Dell Precision™ Workstations
Dell Precision is your key tool for creating architectural drawings,
performing complex engineering design work or wringing
the most from any performance intensive application. Our
workstations provide superb productivity, Independent Software
Vender (ISV) certified1 reliability, and innovative smart design to
maximize your productivity and dependability.
Experience the evolution of productivity
Power through resource-exhausting and graphics-intensive
workloads with the advanced design of the Dell Precision T3610
featuring:
• Intel® Xeon® processor E5-1600 v2 product family provides
the performance you need to complete complex tasks
quickly.
• Easily handle large data sets with up to 128GB4 of quad-
channel 1866MHz ECC or 1600MHz non-ECC memory via
eight total DIMM slots.
• Choose from a broad selection of professional grade AMD
FirePro™ or NVIDIA® Quadro® graphics
• Protect your investment with Generation 3 PCIe slots to help
prepare for the next generation of graphics
• Optional Micron® P320h PCIe SSD drive delivers superb
read throughput, combined with exceptional reliability and
remarkable power eciency
Best-in-class chassis design
The Dell Precision T3610 oers one of the industry's best chassis,
enabling you to perform service and modifications with incredible
ease with features such as:
• Straightforward, clutter-free interior providing easy access to
components
• The only mainstream tower workstation family to oer an
externally accessible tool-less power supply for superior
serviceability
• Integrated front and rear aluminum handles for easy
deployment and moves
• Room for up to two 3.5” or four 2.5” tool-less hard drives
• Handy top tray oers a convenient location to store external
drives or cameras and provides easy access to front-
mounted USB ports
• Easy rack mounting via 0U rail shelf kit (sold separately)
Reduce environmental impact
Dell Precision T3610 is EPEAT®-registered3 and oers ENERGY
STAR® configurations, including 80 PLUS®-registered Gold
power supplies. Not only will you help lower your impact on the
environment, but you can also help reduce your operating energy
costs.
Dependability you can count on
You keep working, no matter what challenges you face. Dell’s
exclusive, patented Reliable Memory Technology helps ensure
that your workstations will too. The new technology maximizes
uptime by eliminating virtually all memory errors so the
workstations can get more reliable over time, providing a stable
and reliable platform you can trust.
Recommended Accessories
Dell oers all of the essential accessories you need to enhance
your workstation productivty including:
• Enjoy outstanding color accuracy, consistency, and
richness with state-of-the-art Dell UltraSharp monitors with
PremierColor. These monitors are perfect for power users
who require precise, accurate, color-critical performance.
• Maximize workspace ergonomics and viewing comfort with
the Dell MDS14 Dual Monitor Stand or Dell MSA14 Single
Monitor Arm.
• The versatile Dell C3765dnf multifunction color laser
printer oers value, quality and eciency to workgroups by
combining low cost per page with excellent print quality.
Exceptional Service
Rest assured that your Dell Precision workstation will be well
protected should an issue arise. The T3610 comes with a 3 year
limited hardware warranty7 standard. Dell’s premium support
service, ProSupport9, features 24/7 direct telephone access
to advanced-level technicians based in your region to end
downtime and resolve problems quickly.
Dell Precision T3610
Mid-range workstation with an excellent balance of performance and scalability
Dell recommends Windows®

Dell Precision T3610 Workstation Technical Specifications
Processors Intel® Xeon® processor E5-1600 v2 with up to six cores and Intel Advanced Vector Extensions, Intel Trusted Execution
Technology, Intel AES New instructions, Optimized Intel Turbo Boost and optional Intel vPro™ technology
Operating
Systems
• Windows® 8 Pro (64-Bit)
• Genuine Windows® 7 Ultimate 32-Bit; Genuine Windows® 7 Ultimate 64-Bit
• Genuine Windows® 7 Professional 32-Bit; Genuine Windows® 7 Professional 64-Bit
• Red Hat® Enterprise Linux® 6.4
• Ubuntu 12.04 SP1 Linux (China only)
Chipset Intel® C602
Memory2, 4 Quad channel; Up to 128GB 1866MHz ECC or 1600MHz non-ECC DDR3 memory; 8 DIMM slots
Graphics4Support for two PCI Express® x16 Gen 2 or Gen 3 graphics cards up to 300W (total for graphics):
High End 3D Mid-range 3D Entry 3D Professional 2D (not ISV certified)
AMD FirePro™ W7000 AMD FirePro V4900 AMD FirePro 2270
AMD FirePro™ W5000 NVIDIA Quadro K600 NVIDIA Quadro NVS™ 510
NVIDIA® Quadro® K4000 NVIDIA Quadro NVS 310
NVIDIA Quadro K2000
Storage Options5Up to three 3.5" or four 2.5" internal SATA, SAS or SSD drives. Additional add-in controller required for SAS hard drives.
SATA 7200RPM SATA 10KRPM SAS 10K RPM SAS 15K RPM SSD PCIe SSD
Up to 3.0TB Up to 500GB Up to 900GB Up to 300GB Up to 512GB Micron P320h 350GB
Storage
Controller
Options
Integrated:
• Intel AHCI 6Gb/s SATA controller with six ports (two
6Gb/s, two 3Gb/s, two reserved for optical drives)
supports software RAID 0, 1, 5, 10
Optional:
• LSI 9217-8i 6Gb/s SAS/SSD PCIe controller supports software RAID 0, 1, 10
configurations
• LSI 9271-8i 6Gb/s SATA/SAS PCIe controller (1GB cache) supports hardware
RAID 0, 1, 5, 10 configurations
Communications Integrated:
• Intel 82579 Gigabit Ethernet controller with Remote
Wake UP, PXE and Jumbo frames support
Optional:
• Broadcom NetXtreme 10/100/1000 Gigabit Ethernet controller (PCIe card)
• Intel Ethernet Server Adapter X520-T2 10GbE (PCIe card)
Remote Access Optional Tera2 dual display PCoIP™ PCIe remote access host card for optional Wyse P25 zero client
Audio Controller Integrated: Realtek ALC269Q High Definition Audio
Optional: Creative Sound Blaster Recon3D PCIe x1 card
I/O Ports Front Internal Rear
3 - USB 2.0 3 - USB 2.0 3 - USB 2.0
1 - USB 3.0 2 - SATA 6.0Gb/s 3 - USB 3.0
1 - Microphone 2 - SATA 3.0Gb/s 2 - PS2
1 - Headphone 2 - SATA 3.0Gb/s (for optical drive(s)) 1 - Serial
1 - RJ45
1 - 1394a (optional via add-in card)
Mid-Tower
Chassis Dimensions (HxWxD): 16.30 x 6.79 x 18.54"; 414 x 172.6 x 471mm
Slots (five full length, one half length): Two PCIe x16 Gen 3;
one PCIe x16 Gen 3 wired x8 (half length); one PCIe x4 Gen
2; one PCIe x1 Gen 2; One PCI 32bit/33MHz
Bays: One external slimline optical bay; Two internal 3.5"
hard drive bays; one external 5.25" bay;
Power Supply (externally accessible, toolless, 80 Plus® Gold
Certified, 90% ecient): 685W or 425W
Monitor
Options
Dell UltraSharp series - High-performance monitors with PremierColor (on select models) and ultrawide viewing from 21.5"-
30". Dell Single Monitor Arm and Dual Monitor Stand is also available.
Keyboard Dell KB522 Business Multimedia Keyboard; Dell KB813 Smartcard Keyboard; Dell KM714 Wireless Keyboard & Mouse Combo
Mouse Dell USB Optical Mouse; Dell Laser USB 6-Button Mouse; Logitech Performance Mouse MX
Speakers Dell 2.0 and 2.1 stereo speaker systems available; Dell sound bar for select flat-panel displays.
Storage Devices Slimline options: DVD-ROM; DVD+/-RW
Optional 5.25" device: DVD+/-RW; 19-in-1 media reader
Security
Options6
Trusted Platform Module 1.2 (TPM 1.2); Intrusion switch; Setup/BIOS Password; I/O Interface Security; Kensington® lock
slot, Padlock ring, lockable power supply; Dell Data Protection | Encryption; Dell Data Protection | Security Tools; Dell Data
Protection | Protected Workspace
Environmental
and Regulatory
Energy Star® configurations available including 80 PLUS® registered Gold power supplies; EPEAT® registered (see epeat.net for
specific registration rating/status by country); China CECP; GS Mark. For a complete listing of declarations and certifications,
see Dell’s regulatory and compliance homepage at dell.com/regulatory_compliance
Service and
Support
3-Year Limited Hardware Warranty7 and 3-year NBD On-Site Service after Remote Diagnosis8
Optional: Dell ProSupport9 is designed to rapidly respond to your business’s needs, help protect your investment and
sensitive data, and provide enhanced proactive support services to help reduce risk and complexity within your IT environment
1. ISV certification applies to select configurations
2. A 64-bit operating system is required to support 4GB or more of system memory.
3. See epeat.net for specific registration rating/status by country.
4. GB means 1 billion bytes and TB equals 1 trillion bytes; significant system memory may be used to support graphics, depending on system memory size and other factors.
5. GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.
6. Available in select regions.
7. For copy of Ltd Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or see www.dell.com/warranty
8. Remote Diagnosis is determination by online/phone technician of cause of issue; may involve customer access to inside of system and multiple or extended sessions. If issue is covered by
Limited Hardware Warranty and not resolved remotely, technician and/or part will be dispatched, usually within 1 business day following completion of Remote Diagnosis. Availability varies. Other
conditions apply.
9. Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescriptions.
