APW10D4
10” SHALLOW MOUNT MARINE SUBWOOFER
USER MANUAL
Installation Instructions | Owners Manual
Due to continuous improvement of the product, specifications are subject to change without notice.
TM
TM

32
TM TM
MARINE / POWER SPORTS TM TM MARINE / POWER SPORTS
PRODUCT SPECIFICATIONS
Introduction
Congratulations on your purchase of a DB Drive state-of-the-art marine subwoofer. Your selec-
tion of a DB Drive car audio product indicates a true appreciation of fine musical reproduction.
Whether adding to an existing system or including your DB Drive subwoofer in a new system, you
are certain to notice immediate performance benefits.
Keep Your Sales Receipt
Take this time to attach your sales receipt to the manual and put in a safe place. In case of any
unforeseen reason this product may need warranty service, your receipt will be necessary to
establish purchase date.
Recommendation
A power subwoofer’s performance is only as good as its installation. Proper installation will maxi-
mize the system’s overall performance. It is recommended that you have our product installed by
an authorized DB Drive retailer. However, if you decide to install it yourself, please carefully read
through this manual and take your time to do a quality installation.
IMPORTANT!
Before making any connections, disconnect the vehicle’s battery until the installation is
completed to avoid possible damage to the electrical system.
WARNING!
Exposure to high power sound system can cause hearing loss or damage. Listening
to your system at loud levels while driving will impair your ability to hear traffic sounds
and emergency vehicles. Use common sense when listening to your system.
S e r i a l # ____________________________________ _M o d e l # ___________________________________
TS Specs
APW10D4
Sensitivity 1W/1m) SPL 82.2 dB
DC Resistance Re 6.420 Ω
Free Air Resonance Fo 33.943 Hz
Equivalent Stiffness Vas 26.695mM
Mechanical Q Qms 3.752
Electrical Q Qes 0.974
Total Q Qts 0.773
Moving Mass Mms 140.296 g
Motor Force BL 14.047 TM
Cone Surface Area Sd 34.636 mM
MECHANICAL MEASUREMENTS
89mm/3.5in
230mm/9.05in
263.5mm/10.37in

54
TM TM
MARINE / POWER SPORTS TM TM MARINE / POWER SPORTS
CALCULATING ENCLOSURES
It is difficult to give exact box dimensions that are universal for all vehicles. It is for this reason that
you must be able to calculate the space in which you have available in order to achieve the proper
air volume required.
It is recommended to build your enclosure from 3/ 4” thick MDF (medium density fiberboard).
Make sure the enclosure is sealed airtight.
Calculating External Volume
To calculate box volume, measure the outside Width x Height x Depth of
the enclosure. Example 12” x 14” x 9”=1512 ÷1728” Cubic feet
Next you must convert cubic inches into cubic feet. To do this, you must
divide the cubic inches total by 1728”. Example 1512 ÷ 1728=.875 Cubic feet
Calculating Internal Volume
To calculate the internal (net) volume of the above box you must first multiply
the thickness of the wood you are using by Two(2). Example 3/4” x 2= 1.5“
Next subtract 1.5 from each of the outside measurements of the box.
Width Height Depth
12 - 1.5 = 10.5 14 - 1.5 = 12.5 9 - 1.5 = 7.5
Multiple the new totals (H x W x D) Example: 10.5 x 12.5 x 7.5 = 984.375
Next you must convert cubic inches into cubic feet. To do this, you must
divide the cubic inch total by 1728”. Example 984.375 ÷1728 =.5696
cubic feet.
RECOMMENDED ENCLOSURES
APW10D4
Sealed Box Range: Box Volume .45cu ft.
Sealed Enclosure:
89mm/3.5in
230mm/9.05in
263.5mm/10.37in

LIMITED WARRANTY
DB Drive warrants any products purchased in the U.S.A. from an authorized DB Drive
dealer. All products are warranted to be free from defects in material and workmanship
under normal use and service for a period of one (1) year when purchased over the
counter. This warranty applies to the original purchase only.
DB Drive will either repair or replace (as its option) any unit that had been found to
be defective and under warranty provided the defect occurs within the one (1) year
warranty period.
DB Drive products installed by an authorized
DB Drive dealer will receive (1) year of warranty.
Either limited warranty periods do not extend to units having been subjected to misuse,
abuse, neglect, or accident. In DB Drive’s judgment, products that show evidence of
having been altered, modified, or serviced without DB Drive’s authorization, will be
ineligible under this warranty.
To obtain warranty services please contact your retailer or visit our website at www.
dbdrive.net for more details.
DB Research L.L.P. - 302 Hanmore Industrial Parkway - Harlingen, TX 78550
Ph: [phone] - Fax: [phone] - www.dbdrive.net - tech support: [email protected]
™
