Console - 20 : Vinyl LP Multichanger
User Manual

2
Contents
1. Introduction Pg 3
2. Important Safety Instructions Pg 4
3. Console - 20 Overview Pg 6
4. Transit Mode Pg 7
5. Touchpad Controls Pg 11
6. Loading Records Pg 12
7. Making Selections / Playing a Record Pg 13
8. Ejecting a Record Pg 14
9. Remote Control Operation Pg 15
10. Adjusting Volume / Sleep Mode Pg 16
11. Shuffle Mode and Sequential Play Pg 17
12. Connecting external audio devices Pg 18
12. Bluetooth Pg 19
13. Lighting Adjustment Pg 20
14. Troubleshooting and Error Codes Pg 21

3
Introduction
Thank you for purchasing the Console - 20 from Sound Leisure, the world’s
premier Jukebox manufacturer. This product has been designed and built to give
you many years of enjoyment and trouble free use.
This owner’s guide provides all the information you will need to install and
operate the product safely.
About Sound Leisure
Sound Leisure has been hand building high quality audio systems and classic
styled Jukeboxes in Leeds, UK since 1978. Started by Alan Black, the company
is still owned and run by the Black family and employs around 80 highly skilled
people.

4
Important Safety Instructions
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves
or other apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has 2 blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or
the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Use only the cart, stand, bracket or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when unused for long
periods of time.
• Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as if a power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally or has been dropped.
Additionally

5
• This product contains high voltage & high temperature parts. Do not attempt
to carry out any work that is not specifically instructed in this manual. If the
product fails to operate correctly, switch off the machine and contact Sound
Leisure.
• This product is heavy. DO NOT attempt to lift the unit.
• This appliance must be connected to a mains socket with a protective earth
connection.
• The mains plug is the designated ‘disconnection device’ and as such should
be readily operable.
• ‘WARNING’ To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
• Fuses should be replaced like for like at all times.
• Terminals marked with the symbol above are considered hazardous live
and external wiring connected to these terminals requires installation by an
instructed person or the use of ready made contact leads.
• This product contains transmitter module FCC ID : T9J-RN52
• Refer to Bluetooth section for more information.
• This product is approved for operation :
below 2000m elevation
between 0°C and 40°C

6
FIG 1: Console - 20 Overview
I
II
III
IV
I. Glass lid (Shown Open). / II. Touchpad control panel. / III. Front glass.
IV. Removable magnetic speaker covers. //REAR// V Rear door bolts / VI Audio
panel : Aux Inputs / Outputs - Reset button - 3 band Eq / VII Power socket and
main power switch.
VIII. Speaker covers removed to
show location of internal LCD
display.
VIII
V
VI
VII

7
Taking Delivery / Transit Mode
Once the Console - 20 has been positioned in its designated space the
following instructions will allow you to prepare it for use.
NOTE : To remove the Console - 20 from transit mode you will need to gain
access to the rear panel. It is important to be able to gain full access to the rear
panel yet still position the Console - 20 once out of transit mode. It is advisable
to find a position where it is able to be repositioned to its final place easily and
safely whilst still having access to the rear panel.
Transit Mode
Upon delivery the player mechanism will be locked into position by 2 x 10mm
bolts. The tone arm and platter motor are also held in place by a retaining plate
and there will be various pieces of packing and foam supports holding the
mechanism and playing components in place. It is important to work through
methodically to remove these in order to set the Console - 20 up - ready to play.
The following pages will show how to remove all these items and set up, ready
to play.
Ensure you store the removed components safely as these will be required
should you need to move the Console - 20 in the future.
Remove the packing foam
Upon delivery the Console -20 will contain various bits of card and foam
packing designed to wedge into moving parts ensuring that they do not move in
transit. These will be required to be removed. The location of the foam packing
is shown in the image below. Gently grasp and pull any foam free.
FIG 2:
Remove denoted
packing foam
- Shown from
rear door.

8
Removing the transit retaining bolts and foam. Fig 3
• With the Console - 20 powered OFF unbolt and remove the rear door.
PLEASE NOTE that there may be packing foam between the rear door and the
mechanism. Remove this and store for future use.
• At the base of the mechanism and you will see 2 x 10mm retaining bolts
securing two wooden blocks and a section of retaining foam underneath the
mechanism arm.
• Remove the retaining foam from beneath the mechanism arm by gently pulling
the foam to the left (towards the record stack).
• Using a 10mm spanner or socket screwdriver, carefully remove the retaining
bolts and the wooden blocks avoiding any contact with the LP Changer Arm.
The Lower section of the mechanism is now ready.
Preparing the Playing Area
• From the rear of the machine (through the rear access door) reach up and push
the glass lid from underneath to raise it. Go to the front of the machine and
Manually raise the glass to its full height.
• Look into the playing area on the right hand side of the cabinet -
as shown in Fig 4.
• Carefully remove the transit plate retaining tabs by loosening the screws with a
suitable screwdriver then removing the bolts with a 5mm nut spinner or spanner.
The transit plate is now able to be lifted from the playing platter and tone arm.
It is important to remove the plate by lifting directly UP so as not to damage the
tone arm. The plate should be kept safe for use if the Console is to be moved in
the future.
• Remove the retaining foam from under the tone arm.
• Remove the clear plastic stylus cover (shown in FIG 4) by sliding it towards you.
• Manually close the top glass.
• Power on the Console-20 using the main power switch on the rear of the
cabinet. (Fig1)
• Press the white RESET button on the back of the Console. (Fig 1) to exit transit
mode. The mechanism will raise then return to its home position with the LP
changer arm at the top.
• The Console-20 is now ready to load records and play.

9
FIG 3: LP Mechanism as seen from above
FIG 4: LP Mechanism playing area
I. Retaining foam / II. 2 x 10MM retaining bolts. / III Wooden blocks
I
II
III
II
III
IV
I
I. Transit plate retaining screws and bolts / II. Transit plate / III. Retaining
foam / IV. Tone arm / V. Stylus cover - gently pull forward to remove
V

10
Placing the Console-20 in Transit mode
REMOVE ALL RECORDS BEFORE TRANSIT
• Should you need to move the Console - 20 it is recommended you put
it into “Transit” mode. This ensures that nothing can be damaged whilst
it is being transported.
• ENSURE that all records are removed from the Console - 20 before
transporting
To place in Transit mode :
• When the Console is “idle - i.e. not playing a record” press and hold
the white RESET button on the rear of the Console for 5 seconds
• The mechanism will first move to its home position at the top of the
cabinet. Then the LP changer arm will move to the lowest position in
the cabinet.
• Replace all the playing area transit parts.
• Using a suitable screwdriver, replace the screws into the transit
plate and secure.
• Replace the tone arm sponge and stylus cover.
• Once the transit components in the playing area are secure close the
top glass.
• Power off the Console - 20 using the power switch on the back.
• Open the back door of the cabinet.
• The wooden transit blocks and retaining bolts can be replaced and
screwed securely into position.
• Replace the foam underneath the mechanism arm.
• Replace any additional foam between the door and the mechanism
before replacing the back door of the cabinet.
• The Console - 20 can now be safely moved.

11
Touchpad Controls
The Console - 20 utilises a capacitive touchpad for the majority of its controls (The
console - is supplied with an additional remote control for further functionality) Using
the touchpad is simple and requires only a light touch to select items. When an item is
selected the LED light above the item will be lit in either Red or Green. As a touchpad
selection may have more than one function, these colours might indicate different
things so its important to read this manual to familiourise yourself with the lights.
123456789 AB
0
Sound Leisure Music Systems
FIG 5: Touchpad Controls
I. LP Number Selections // II. A and B side selection // III. Play - Speed select -
Initiate shuffle mode // IV. Eject side/all - Cancel - Raise Lid - Initiate load mode //
V. Volume // VI. Sleep mode
II
III
I
V
VI
IV
Console Operation

12
CAUTION! MOVING PARTS! THE MECHANISM OF THE CONSOLE-20
CONTAINS MOVING AND ROTATING PARTS. PLEASE BE VERY CAREFUL
WHEN LOADING OR OPERATING WITH THE TOP GLASS OPEN. ENSURE THAT
LOOSE CLOTHING, JEWELLERY, LONG HAIR ETC ARE KEPT AWAY FROM THE
Console MECHANISM
The Console - 20 has an auto loading mechanism to ensure the safe delivery of
your vinyl records. DO NOT attempt to load records manually as this will cause
damage to your records and the console : Follow the procedure carefully.
How to load records using the auto load facility
• Eject any records currently playing using the eject button on the
touchpad. The mechanism will return the record to its position in the
record stack and the changer arm will return to its idle position.
• Use the eject button on the touchpad again to open the top glass
door of the console. The lid will open a small amount. Manually lift the
glass the rest of the way open.
• Press the eject button on the touchpad once more and the LED above
the eject button will illuminate RED. This indicates the Console is in load
mode. (The load button on the playdeck will also illuminate Red)
• Select the number of the record position you wish to load using the
number keys 0 - 20 then press the “Play” button.
• The mechanism will move and select the record chosen and place it on
the turntable.
NOTE : Even if there is no record in the stack (i.e. when the Console is first
delivered and the stack is empty) the mechanism will still run through the
Loading Records
123456789 AB
0
Sound Leisure Music Systems
123456789 AB
0
Sound Leisure Music Systems
123456789 AB
0
Sound Leisure Music Systems
123456789 AB
0
Sound Leisure Music Systems
IMPORTANT WARNING!
DO NOT USE WARPED RECORDS IN THIS MACHINE. RECORDS
THAT ARE NOT FLAT WILL NOT BE ABLE TO BE SELECTED BY THE
ARM AND WILL CAUSE SERIOUS DAMAGE TO THE MECHANISM
AND YOUR RECORDS. DOUBLE CHECK YOUR RECORDS FOR
WARPING BEFORE LOADING THEM.

13
process of selecting the record from that position and moving it to the turntable.
• Swap the record you wish to replace with the new record on the turntable.
Or, if this is the first time you have loaded the Console, place the record A
side up on the turntable.
• Set the speed of the record by pressing the play button once again.
The LED over the top of this button indicates the speed set. Green indicate
33rpm (LP’s) and Red indicates 45rpm (12” singles usually play at 45rpm)
Pressing the play button will change the speed.
NOTE : THE Console WILL NOT PLAY 7” SINGLES
Green = 33 RPM
Red = 45 RPM
• Once the desired speed has been set. Press the eject button and the
mechanism will return the record to the chosen position in the record stack.
• Repeat this procedure for all records you wish to change. Once finished
close the glass door and the Console will return to normal operational
mode.
123456789 AB
0
Sound Leisure Music Systems
123456789 AB
0
Sound Leisure Music Systems
123456789 AB
0
Sound Leisure Music Systems
Playing the Console
Making Selections
• Once the Console is loaded with records selections can be made.
• To play a record, select the 2 digit number (1 - 20) as required using the
touchpad. For instance pressing 1 then 4 will select the record in position
14 in the stack. The LED will light for each number pressed. If you make a
mistake while entering a selection selecting that number again will DE-Select
it and the LED will go out.
• The “Side” LED A/B will be illuminated. Leave them both lit to play the
entire album or de-select a side as required. Any side that is Illuminated will
play.
• Press the Play button and the mechanism will select the record and
play.
123456789 AB
0
Sound Leisure Music Systems

14
• Continue this process to build up a playlist.
Note the Console only plays entire sides and cannot play individual tracks.
Ejecting a side, record or playlist
The eject button can be used to remove the current record playing from the
turntable. If more than one side is programmed into the playlist, for instance if
the record has been set to play both sides and is currently playing side A, the
eject mode will eject just this side and then play side B.
If the eject button is held down for a few seconds, this will clear all selections
from the Console’s memory.
Using the remote control
The Console - 20 is equipped with a remote control. This can be used to make
selections and eject records, adjust the volume and lighting and select shuffle
modes. A diagram of the available functions of the remote are shown in Fig6
opposite.
PLEASE NOTE : Some of the functions on the remote control are not available
on the Console -20
123456789 AB
0
Sound Leisure Music Systems

15
Selections and additional functionality of the Console can be controlled via the
remote control supplied with your Console.
FIG 6 : Remote Control
X.
XI.
I.
VII.
IX.
XIII.
XIV
XVI.
XV.
V.
IV.
VI.
VIII.
II.
III.
XII.
I.Sleep mode (places the Console into low power standby) // II.Bluetooth pairing // III. Sequential play
// IV .Skip forwards (Plays next track if applicable) // V. Turn shuffle mode OFF // VI.Reject disc //
VII. Numeric selection keys. Used to make track selection // VIII. Keyboard cancel // IX. Reject track
// X. Vol 1 (stereo pair) Console speakers // XI.Mute vol // XII. Raise top glass // XIII.Skip backwards
(replays current track) // XIV. Turn shuffle mode ON // XV. Clear playlist // XVI .Lighting control (see
lighting section)

16
Adjusting Volume
As a precaution against overloading the speakers when switching the Console
on, the volume is preset to a low level.
• To raise the volume to the preferred level, select a track, wait until the disc
is playing, then adjust the volume using the + - Keys on the touchpad. The
VOL 1 buttons on the remote can also be used.
• Pressing the ‘MUTE’ key on the remote, will instantly mute the amplifier. To
return the volume to the previous level press any of the volume keys.
Adjusting the EQ
The eq tone can be adjusted using the EQ pots on the rear of the Console-20
(shown in Fig1) Adjustments can be made for Bass / Mid / Treble
Powering Off the Console : Sleep Mode
It is recommended that the Console is powered off using the standby procedure
and then to “full off” at the mains switch if required. This ensures that discs are
ejected and the mechanism is in a safe position. Failure to power the Console
down in this way could damage the Console mechanism.
To power off the Console
• Press the “POWER” button on the right hand side of the touch pad or
at the top remote control (Fig6) If a disc is playing it will be returned to its
position in the mechanism stack. The mechanism will then return to its home
position at the left hand side. The LED’s on the touch pad will “cascade”
and the Console will go into sleep mode. To bring the Console out of sleep
mode press the power button again.
NOTE : Sleep mode is useful if you are going to be using your Console within a
day or so. This will conserve power but still “wake’ the Console quickly should
you wish to use it.
If you are not going to use the Console for a few days then it is recommended
to use sleep mode followed by a full power off using the power switch on the
back of the Console.
123456789 AB
0
Sound Leisure Music Systems

17
Shuffle Mode and Sequential Play
The Console features a random shuffle mode as well as a sequential play mode.
These features allow continuous play until the function is disabled. If a manual
selection is made when shuffle mode is enabled then the currently playing side
will play out before the chosen selection is played. Once the manual selection
has been played shuffle or sequential mode will continue until it is disabled.
Shuffle Mode
• This mode will play the entirety of a disc (both A&B sides) before randomly
selecting another disc and playing. This mode will continue to play random
disc albums until the mode is disabled.
To Enable or disable Shuffle Mode
• Press the play button on the touchpad until the LED over the icon shows
BLUE.
• This indicates that shuffle mode is enabled.
• Shuffle mode can also be enabled using the Shuffle On/Off buttons on the
remote control.
• To disable shuffle mode, Press play again. This will disable shuffle mode
and the blue LED indicating shuffle mode will not be illuminated.
Sequential Play
This feature plays the records in ascending order e.g: 1A - 1B - 2A -2B. The
mechanism will start from its current position and then play sequentially until the
feature is turned off.
NOTE : Random shuffle mode will over ride sequential mode and sequential
mode cannot be activated when other shuffle modes are in operation.
To enable or disable Sequential Modes
• Sequential mode is only selectable via the remote control.
• Ensure random shuffle mode is not in operation.
• Press the F2 function key on the remote control.
• To disable sequential mode press F2 on the remote control.
123456789 AB
0
Sound Leisure Music Systems
123456789 AB
0
Sound Leisure Music Systems

18
Connecting external audio devices
Connecting an audio source to the Jukebox input
Audio sources, such as DAB radios or streaming devices can be connected to
Aux 2 input on the D4 amplifier. The Console -20 automatically switches inputs.
• The player mechanism is the default device and will always take priority
over any other audio sources.
• If the player mechanism is idle (no disc playing), the Bluetooth will take
priority.
• If the player and Bluetooth are not playing then the Aux 2 input will take
priority.
Please note: It is recommended that the audio output level of the connected
device is kept at between 3⁄4 and full and the volume is adjusted using the
volume control of the Console.
Connecting to the Jukebox audio output
An audio output is provided to allow the Jukebox to play through another
amplifier, such as Surround Sound or Multi-room audio system.
Connect a stereo phono lead to the Audio Out connections located on the rear
of the Console - 20. (FIG1)
The audio level is approximately 2Vp-p but will vary depending upon the audio
being played.

19
Bluetooth
The Console allows audio streaming from any compatible device via Bluetooth.
To pair an audio device to the Console -20.
• Press the BT PAIR button on the Console remote control.
• “BT ON” will show on the Console display.
• Turn on the Bluetooth connection on your audio device and begin searching
for devices (refer to your audio device manual for instruction on how to
search and pair to a device).
• The Console will show as the name “ClassicJB - XXXXX”
• The pairing procedure is only required on the first connection. Once your
device is paired, it is possible to reconnect by selecting “SoundleisureJB”
from your devices paired list. It is not necessary to press the BT PAIR button
again.
• The Console can remember up to 8 paired devices. (Although only one can
be playing at a time)
Important Bluetooth Information
Console contains transmitter module FCC ID : T9J-RN52
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into a mains outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

20
Console Lighting Adjustment
The Console - 20 has two interior LED lighting strips giving subtle illumination to
the mechanism as it selects records and to the turntable area as the records play.
The brightness of these areas can be set using the remote control.
To Set the brightness of the mechanism area lighting
• Initiate the lighting mode by pressing “COLOUR MENU” ONCE on the remote
control.
• This selects the mechanism section of LED lighting
• The brightness can be set from 0 (off) - 9 (full)
• Use the number buttons 0 - 9 on the remote control to set the brightness
• Press COLOUR EXIT on the remote control to exit lighting mode and revert
back to music selection mode.
Note : The mechanism LED is not always illuminated when in operation. It
fades up and down as the mechanism moves.
To set the brightness of the playing area lighting
• Initiate the lighting mode by pressing “COLOUR MENU” TWICE on the
remote control.
• This selects the playing area section of LED lighting
• The brightness can be set from 0 (off) - 9 (full)
• Use the number buttons 0 - 9 on the remote control to set the brightness
• Press COLOUR EXIT on the remote control to exit lighting mode and revert
back to music selection mode.
