Denon professional Dn-500bd mkii User manual

User Guide English ( 3 – 30 )

Guía del usuario Español ( 31 – 59 )

Guide d’utilisation Français ( 60 – 87 )

Guida per l’uso Italiano ( 88 – 115 )

Benutzerhandbuch Deutsch ( 116 – 144 )

Appendix English ( 145 – 147 )

User Guide (English)

Introduction

Box Contents

Support

DN-500BD MKII

Power Cable

Remote Control

Rack Ears & Screws

User Guide

Safety & Warranty Manual

For the latest information about this product (system

requirements, compatibility information, etc.) and

product registration, visit denonpro.com.

Safety Instructions

Please also see the included Safety & Warranty Manual for more information.

Before turning the

power on:

Make sure all connections are secure and correct and that there are no

problems with the connection cables.

Power is supplied to some of the circuitry even when the unit is powered off.

When the unit will not be used for long periods of time, disconnect the power

cable from the power outlet.

Proper ventilation: If the unit is left in a room which is not properly ventilated or is full of smoke

from cigarettes, dust, etc. for long periods of time, the surface of the optical

pickup may get dirty, causing incorrect operation.

bout condensation: If there is a major difference in temperature between the inside of the unit and the

surroundings, condensation may form inside the unit, causing the unit not to

operate properly. If this happens, let the unit sit for an hour or two while powered

off, and wait until there is little difference in temperature before using the unit.

Cautions on using

mobile phones:

Using a mobile phone near this unit may cause noise. If this occurs, move the

mobile phone away from this unit when it is in use.

Moving the unit: Before moving the unit, turn off its power and disconnect the power cable from

the power outlet. Next, disconnect its connection cables from other devices

before moving it.

bout care: Wipe the cabinet and control panel clean with a soft cloth.

Follow the instructions when using a chemical cleaner.

Do not use benzene, paint thinner, insecticide, or other organic solvents to

clean the unit. These materials can cause material changes and discoloration.

Rackmount warnings:

(required rack specifications

for mounting the unit in a

rack)

EIA standard 19-inch (483 mm) rack

1U-size installation compatible rack

Rack that has a guide rail or shelf board that can

support this device

Rack installation: This product will work normally when the player unit is

mounted within 10° off the vertical plane at the front

panel. If the unit is tilted excessively, the disc may not

load or unload properly. (See image.) Unit

Maximum 10°

Features

Front Panel

1. Power: Press this button to turn DN-500BD MKII on/off. The light above the button will be red when it

is off or green when it is on. Make sure the AC In is properly connected to a power outlet. Do not turn

the unit off during media playback—doing so could damage your media.

2. USB Port: Connect a mass-storage-class USB device to this port. See Operation > Playing Files

(Video, Audio, or Picture)for more information.

3. SD Card Slot: Insert your SD card here to play music files. See Operation > Playing Files (Video,

Audio, or Picture)for more information.

4. Disc Tray: Insert a compatible disc into this tray when it is open.

5. Eject: Press this to eject or close the disc tray.

6. Remote Sensor: Point the remote control at this sensor when operating it. See Remote Control for

more information.

7. Display: This screen indicates the unit’s current operation.

8. Mode Indicators: These lights indicated whether or not certain functions are enabled or disabled

(Lock, IR Lock, or Hide OSD). See Other Features for more information.

9. Shift: Press and hold this button to perform the secondary function of any one of the five buttons next

to it (described below).

10. Skip Back ():Press this button to skip to the previous chapter, track, or file. Press and hold Shift

and press this button to cycle through the Repeat modes. See the Operation chapter for more

information.

11. Skip Forward ():Press one of these buttons to skip to the previous or next track or chapter. Press

and hold Shift and press this button to loop a section of video or audio during playback. See the

Operation chapter for more information.

12. Stop ():Press this button to stop playback. Press and hold Shift and press this button to

enable/disable the Lock feature. See Other Features for more information.

13. Pause ():Press this button to pause playback. Press and hold Shift and press this button to

enable/disable the IR Lock feature. See Other Features for more information.

14. Play ():Press this button to start or resume playback. Press and hold Shift and press this button to

enable/disable the Hide OSD feature. See Other Features for more information.

468

910 11

12 13

Rear Panel

1. Audio Outputs (balanced, XLR):These outputs send the audio signal to your external speakers,

receiver, etc. Use XLR cables to make these connections. See Setup > Connections for more

information.

2. Audio Outputs (unbalanced, RCA):These outputs send the audio signal to your external speakers,

receiver, etc. Use RCA cables to make these connections. See Setup > Connections for more

information.

3. 7.1 Outputs (unbalanced, RCA):These 8 outputs send the audio signal to your 7.1 surround sound

system. Use RCA cables to make these connections. Please refer to the documentation for your sound

system, as well.

4. Coaxial Output: This output sends the digital audio signal to your TV. Use a standard coaxial cable to

make this connection.

5. HDMI Output: This output sends an HDMI audio and video signal from an external device. Use a

standard HDMI cable to make this connection.

6. LAN Port: This input lets you connect a host device (usually a computer) to DN-500BD MKII. You can

use the host device to control DN-500BD MKII via commands sent from it. Alternatively, use this

connection to access the internet. Use a standard Ethernet cable to make this connection.

7. USB Input: This input receives the audio and video signal from a connected USB device. Use a

standard USB cable to make this connection.

8. Remote Input: This input lets you connect a host device (usually a computer) to DN-500BD MKII. You

can use the host device to control DN-500BD MKII via commands sent from it (using RS-232C serial

communication). Use a standard Ethernet cable to make this connection.

9. AC In: Use the included power cable to connect this input to a power outlet. See Setup >

Connections for more information.

7.1

2345 6 7 8 9

Remote Control

Important: Point the remote control at the remote sensor when operating it. If

the remote sensor is exposed to direct sunlight, strong artificial light (like from an

interverter-type fluorescent lamp), or infrared light, the unit or remote control may

not function properly.

1. Power ():Press this button to turn DN-500BD MKII on/off. The light above

the button on DN-500BD MKII will be red when it is off or green when it is on.

Make sure the AC In is properly connected to a power outlet. Do not turn the

unit off during media playback—doing so could damage your media.

2. Mute ():Press this button to mute DN-500BD MKII’s audio. If this button

does not work, set the Output Volume to Variable instead of Fixed (see

Adjusting the Settings > Setting > Audio Setup to learn how to do this).

3. Eject ():Press this to eject the disc tray.

4. HDMI: Press this button to select the next available picture resolution: Auto

(DN-500BD MKII will detect the optimal resolution automatically), 480i/576i,

480p/576p, 720p, 1080i, or 1080p.

5. 2nd Audio: Press this button to select the language of the audio used with the

Picture-in-Picture feature. This feature is available only on discs that support it.

See Operation > Adjusting the Sound for more information.

6. Volume –/+: Press these buttons to lower or raise the volume (respectively). If

these buttons do not work, set the Output Volume to Variable instead of

Fixed (see Adjusting the Settings > Setting > Audio Setup to learn how to

do this).

7. Number Buttons (0–9):Press these buttons to enter their corresponding

numbers. While playing media and not viewing an additional menu or screen,

entering a number or numbers will select that disc chapter or audio track.

8. Return: Press this button to return to the previous menu/screen.

9. Clear: Press this button to clear (delete everything in) the current field.

10. Home: Press this button to open the Home screen. See Operation > Getting

Started (Home Screen)for more information.

11. Setup: Press this button to open the Setup Menu. See Operation > Adjusting

the Settings > Setting for more information.

12. Option: Press this button to open the Options Menu. See Operation > Adjusting the Settings >

Options for more information.

13. Info: Press this button to open the Information screen.

14. Cursor Buttons ():Use these buttons to navigate through the files and folders.

15. OK: Press this button to confirm a selection.

16. GoTo: Press this button to manually enter a time you want to skip to. See the Operation chapter for

more information.

17. Stop ():Press this button to stop playback.

18. Pause ():Press this button to pause playback.

19. Play ():Press this button to start or resume playback.

20. Search Back/Forward (/ ):Press these buttons to rewind/fast-forward, respectively. Each time

you press the same button, the speed will increase. You can do this up to 5 times before it returns to

normal playback speed.

21. Skip Back/Forward (/ ): Press one of these buttons to skip to the previous or next track or

chapter.

22. Audio: Press this button during video playback to show current audio setting in the upper-left corner

of the screen. Each press after that will select the next available setting. The available settings depend

on the supported audio configurations of your video. For example, a video file may let you select

Stereo, Mono, Left, or Right, while a Blu-ray Disc may let you select DTS-HD MA (Master Audio) or

Dolby Digital in various languages.

23. Subtitle: Press this button to show the current subtitle language in the upper-right corner of the

screen. Each press after that will select the next available subtitle language. Select Off to disable the

subtitles.

24. Title Popup: Press this button to view the disc’s title menu without stopping playback.

25. Disc Menu: Press this button to stop playback and return to the disc’s main/top menu.

26. PIP: Press this button to enable/disable the Picture-in-Picture feature.

27. Random: Press this button to cycle through the Random modes. See the Operation chapter for more

information.

28. Repeat: Press this button to cycle through the Repeat modes.

29. A-B: Use this button to loop a section of video or audio during playback.

30. Prog: Press this button to show the Program page, which lets you select tracks that will play in a

specific order. See Operation > Playing Audio Discs > Additional Functions for more information.

31. Mark: Press this button to “mark” a location of a video.

32. Zoom: Press this button to zoom in or out of the picture. Each press will select the next available

zoom distance: 2x, 3x, 4x, 1/2, 1/3, and 1/4. When no zoom distance is shown on the screen, the

picture is at its normal zoom distance.

33. Angle: Press this button to select a different camera angle. This feature is available only on certain

DVD or Blu-ray Discs.

34. Red, Green, Yellow, Blue: Press these buttons to perform functions that are specific to the disc you

are using. (Your disc may provide information about how to use these buttons.) These functions vary

between discs and may not be supported on all discs.

Battery Usage

To replace the battery:

1. On the back of the remote control, push the small tab inward and remove the battery compartment

door.

2. Remove any old batteries from the compartment and insert 2 new AAA batteries. Make sure each one

is facing the proper direction according to its polarities (+ or –).

3. Push the battery compartment door back into its original position.

Important: Keep the following points in mind when using or replacing batteries:

•Use 2 AAA batteries.

•Do not handle batteries roughly or disassemble them.

•When replacing the batteries, place them with their polarities (+ and –) facing the correct directions.

•Do not leave batteries in a place subject to high temperature or direct sunlight.

•Keep batteries in a place beyond the reach of infants or children. If a battery is swallowed, consult a

physician immediately.

•Discard any leaking battery immediately. Be careful when handling it as the electrolyte can burn your

skin or clothes. If the electrolyte touches your skin or clothes, immediately wash with tap water and

consult a physician.

•Before discarding a battery, insulate it with tape, etc. and dispose of it in a place without fire, by

following the directions or regulations laid down by the local authorities in the area of its disposal.

Setup

Connections

7.1

Items not listed in Introduction > Box Contents are sold separately.

Important: Connect all cables securely and properly (with stereo cables: left with left, right with right). Do

not bundle or wrap them with the power cable.

Not all of these steps may apply to your specific audio/video setup, but you will need to do Steps 1 and 5

at the very least.

1. Connect DN-500BD MKII to your TV monitor or display by doing one of the following:

•Use an HDMI cable to connect the HDMI Output to the HDMI input of your TV monitor or display.

•Audio only: Use a coaxial cable to connect the coaxial output to the coaxial input of your TV monitor.

2. Optional: Connect DN-500BD MKII to your sound system by doing either/both of the following:

•Use XLR cables or a stereo RCA cable to connect the audio outputs (balanced or unbalanced) to

the analog inputs of your external receiver, amp, powered speakers, etc.

•Use RCA cables to connect the 7.1 outputs to your 7.1 surround sound system.

3. Optional: Connect a USB hard drive with playable content to the USB port (front panel or rear panel).

4. Optional: Use a 9-pin D-Sub cable to connect the Remote Input to a host device (usually a computer)

that will control it.

5. Optional: Use an Ethernet cable to connect the LAN port to your modem or a host device.

6. After completing all the connections, use the included power cable to connect the AC In to a power outlet.

TV or display

Power

Powered Monitors,

receiver, amp, etc.

Modem

USB hard drive

To 7.1

sound system

Initial Wizard

1. Press DN-500BD MKII’s Power button to power it on. Make sure your TV is on, too.

2. The Initial Wizard screen will appear. On each page of the Initial Wizard:

•Use the up/down cursor buttons () on the remote control to move through the available options.

•Press OK to confirm your selection and move to the next page.

•Press Skip Back ( ) to return to the previous page.

3. On Page 1, press OK on the remote control to move to the next screen.

4. On Page 2, select the language you want the display to use.

5. On Page 3, select the broadcasting standard for your location: NTSC, PAL, or Multi. Select Multi only

if your TV supports both NTSC and PAL systems.

6. On Page 4, select your TV’s resolution. Once you press OK, the resolution will change temporarily. At

that point, select Yes or No to confirm that you want to use that resolution. If you do not do this within

12 seconds, the resolution will return to the previous setting.

7. On Page 5, select your TV’s aspect ratio. Once you press OK, the aspect ratio will change and you

continue to Page 5. If you do not want to use that aspect ratio, press Skip Back ( ) to return to the

previous page and select a different one.

8. On Page 6, press OK to view the Home screen and start using DN-500BD MKII, or press Skip Back

() to return to the previous page.

Operation

If the unit is off, press the Power Button to power it on.

Getting Started (Home Screen)

To select what kind of media you want to play:

1. On the remote control, press Home to open the Home screen.

2. Press the left/right cursor buttons () on the remote control to move through the options.

•Blu-ray Disc: Select this to play a video disc in the standard Blu-ray or DVD format.

•Media Center: Select this to browse the contents of a USB drive (mass storage class) or SD card

with video, audio, or picture files.

•Setting: Select this to open the Setting menu for DN-500BD MKII.

3. To confirm your choice, press OK on the remote control.

Playing Video Discs

DN-500BD MKII can play and view the following video disc formats:

Supported Blu-ray Disc formats BD25, BD50, BD-ROM, BD-R, BD-RE

Supported DVD formats DVD, DVD+R, DVD-R, DVD+RW, DVD-RW

See the Basic Functions section to learn some basic operations.

See Additional Functions to learn more advanced ones.

Basic Functions

Important: Do not place heavy objects on top of DN-500BD MKII. Doing so can cause issues with disc

playback or damage the unit.

To play a disc:

1. Press Eject ( ) on DN-500BD MKII or the remote control to open the disc tray.

2. Insert a disc into the disc tray, and press Eject ( ) on DN-500BD MKII or the remote control again to

close it. The display will show LoAd when the disc is loading and then bdnU when the disc is loaded.

3. If DN-500BD MKII has not played the disc before, it will start playing automatically.

If DN-500BD MKII has played the disc before, you can do either of the following:

•Press Return on the remote control to play the disc from the beginning.

•Press OK on the remote control to play the disc from the point where you last stopped it.

To stop playback, press Stop () on DN-500BD MKII or the remote control.

To pause playback, press Pause () on DN-500BD MKII or the remote control. To resume playback,

press Pause () or Play ( ) on DN-500BD MKII or the remote control.

To rewind or fast-forward, press Search Back/Forward ( / ) on the remote control. Each time you

press the same button, the speed will increase. You can do this up to 5 times before it returns to normal

playback speed. To resume playback, press Play ( ) on DN-500BD MKII or the remote control.

To skip to the next chapter, press Skip Forward ( ) on DN-500BD MKII or the remote control. If

Chapter Repeat is on (described later), this will skip to the beginning of the current chapter.

To skip to the previous chapter, press Skip Back ( ) twice on DN-500BD MKII or the remote control

(though if you are within the first few seconds of the current chapter, you can press it just once.) If Chapter

Repeat is on (described later), this will skip to the beginning of the current chapter.

To return to the beginning of the chapter, press Skip Back ( ) once on DN-500BD MKII or the remote

control. If you are within the first few seconds of the current chapter, though, doing this will skip to the

previous chapter.

Additional Functions

To view the disc menu, press Disc Menu on the remote control. This will stop playback.

To view the title menu without stopping playback, press Title Popup on the remote control.

To select a Repeat mode, press Repeat on the remote control, or press Shift and Skip Back ( ) on

DN-500BD MKII. It will cycle through 3 modes:

•Off: Normal operation.

•Chapter Repeat (CH):The current chapter will repeat continuously. In this Repeat mode,

pressing will Skip Back/Forward ( /) will skip to the beginning of the current chapter

only.

•Title Repeat (TT):The current title will repeat continuously.

To loop a section of the video:

1. Set the desired starting point by pressing A-B on the remote control, or press Shift and Skip Forward

() on DN-500BD MKII. A- will appear on the screen.

2. Set the desired ending point by pressing A-B again or pressing Shift and Skip Forward ( ) on DN-

500BD MKII again. A-B will appear on the screen, and the loop will start and repeat continuously.

3. To stop the loop, press A-B on the remote once more, or press Shift and Skip Forward ( ) on DN-

500BD MKII once more. A-B will disappear from the screen, and playback will continue normally.

To jump to a specific chapter of the disc:

1. Use the number buttons (0–9) on the remote control to select the number of the desired chapter.

2. To confirm your choice, press OK or wait a few seconds. The desired chapter will start playing.

To cancel, press Clear.

To jump to a specific title, chapter, or time of the disc:

1. Press GoTo on the remote control. The Information panel will appear at the top of the screen. (To

cancel the operation before selecting a title, chapter, or time, press GoTo again or wait until the blue

square cursor in the Information panel disappears, and then press Info.)

2. Use the left/right cursor buttons () to select any of the available fields:

•Title: Press OK to “unlock” this field. Use the up/down cursor buttons () or number

buttons (0–9) to select the number of the desired title, and then press OK to jump to it.

•Chapter: Press OK to “unlock” this field. Use the up/down cursor buttons () or

number buttons (0–9) to select the number of the desired chapter, and then press OK to

jump to it.

•Time: Use the up/down cursor buttons () to select whether these 3 fields show the

elapsed time for the chapter (CH) or title (TT). After that, press OK to “unlock” these 3

fields. Use the left/right cursor buttons () to select each field: hours, minutes, and

seconds. Use the up/down cursor buttons () or number buttons (0–9) to enter each

as a 2-digit number. Press OK to jump to that time in the chapter (CH) or title (TT).

3. To jump to another location, repeat Steps 1–2.

To close the Information panel, press Info. (If the panel does not close, press OK once and then press

Info.)

A bookmark is a specific location in a video that is stored in DN-500BD MKII’s memory. You can set up to

12 bookmarks and then jump to those locations directly, saving you the time of scanning through the

video later.

To create a bookmark, press Mark on the remote control at the desired location during video playback.

The screen will show the number of the bookmark, current title, current chapter, and current time.

To jump to a bookmark:

1. Press and hold Mark on the remote control for 6 seconds. Playback will pause and the bookmarks will

appear on the screen.

2. Use the left/right cursor buttons () to move through the bookmarks. When you select a

bookmark, you will see the current title, current chapter, and current time above it. The bookmarks you

have created are white, and unused bookmarks are gray.

3. Press OK to jump to the desired bookmark. Playback will resume from that bookmark’s location.

To cancel the operation and return to normal playback, press Mark.

To erase a bookmark:

1. Press and hold Mark on the remote control for 6 seconds. Playback will pause and the available

bookmarks will appear on the screen.

2. Press Clear to erase the last-created bookmark.

3. Press Mark to close the bookmarks and return to normal playback.

To view subtitles, press Subtitle on the remote control. The current subtitle language will appear in the

upper-right corner of the screen. Each press after that will select the next available subtitle language.

Select Off to disable the subtitles.

Note: For this feature to work properly, the video must have subtitles available.

Playing Audio Discs

DN-500BD MKII can play and view the following audio disc formats:

Supported CD formats CD, CD-R, CD-RW, DTS Music Disc (DTS Audio CD, 5.1 Music

Disc), HDCD, Super Video CD (SVCD), Video CD (VCD)

Supported DVD formats DVD, DVD+R, DVD-R, DVD+RW, DVD-RW

See the Basic Functions section to learn some basic operations.

See Additional Functions to learn more advanced ones.

Basic Functions

To play audio from a CD:

1. Press Eject ( ) on DN-500BD MKII or the remote control to open the disc tray.

2. Insert an audio CD into the disc tray, and press Eject ( ) on DN-500BD MKII or the remote control

again to close it. (The CD must be properly finalized.) The display will show LoAd when the disc is

loading and then Cd when the CD is loaded.

3. The CD will start playing automatically.

To stop playback, press Stop () on DN-500BD MKII or the remote control.

To pause playback, press Pause () on DN-500BD MKII or the remote control. To resume playback,

press Pause () or Play ( ) on DN-500BD MKII or the remote control.

To rewind or fast-forward, press Search Back/Forward (/) on the remote control. Each time you

press the same button, the speed will increase. You can do this up to 5 times before it returns to normal

playback speed. To resume playback, press Play ( ) on DN-500BD MKII or the remote control.

To skip to the next track, press Skip Forward ( ) on DN-500BD MKII or the remote control.

To skip to the previous track, press Skip Back ( ) twice on DN-500BD MKII or the remote control

(though if you are within the first few seconds of the current track, you can press it just once.)

To return to the beginning of the track, press Skip Back ( ) once on DN-500BD MKII or the remote

control. If you are within the first few seconds of the current track, though, doing this will skip to the

previous track.

Additional Functions

To select a Repeat mode, press Repeat on the remote control, or press Shift and Skip Back ( ) on

DN-500BD MKII. It will cycle through 3 modes:

•Off: Normal operation.

•Repeat Track: The current track will repeat continuously. In this Repeat mode, pressing

will Skip Back/Forward ( /) will skip to the beginning of the current chapter only.

•Repeat All: The current title will repeat continuously.

To select a playback mode, press Random on the remote control. It will cycle through 3 modes:

•Shuffle: Tracks on the CD will play in a random order without repeating. When all tracks on the CD

have played, playback will stop (unless a Repeat mode is selected).

•Random: Tracks on the CD will play in a random order. Playback will continue indefinitely. Also,

tracks will also be allowed to play more than once.

•Off: Normal operation.

To loop a section of the track:

1. Set the desired starting point by pressing A-B on the remote control, or press Shift and Skip Forward

() on DN-500BD MKII. A- will appear on the screen.

2. Set the desired ending point by pressing A-B on the remote control again, or press Shift and Skip

Forward ( ) on DN-500BD MKII again. A-B will appear on the screen, and the loop will start and

repeat continuously.

3. To stop the loop, press A-B on the remote once more, or press Shift and Skip Forward ( ) on DN-

500BD MKII once more. A-B will disappear from the screen, and playback will continue normally.

To jump to a specific track of the disc:

1. Use the number buttons (0–9) on the remote control to select the number of the desired track.

2. To confirm your choice, press OK or wait a few seconds. The desired track will start playing.

To cancel, press Clear.

To jump to a specific track or time of the disc:

1. Press GoTo on the remote control. The Information panel will appear at the top of the screen. (To

cancel the operation before selecting a track or time, press GoTo again or wait until the blue square

cursor in the Information panel disappears, and then press Info.)

2. Use the left/right cursor buttons () to select either of the available fields:

•Track: Press OK to “unlock” this field. Use the up/down cursor buttons () or number

buttons (0–9) to select the number of the desired track, and then press OK to jump to it.

•Time: Use the up/down cursor buttons () to select whether these 3 fields show the

elapsed time for the Track or Disc. After that, press OK to “unlock” these 3 fields. Use the

left/right cursor buttons () to select each field: hours, minutes, and seconds. Use the

up/down cursor buttons () or number buttons (

0–9) to enter each as a 2-digit

number. Press OK to jump to that time in the track or disc.

3. To jump to another location, repeat Steps 1–2.

To close the Information panel, press Info.

All

TRACK

DISC

To create a Program (a list of tracks that will play in a specific order):

1. Press Prog on the remote control. The Program page will appear on the screen.

In the Program page, the type of media and total number of tracks (Track Total) will appear above the

15 available slots of the Program.

2. Do any of the following in the Program page:

•At any time, press Play ( ) on DN-500BD MKII or the remote control to start playing the Program.

•At any time, press Return on the remote control to exit the Program page. This will clear all slots of

the Program.

•Press OK on the remote control to “unlock” the current slot of the Program (outlined in yellow). Use

the up/down cursor buttons () or number buttons (0–9) to enter the desired track, and then

press OK to confirm your choice.

•If the current slot of the Program (outlined in yellow) contains a track number, press Clear on the

remote control to clear that slot.

While viewing the Program page, you cannot use any buttons (on DN-500BD MKII or the remote

control) other than the ones described above.

Playing Files (Video, Audio, or Picture)

DN-500BD MKII can play and view the following file formats on a USB drive (mass storage class) or SD

card:

Supported video file formats .3gp, .asf, .avi, .dat, .divx, .mkv, .mov, .mp4,

.mpg, .m2ts, .ogm, .rmvb, .tp, .ts, .wmv

Subtitle formats (for video) .ass, .smi, .srt, .ssa, .sub

Supported audio file formats .ape, .flac, .m4a (AAC), .mp3, .wav

Supported picture file formats .gif, .jpg (or .jpeg), .png

Important: The USB drive or SD card must use a FAT16, FAT32, or NTFS file system.

See the Basic Functions section to learn some basic operations.

See Additional Functions to learn more advanced ones.

Basic Functions

USB Drive:

To browse your files and play a file:

1. Gently insert a USB drive to the USB port on the front panel or rear panel. The display will show USB

In when DN-500BD MKII recognizes the USB drive.

2. Press Home on the remote control to view the Home screen.

3. Use the left/right cursor buttons () to select Media Center, and then press OK. The Media

Center will appear on the screen.

4. Do any of the following in the Media Center:

•Use the up/down cursor buttons () to move to the previous/next item in a list.

•Press OK or Play ( ) to enter a selected folder.

•Press the left cursor button () or Return to return to the next-highest folder (one level above the

current one). Alternatively, use the up cursor button () to move to folder labeled .. at the top of

the list, and then press OK or Play ( ).

•Press OK or Play ( ) to play a selected file. If you have previously played the file and stopped it

before the end, the file will start playing from that point.

•Press Title Popup to view options related to creating a playlist. See Additional Functions (below)

to learn about this.

•Press Home to return to the Home screen.

While using the Media Center, you cannot use any buttons (on DN-500BD MKII or the remote control)

other than the ones described above.

To stop playback, press Stop () on DN-500BD MKII or the remote control.

To pause playback, press Pause () on DN-500BD MKII or the remote control. To resume playback,

press Pause () or Play ( ) on DN-500BD MKII or the remote control.

While viewing pictures, these buttons let you pause or resume playback of the slide show.

To rewind or fast-forward, press Search Back/Forward (/) on the remote control. Each time you

press the same button, the speed will increase. You can do this up to 5 times before it returns to normal

playback speed. To resume playback, press Play ( ) on DN-500BD MKII or the remote control.

While viewing pictures, these buttons let you change the speed of the slide show (Slow, Middle, or Fast).

To skip to the next file, press Skip Forward ( ) on DN-500BD MKII or the remote control.

To skip to the previous file, press Skip Back ( ) twice on DN-500BD MKII or the remote control

(though if you are within the first few seconds of the current file, you can press it just once.)

While viewing pictures, press this button only once instead of twice.

To return to the beginning of the file, press Skip Back ( ) once on DN-500BD MKII or the remote

control. If you are within the first few seconds of the current file, though, doing this will skip to the previous

file.

While viewing pictures, pressing this button will skip to the previous file.

While playing an audio file, the screen will show the following information: File Name, Type (file format),

Total Time, Title, Artist, Album, and Genre. The last four items are usually included as ID3 tags but are

not always present in all audio files. If the file is missing an ID3 tag, the field will be blank.

While viewing a picture, you can do the following:

•Press the up cursor button () to flip (mirror) the picture vertically.

•Press the down cursor button () to flip (mirror) the picture horizontally.

•Press the left cursor button () to rotate the picture 90° counterclockwise.

•Press the right cursor button () to rotate the picture 90° clockwise.

SD Card:

To browse your files and play a file:

1. Insert the SD card into the SD card slot.
