EM20 Technical Speci󽗉cations and
User Manual

●Frequencyrange:1GHz;Fieldstrengthcalibrationrange:5V/m±0.5dB(20℃~30℃);

●This󽗉eldstrengthcalibratorissuitableforcalibratingthe󽗉eldstrengthofallkindsof
electromagnetic󽗉ledstrengthmeterswithprobemeridionalsizebelow65mm,aswellas360
degreesisotropydetectionandveri󽗉cationofelectromagnetic󽗉eldprobe;

●Inserttheantennaprobeintothecircularholeofcalibratorinaxialparallelasshownin󽗉gure,
keepthegeometriccenteroftheelectromagnetic󽗉eldprobeoverlapwiththegeometric
centerofcalibratorcircularhole;

●AvoidusingthecalibratorinhighpowerRFradiationenvironment;

●Pleasekeepthecalibratorover1mawayofhumanbody;

●Beawareofdevicebatteryvoltagewarningwhencalibrating,lowbatteryvoltagecancause
inaccuratecalibration;

●Thefrequencyrangeand󽗉eldstrengthcalibrationrangecanbecustomized;

●Poweredby4AAbattery,6VorAClineadaptor,12V,󽗊exibleandconvenient.

●Calibrationtuningpotentiometerhole(adj)isspeciallyusedbyprofessionalstocalibrate󽗉eld
strength.
Calibration tuning
potentiometer hole Power On/Off Power switch(DC/AC)
Charging port
Power indicatorCalibrator hole

User Manual of 󽗉eld strength calibrator
① . Afterclaibration,this󽗉eldstrengthcalibratorissuitableforcalibratingthe󽗉eldstrength
ofallkindsofelectromagnetic󽗉ledstrengthmeterswithprobemeridionalsizebetween
60mmto66mm.
② . Placetheantennaprobeintothecircularholdofcalibrtaiortoensurethereliabiity
ofclaibrationasshownin󽗉gure(EM9N),suggesttomakepositionholderincasethe
antennaprobemeridionalsizeissmallerthanthecircularholdofEM20calibrator.
③ . Placethecalibratorandelectromagnetic󽗉ledstrengthmeterontablehorizontally,insert
antennaprobeverticallyintothecircularholeofcalibratorandpoweroncalibrator(select
topowerbyinternalbatteryorAClineadaptor).Poweronelectromagnetic󽗉ledstrength
meterandwaitforstableresultdata,iftheresultdatachangesgreatly,pleasecheckthe
electromagneticenvironmentorchangeanotherlocationuntilgetstableresultdata.
（NOTE: Please keep the calibrator over 1m away of humanbody, and in no
electric appliance environment(IE: computer) during the calibration.）
④ . EM20 supports the calibrtaion of electromagnetic
󽗉led strength meter from di󽗈erent vendors
⑤ . Isotsopy index testing of antenna probe
Placetheantennaprobeverticallyintothecircularholeofcalibrator,orparallel
tothesideofthecircularholeasshownin󽗉gure,rotateelectromagnetic󽗉eldstrength
meter360degrees,recordtheresultdatainallangles,theaveragedi󽗈erencevalue
betweentheresultdataandstandardvalueisthe"isotropyindex".
DEVISER EM9N
WAVE CONTROL SMP2
MCRRAD PRO5
NARDA NBM-550 / NBM-520
