DeskBook B145
User’s guide
Jaguar-e.book Page i Wednesday, March 12, 2003 2:46 PM

Changes may be made periodically to the information in this publication without obligation to notify any
person of such revision or changes. Such changes will be incorporated in new editions of this manual or
supplementary documents and publications. This company makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically disclaims the implied warranties of
merchantability or fitness for a particular purpose.
Record the model number, serial number, purchase date, and place of purchase information in the space
provided below. The serial number and model number are recorded on the label affixed to your computer.
All correspondence concerning your unit should include the serial number, model number, and purchase
information.
Model Number : __________________________________
Serial Number:____________________________________
Purchase Date: ___________________________________
Place of Purchase: ________________________________
Copyright © 2003
All Rights Reserved
DeskBook B145 User’s guide
Original Issue: March 2003
DeskBook B145
All trademarks and registered trademarks are the properties of their respective companies.
Jaguar-e.book Page ii Wednesday, March 12, 2003 2:46 PM

iii
Preface
This DeskBook B145 is the alternative to your desktop PC, making innovative use
of desktop components including the CPU, hard disk and LCD. Features include a
full-size keyboard, CardBus, and an internal pointing device. This DeskBook
B145 offers desktop performance in a notebook form-factor.
This manual should answer most of the questions you have about the day-to-day
operation of your DeskBook B145.
You should also take advantage of the online help files that are available with
almost all of the programs shipped with your computer.
We hope you enjoy your DeskBook B145. With proper care, your computer will
provide you with years of productive service.
Connecting the computer
Connecting the computer is as easy as 1-2-3.
1. Before connecting anything, fold down the footstand to serve as a stand for
the DeskBook B145.
For the DeskBook B145 not equipped with the handle, fold down the foldable
Jaguar-e.book Page iii Wednesday, March 12, 2003 2:46 PM

iv
legs under the system to serve as the footstand for the DeskBook B145.
2. Connect one end of the AC adapter to the DC-in port on the computer’s rear
panel and the other end to a properly grounded power outlet.
Jaguar-e.book Page iv Wednesday, March 12, 2003 2:46 PM

v
3. Slide the display cover latch to the left (1) and open the display (2) to a
comfortable viewing angle. Press and release the power switch (3) to turn on
the power.
The POST (power-on self-test) routine executes and Windows begins loading.
Note: To turn off the power, we recommend that you use the Windows Turn
Off command to shut down the computer. If you are unable to shut down
your computer normally, press and hold the power switch for more than four
seconds to turn off the computer. If you turn off the computer and want to
turn it on again, wait at least two seconds before powering up.
Care and maintenance
Taking care of your computer
Your computer will serve you well if you take care of it.
• Do not expose the computer to direct sunlight. Do not place it near sources of
heat, such as a radiator.
• Do not expose the computer to temperatures below 0ºC (32ºF) or above 50ºC
(122ºF).
• Do not subject the computer to magnetic fields.
• Do not expose the computer to rain or moisture.
Jaguar-e.book Page v Wednesday, March 12, 2003 2:46 PM

vi
• Do not spill water or any liquid on the computer.
• Do not subject the computer to heavy shock and vibration.
• Do not expose the computer to dust and dirt.
• Never place objects on top of the computer to avoid damaging the computer.
• Never place the computer on uneven surfaces.
Taking care of your AC adapter
Here are some ways to take care of your AC adapter:
• Do not connect the adapter to any other device.
• Do not step on the power cord or place heavy objects on top of it. Carefully
route the power cord and any cables away from all potential traffic.
• When unplugging the power cord, do not pull on the cord itself but pull on the
plug.
• The total ampere ratings of the equipment plugged in should not exceed the
ampere rating of the cord if you are using an extension cord. Also, the total
current rating of all equipment plugged into a single wall outlet should not
exceed the fuse rating.
Cleaning and servicing
When cleaning the computer, follow these steps:
1. Power off the computer.
2. Disconnect the AC adapter.
3. Use a soft cloth moistened with water. Do not use liquid or aerosol cleaners.
Contact your dealer or see your service technician if any of the following occurs:
• The computer has been dropped or the body has been damaged.
• Liquid has been spilled into the product.
• The computer does not operate normally.
Jaguar-e.book Page vi Wednesday, March 12, 2003 2:46 PM

Preface iii
Connecting the computer iii
Care and maintenance v
Contents vii
1 Getting familiar with your computer 1
A tour of your computer 3
Top view 3
Front view 5
Left view 6
Right view 6
Rear view 8
Bottom view 9
Features 10
Display 12
Indicators 13
Keyboard 15
Special keys 15
Keyboard ergonomics 19
Touchpad 20
Launch keys 22
Storage 24
Hard disk 24
Floppy drive 24
Optical drive 24
Connectivity options 28
Ethernet and LAN 28
Fax/data modem 28
Audio 30
Securing your computer 32
Security notch 32
Passwords 32
Power management 33
Advanced Configuration and Power Interface 33
2 Peripherals and options 35
External monitor 37
Using simultaneous display 37
S-video 38
External keyboard 39
Jaguar-e.book Page vii Wednesday, March 12, 2003 2:46 PM

Contentsviii
External pointing device 40
Printer 41
USB devices 42
IEEE 1394 devices 44
Miscellaneous options 45
Key component upgrades 46
Processor 47
Hard disk 50
Memory 51
Optical disk drive 52
Floppy disk drive 54
LCD panel 55
3 Moving with your computer 59
Disconnecting from the desktop 61
Moving around 61
Preparing the computer 62
Taking the computer home 62
Preparing the computer 62
What to bring with you 62
Special considerations 62
Setting up a home office 63
Traveling with the computer 63
Preparing the computer 63
What to bring with you 63
Special considerations 63
Traveling internationally with the computer 64
Preparing the computer 64
What to bring with you 64
Special considerations 64
4 Software 65
System software 67
Launch Manager 68
BIOS Utility 69
Password Option 71
Save and Exit Setup 72
Exit Without Saving 72
5 Troubleshooting 73
Frequently-asked questions 75
Error messages 78
Jaguar-e.book Page viii Wednesday, March 12, 2003 2:46 PM

ix
A Specifications 81
B Notices 85
Index 93
Jaguar-e.book Page ix Wednesday, March 12, 2003 2:46 PM

Contentsx
Jaguar-e.book Page x Wednesday, March 12, 2003 2:46 PM

1 Getting familiar with
your computer
Jaguar-e.book Page 1 Wednesday, March 12, 2003 2:46 PM

This DeskBook B145 combines high-performance,
versatility, power management features and multimedia
capabilities with a unique style and ergonomic design. Work
with unmatched productivity and reliability with your new
power computing partner.
This chapter gives an in-depth "tour" of the computer’s many
features.
Jaguar-e.book Page 2 Wednesday, March 12, 2003 2:46 PM

3
A tour of your computer
Let us show you around your new DeskBook B145.
Top view
#Item Description
1 Display screen Also called LCD (liquid-crystal display), displays
computer output.
Jaguar-e.book Page 3 Wednesday, March 12, 2003 2:46 PM

1 Getting familiar with your computer4
2 Status indicators LEDs (light-emitting diodes) that turn on and off to
show the status of the computer and its functions and
components.
3 Power button Turns on the computer power.
4 Keyboard Inputs data into your computer.
5 Touchpad Touch-sensitive pointing device which functions like a
computer mouse.
6 Click buttons (left
and right)
The left and right buttons function like the left and
right mouse buttons.
7 4-way scroll key This button mimics your cursor pressing on the
vertical and horizontal scroll bars of Windows
application.
8 Palm rest Comfortable support area for your hands when you use
the computer.
9 Launch keys Buttons for launching frequently-used programs. See
“Launch keys” on page 22 for more details.
10 Speaker Outputs sound.
# Item Description
Jaguar-e.book Page 4 Wednesday, March 12, 2003 2:46 PM

5
Front view
#Item Description
1 Display cover latch Slide to the right to unlatch the LCD display.
2 Optical drive cover Protects the optical drive from dust.
3 Optical drive Internal optical drive (CD, DVD, or DVD/CD-RW
combo drive).
4 Floppy drive Internal diskette drive, accepts 3.5-inch floppy
diskettes.
5 Floppy activity
indicator
Lights up when the floppy drive is active.
6 Optical drive activity
indicator
Lights up when the optical drive is active.
7 Eject button Ejects the CD/DVD tray.
8 Emergency eject slot Ejects the optical drive tray when the computer is
turned off. See page 76 for more details.
9 Floppy disk eject
button
Push this button to eject the floppy disk.
Jaguar-e.book Page 5 Wednesday, March 12, 2003 2:46 PM

1 Getting familiar with your computer6
Left view
Right view
# Item Description
1 Fan slots Help keep the computer cool. Do not cover these slots
which promote proper airflow to the computer.
# Item Description
1 Line-out jack Connects to audio line-out devices (e.g., speakers,
headphones).
2 Line-in jack Accepts audio line-in devices (e.g., audio CD player,
stereo walkman).
3 Microphone-in jack Connects to a microphone.
Jaguar-e.book Page 6 Wednesday, March 12, 2003 2:46 PM

7
4 PS/2 port Connects to any PS/2-compatible device (e.g. PS/2
keyboard/mouse/keypad).
5 IEEE 1394 port Connects to an IEEE 1394-compatible device (e.g.,
digital video camera).
6 Network jack Connects to an Ethernet 10/100-based network.
7 Modem jack Connects a phone line (only for models with an
internal fax/data modem).
8 USB 2.0 port Connect to USB devices (e.g., USB mouse).
9 Heavy-duty handle For carrying the DeskBook B145 computer and also
used as a stand for tilting the system. Available in some
model.
#Item Description
Jaguar-e.book Page 7 Wednesday, March 12, 2003 2:46 PM

1 Getting familiar with your computer8
Rear view
#Item Description
1 USB 2.0 ports Connect to USB devices (e.g., USB mouse).
2 Serial port Connects to a serial device (e.g. serial mouse).
3 External monitor port Connects to a display monitor (up to 2048x1536
resolution).
4 S-video out port Connects to a television or display device with S-
video input.
5 Fan slots Help keep the computer cool. Do not cover these
slots which promote proper airflow to the computer.
6 Security keylock Connects to a Kensington-compatible computer
security lock.
7 Parallel port Connects to a parallel device (e.g., parallel printer).
8 DC-in jack Connects to the AC adapter.
Jaguar-e.book Page 8 Wednesday, March 12, 2003 2:46 PM

9
Bottom view
#Item Description
1 Heavy-duty handle For carrying the DeskBook B145 computer and also
used as a stand for tilting the system. Available on
some models.
2 Memory and CPU
cooling slots
Slots for cooling the computer’s main memory and
processor. Do not cover these slots to prevent the
system from overheating.
3 Foldable leg For tilting the computer to provide a more comfortable
typing posture.
Jaguar-e.book Page 9 Wednesday, March 12, 2003 2:46 PM

1 Getting familiar with your computer10
Features
This computer was designed with the user in mind. Here are just a few of its many
features:
Performance
• Intel® Pentium® 4 processor
• 512KB FLASH BIOS with boot block; shadow RAM support
• Desktop 15” XGA, or 16” UXGA/SXGA+ LCD
• Intel® 845GV chipset with UMA VGA support with 8MB or 16 MB DDR
graphic memory
• Memory upgradable to 2 GB with two PC1600/PC2100/PC2700 (200/266/
333MHz DDR) soDIMM slots
• One 3.5” desktop hard disk up to 7200rpm
• Power management system
• Dual display capability
• Simultaneous LCD and CRT display
• LCD panel supports resolution up to 1600 x 1200 at 262144 colors for 16”
UXGA
Multimedia
• AC’97 2.2-compliant stereo audio with two speakers
• DVD/CD-RW combo drive, DVD drive, or CD-ROM drive
• S-video output port
Connectivity
• High-speed fax/data software modem
• Onboard PCI 10/100 Mbps LAN support
• Optional 802.11b USB module
Human-centric design and ergonomics
• Full-sized keyboard
• Ergonomically-centered touchpad pointing device
• Launch keys
Jaguar-e.book Page 10 Wednesday, March 12, 2003 2:46 PM
