Definitive Technology Studio 3D Mini User manual

Setup Guide
4.1 Home Theater Sound Bar and Wireless Subwoofer System
Studio 3D Mini
1.Studio3DMini_QSG_ENG_00A_201006.indd 11.Studio3DMini_QSG_ENG_00A_201006.indd 1 2020/10/06 16:29:382020/10/06 16:29:38

1
What’s in the Box
Sound bar
AAA AAA
HDMI cable
Subwoofer Power cords Optical cable
2
1
Wall mount spacers Wall mount template Literature
AAA AAA
Remote control Two AAA batteries
1.Studio3DMini_QSG_ENG_00A_201006.indd 11.Studio3DMini_QSG_ENG_00A_201006.indd 1 2020/10/06 16:29:392020/10/06 16:29:39

2
Setup
Place the sound bar
For the best listening experience, position the
sound bar centered under your TV. You may
choose to place it either on your furniture, or
wall-mount the sound bar below the TV.
OPTIONAL: The Studio 3D Mini can be wall
mounted. Please refer to the wall
mount template in the product
carton.
Connect the sound bar to an AC
outlet
During startup, you will see a single LED on
your sound bar blinking slowly. When the
light appears as solid amber, you can move
on to the next step.
Place the subwoofer
For the best performance, place on the same
wall as the TV, no more than 30 ft (10 m) from the
sound bar.
Performance Tip: placing the subwoofer in
a corner can make the bass seem even
more pronounced.
1.
2.
3.
Sound Bar
TV
Subwoofer
TV
Power
Inlet
1.Studio3DMini_QSG_ENG_00A_201006.indd 21.Studio3DMini_QSG_ENG_00A_201006.indd 2 2020/10/06 16:29:402020/10/06 16:29:40

3
Connect the subwoofer to an AC outlet
and switch power to ON
On the back of the subwoofer, the SYNC LED
will be solid green to indicate that it is paired to
the sound bar.
Download the HEOS App
Download the HEOS App on your iOS or Android Device.
4.
5.
Subwoofer
SYNC LED
Open the HEOS App
Once download is complete, open the HEOS App on your iOS or Android Device.
6.
1.Studio3DMini_QSG_ENG_00A_201006.indd 31.Studio3DMini_QSG_ENG_00A_201006.indd 3 2020/10/06 16:29:402020/10/06 16:29:40

4
Tap Settings Icon
7.
Music
Tap “Add Device” in the Settings Screen
8.
Settings
Add Device
Follow instructions in App to complete the setup and conguration of Studio 3D Mini.
Owner’s Manual
For more information, visit https://www.denitivetechnology.com/.
Refer to the Online Manual for other functions information and
operation procedure details.
manuals.denitivetechnology.com/Studio3Dmini/NA/EN/
1.Studio3DMini_QSG_ENG_00A_201006.indd 41.Studio3DMini_QSG_ENG_00A_201006.indd 4 2020/10/06 16:29:402020/10/06 16:29:40

5
Power On/Off
TV Input
Dialogue Enhancer
Subwoofer Down
Music Mode
Night Mode
Mute
Auxilary Input
Subwoofer Up
Movie Mode
Master Volume Down
Remote Control
Master Volume Up
Bluetooth
HDMI Input Optical Input
- Adjust the volume
of dialog in movies,
vocals in music, etc.
so these can be
heard more easily.
- Switches to the
sound mode suitable
for enjoying music.
- Make audio easier to
hear at low volumes.
- Switches to the sound
mode suitable for
enjoying movies and TV
programs.
1.Studio3DMini_QSG_ENG_00A_201006.indd 51.Studio3DMini_QSG_ENG_00A_201006.indd 5 2020/10/06 16:29:402020/10/06 16:29:40

6
• Power -Turns the Studio 3D Mini on/off
• Source - Switches sound bar inputs
• Bluetooth - Initiates Bluetooth pairing
• Master Volume Down - Decreases the master volume
• Master Volume Up - Increases the master volume
Front of Studio 3D Mini
Sound Bar Controls
Status LED
- Shows current sound bar status.
(See pages 9 and 13.)
Visual Indicator LEDs
- Indicates sound bar volume, input source,
subwoofer volume, dialogue, night mode, and
sound modes. (See on page 8.)
1.Studio3DMini_QSG_ENG_00A_201006.indd 61.Studio3DMini_QSG_ENG_00A_201006.indd 6 2020/10/06 16:29:412020/10/06 16:29:41

7
Back of Studio 3D Mini
Power
USB
Ethernet
Connect Button Sync Button
AUX
Optical
HDMI OUT
(eARC/ARC)
HDMI IN
Connect/Sync
LED
- Used for Wi-Fi setup. - Used to wirelessly
connect the
sound bar and
subwoofer.
1.Studio3DMini_QSG_ENG_00A_201006.indd 71.Studio3DMini_QSG_ENG_00A_201006.indd 7 2020/10/06 16:29:412020/10/06 16:29:41

8
TV
HDMI
OPTICAL
AUX
BLUETOOTH
HEOS
Several source colors indicate the audio bitstream for non-streaming inputs.
PCM CONTENT DOLBY SIGNAL DTS SIGNAL
Sound Bar Indicators and Status Lights
NOTE: “TV” Input is set as HDMI OUT (eARC / ARC) by default, but the input source is congurable
by going to the “TV Input” setting in the “My Devices” menu within the HEOS App.
12345
Visual Indicator LEDs
Status LED
Source Indication
Below is a table showing the source indicators.
1.Studio3DMini_QSG_ENG_00A_201006.indd 81.Studio3DMini_QSG_ENG_00A_201006.indd 8 2020/10/06 16:29:412020/10/06 16:29:41

9
Volume Indication
Master Volume will be communicated with the
ve LEDs in the row of Visual Indicators LEDs.
Volume of 1% will be indicated by the leftmost
LED as dimly lit, and 100% will be indicated with
all 5 Visual Indicator LEDs fully illuminated.
Visual indicator LEDs will illuminate purple
when NIGHT MODE is active.
Mute will be indicated by the Status light.
Volume mute when Status LED is Blue and
slowly blinking.
12345
Visual Indicator LEDs
NIGHT MODE - enabled
Status LED
1.Studio3DMini_QSG_ENG_00A_201006.indd 91.Studio3DMini_QSG_ENG_00A_201006.indd 9 2020/10/06 16:29:412020/10/06 16:29:41

10
Subwoofer Back Panel & Visual LED Indicators
Back Panel of Subwoofer
SYNC LED
- Indicates connection status between
sound bar and subwoofer.
SYNC Button
- Used for troubleshooting or resetting the
connection between the sound bar and
subwoofer.
Power Switch
Power
1.Studio3DMini_QSG_ENG_00A_201006.indd 101.Studio3DMini_QSG_ENG_00A_201006.indd 10 2020/10/06 16:29:412020/10/06 16:29:41

11
Streaming Music from Your Device
STREAMING MUSIC FROM YOUR MOBILE DEVICE USING BLUETOOTH
1. Activate the Bluetooth setting on your mobile device.
2. Press and hold the Bluetooth Button ( ) located on the remote control or on the top panel of the
sound bar until the status light on the front ashes green.
3. Select “Studio 3D Mini” from the list of available Bluetooth speakers from your mobile device.
4. Play music using any app on your device and the sound will now play from the speaker.
STREAMING MUSIC FROM YOUR DEVICE USING APPLE AIRPLAY
1. Play music from your favorite app.
2. “Swipe up” to open iOS Control Center.
3. Tap the AirPlay icon from the “Now Playing” panel.
4. Choose “Studio 3D Mini” from device list in AirPlay.
5. Enjoy your music.
NOTE: Using Apple AirPlay requires your sound bar to be connected to Wi-Fi. To connect your sound
bar to your local network, follow instructions in the HEOS App to complete the setup and
conguration of Studio 3D Mini. (See on page 3.)
1.Studio3DMini_QSG_ENG_00A_201006.indd 111.Studio3DMini_QSG_ENG_00A_201006.indd 11 2020/10/06 16:29:412020/10/06 16:29:41

12
MY SOUND BAR WON’T CONNECT TO MY NETWORK
- Make sure your mobile device is connected to your wireless network before setting up your sound bar.
- Alternatively, you can connect your sound bar to your network router using an Ethernet cable sold
seperately. Once connected via Ethernet, the HEOS App should recognize the sound bar and you
can manually move it to your wireless network using “Settings” - “My Devices” - “(Device Name)” -
“Advanced” - “NETWORK SETTINGS”.
I DON’T HEAR THE TV SOUND COMING FROM THE SOUND BAR
- Check cable connection between the sound bar and your TV and other devices. Ensure cables are fully
connected and connected to the right ports.
- Ensure that TV Speakers are “Off” in your TV settings menu*
- If you are using HDMI eARC/ARC as your connection between your sound bar and your TV, ensure
that “ARC” setting is “On” in your TV settings**
* NOTE: “TV Speakers” settings may be labeled as Receiver, or External speakers depending on your
make of TV.
** NOTE: Not all TV’s have these settings.
- Verify that CEC functions are enabled in your TV settings.
- Check that the connections between your sound bar and your TV are synced with the settings in the
HEOS app. To nd out the TV input settings, open the HEOS App and navigate to Music View >
Settings > My Devices > TV Input
- To update the connection go to Music View > Settings > My Devices > TV Input > Select the Input
type that currently connects your sound bar and your TV.
Basic Troubleshooting
1.Studio3DMini_QSG_ENG_00A_201006.indd 121.Studio3DMini_QSG_ENG_00A_201006.indd 12 2020/10/06 16:29:412020/10/06 16:29:41

13
NO SOUND COMING OUT FROM THE SUBWOOFER
- Ensure that your subwoofer is connected to power and switched ON.
- Check the SYNC LED at the back of the subwoofer. Make sure that it is solid green. If it is not green,
refer to the online manual for detailed instructions on how to manually reset the connection between
the sound bar and subwoofer.
RESETTING YOUR SOUND BAR
- Resetting your sound bar will clear out the wireless network settings, EQ, and name, but retain its
current software.
- You will have to use “Settings” - “Add Device” to reconnect the sound bar to your home network
before it can be used.
- To reset your sound bar, press and hold both the CONNECT button (located on the back panel of the
sound bar) and Bluetooth ( ) button (located on the top panel of the sound bar) for 5 seconds until
the status LED on the front of the sound bar begins to ash amber.
Owner’s Manual
For more information, visit https://www.denitivetechnology.com/.
Refer to the Online Manual for other functions information and
operation procedure details.
manuals.denitivetechnology.com/Studio3Dmini/NA/EN/
1.Studio3DMini_QSG_ENG_00A_201006.indd 131.Studio3DMini_QSG_ENG_00A_201006.indd 13 2020/10/06 16:29:422020/10/06 16:29:42

14
For Further Assistance:
Phone Number
[phone] (North America)
[phone]
Email
de[email protected]
Mail
Denitive Technology
15541 Fermi Court Carlsbad,
CA 92008 U.S.A
Warranty
This sound bar is covered by a limited warranty.
Details can be found on the Denitive Technology website:
https://www.denitivetechnology.com/warranty-information
