DeDietrich DME7121A User manual

MICROWAVE OVEN
EN USER GUIDE

380
23
331
120
592
390
540.5
600
100
4 x 13 mm x2
x2
x1
x1
3.5 x 9.5 mm
Nr
SERVICE: TYPE:
CC
XXXXXXXXX
XXXXXXXXX
XXXXX XXX
XXXX
XXXXX
XXXXXXXXX
XXXXXXXXX
XX XX XXXX
XXXXX
100≥mm
380
100≥mm
450 ≥100 mm
≥ 100 mm
850≥
•1
A
BC

3.5 x 9.5 mm
(x 2)
4 x 13 mm
(x 2)
1.2.3
X mm
X mm
1 mm
X mm
2 mm
3 mm
•1
1.2.4
D
E

•2
AB

DEAR CUSTOMER,
EN
Discovering a De Dietrich product means experiencing the range of unique
emotions.
The attraction is immediate, from the moment you set eyes on the product.
The sheer quality of the design
shines through, thanks to the timeless style and outstanding finishes which
make each component an elegant and refined masterpiece in its own right,
each one
in perfect harmony with the others. Next, comes the irresistible urge to
touch it.
De Dietrich design makes extensive use of robust and prestigious
materials, where the accent is placed firmly upon authenticity. By combining
state-of-the-art technology
with top quality materials, De Dietrich produces
beautifully crafted products to help you get the most from the culinary arts,
a passion
shared by all lovers of cooking and fine food. We hope that you enjoy
using this new appliance.
Thank you for choosing a De Dietrich product.

2
CONTENTS
EN
Important safety advice and precautions ........................................3
Environment........................................................................................6
Installation and electrical connection ..............................................7
Description of the oven......................................................................8
The appliance ......................................................................................8
The accessories....................................................................................8
The control panel ..................................................................................9
The display ........................................................................................10
Settings..............................................................................................11
Setting the time ..................................................................................11
Changing the time ..............................................................................11
Using the timer 11
Locking the controls ............................................................................11
Settings menu ....................................................................................11
Cooking ............................................................................................12
Operating principle..............................................................................12
Cooking functions ..............................................................................13
Microwave function.......................................................................... 13
Programming ......................................................................................13
Automatic cooking functions............................................................ 14
Automatic defrost functions ............................................................ 15
Memory functions ............................................................................ 15
Care....................................................................................................16
Problems and solutions ..................................................................16
Suitability for the function ............................................................ 17
After-Sales Service ..........................................................................18

3
Important:
Before switching your
appliance on, please read this
installation guide carefully to
familiarise yourself quickly
with its operation. Keep this
manual with the appliance. If
you sell or give the appliance
to someone else, make sure
that you also give them this
manual.
Please read these instructions
before installing and using
your appliance. They have
been written for your safety
and the safety of others.
— This appliance is designed
to be used for domestic and
similar applications such as:
kitchen areas for the staff of
shops, offices and other
professional premises; farms;
use by customers in hotels,
motels and other residential
environments; guest house
type environments.
— This appliance may be
used by children aged 8 years
and older, and by persons with
impaired physical sensory or
mental capacities, or without
experience or knowledge, if
they are supervised or have
received prior instructions on
how to use the appliance
safely and have understood
the risks involved Children
must not be allowed to play
with the appliance. The
appliance should not be clea-
ned or maintained by children
unless supervised.
— Children should be supervi-
sed to prevent them from
playing with the appliance.
WARNING:
Accessible parts of the
appliance become hot during
use. Be careful not to touch
the heating elements inside
the oven. Children under 8
years of age should not be
allowed near the appliance,
unless they are constantly
supervised.
It is dangerous for anyone
other than a qualified person
to perform maintenance or
repairs that requires the remo-
val of the cover providing
protection against exposure to
microwave power.
IMPORTANT SAFETY ADVICE AND PRECAUTIONS
IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY AND
KEEP FOR FUTURE REFERENCE.
This user guide is available for download on the brand’s website.

WARNING: If the appliance is
being used in combination
mode, it is recommended that
children only use the oven
under adult supervision, due
to the temperatures
involved.
— Use only microwave-safe
utensils.
— When heating food items in
plastic or paper containers,
keep an eye on the microwa-
ve’s contents, since there is a
risk of spontaneous combus-
tion.
— If smoke appears, stop or
unplug the oven and leave the
door closed to smother any
flames that may appear.
WARNING: Liquids and other
foods must not be heated in
sealed containers, as they
may explode.
Metal food and beverage
containers cannot be used for
microwave cooking.
— Heating beverages in a
microwave oven can cause
the sudden and/or delayed
spitting of boiling liquid, so
care should be taken when
handling their containers.
— The contents of baby
bottles and baby food jars
must be stirred or shaken and
the temperature must be
checked before consumption,
so as to prevent burns.
— Heating eggs in their shells
or whole hard-boiled eggs in a
microwave oven is not recom-
mended, since they may
explode even after cooking
has ended.
— This appliance has been
designed for closed door
cooking.
— A microwave oven is inten-
ded for heating food and
drinks.
Drying food products or linen
or heating heat pads, slippers,
sponges, damp clothes or
similar could cause injury or
fire.
WARNING:
If the door or door seal is
damaged, the oven should not
be used until it has been repai-
red by an authorised person.
It is recommended that the
oven is cleaned regularly and
4
IMPORTANT SAFETY ADVICE AND PRECAUTIONS

5
that any food residue is remo-
ved.
— If the appliance is not clea-
ned regularly, its surface could
become damaged, perma-
nently affecting the applian-
ce’s service life and possibly
causing a safety hazard.
Do not use abrasive cleaners
or hard metal scrapers to
clean the oven’s glass door;
they could scratch the surface
and cause the glass to crack.
Do not use a steam cleaner.
The electrical plug must
remain accessible after instal-
lation.
It must be possible to discon-
nect the appliance from the
power supply, either using a
plug or by fitting a switch on
the fixed wiring system in
accordance with installation
rules.
If the power cable is damaged,
it should be replaced by the
manufacturer, its after-sales
service department or by a
similarly qualified person in
order to avoid danger.
Centre the oven in the unit so
as to ensure a minimum
distance of 10 mm between
the appliance and the surroun-
ding unit. The unit supporting
the appliance must be made
of heat-resistant material (or
covered with a heat-resistant
material). For greater stability,
attach the oven to the unit with
2 screws through the holes
provided on the side panels.
WARNING:
Only allow children to use the
oven without supervision if
adequate instructions have
been given so that the child is
able to use the oven safely
and understands the dangers
of incorrect use.
This appliance is not designed
to operate above an oven in
pyrolysis mode.
This appliance must be instal-
led at a height of 850mm or
more above the ground the
ground.
This appliance may be instal-
led in a cabinet column, as
shown in the installation
diagram.
This appliance is not designed
to operate under another built-
in appliance.
Make sure you do not move
the turntable when removing
containers from the appliance.
IMPORTANT SAFETY ADVICE AND PRECAUTIONS

6
ENVIRONMENT
CARE FOR THE ENVIRONMENT
This appliance’s packaging can be
recycled. Recycle and help protect
the environment by disposing of
packaging in local waste containers
designed for this purpose.
Your appliance also contains a lot of recyclable
material. This logo indicates that used
appliances must not be mixed with other
waste.
Appliance recycling organised by your
manufacturer is carried out under optimum
conditions, in accordance with European
Directive 2002/96/EC on the disposal of waste
electrical and electronic equipment.
Contact your local authority or retailer for
information on used appliance collection points
close to your home.
We thank you for your help to protect the
environment.

7
Ensure that:
- the circuit has sufficient power (16 Amps),
If the electrical installation in your home
requires a modification to connect the
appliance, call a qualified electrician.
During maintenance, the appliance must be
disconnected from the mains, the fuses must
be cut off or removed.
Warning:
The safety wire (green-yellow) is
connected to the appliance’s terminal
and must be connected to the installation’s
earth.
If the oven malfunctions in any way,
unplug it or remove the fuse for the circuit
where the oven is installed.
Warning:
We cannot accept liability for any
accident or incident resulting from non-
existent, defective or incorrect earthing.
UNPACKING
When you receive the appliance, unpack it or
have it unpacked immediately. Check its
general appearance. Make a note of any
reservations on the delivery slip and keep a
copy. Remove all protective packing. Check
the appliance’s characteristics on the
nameplate and make sure you comply (fig.
A).
CHOICE OF LOCATION AND BUILDING IN
This appliance must be installed in a cabinet
column as shown in the installation diagram
(fig. B-C-D-E).
Do not use your appliance immediately (wait
approximately 1 to 2 hours) after moving it
from a cold location to a hot location, as the
condensation may cause a malfunction.
Centre the oven in the cabinet so as to ensure
a minimum gap of 10mm between the
appliance and the surrounding unit. The unit
supporting the appliance must be made of
heat-resistant material (or covered with a
heat-resistant material).
For greater stability, attach the oven to the unit
with 2 screws through the holes provided on
the side panels.
ELECTRICAL CONNECTION
Important:
Only qualified installers and
technicians should install electrical
appliances.
The appliance must be correctly fitted into its
housing to ensure electrical safety. The
electrical connections should be made before
the appliance is installed in its housing.
•1INSTALLATION

8
•2DESCRIPTION OF THE OVEN
THE ACCESSORIES
• The turntable ensures that food cooks
evenly without further attention.
It rotates in both directions. If it does not
turn, check that all components are
properly positioned.
It may be used as a cooking dish. For
easy removal, recesses are provided on
both sides (fig.A). Do not try to turn it
manually, since you could damage the
drive system.
• Rotation is controlled by the drive
hub (fig.B).
If you take out the support with the drive
hub, make sure you do not let water get
into the motor shaft orifice.
Remember to put back the support, the
support wheels and the turntable. Do not
try to turn it manually, since you could
damage the drive system.
• The roller support: If the turntable
does not turn properly, check that there
is nothing underneath it stopping it from
turning.
• When the turntable is in the stopped
position, large dishes can be used
which cover the entire surface of the
oven. In this case, it is necessary to turn
the container or mix its content half-way
through the program.
THE APPLIANCE
ABCDE
Turntable
Drive hub
Wheel support
Identification label
A
B
C
D
E
Control panel

9
THE CONTROL PANEL
•2DESCRIPTION OF THE OVEN
The display:
simplifies programming by displaying:
the function, cooking time, weight or
clock time.
The control dial:
is used to select a cooking function.
The door open key
The clock key:
is used to set the clock time or access
the timer.
The + et - keys
are used to set the weight, program
cooking time and the timer and to
select a memory.
Memorykeys 1-2-3:
confirm that a cooking program has
been saved (max. 3).
The Cancel key:
a long press on this key stops the
cooking or programming in progress.
The Stop turntable key:
stops and re-starts the turntable.
The start key:
starts any program.
B
A
C
B
A
C

10
Micro-wave indicator.
Programming time and clock indicator.
Displays the microwave power, the time, weight or
cooking time.
Weight indicator.
Timer indicator.
Saved programs indicator
.
1
23
4
5
1
2
3
4
5
6
THE DISPLAY
•2DESCRIPTION OF THE OVEN
6

11
•3SETTINGS
SETTING THE TIME
When you switch the oven on or after a
power cut, 12:00 flashes.
Set the time using the + and - keys and
then press the key to confirm.
CHANGING THE TIME
Hold the key pressed until the time
flashes. Adjust the time with the + and -
keys and then press the key to
confirm.
Your appliance will now show the right
time.
SETTINGS MENU
You can adjust a number of settings on
your oven:
sounds and demonstration mode.
Hold the + and - keys pressed for a few
seconds to access the settings menu.
See the table below:
To select the different parameters, if
necessary, press the key and press the
+ key to change the selection.
To exit the settings menu at any time,
press .
Default
settings
Key sounds- beeps:
ON position, sounds active.
OFF position, no sounds.
DEMO mode:
Position ON, mode active.
Position OFF, normal
mode.
LOCKING THE CONTROLS
Child safety lock
Press the key until the
symbol is displayed.
To unlock, hold the key pressed until
the symbol disappears from the
screen.
USING THE TIMER
Press the key and the timer indicator
is displayed; the time set flashes.
Adjust the time setting using the + and -
keys and then press the key to confirm.
At the end of the time, an audible signal
sounds; press the key to stop it.
The timer function cannot be
accessed during cooking.

12
Microwaves used for cooking are
electromagnetic waves. They are
commonly found in our environment in
the form of radio waves, light and infra-
red rays.
Their frequency is in the 2450MHz range.
Their behaviour:
· They are reflected by metals.
• They pass through any other
material.
• They are absorbed by water, fat
and sugar molecules.
When food is exposed to microwaves, its
molecules begin moving rapidly, causing
it to heat up.
The depth of penetration of the waves
into the food is about 2.5 cm. If the food
is thicker, cooking at its centre occurs by
conduction just like traditional cooking.
In essence, microwaves are simply
causing a thermal change inside the food
and are therefore not harmful to health.
•4COOKING
OPERATING PRINCIPLE

13
MICROWAVE FUNCTIONS
•4COOKING
Open the door. Place the dish inside and
close the door.
If the door is not properly shut, the
appliance will not operate.
If the dish is too large to turn freely inside
the oven, press the stop turntable key
before or during the program.
There are five microwave power levels
available :
350, 500, 700 and 900 Watts.
Setting a cooking program:
1. Select the power using the function
selector, e.g. 900W - high power).
2. Set the cooking time using the +and -
keys (for example, 5 minutes).
3. Press the start key .
Position Use
To cook fresh vegetables and soup. To heat up all liquids.
To reheat all fresh or frozen pre-cooked dishes and frozen vegetables. To
bring pre-cooked dishes and frozen vegetables up to temperature.
To cook fish and poultry. To finish programs begun with the «FAST COOK»
setting such as beans, lentils or milk-based dishes.
To finish programs begun with the «FAST COOK» setting, which might
otherwise overcook on the outside, for instance veal or pork roast.
To defrost meat, fish, fruit, bread or delicate dishes.
To cook fresh vegetables.
To cook fish.
To defrost frozen dishes.
To defrost meat or poultry.
For defrosting bread, pastries and cakes.
To defrost vegetables.
To access the MEMO program.
COOKING FUNCTIONS

14
The program begins: the turntable
revolves, the oven light comes on.
Three beeps announce the end of a
program.
The beeps are repeated every minute for
ten minutes until you open the door.
During the program:
- You can change the power by using the
selector.
Setting a defrost program:
Proceed in a similar fashion but select the
defrost function .
1. Set the time using the +and -keys, e.g.
10 minutes.
2. Press the start key .
In the defrost function (150W), a beep
sounds in mid-program and TURN is
displayed to tell you to turn the food over to
obtain the best results. Close the door and
press the key to continue defrosting.
During the program:
-You may stop or start the turntable by
pressing .
The symbol flashes in the display with
the word OFF, telling you to stop the
turntable.
Press to re-start the turntable.
The symbol flashes in the display with
ON telling you to re-start the turntable.
-If you open the door before the end of the
•4COOKING
program, close it and press to resume the
program.
-At the end of a program, the fan may continue
to run to ensure proper cooling. It will stop
automatically.
AUTOMATIC COOKING FUNCTIONS
The automatic cooking functions select the
appropriate cooking parameters according to
the food to be prepared and its weight. Select
one of the following two cooking functions:
: Fresh vegetables*.
: Fish.
Select the function.
A suggested weight flashes on the screen.
Adjust the weight of food using the + and - keys
and then confirm by pressing
The oven starts.
*
A beep sounds in mid-program and
TURN is displayed to tell you to turn the
food over to achieve the best results.
Close the door and press the key to
resume cooking.

15
•4COOKING
The automatic functions select the appropriate
defrost parameters for you based on the food
being prepared and its weight. Select a pre-
programmed food from the list below:
: Defrosting ready meals.
: Defrosting meat, poultry *.
: Defrosting bread, pastries and
cakes*.
: Defrosting vegetables.
Select an automatic defrost function and
enter the weight of the food, using the + and
- keys (in 50g steps) and then confirm by
pressing . The oven starts.
* A beep sounds in mid-program and
TURN is displayed, advising you to turn
the food over to achieve the best
results. Close the door and press the
key to resume defrosting.
AUTOMATIC DEFROST FUNCTIONS
The Memory functions allow you to
store three frequently used programmes
which you can then access by selecting
the function with the function
selector.
You can save any program you wish.
Example:
Program as for an immediate start:
1. Select the microwave function of your
choice, e.g. FAST
COOK (900W).
2. Set the cooking time, e.g. 2 minutes.
3. Instead of pressing start, give a long
press on the memory key .
MEM1 is displayed on the screen.
Select MEM1, MEM2 or MEM3 with the
+ and - keys.
Press the start key.
A beep sounds to confirm that your
custom program has been saved.
To start a saved program:
Select the memory function with the
function selector.
Select MEM1, MEM2 or MEM3 with the
+ and - keys.
Press the start key to start the
program.
THE MEMORY FUNCTION

1616
We recommend that you clean the oven
regularly and remove any deposits of
food inside and outside the appliance.
Use a damp sponge and a little soap. If
the appliance is not cleaned regularly,
its surface could become damaged,
permanently affecting the appliance’s
lifespan and possibly causing a safety
hazard.
if the door or door seal are damaged, the
oven should not be used until it has been
repaired by a qualified person.
The use of abrasive products, alcohol or
thinners is not recommended as they
CLEANING THE INNER AND OUTER
SURFACES
•5CARE
are likely to damage the appliance.
If the oven smells bad or is dirty, boil a
cup of water with lemon juice for 2
minutes and clean the walls with a small
amount of washing up liquid.
The turntable can be removed for easy
cleaning. To remove it, pick it up using
the hand-holds provided for the
purpose. If you remove the drive hub,
take care not to allow water to enter the
motor shaft hole. Remember to put back
the support, the support wheels and the
turntable.
The appliance does not start.
Check that it is plugged in properly.
Check that the oven door is properly closed.
The appliance is noisy.
The turntable does not rotate properly.
Clean the wheels and the rolling area under
the turntable.
Ensure that the wheels are properly
positioned.
You see steam on the window.
Wipe away the condensation with
a cloth.
Food is not heated during a microwave
program.
Ensure that the utensils are suitable
for microwave ovens and that the power
level
is suitable.
Check that the oven is not in
«DEMO» mode (see p. 11).
There are sparks coming from the
appliance.
Clean the appliance properly: remove any
grease, food deposits, etc.
Remove any metal items from the walls of
the oven.
•6PROBLEMS AND SOLUTIONS
