Deluxe Electronic PEB-215N User manual

Deluxe Electronic
Body Weight Scale
Instruction Manual Model No.: PEB-215N
Important!
This Body Weight Scale (PEB-215N) will provide accurate body weight readings for you.
This Body Weight Scale is made for normal home use only; it is not designed for use in
commercial or medical fields.
Reset the scale – You may be able to reset the scale simply by removing and re-inserting the
battery.
Always turn on (Tap and Press on the glass platform) the scale first and wait for the display
“0.0” (Fig. 4) before stepping onto the glass platform.

IMPORTANT SAFETY INSTRUCTIONS:
When using this Body Weight Scale (PEB-215N), please observe the
following basic precautions.
1. User must read and understand this manual prior to the using this product. Use as
described in this manual.
2. Do not step onto the scale with wet feet or when the glass platform is damp or wet.
Personal Injury Risk!
3. Protect the scale against moisture, dust, chemical, impacts, extreme temperature
fluctuations and keep it away from heat sources (heaters, ovens and etc.,).
4. Do not use the scale on Carpet or Rug.
5. Place the scale on NON-SKID hard, dry and smooth floor/surface.
6. Do not place the scale on a wet surface. Personal Injury Risk!
7. Always put the scale on the exact same smooth and hard floor/surface to ensure the accuracy
of the user’s body weight readings.
8. The scale may tilt when you step on it. You should place your left foot or right foot on the
glass platform at least one inch from the edge of the glass platform. Once the position is
secured and safe, place the other foot onto the scale.
9. Center your body weight toward the mid section of the scale before stepping on / off the
scale. Otherwise, the scale may tilt. Personal Injury Risk!
10. Follow all labels and marking instructions on your scale.
11. To reduce the risk of electric shock, do not use the scale outdoors.
12. Do not use in area where dangerous items are stored.
13. Do not continue to use this scale if it appears to be malfunctioning.
14. Always dry your feet before using scale. Personal Injury Risk!
15. Do not use this scale if it appears to be uneven, cracked or broken.
16. Do not use this scale if cracks or chips appeared on glass platform. Personal Injury Risk!
17. If unit is not working, has been damaged, dropped, left out-door, or dropped into water,
bring it to a licensed electrician or shop for service and repair.
18. Do not disassemble the scale. There are no serviceable parts inside the scale.
19. Never jump on, or jump off the scale. Personal Injury Risk!
20. Observe the battery precautions and battery disposal instructions listed in this manual
21. Do not remove the battery from the scale, other than replacing the battery, or for storing the
scale. The battery poses a choking hazard and is extremely dangerous for children to swallow.
Personal Injury Risk!
22. This scale is not a toy. Do not let children use the scale without the supervision of an adult.
Please keep it away from children.
(SAVE THESE INSTRUCTIONS)
Page: 1

To Know Your Produex Body Weight Scale
Model No.: PEB-215N (Fig. 1)
1. L.C.D. Display 5. Components and Parts Holder
2. Glass Platform (Front View) 6. KG / LB / ST Switch
3. Stoppers / Sensor Contacts 7. Battery Chamber and Cover
4. Wire Covering Pipes 8. Glass Platform (Back View)
Facts for an accurate weighing:
This Electronic Scale should be used in consistent manner for the precise reading of your
body weight. The readings may very between this scale and other methods of
measurement.
The changing in body weight shown by this Electronic Scale will be reflected precisely.
If you can, please weigh yourself at the same time of the day (ideally in the morning or
before going to bed), on an empty stomach, and without clothing to achieve precise body
weight readings.
Place your scale on the same hard, dry and flat surface for better performance.
Errors Indicator:
 “ERR” or “ERR1” indicated a damaged or malfunctioning load cell.
 “FFFF” indicates the weight has exceeded approx. 398.8 Lbs (180.9 kgs).
Page: 2

How to measure your Body Weight:
1. Select (lb / in) or (kg / cm) or (st). The Switch is located at the bottom of the scale, on the
backside of the L.C.D. Display (see Fig. 1 – Item #6). (Example: turn switch to lb / in)
2. Place the scale on a smooth, firm, flat surface to achieve the precise accuracy. (do not use
the scale on Carpet or Rug).
3. Turn-on the scale by tapping on the center of the glass platform.
(This unit uses a Tap and Press system to “Turn On” the unit. If the unit
won’t turn on after Tap and Press of the glass platform, please Tap and
Press again with a little more pressure on the glass platform. Otherwise,
please check and clean the battery and battery terminal contact plates).
(Fig. 3)
4. The 8888 lb will show on the LCD Display (see above Fig. 3). And, within seconds the
L.C.D. Display will change to a zero reading -“ready to use mode”. (See Fig. 4)
(Fig. 4)
Ready to use mode
5. Step onto the glass platform carefully and stand still to measure your body weight. When
the scale is complete weighing your body your weight will be displayed on the L.C.D.
(See Fig. 5)
Example (Fig. 5)
6. The scale will shut off in 10 seconds (approx) by itself after the weight reading is shown
on the LCD Display.
Important:
Do not remove the (3) screws on the Components and Parts Holder at
the bottom of the scale (see Fig. 1. Item # 5 on Page 2)
Battery Compartment Cover Screw – It is a safety feature to lock the
battery in place securely (see Fig. 1. Item # 7 on Page 2)
The battery poses a choking hazard and is extremely dangerous for children to swallow.
Personal Injury Risk!
Page: 3

Battery Removal
Step – 1
Remove screw on Battery
Compartment Cover
Step – 2 Step - 3
INSERT BALL PEN OR
SCREW DRIVER INTO SLOT
TO REMOVE BATTERY
BATTERY IS REMOVED
1. Replace the battery when
Low Battery Warning
“Lo” is displayed.
2. Remove battery if the
product is to be stored for
a long time.
3. Dangerous! Keep battery
away from Children
Step – 4 Step – 5
Battery Installation
The Electronic Scale uses 1 piece 3-Volt Lithium (CR 2032) Cell.
Replace the battery when Low Battery Warning “Lo” is displayed.
Battery Installation
Step-1 Step-2
Replace Battery
Step-3 DONE
Replace Battery Cover
REPLACE SCREW TO
LOCK THE BATTERY
COMPARTMENT COVER.
Page: 4

Battery disposal:
DO NOT DISPOSE OF BATTERY IN FIRE. BATTERY MAY EPLODE OR LEAK”
Warning:
When trashing the battery - The battery
must be separated from the regular household
trash. Please consult with your local authorities for battery disposal instructions.
Battery – First-Aid:
Battery may leaks in extreme weather and conditions. If leaks get on skin and eyes, flush area
with cold water and seek medical attention immediately.
Note:
Coffee, beer, wine, alcohol, and diuretic medications or workouts all affect your level of
hydration and the accuracy of this Scale. Please wait a few hours before taking a body
weight reading.
Place your unit on the same hard, dry and smooth and flat surface for better performance.
Important Note:
This is a high precision electronic scale. Please handle the unit with care. Do not drop or
throw the unit on floor or immerse the scale into water.
The scale will shut off in 10 seconds after the reading of your weight is shown on the
LCD Display.
Low Battery Warning – when voltage of battery is down to approx. 2.5V, the “Lo” low
battery warning will come on. Replace battery.
Do not place the scale under direct sunlight, high temperature or high humidity areas.
Do not place any items or objects on the glass platform of the scale for any reasons. It is
used for body weight readings only.
Clean the outside of the scale with a damp cloth only. Do not use chemical cleaning
agents or immerse the unit into water. Do not saturate the scale with water as it may
damage the electronic components.
Remove the battery is the scale is to be stored for a long time.
Page: 5

Reset your Body Weight Scale (PEB-215N):
You can easily reset the PEB-215N by removing and re-inserting the battery (see above
Battery Removal and Battery Installation).
Model No.: PEB-215N
Specifications:
Maximum Weight capacity: 180kgs (396 lbs)
Minimum Weight Capacity: 2 kgs (4.4 lbs)
Weight Graduation: 100g or 0.2lb
Turn-On: Tap and Press turn-on feature with automatic shut off system
User selectable units of measure (lb/in) or (kg/cm) or (st)
Lower battery indicator “Lo”.
Operates on one 1 X 3-Volt (CR2032) Lithium button cells.
Important:
Always dry your feet before using the scale.
Place your unit on the same hard, smooth and flat surface for better performance.
Do not put this product under direct sunlight, high temperature or high humidity areas.
After using the scale, do not place any items or objects on the scale, as it might turn on
the scale and deplete the battery.
Clean the exterior of the scale with a lightly dampened cloth only.
Errors Indicator:
Overloading: If the weight exceeds 398.8 lbs, the screen will display “FFFF”.
Low Battery - Low voltage alert: Change the battery immediately.
As inner code is too low or too high by the reason that the load cell has been damaged, the
scale will displays ERR), ERR1
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Page: 6

Note: (continue)
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio TV technician for help.
