Installation and Operation Manual
MCD-9101-101-X
Air Jukebox
Document # 540360

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 1 of 28
Document Revision History
Rev. Level Date Description
IR 03/2008 Initial Release
Reference Documents
(or latest revision)
Document # Description
526077 Rev A MCD-9101-101-x Outline Drawing
Service Bulletin List
Service
Bulletin # Subject Manual Revision
Revision
Date
Table of Illustrations
Section # Description Page #
2.2 Typical Application 5-6
4.3 Front Panel Illustration 15
4.5 Front Panel OLED Screen and Menus 16-22
4.6 Front Panel Controls 23
4.7 Front Panel Navigation 23
7.0 Reference Drawings 27-28
PROPRIETARY INFORMATION NOTICE:
Despite any other copyright notice, this document and
information disclosed herein contains confidential, proprietary designs owned by DeCrane
Aerospace Audio International’s. Neither this document nor the data contained herein shall be
reproduced, used, or disclosed to anyone without the written authorization of
D
eCrane Aerospace

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 2 of 28
Table of Contents
Section Description Page
1.0 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Purpose of the Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Operational Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Optional Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.0 Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2 Typical Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3 Media and Format Compatibilities . . . . . . . . . . . . . . . . . . . . . . 6
3.0 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 Prior to Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 Unpacking and Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3 Cautions &Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 Wiring Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.5 Physical Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.6 Electrical Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.7 Mating Connector Information. . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.8 Pinout Assignments and Descriptions. . . . . . . . . . . . . . . . . . . . 13
3.9 Post Installation Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2 General Operation Information. . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3 Front Panel Illustration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4 Front Panel Capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.5 Front Panel OLED Screen and Menus . . . . . . . . . . . . . . . . . . . 16
4.6 Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.7 Front Panel Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.8 Compact Disc Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.9 Playing a CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.0 Instructions for Continued Airworthiness . . . . . . . . . . . . . . 25
5.1 Airworthiness Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.2 Cleaning Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.3 General Troubleshooting Procedures. . . . . . . . . . . . . . . . . . . . 25
5.4 Troubleshooting Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.0 Reference Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 3 of 28
MCD-9101-101-x
Air Jukebox
1.0 General Information
1.1 Introduction
This manual contains information for the proper installation and operation
of DeCrane Aerospace Audio International’s Air Jukebox, Model
# MCD-9101-101-x. The “-x” suffix in the model number designates the
type of connector utilized; “-1” = Positronic and “-2” = D-Subminiature.
Also included are mechanical and electrical characteristics of the unit.
1.2 Purpose of the Equipment
The MCD-9101-101-x is a single compact disc player, with a serial digital
interface and multi-disc audio file storage capabilities. It is specifically
designed to meet the special requirements of aircraft use. This unit
accepts and plays back standard audio CDs and also functions as a self-
contained media CD playback device. This enhances the normal
operation of a single CD module. It allows the temporary storage of audio
content from CD to a non-removable memory (NAND flash). It allows
complete control of track selection through a variety of front panel controls
and/or RS-485 data bus commands. The unit has a high quality output
and a full range frequency response of 20 Hz to 20 kHz ± 3 dB. A
removable cover bezel allows customization of the unit to other décor.
1.3 Operational Features
 Operates directly from +28 VDC
 Monochrome green OLED display
 Allows complete control of track selection
 Easy-to-use front panel controls
 DeCrane Aerospace Audio International proprietary RS-485 data
bus compatible
 Frequency response of 20 Hz to 20 kHz ± 3 dB
 Compact, lightweight package
 Recording into memory at 4X regular CD speed while
simultaneously performing CD playback
 Two recording bitrates at 32 kbps and 64 kbps
 Up to 7.5 hours of music can be stored in flash memory
 Approximately 450 minutes of music at 32 kbps bitrate or 225
minutes at 64 kbps bitrate
 Storage into 128 MB flash memory
 Unique sequential directory labeled song storage
 10 seconds shock-memory for CD-DA playback

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 4 of 28
1.4 Optional Equipment
1.4.1 The MCD-9101-101-x can be optionally controlled by infrared
remote or DeCrane Aerospace Audio International’s touch screen
panel. Digital codes allow the unit to interface with an infrared
handheld remote via an infrared receiver. Multiple units can be
controlled independently using available programming pins.
1.4.2 The removable front cover bezel may be customized to match the
interior style of any aircraft. This option includes plating or painting
to match aircraft décor. Each MCD-9101-101-x unit may be fitted
with bracket assemblies allowing the unit to be mounted in the
same space as any existing Audio International CD model. The
cover bezel is not an integral part of the CD and must be ordered
as a separate item (P/N 13901720). Contact your DeCrane
Aerospace Audio International representative for details.
1.4.3 DeCrane Aerospace Audio International also offers a wide variety
of monitors, speakers, headphone jacks, video distribution devices,
and other equipment that will perfectly complement the
MCD-9101-101-x.
2.0 Application
2.1 Introduction
The MCD-9101-101-x is an Air Jukebox that will accept a +5 VDC infrared
digital input and DeCrane Aerospace Audio International’s proprietary
RS-485 two-wire serial data bus input.
MCD-9101-101-x is compatible with standard commercial audio CD. Note
that since compact disc format standards are constantly evolving, some
discs may not play properly or may cause the unit to malfunction.
DeCrane Aerospace Audio International does not guarantee the
MCD-9101-101-x is compatible with all media or formats.
The MCD-9101-101-x can be mounted in a cabinet or bulkhead. A unique
ID address pin feature allows multiple devices to be used in the same
system at the same time while maintaining independent control.

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 5 of 28
2.2 Typical Application
2.2.1 This system is fully compatible with DeCrane Aerospace Audio
International’s proprietary RS-485 digital data bus system. It can be
configured for IR remote control utilizing DeCrane Aerospace Audio
International’s remote control unit and Infrared Receiver (IFR).
2.2.3 The unit can also be configured for Touch Screen or remote panel
control (i.e. entertainment control panels). The panels are on
DeCrane Aerospace Audio International’s proprietary RS-485
digital data bus system and configured to control the operational
features of the MCD-9101-101-x.

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 6 of 28
2.2.4 This unit has a digital IR input that can be directly connected to the
digital output of an Infrared Receiver (IFR) to allow for remote
control on systems that do not utilize a RS-485 control data bus.
2.3 Media and Format Compatibilities
MCD-9101-101-x is compatible with standard commercial audio CDs.
Note that since compact disc format standards are constantly evolving,
some compact discs may not play properly or may cause the unit to
malfunction. DeCrane Aerospace Audio International does not guarantee
the MCD-9101-101-x is compatible with all media or formats.
Capability to Read
•CD-DA (Normal Digital Audio CDs)
•CD-R / CD-RW
•Multisession CD
•Mixed mode CD (CD-DA part)
•CD-CA (MP3)
Capability to Record to Flash Memory
•CD-DA (Normal Digital Audio CDs)
•CD-R / CD-RW (CD-DA part)
•Multisession CD (CD-DA part)
•Mixed mode CD (CD-DA part)
•Common “Copy protected” CDs (CD-DA part)
•Can NOT record CD-CA (MP3 files) source material to flash memory

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 7 of 28
3.0 Installation
3.1 Prior to Installation
3.1.1 During the design and layout of the aircraft cabin, careful
consideration of the location of this and all other audio/visual
modules is necessary. Some of the items to be considered include:
•Space
•Proximity to other devices (i.e. source equipment)
•Available power supply
•Length of cable runs
•Environmental conditions (temperature, humidity, etc.)
•Location of other aircraft systems (i.e. oxygen delivery)
•Access for service repair (if applicable)
•Convenience for user interface (if applicable)
3.1.2 The MCD-9101-101-x shall be installed to conform to the standards
designated by the customer, installing agency, and existing
conditions as to the unit location and type of installation.
3.1.3 Mounting screws are required to secure the unit. Long low-level
audio runs may introduce noise into the audio signal.
3.1.4 All headphone amplifiers and line level amplifiers should be located
no more than 3 feet away from source equipment.
3.1.5 Avoid installing the unit where it will be exposed to excessive heat,
moisture, splashing liquids, dusty areas, direct sunlight, or
angled/inclined installation.
3.1.6 A minimum of 5" clearance is required in front of the CD slot. When
the CD is ejected, it will project approximately 2.25".
3.1.7 The installing agency shall supply and fabricate all external cables
to the MCD-9101-101-x. The length and routing of external cables
shall be carefully studied and planned before attempting installation
of the unit. Allow adequate space for installation of cable and
connectors. Mating connectors are the responsibility of the
installing agency. Correct pin assignments as outlined in Section
3.8 are the responsibility of the installing agency.

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 8 of 28
3.2 Unpacking and Inspection
3.2.1 Carefully open the packaging and remove the MCD-9101-101-x.
Verify that all components have been included in the package per
the packing list. Inspect the unit for shipping damage.
3.2.2 If damage has occurred during shipping, a claim should be filed
with DeCrane Aerospace Audio International WITHIN 24 hours and
a Return Request Authorization Number shall be obtained from
DeCrane Aerospace Audio International by contacting the Repair
Department at 501.801.8101. Repackage the unit in its original
packaging materials and return it to DeCrane Aerospace Audio
International following instructions given by the DeCrane
Aerospace Audio International representative. Refer to the front
cover of this manual for address. If no return is necessary, retain
the packing list and the packing materials for storage.
3.3 Cautions & Warnings
3.3.1 It is important to do a pin-to-pin power and ground check on all
connectors. Ensure that power and ground are applied only where
specified. Damage to the unit may result if power or ground is
applied to the wrong points.
3.3.2 DO NOT connect or disconnect the unit while power is applied.
3.3.3 DO NOT remove any factory-installed screws. Damage to the unit
may result and void any warranties.
3.3.4 DO NOT drop the unit or subject it to strong shock. The unit
contains glass parts that may break or crack.
3.3.5 DO NOT use commercially available CD accessories that can be
loaded into the CD slot (stabilizers, protective sheets, CD cleaning
discs, etc.). They can cause the unit to malfunction.
3.3.6 DO NOT use dirty CDs or CDs colored on the data side. If you try
to play CDs that are colored on the recorded side (opposite the
label), or CDs that are dirty, they may fail to slide in or out. Also, do
not put tape on CDs and attempt to insert into the unit. This could
cause failure or damage to the unit.

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 9 of 28
3.3.7 ESD (Electro Static Discharge) guidelines shall be followed.
3.3.8 No scheduled maintenance is required to ensure continued
airworthiness.
3.4 Wiring Requirements
3.4.1 Introduction
The installing agency shall supply and fabricate all external cables.
The length and routing of external cables shall be carefully studied
and planned before attempting installation of the equipment. Allow
adequate space for installation of cable and connectors. Avoid
sharp bends and placing cables near aircraft control cables.
Maintain a minimum clearance of 3" from any control cable. If wiring
is run parallel to combustible fluid or oxygen lines, maintain a
separation of 6" between the lines.
3.4.2 Power Wires
The chassis shall be electrically bonded to the airframe structure by
a conductive mounting point with <0.1 resistance using <50 
impedance cable. Aluminum wool, nylon webbing impregnated with
aluminum oxide abrasive or fiber bristle brushes are the approved
tools for removing anodized surfaces at mounting point where the
bonding wire is attached. Power and Ground wires shall be in
accordance with M227589 or equivalent.
3.4.3 Serial Digital Audio Wiring
All serial digital audio wire connections must be twisted shielded
cable with the shield properly grounded to the dedicated pin at the
source end to the dedicated pin at the load end. Twisted shielded
cable shall be 22 AWG (minimum) for digital audio signals and shall
be in accordance with NEMA WC 27500. Cable impedance must
be 110 +/- 10%.

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 10 of 28
3.4.4 Analog Audio Wiring
DeCrane Aerospace Audio International recommends that all
analog audio wire connections be twisted shielded cable with the
shield properly grounded at the source (ideal practice). If shield
cannot be grounded at the source, then ground at the load end with
opposite end floating. Twisted shielded cable shall be in
accordance with NEMA WC 27500.
3.4.5 DeCrane Aerospace Audio International’s Proprietary
RS-485 Data Bus
The MCD-9101-101-x is designed to interface with other DeCrane
Aerospace Audio International equipment via DeCrane Aerospace
Audio International’s proprietary RS-485 serial data bus. The data
bus shall be implemented using a twisted shielded pair cable in
accordance with NEMA WC 27500 or equivalent. The wire size for
the conductors in this cable shall be 22 AWG, MINIMUM. Shield
pins are available for connecting data bus shields when required.
Refer to DeCrane Aerospace Audio International document 650007
for RS-485 Serial Data Bus design architecture.
3.5 Physical Characteristics
3.5.1 Refer to Section 7.0 for unit dimensions and attachment points.
3.5.2 When mounting the unit, allow sufficient space for mating
connectors.
3.5.3 Mounting provisions are provided via four (4) 8-32 UNF-2B
threaded mounting holes – two (2) on each the left and right sides
of unit.
3.5.4 Do not insert any screw more than 0.25" into the case. Mounting
holes on the unit provide multiple anchoring points. These threaded
inserts do not have physical stops. Care should be taken not to
penetrate the outer casing with any screw more than 0.25". This
could result in serious damage to the unit.
3.5.5 Allow a MINIMUM of 1 inch of air space around the unit to allow for
proper air circulation. This unit has an internal fan and ventilation
holes in the chassis for cooling. Installation recommendation
requires 1-inch spacing from other components and structures
except the mounting surface for which the unit should be in direct
contact.

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 11 of 28
3.5.6 The cover bezel snaps easily on the MCD-9101-101-x faceplate
without the need of special tools. The cover bezel does not require
mounting bracket attachments.
3.5.7 Bonding between chassis mounting point and airframe installation
to be <0.1 ohm resistance using <50 ohm impedance cable. No
surface prep is required due to conductive chassis (except front
bezel).
3.6 Electrical Characteristics
3.6.1 Electrical Specifications
3.6.2 Typical interfaces include various AES-3 distribution and/or signal
manipulation devices. This unit is capable of interfacing and
providing output to compatible Audio International devices capable
of distributing and/or processing the source output digital audio
including, but not limited to: Audio routers, stand-alone AES-3
decoders, and audio power amplifiers with built-in AES-3 decoding
capability.
3.6.3 The MCD-9101-101-x utilizes one (1) 25-pin connector for electrical
connections, which provides power, data bus control, infrared input,
and three (3) ID address pins and a common ID for unit
identification on the RS-485 data bus and for IR control.
3.6.4 Infrared input provides a ground reference connection (-). For
optimum infrared signal transmission, this ground reference should
connect to the module being utilized.
3.6.5 The three (3) ID address pins can be connected to the ID common
to provide address configuration, on the RS-485 data bus. This
Electrical Nominal Power 0.80A @ +28 VDC
Maximum Power 1.00A @ +28 VDC
Operating Voltage Range +18 to +32 VDC
Data Bus Type DeCrane Aerospace Audio
International’s Proprietary RS-485
Audio Frequency Response 20 Hz to 20 kHz ± 3 dB
Audio Output 3 AES-3 Channels
2 VRMS (Typical)
Stereo Channel Separation <85 dB
Backlight/Digital Display Green
Infrared Signal Input +5 V digital logic level
Operating Temperature +5°to +131°F
-15°to +55°C
Storage Temperature 4°to +176°F
-20°to +80°C

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 12 of 28
allows up to eight (8) identical units to be individually controlled on
a system.
The RS-485 sub-address of each player is set by placing the
appropriate ID pin to ID COMMON.
The RS-485 sub-address of this unit is based on ID address pins as
indicated below:
ID 2 ID 1 ID 0 Sub-Address
0 0 0 0
0 0 1 1
0 1 0 2
0 1 1 3
1 0 0 4
1 0 1 5
1 1 0 6
1 1 1 7
Note: A value of 1 indicates the associated ID pin is connected to
ID COMMON. A value of 0 indicates the associated ID pin is a No
Connect.
3.7 Mating Connector Information
Model # Mating Connector
MCD-9101-101-1 RD25F10JVL0
(Positronic Industries)
MCD-9101-101-2 DAMA-25S
(ITT Cannon)

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 13 of 28
3.8 Pinout Assignment and Descriptions
Pin # Description
1 + 28 VDC
2 Circuit and Chassis Ground
3 RS-485 Serial Data Bus A (HI)
4 RS-485 Serial Data Bus B (LO)
5 RS-485 Serial Data Bus Shield
6 ID Common
7 ID 0
8 ID 1
9 ID 2
10 NC – No Connection
11 Analog Audio Output L+
12 Analog Audio Output L-
13 Analog Audio Output R+
14 Pause Input
15 Infrared Digital Input
16 AES3 Audio Output #1 +
17 AES3 Audio Output #1 -
18 AES3 Audio Output #1 Shield
19 AES3 Audio Output #2 +
20 AES3 Audio Output #2 -
21 AES3 Audio Output #2 Shield
22 AES3 Audio Output #3 +
23 AES3 Audio Output #3 -
24 AES3 Audio Output #3 Shield
25 Analog Audio Output R-
3.9 Post Installation Test
3.9.1 Verify +28 VDC power has been connected to the unit. The audio
signal output of the unit is generally connected to cabin speaker
systems in addition to headphone locations. Verify all connections
before supplying power to the unit.
3.9.2 Load the MCD-9101-101-x with a CD. Use the MCD-9101-101-x
front panel controls or the handheld remote control unit to select
PLAY. Verify audio can be heard through the speaker/headphone
system.

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 14 of 28
4.0 Operation
4.1 Overview
4.1.1 Only standard CDs can be recorded to the flash memory. Discs
containing MP3 songs can not be recorded to the flash memory,
but they can be played.
4.1.2 Recording speed is 4X faster than playback speed. A four (4)
minute song will record in about one (1) minute. A 60 minute CD
will record in about 15 minutes.
4.1.3 There are two recording bitrates (32 kbps and 64 kbps). The higher
bitrate is better quality but requires twice the amount of memory.
You can record some songs at one bitrate and other songs at a
different bitrate. The bitrate can be changed in the setup menus.
The Record Quality of previously recorded songs can not be
changed. The song must be deleted and re-recorded to change the
Record Quality of a song.
4.1.4 The flash memory can store about 450 minutes of music at 32 kbps
bitrate or about 225 minutes at 64 kbps bitrate.
4.1.5 Songs can not be played from the CD while the CD is recording,
however a work around is described in Section 4.5.
4.1.6 CD songs are stored in a unique directory labeled DIR_XX. When
songs from a new CD are recorded they will be stored in the next
sequential directory. Songs from the same CD will always be
recorded in the same directory.
4.1.7 CD song tracks are labeled TrackXX.cda. Songs stored in flash
memory are labeled TrackXX.aac. The song number (XX) when
recorded will remain the same as it is on the CD. So if Track05.cda
is recorded from the CD, it will be labeled Track05.aac in the flash
memory.
4.2 General Operation Information
4.2.1 The MCD-9101-101-x can be operated via front panel buttons or
optionally controlled by infrared remote or DeCrane Aerospace
Audio International’s touch screen panel. Digital codes allow the
unit to interface with an infrared handheld remote via an infrared
receiver. Multiple units can be controlled independently using
available programming pins.

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 15 of 28
4.2.2 Playback options with front button controls, remote or touch screen
include stop/eject, fast-forward, rewind, track repeat, and pause.
4.2.3 The MCD-9101-101-x shall automatically stop playback at the end
of the disc. Once a CD is inserted, the device will begin playing the
disc automatically (unless the unit is currently playing from flash
memory). If power is interrupted (>200 ms) or drops below +18 Vdc
while a disc is playing, then the player will automatically shut down.
When normal operating power is restored, the device will
automatically start playing again.
4.3 Front Panel Illustration
Illustration of MCD-9101-101-x front panel without cover bezel:
4.4 Front Panel Capabilities
•Common transport controls such as Play, Pause, Stop, Eject, etc.
•Special playback modes such as repeat all/album/track, and shuffle
all/album/track.
•OLED display is provided on the front of the unit to provide the
following information:
Playback selection of any song on CD or stored in flash memory
CD playback information for track and time
Song names and artist information are only available during CD playback of MP3
songs (MP3s, song titles, and artist information are not storable)
Recording of all CD tracks or selected tracks to flash memory
Deleting individual songs or entire albums from flash memory
User feedback during other operations including disc loading or audio ‘Ripping’

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 16 of 28
4.5 Front Panel OLED Screen and Menus
For detailed instructions for using the navigation keys to make menu
selections see Section 4.7.
Screen Saver
Screen Saver is active after 30 seconds of inactivity. OLED goes blank
after 1 minute of Screen Saver Mode. Any press of a button wakes up the
player, making the main screen active. An additional button must be
pushed to perform a function.
Main Menu
Playing Music
Select PLAYALL to start playing the previously recorded music from the
flash memory.
MAIN MENU
PLAY >
RECORD >
DELETE >
SETUP >
PLAY
ALL
CD >
FLASH >
0:01 1:15

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 17 of 28
Song number and total
Song name, album name,
and artist name (if available)
Play, pause, or stop status
Current song time Total song time
The status of the current playing track will then appear on screen.
Playing CDs
Select PLAYCDALL to start playing the CD from the first track.
SONG 1/
53
Track01.aac
DIR_0001
0:01 1:15
PLAY
ALL
CD >
FLASH >



PLAY CD DIR
ALL
DIR_0001 >
SONG 1/
12
Track01.cda
DIR_0001
0:01 1:15
PLAY
ALL
CD >
FLASH >



PLAY CD DIR
ALL
DIR_0001 >



PLAY CD SONG
ALL
Track_01.cda
Track_02.cda
Track_03.cda
Track_04.cda

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 18 of 28
Select PLAYCDDIR_01TrackXX to play a particular CD track.
Playing from Flash Memory
From the Main Menu select PLAYFLASHALL to start playing from the
first directory and song in memory.
Select PLAYFLASHDIR_XXTrackXX to start playing from a
particular directory and / or song.
Recording a CD to Flash Memory



PLAY FLASH DIR
ALL
DIR_0001 >
DIR_0002 >
DIR_0003 >
DIR_0004
>
PLAY
ALL
CD >
FLASH >



PLAY FLASH DIR
ALL
DIR_0001 >
DIR_0002 >
DIR_0003 >
DIR_0004
>
PLAY
ALL
CD >
FLASH >
MAIN MENU
PLAY >
RECORD >
DELETE >
SETUP >



RECORD CD SONG
ALL
Track_01.cda >
Track_02.cda >
Track_03.cda >
Track_04.cda
>



RECORDING
SONG 1/12
SONG PROGRESS 35%
TASK PROGRESS 50%

DeCrane Aerospace Audio International MCD-9101-101-x Installation & Operation Manual
Document # 540360, Rev IR, 03/2008 Page 19 of 28
•Insert CD to record
•From the Main Menu select RECORDALL to start recording the
entire CD to memory, or select RECORDTrackXX to start recording
a particular track.
•While recording, songs stored in flash memory can be played. Songs
on the CD can not be played while recording from the CD.
•If none of the songs on the CD have previously been recorded to
memory, a new directory will be created and the songs will be stored in
that directory.
•If some songs from the CD were already recorded to a directory in
memory, any new songs recorded from that CD will be added to that
directory.
•If all the songs on the CD are already recorded to memory, the
recording task will complete immediately, because all the songs are
already stored. You can not record the same song from the same CD
multiple times to memory.
•If it is desired to record the same song at a different bitrate, the song
must first be deleted from memory and then recorded again.
Playing songs from a CD while recording the same CD
•You can not play songs from a CD while recording from the CD.
However, since recording is 4X faster than playing, you can start
recording a CD then immediately start playing the first track of the CD
from flash memory. In this way, you can play the CD songs while it’s
recording but you are actually playing from flash memory, not the CD.
Recording progress appears
in the upper right hand corner.
Deleting songs from Flash Memory



DELETE FLASH DIR
DELETE ALL FLASH
DIR_0001 >
DIR_0002 >
DIR_0003 >
DIR_0004
>
MAIN MENU
PLAY >
RECORD >
DELETE >
SETUP >
SONG 1/
10
REC: 25%
Track01.cda
DIR_0001
0:01 1:15
