DB Drive WDX18 7KD2 User manual

WDX18 7KD2 : WDX18 7KD4
USER MANUAL
Installation Instructions | Owners Manual
Due to continuous improvement of the product, specifications are subject to change without notice.
7K

32
Introduction
Congratulations on your purchase of a DB Drive state-of-the-art subwoofer. Your selection of a
DB Drive car audio product indicates a true appreciation of fine musical reproduction. Whether
adding to an existing system or including your DB Drive subwoofer in a new system, you are
certain to notice immediate performance benefits.
Keep Your Sales Receipt
Take this time to attach your sales receipt to the manual and put in a safe place. In case of any
unforeseen reason this product may need warranty service, your receipt will be necessary to
establish purchase date.
Recommendation
A power subwoofer’s performance is only as good as its installation. Proper installation will max-
imize the system’s overall performance. It is recommended that you have our product installed
by an authorized DB Drive retailer. However, if you decide to install it yourself, please carefully
read through this manual and take your time to do a quality installation.
IMPORTANT!
Before making any connections, disconnect the car’s battery until the installation is
completed to avoid possible damage to the electrical system.
WARNING!
Exposure to high power sound system can cause hearling loss or damange. Listening
to your system at loud levels while driving will impair your ability to hear traffic sounds
and emergency vehicles. Use common sense when listening to your system.
S e r i a l # ____________________________________ _M o d e l # ___________________________________
PRODUCT SPECIFICATIONS
TS SPECS WDX18 7KD2
Resonant Frequency (fs) ........................................................................ 30.398Hz
DC Resistance (Re) ........................................................................................4.000 Ω
Mechanical (Qms) .............................................................................................. 8.471
Electromagnetic (Qes) .....................................................................................0.554
Total Q (Qts) ..........................................................................................................0.520
Compliance Equivalent Volume (Vas) .................................................... 64.473
Mechanical Compliance of Suspension (Cms) .......................35.300u M/N
BL Product (Bl) ...................................................................................................32.717
Diaphragm Mass inc. Airload (Mms) ..............................................776.540 gr
Sound Pressure Level (SPL) ........................................................................87.0 dB
WDX18 7KD4
............................32.595Hz
................................6.800 Ω
....................................8.836
....................................0.798
.................................... 0.732
.................................90.558
....................49.582u M/N
..................................28.974
.........................480.852 gr
............................... 87.8 dB
256/10.08”
290/11.42”
470/18.50”
424/16.69”

TM
7K
DB Drive warrants the WDX 7K woofers for a period of 30 days from the date of the
original sales invoice.
This warranty applies to the original purchase only.
The WDX 7K woofer must be purchased directly from and authorized DB Drive
dealer for this warranty to take eect.
Due to the nature of the use of these woofers the warranty only covers
manufacturing defects.
This limited warranty does not extend to units that have been subjected to abuse,
neglect, or have been damaged due to any installation accident.
The limited warranty does not cover open or burnt voice coils that were caused
during competition, testing or normal use.
To obtain the limited warranty you must send the woofer to the DB Research L.L.P
RA department for warranty coverage evaluation.
Only DB Research can determine the warranty coverage status of woofer.
Woofers will not be accepted without a DB Research issued RA number.
The original sales invoice must be presented at the time the RA number is requested.
All WDX 7K woofers will be inspected by DB research before any warranty
agreement is made.
If the WDX 7K woofer does not qualify for warranty you will be contacted with
repair and cost options.
For questions about the warranty service please contact the DB Research RA
department at 1-877-787-0101
LIMITED WARRANTY
DB Research L.L.P.
302 Hanmore Industrial Parkway Harlingen, TX 78550
Phone [phone] : Fax [phone] : www.DBDrive.net
