces of Bolts (C), 6 pieces of Lock
washers (E) and 6 pieces of Flat washers (D). Tighten all Bolts (C) by using Allen wrench (F) as shown
in Figure 1. Pls note there are adjustable foot glide on the bottom of Center support leg (5) and you can
adjust the height if necessary.
2. Attach the assembled Center rail (4) and Center support leg(5) to Headboard &Footboard by using 4
pieces of Bolts (C), 4 pieces of Lock washers (E) and 4 pieces of Flat washers (D). Tighten Bolts(C) by
using Allen wrench (F) as shown in Figure 2.
STEP 4:
Insert 2 pieces of Side Plastic Cover (7) into each end of 2 pieces of Slats (8) as shown.
Insert the other end of the Slats (8) into 1 piece of Center Plastic Cover (6) as shown.
Insert the assembled Side Plastic Covers (7) into the corresponding holes on the Slat support of the Bed rail (2), and
the assembled Center Plastic Cover (6) into the corresponding holes on Center Rail (4) as shown.
Repeat the same steps for the remaining 24 pieces of Slats (8).
C
x 10
x 10
E
x 10
D
F
x 1
87
6
7
1
3
4
2
4

MOD-5808 /MOD-5812 QUEEN BED
Customer Service 908-368-1025︱www.modway.com
Page 4 of 4
Assembly is complete. The Queen Bed is ready to enjoy now!
MOD-5808 MOD-5812
