Rowe GrandSTAR User manual

GrandSTAR®
Internet Jukebox
22022603
Volume 1 of 1
Rev. G

GrandSTAR Internet Jukebox Safety
22022603 i
Safety
IMPORTANT SAFETY INFORMATION
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this jukebox near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other jukebox
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the jukebox.
11. Only use the attachments/accessories specified by the
manufacturer.
12. Unplug this jukebox during lightning storms or when
unused for long periods of time.
13. Refer all servicing to qualified service personnel.
Servicing is required when the jukebox has been
damaged in any way, such as when the power-supply
cord or plug is damaged, liquid has been spilled or
objects have fallen into the jukebox, the jukebox has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
14. When replacing a battery – “CAUTION: Danger of
explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.”

Safety GrandSTAR Internet Jukebox
ii 22022603
CAUTION!
The lightning flash with arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of non-
insulated “dangerous voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a risk of electric shock
to persons.
CAUTION!
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance or servicing instructions.
! WARNING!
Do not expose this jukebox to rain or moisture.
No objects filled with liquid, such as vases, shall be placed on the
jukebox.
DO NOT REMOVE ANY COVERS, GUARDS, OR SHIELDS.
NO USER SERVICEABLE PARTS ARE INSIDE THIS JUKEBOX.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
CAUTION!
RISK OF ELECTRIC SHOCK
DO NOT OPEN

GrandSTAR Internet Jukebox Contents
22022603 iii
Table of Contents
SECTION: 1 UNPACKING & SYSTEM DESCRIPTION .................................................................1-1
Introduction ...............................................................................................................................1-1
GrandSTAR Jukebox Features.................................................................................................1-2
General Features: ...............................................................................................................1-2
Service Features: .................................................................................................................1-2
Unpacking Instructions..............................................................................................................1-3
Doors ........................................................................................................................................1-3
Visual Inspection.......................................................................................................................1-3
Handy Case ..............................................................................................................................1-3
Warranty Registration Card ......................................................................................................1-3
Major Components of the GrandSTAR .....................................................................................1-4
Core Computer.....................................................................................................................1-4
Touch-screen 19” LCD Monitor............................................................................................1-4
System Power Supply ..........................................................................................................1-4
Transformer Assembly .........................................................................................................1-4
Rowelink Controller ..............................................................................................................1-4
LED Controller......................................................................................................................1-4
Router ..................................................................................................................................1-4
Dial-Up Modem ....................................................................................................................1-4
Volume Control Unit .............................................................................................................1-5
4 Channel Preamplifier.........................................................................................................1-5
1000-Watt Audio Digital Power Amplifier .............................................................................1-5
Audio Output Transformers..................................................................................................1-5
Bill Acceptor .........................................................................................................................1-5
GrandSTAR Specifications .......................................................................................................1-7
Sound System......................................................................................................................1-7
Fuses And Circuit Breakers .................................................................................................1-7
Lighting.................................................................................................................................1-7
SECTION: 2 INSTALLING HARD DRIVE & TESTING...................................................................2-1
Installing the Hard Drive............................................................................................................2-1
Testing the Unit.........................................................................................................................2-5
Touchscreen ........................................................................................................................2-5
Credit Test............................................................................................................................2-6
Audio Test ............................................................................................................................2-6
Music Selection And Pricing.................................................................................................2-7
Connection Rules......................................................................................................................2-7
Wireless Router Reception .......................................................................................................2-8

Contents GrandSTAR Internet Jukebox
iv 22022603
SECTION: 3 SOUND SYSTEM SETUP ..........................................................................................3-1
Introduction ...............................................................................................................................3-1
Extension Speaker Operation ..............................................................................................3-1
70-Volt Speakers..................................................................................................................3-1
Low Impedance Speakers....................................................................................................3-2
Selecting Speaker Power .........................................................................................................3-3
General Instructions.............................................................................................................3-3
Selection Procedures...........................................................................................................3-3
Extension Speakers Connected E1 to E7............................................................................3-3
4-Ohm Speakers Connected To Transformer Taps E1 through E6.....................................3-4
4-Ohm Speakers connected to Channel 1 transformer taps................................................3-4
4-Ohm Speakers connected to Channel 2 transformer taps................................................3-4
8-OHM Speakers Connected To Transformer Taps E1 through E6 ....................................3-5
8-Ohm Speakers connected to Channel 1 transformer taps................................................3-5
8-Ohm Speakers connected to Channel 2 transformer taps...............................................3-5
Combine Power Consumption of all Speakers.....................................................................3-6
Amplifier Overload Check ....................................................................................................3-7
Speaker Synopsis...................................................................................................................3-11
1000 Watts of RMS Power per Amplifier or 500 Watts per Channel..................................3-11
SECTION: 4 ADDING MICROPHONES .........................................................................................4-1
SECTION: 5 LED LIGHTING AND BILL ACCEPTOR ...................................................................5-1
Introduction ...............................................................................................................................5-1
LED Control Assembly (#40931103)....................................................................................5-1
Features of the LED Control Assembly (#40931103) (Figure 5-2).......................................5-1
Flash Rate (Speed) of the LEDs ..........................................................................................5-2
Brightness of the LEDs ........................................................................................................5-2
Music Beat Sensitivity ..........................................................................................................5-2
Remote Enable/Disable Program Switch.............................................................................5-2
Setting LED Mode................................................................................................................5-3
Adjusting Mode with the IR Remote .........................................................................................5-3
Setting Pattern .....................................................................................................................5-4
Adjusting Patter with the IR Remote ....................................................................................5-4
Bill Acceptor Settings................................................................................................................5-5
Coinco Vantage Setup .........................................................................................................5-5
MEI AE2611 Setup...............................................................................................................5-7
SECTION: 6 ROUTINE SERVICE...................................................................................................6-1
Introduction ...............................................................................................................................6-1
Preventive Maintenance ...........................................................................................................6-2
Exterior.................................................................................................................................6-2
Touch-screen Calibration.....................................................................................................6-2
Air Filter................................................................................................................................6-3
SECTION: 7 TROUBLESHOOTING ...............................................................................................7-1

GrandSTAR Internet Jukebox Contents
22022603 v
Introduction ...............................................................................................................................7-1
Power Supply Board .................................................................................................................7-2
+9 V LED..............................................................................................................................7-2
+12 V LED............................................................................................................................7-2
+24 V LED............................................................................................................................7-2
Rowelink Controller...................................................................................................................7-2
5 VDC, 12 VDC, 24 VDC LEDs............................................................................................7-2
IR RCV LED .........................................................................................................................7-2
KID RL TX LED ....................................................................................................................7-2
Core Computer RL RX LED .................................................................................................7-2
Core Computer RL TX LED .................................................................................................7-2
CRDT RL TX LED ................................................................................................................7-2
CRDT Status LED ................................................................................................................7-2
4 Channel Preamplifier .............................................................................................................7-3
Power LED ...........................................................................................................................7-3
Status LED ...........................................................................................................................7-3
Rowelink LED.......................................................................................................................7-3
Volume Control Unit..................................................................................................................7-3
Period LED (on the 10’s digit) ..............................................................................................7-3
Period LED (on the 1’s digit) ................................................................................................7-3
Power Amplifier.........................................................................................................................7-3
Yellow Clip LED ...................................................................................................................7-3
Red Overload LED ...............................................................................................................7-3
Computer Core Assembly.........................................................................................................7-3
Hard Drive Green LED .........................................................................................................7-3
Hard Drive Red LED ............................................................................................................7-3
Sequence of Operation.............................................................................................................7-4
Troubleshooting Charts...........................................................................................................7-12
SECTION: 8 PARTS CATALOG.....................................................................................................8-1
Introduction ...............................................................................................................................8-3
Catalog Description..............................................................................................................8-3
Parts List Description ...........................................................................................................8-3
Ordering Replacement Parts................................................................................................8-3
Jukebox Assembly (Front View) ...............................................................................................8-4
Jukebox Assembly (Rear View) ................................................................................................8-6
Top Door Assembly (External View) .........................................................................................8-8
Top Door Assembly (Internal View) ........................................................................................8-10
Top Door Assembly (Internal — Top and Side View) .............................................................8-12
Lower Door Assembly (External View) ...................................................................................8-14
Lower Door Assembly (Internal View).....................................................................................8-15
Component Identification and Location (Internal View, Left Hand Side).................................8-16
Pilaster Assembly (Left Hand Shown) ....................................................................................8-18

Contents GrandSTAR Internet Jukebox
vi 22022603
Component Identification and Location (Internal View, Right Hand Side) ..............................8-20
Shell Assembly (Front View with Lower Door Removed) .......................................................8-22
Bill Acceptor Assembly ...........................................................................................................8-24
Core Computer Assembly - Exploded View............................................................................8-26
LED Controller Assembly........................................................................................................8-28
Transformer Assembly............................................................................................................8-29
Power Supply Assembly .........................................................................................................8-30
4 Channel Preamplifier ...........................................................................................................8-31
Output Transformer Assembly................................................................................................8-32
Rowelink Controller Assembly ................................................................................................8-33
19" TouchScreen and Panel Assembly ..................................................................................8-34
Accessory Equipment .............................................................................................................8-35

GrandSTAR Internet Jukebox Tables
22022603 vii
List of Tables
Table 3-1 -Extension Speaker Worksheet Sheet 1..................................................................................... 3-3
Table 3-2 -Extension Speaker Worksheet Sheet 2..................................................................................... 3-4
Table 3-3 -Extension Speaker Worksheet Sheet 3..................................................................................... 3-5
Table 3-4 -Extension Speaker Worksheet Sheet 4..................................................................................... 3-6
Table 3-5 - Jukebox Speaker Power............................................................................................................. 3-6

Tables GrandSTAR Internet Jukebox
viii 22022603
This page intentionally left blank

GrandSTAR Internet Jukebox Figures
22022603 ix
List of Figures
Figure 1-1 - Major Components ....................................................................................................................... 1-6
Figure 2-1 - Removing Hard Drive Housing..................................................................................................... 2-1
Figure 2-2 - Hard Drive Installed in Housing.................................................................................................... 2-2
Figure 2-3 - IDE & Power Cable ...................................................................................................................... 2-3
Figure 2-4 - Hard Drive Installed...................................................................................................................... 2-4
Figure 2-5 - Rowelink Controller ...................................................................................................................... 2-5
Figure 2-6 - Calibration Screen........................................................................................................................ 2-5
Figure 2-7 - Jukebox User Interface ................................................................................................................ 2-6
Figure 2-8 - Wireless Router Antenna in Horizontal Position .......................................................................... 2-8
Figure 2-9 - Wireless Router Antenna in Vertical Position............................................................................... 2-9
Figure 3-1 - Speaker Connections ................................................................................................................... 3-8
Figure 3-2 - Audio Output Transformer Wiring Diagram (#40832115) .......................................................... 3-10
Figure 3-3 Diagrams 1 - 5 - External Speaker Connections with Jukebox Speakers Connected ................. 3-12
Figure 3-4 Diagrams 1N - 3N – External Speaker Connections with Jukebox Speakers NOT Connected .. 3-17
Figure 3-5 - Volume Control Unit ................................................................................................................... 3-20
Figure 3-6 – Volume Connections Using Existing 3-Wire or 4-Wire Cable ................................................... 3-21
Figure 4-1 - Microphone Connections.............................................................................................................. 4-1
Figure 4-2 - Paging Microphone Setup Screen................................................................................................ 4-2
Figure 4-3 – VCU Setup Screen ...................................................................................................................... 4-3
Figure 5-1 – IR Remote.................................................................................................................................... 5-1
Figure 5-2 – LED Control Assembly ................................................................................................................ 5-4
Figure 5-3 – Program DIP Switches ................................................................................................................ 5-4
Figure 5-4 - Coinco Vantage DIP Switch Settings ........................................................................................... 5-5
Figure 5-5 - Service Mode Button and Diagnostic Indicator LED .................................................................... 5-5
Figure 5-6 - Removing the Lower Housing ...................................................................................................... 5-6
Figure 5-7 - Configuration Settings .................................................................................................................. 5-6
Figure 5-8 - MEI Bill Acceptor .......................................................................................................................... 5-7
Figure 6-1 – Calibrate Button........................................................................................................................... 6-2
Figure 6-2 – Calibration Screen ....................................................................................................................... 6-2
Figure 6-3 – Filter Removal.............................................................................................................................. 6-3
Figure 7-1 – GrandSTAR Wiring Diagram (Sheet 1) ....................................................................................... 7-5
Figure 8-1 – Front View.................................................................................................................................... 8-4
Figure 8-2 – Rear View .................................................................................................................................... 8-6
Figure 8-3 – Top Door Assembly (External View)............................................................................................ 8-8
Figure 8-4 – Top Door Assembly (Internal View)........................................................................................... 8-10
Figure 8-5 – Top Door Assembly (Internal - Top and Side View).................................................................. 8-12
Figure 8-6 – Lower Door Assembly (External View)...................................................................................... 8-14
Figure 8-7 – Lower Door Assembly (Internal View) ....................................................................................... 8-15
Figure 8-8 – Component Identification and Location (Internal View, Left Hand Side)................................... 8-16
Figure 8-9 – Pilaster Assembly (Left Hand Shown)....................................................................................... 8-18
Figure 8-10 – Component Identification and Location (Internal View, Right Hand Side) .............................. 8-20

Figures GrandSTAR Internet Jukebox
x 22022603
Figure 8-11 – Shell Assembly (Front View with Lower Door Removed) ........................................................8-22
Figure 8-12 – Bill Acceptor Assembly.............................................................................................................8-24
Figure 8-13 – Core Computer Assembly - Exploded View.............................................................................8-26
Figure 8-14 – LED Controller Assembly.........................................................................................................8-28
Figure 8-15 – Power Transformer Assembly..................................................................................................8-29
Figure 8-16 – Power Supply Assembly ..........................................................................................................8-30
Figure 8-17 – 4 Channel Preamplifier.............................................................................................................8-31
Figure 8-18 – Output Transformer Assembly .................................................................................................8-32
Figure 8-19 – Rowelink Controller Assembly .................................................................................................8-33
Figure 8-20 – 19" Touchscreen and Panel Assembly ....................................................................................8-34

GrandSTAR Internet Jukebox Unpacking & System Description
22022603 1-1
Section: 1 Unpacking & System Description
Introduction
The GrandSTAR®jukebox is part of a much larger system - the AMI Entertainment™
network. This network is a digital platform that delivers music across the Internet to Rowe®
Jukeboxes anywhere.
The GrandSTAR jukebox is an Internet-enabled jukebox that allows all the traditional
functions of a jukebox backed by the power of the Internet. This Internet connectivity gives
patrons more features, such as the ability to download “Music On Demand” songs when
their song choice is not already on the jukebox.

Unpacking & System Description GrandSTAR Internet Jukebox
1-2 22022603
GrandSTAR Jukebox Features
The major GrandSTAR features are:
General Features:
•Sturdy construction and reliable design
•Conveniently located customer, operator, and service controls
•All major components are modular and easy to replace, if needed
•Computer-controlled digital music
•A 1000-watt amplifier with dual 5-band graphic equalizers
•Song reject
•300 album and cover art capacity
•Unwanted music categories can be blocked
•Quarter Coin Acceptance
•Bill acceptance of $1, $5, $10, and $20
•1000-bill capacity
•Web-based management
•Attract mode
•“Music On Demand” song download
•Dynamic search capabilities
•No pause between plays
•Easy to change pricing
Service Features:
•All servicing can be done from the front of the jukebox
•Modular component construction for easy replacement
•No CD’s to bother with or cumbersome cover art mechanisms
•Complete cash and play audit information
•Password protected Operator web site
•Access anytime and from anywhere
•Track revenue and usage
•Download new music and other content
•Check system status

GrandSTAR Internet Jukebox Unpacking & System Description
22022603 1-3
Unpacking Instructions
This section contains information for unpacking the jukebox and installing it at a location.
The jukebox is shipped with all major components except the Volume Control Unit in place.
1. Remove the shipping carton with care: Do not use shipping hooks or sharp tools that
could damage the jukebox cabinet.
2. Remove the plastic bag that covers the jukebox.
3. Carefully inspect the interior and exterior of the jukebox to ensure that no damage
occurred during transit.
If damage is detected, the carrier who delivered the jukebox should be contacted
immediately to examine it. Regardless of the exterior condition of the shipping cartons, the
carrier should be called and notified of damage. Do not destroy packing material or boxes
until the carrier’s agent has examined them.
Damage claims are your responsibility. Do not return damaged merchandise until after your
claim has been established. Once your claim has been established, merchandise may be
returned to your Rowe distributor for repair. The invoice amount for repair charges can then
be collected from the carrier.
Doors
Locate the white bag in the coin return on the side of the cabinet. Remove the door key
from the bag and unlock the door. Turn the key to the right and press in on the door as you
turn the key.
Visual Inspection
Check to be sure that all electrical plugs are completely seated into their receptacles.
Handy Case
Locate the Handy Case in a blue plastic envelope. The Handy Case contains a variety of
items, including this jukebox service manual and parts catalog, Volume Control Unit, spare
parts, and fuses. Keep the Handy Case with the jukebox at all times for ready reference.
Warranty Registration Card
A postage-paid Warranty Registration Card is included in this manual. This card should be
filled out and returned to Rowe.

Unpacking & System Description GrandSTAR Internet Jukebox
1-4 22022603
Major Components of the GrandSTAR
Figure 1-1 shows the major components of the GrandSTAR Jukebox. Take a minute to familiarize
yourself with these components.
Core Computer
The Core Computer is the heart of the system and has a hard drive and a single board
computer. The hard drive is the only storage in the system and contains Windows XP
Embedded Operating System software, all Application software, all music, and all setup and
audit data. The single board computer converts music selections stored on the hard drive
into a stereo signal for the system’s audio components. It also connects to the Internet, the
SVGA touch-screen monitor, and the Rowelink modules.
Touch-screen 19” LCD Monitor
All machine operations are done through the touch-screen monitor. These include viewing
and making selections, displaying the selection being played, displaying pricing and credits,
viewing and changing setup and audit data, and downloading “Music On Demand”
selections.
System Power Supply
The system power supply produces +9 VDC, +12 VDC, +24 VDC, and contains a relay to
switch the jukebox lights, touch-screen monitor, and the Bill Acceptor ON or OFF. It has an
IEC 320 power inlet, two 6A circuit breakers, a 3A breaker (unused in GrandSTAR) and two
4A fuses.
Transformer Assembly
The transformer assembly supplies power for the Audio/Video Controller, 1000-Watt Audio
Digital Amplifier, and the system power supply described above.
Rowelink Controller
The Rowelink controller connects the Core Computer’s serial RS-232 COM2 port to the
serial RS-485 Rowelink modules. It also includes the interface circuits for the coin switch,
router reset, fan circuits, bill acceptor, song reject, infrared remote control detector and
amplifier mute.
LED Controller
This module controls the LEDs that illuminate the perimeter lighting on the top door, the
door graphics, and the lower cabinet pilasters of the jukebox. It provides adjustments for the
Brightness, Flash Rate, and Music Sensitivity along with controls for the patterns used
during standby and, separately, the times when music is playing.
Router
This device provides the interface between the Core Computer and the broadband modem
or satellite receiver. There is a one-time configuration process to set this device for your
particular Internet Service Provider (ISP). In addition to the port required for the Core
Computer, there are three other ports provided for other devices.
Dial-Up Modem
This device provides the ability to use a standard dialup Internet connection for locations
where Broadband access is unavailable.

GrandSTAR Internet Jukebox Unpacking & System Description
22022603 1-5
Volume Control Unit
The Volume Control Unit (VCU) shown in Figure 3-5, is a Rowelink module and should be
mounted remotely (behind bar, etc.). A plate is supplied in the Handy Pack to cover the hole
if the VCU is removed. Use the VCU screws to secure the plate. It displays and controls the
volume of the amplifier channels and microphones. If an existing 100 foot cable is already in
place, you can use the 3-wire or 4-wire (see Figure 3-6) alternate wiring.
•The POWER button turns the GrandSTAR Jukebox lights, touch-screen monitor and Bill
Acceptor ON or OFF.
•The REJECT button rejects the selection playing.
•The FUTURE button adds credits toward selections (See “Credit Management” in the
Operator Setup Screens Manual).
•The MODE key toggles between channels and microphones.
•The VCU also raises or lowers the volume of the channel(s) or microphone using the UP
DOWN keys. The volume range is 0 to 63. Channel Volume is displayed when the
mode LED is off, and microphone volume is displayed when the mode LED is on.
The CH, MIC, and SINGER LEDs indicate what volume is being displayed when toggled
by the Mode Switch. When adjusting channel volume, if more than one LED is on, it
means those channels have the same volume. All four channels have the same volume
when shipped from the factory (see Section 3 of the included “Network Setup, Jukebox
Operation, Operator Setup Screens” manual for other possible configurations).
4 Channel Preamplifier
This Rowelink module transforms audio signals from the Core Computer, microphones, and
other sound processors/equipment/systems into signals for the Power Amplifier. It also
contains Automatic Volume Control (AVC) to adjust for varying recording levels and tone
controls via 5-band equalizers. All adjustments and options are programmable via the
touch-screen and are retained on the Core Computer hard drive (see Section 3 of the
included “Network Setup, Jukebox Operation, Operator Setup Screens” manual for setup
information).
1000-Watt Audio Digital Power Amplifier
The 2-channel digital audio power amplifier is rated 1000 watts RMS (500 per channel) into
a 2-ohm load. The full volume output voltage is 32 volts.
The amplifier is protected against overloads and short circuits. Continuous severe
overloads or shorts may shut down the amplifier (or a channel) but will not damage it. If the
overload is removed a signal will reset the amplifier when the next selection plays.
Audio Output Transformers
The output transformers “step up” the power amplifiers output voltage for 70-volt extension
speakers. They also provide screw connections for selecting different power levels for
extension speakers.
Bill Acceptor
The Coinco®Vantage™, with an 1100-bill stacker or optional MEI®Series 2000 bill acceptor,
with a 1000-bill stacker, operates on 120 VAC input power and sends its pulsed credit
signals to the Rowelink Controller.

Unpacking & System Description GrandSTAR Internet Jukebox
1-6 22022603
Figure 1-1 - Major Components
POWER
TRANSFORMER
CORE
COMPUTER
ROWELINK
CONTROLLER
ROUTER
SURGE
SUPPRESSOR &
ON/OFF SWITCH
COIN
ACCEPTOR
COIN INLET
BILL ACCEPTOR
LED
CONTROLLER
SYSTEM POWER
SUPPLY
AUDIO OUTPUT
TRANSFORMER
CABINET FAN
VOLUME
CONTROL UNIT
4 CHANNEL
PREAMPLIFIER
1000 WATT DIGITAL
AMPLIFIER
DIAL-UP
MODEM
LOW
FREQUENC
Y
SPEAKERS
TOUCH-SCREEN &
19” LCD MONITOR
HIGH-FREQUENC
Y
SPEAKER
LCD POWER
A
DAPTER
MID-FREQUENC
Y
SPEAKER
A
TX RESET SWITCH
(BEHIND BILL ACCEPTOR)
ROUTER RESET
SWITCH

GrandSTAR Internet Jukebox Unpacking & System Description
22022603 1-7
GrandSTAR Specifications
General
Depth.................................................................................................................25-1/2 in.
Width .................................................................................................................41-1/2 in.
Height ................................................................................................................63-1/2 in.
Power Requirements.............................................................................. 120 VAC 60 Hz.
1200 watts 11.9 amps
Pricing ...................................................................................................See “Credit Pricing” in
The “Network Setup and Jukebox Operation Manual” (P/N21822693)
Bill Acceptor ......................Coinco Vantage w/1100 Bill Stacker. Accepts $1, $5, $10, & $20
Or Optional MEI Series 2000 w/1000 Bill Stacker. Accepts $1, $5, $10, & $20
Coin Acceptor...................................................................................................... Accepts 25¢
Credit Card Reader ......................................................... Optional Magnetic Card Reader Kit
Touch-screen Monitor ................................................................ 19" LCD with Touch-screen
Sound System
Core Computer Type................................................................................... 16-bit Stereo
Frequency Response ............................................................................ 20 to 20,000 Hz.
Channel Separation........................................................................... 90 dB @ 1,000 Hz.
Output................................................................0.7 V (approx. depending on the album)
Power Amplifier (Second 1000-watt Stereo Amplifier is Optional)
1000-Watt Stereo
FTC Rating, 2-ohm Loads @ .5% THD................................................. 1000 watts RMS
FTC Rating, 70V Lines @ .5% THD (125 per channel)........................... 250 watts RMS
4 Channel Preamplifier
Channels (Two Stereo, or One Stereo and Two Mono, of Four Mono).................... Four
AVC Control Range................................................................................................ 20 dB
Tone control is accomplished through a 5-band equalizer (10dB/filter band)
Selection System Capacity .................................................................................300 Albums
Transformer Package
70 V line for extension speakers
System Frequency Response ............................................................40 to 20,000 ±4 dB
Fuses And Circuit Breakers
System Power Supply
120 VAC (Transformer Primary Only) ................................. Two 6-amp Circuit Breakers
24 VAC ..........................................................................................................4-amp Fuse
+12 VDC........................................................................................................4-amp Fuse
Lighting
LED ..................................................................................................................... Custom

Unpacking & System Description GrandSTAR Internet Jukebox
1-8 22022603
