AMC CSUB User manual

User
Manual
CSUB
Compact Active Subwoofer

Table of contents
USER MANUAL CSUB Compact Active Subwoofer
Safety instructions
USER MANUAL CSUB Compact Active Subwoofer
When using this electronic device, basic precautions
should always be taken, including the following:
1 Read all instructions before using the product.
2 Do not use this product near water (e.g., near a bathtub, washbowl, kitchen sink, in a
wet basement or near a swimming pool etc). Care should be taken that objects do not
fall into liquids and liquids would not be spilled on the device.
3 Use this device when you are sure that it has a stable base and it is fixed securely.
4 This product may be capable of producing sound levels that could cause permanent
hearing loss. Do not operate for a long period of time at a high volume level or at a
level that is uncomfortable. If you experience any hearing loss or ringing in the ears,
you should consult with otorhinolaryngologist.
5 The product should be located away from heat sources such as radiators, heat vents,
or other devices that produce heat.
6 Note for power connections: for pluggable equipment, the socket-outlet shall be
installed near the equipment and shall be easily accessible.
7 The power supply should be undamaged and never share an outlet or extension
cord with other devices. Never leave device plugged into the outlet when it is not
being used for a long period of time.
8 Power disconnection: when the power cord connected to the power grid is
connected to the machine, the standby power is turned ON. When the power switch
is turned ON, the main power is turned ON. The only operation to disconnect the
power supply from the grid, unplug the power cord.
9 Protective Grounding - An apparatus with class I construction shall be connected to
a power outlet socket with a protective grounding connection.
Protective Earthing - An apparatus with class I construction shall be connected to a
mains socket outlet with a protective earthing connection.
10 The lightning flash with an arrowhead symbol, with an equilateral triangle,
is intended to alert the user to the presence of uninsulated dangerous
voltage’within the products enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
11 The exclamation mark within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
12 There are some areas with high voltage inside, to reduce the risk of electric shock
do not remove cover of the device or power supply.
The cover should be removed by the qualified personnel only.
13 The product should be serviced by qualified service personnel if:
– The power supply or the plug has been damaged.
– Objects have fallen into or liquid has been spilled on the product.
– The product has been exposed to rain.
– The product has been dropped or the enclosure damaged.
Before you start
Introduction......................................................................................................................................................2
Features................................................................................................................................................................2
Operation
Rear panel of CSUB ......................................................................................................................................3
Rear panel functions...................................................................................................................................4
Specifications
General specifications................................................................................................................................5

USER MANUAL CSUB Compact Active SubwooferUSER MANUAL CSUB Compact Active Subwoofer
Before you start
02
CSUB is a compact active subwoofer for installation in home or public address systems. It features
10" low frequency driver, 200 W rated Class-D power amplifier, RCA line level input, 100 V level input,
selectable crossover point, phase and volume controls.
FEATURES
• Ready to pick up audio from 100 V lines
• DSP based EQ correction
• Built in audio limiter
• Standby mode
• Class-D amplifier and switching power supply
• Compact cabinet with 10” woofer
03
Rear Panel | CSUB
1. Power mode switch
2. LED power indicator
3. Phase degree selector
4. Crossover frequency selector
5. Volume control
6. Line level input
7. 100 V level input
8. Power plug socket and fuse box
9. Power button
Operation
1
3
5
7
8
2
4
6
9

USER MANUAL CSUB Compact Active SubwooferUSER MANUAL CSUB Compact Active Subwoofer
Rear panel functions
POWER MODE SELECTOR
CSUB has two modes designed to control the main power supply. “AUTO” mode
sets the subwoofer’s power supply to standby if MCU can’t detect an audio signal
within 20 minutes. This function can be eliminated by setting the power mode
selector to position “ON”. In this setting, the subwoofer power supply always stays
active. Subwoofer needs about 5 seconds to wake up from standby.
POWER INDICATOR
Bi-color LED indicates subwoofer status.
Red color indicates standby mode.
Green color means that CSUB is active and ready to play audio.
PHASE CORRECTION
Potentiometer designed to smoothly adjust audio signal phase in 0° – 180° range.
This setting depends on the acoustic environment, we are recommending starting
the system with a 0° value and adjusting it later if necessary to have the best bass
performance in the chosen sweet spot.
CROSSOVER
Option to adjust DSP low pass filter settings. This adjustment takes impact to
reproduced frequency and can be set in the 40 – 120 Hz range.
VOLUME
Subwoofers' volume potentiometer. Set the volume level according to your
environment and needs.
LINE INPUT
RCA-type audio input, designed for line-level signal.
HI-LEVEL INPUT
Hi-level audio input is designed for direct connection to the 100V background
music audio system line. This input is galvanic isolated inside the subwoofer and
has a specially designed DSP setting to recover low-frequencies, lost in constant
voltages audio lines.
NOTE: subwoofer has two audio inputs linked to different DSP settings. This DSP
correction is based on an auto-detection circuit designed to detect which audio
input is used. Do not use RCA and Hi-level input at the same time to prevent EQ
correction switching from one DSP preset to another.
MAIN POWER CONNECTOR
Power connector with built-in fuse holder. The fuse specification is listed on the rear
panel.
POWER SWITCH
Switch subwoofer ON or OFF.
Operation
04 05
General Specifications
CSUB Compact Active Subwoofer
The specifications are correct at the time
of printing this manual. For improvement
purposes, all specifications for this unit,
including design and appearance, are
subject to change without prior notice.
Technical Specifications CSUB
Rated output power 200 W
Max power consumption 300 W
Stand by power consumption 3 W
Power supply ~ 220-230 V, 50 Hz
Driver dimensions 10”(254 mm)
Frequency Response 35 Hz - 150 Hz
Crossover point 40 Hz - 120 Hz
Inputs 1 x Stereo RCA, 1 x Mono hi-level input
RCA input sensitivity -14dBu
RCA input impedance 10 kΩ
Cooling Passive cooling
Material Laminated MDF
Colour Black (RAL 9017)
Dimensions (H x W x D) 44 x 430 x 245 mm
Weight 10.6 kg
