Devolo dsl+1100 User manual

dsl
+
1100 WLAN
ADSL2+ Modem & WLAN-Router
+ WLAN-USB-Stick
devolo AG
Sonnenweg 11 • 52070 Aachen • Tel: [phone] • Fax: [phone] • www.devolo.de • [e-mail]
Stand: 20.05.08
Technical specifications
LAN standards Ethernet specification IEEE 802.3
Fast Ethernet specification IEE 802.3u
Fullduplex specification IEEE 802.3x
Auto MDI/MDIX
WLAN IEEE 802.11b/g(g++)
DSL standards ADSL over ISDN (Annex B)
T-Com specification 1TR112 (U-R2)
ITU G.992.1 (G.dmt)
ITU G.992.3 (ADSL2)
ITU G.992.5 (ADSL2+)
ITU G.994.1 (G.hs)
oder: ADSL over POTS (Annex A)
ANSI T1.413 Issue2
ITU G.992.1 (G.dmt)
ITU G.992.2 (G.lite)
ITU G.992.3 (ADSL2)
ITU G.992.3 Annex L (RE-ADSL2)
ITU G.992.5 (ADSL2+)
ITU G.994.1 (G.hs)
ITU G.997.1 (G.ploam)
Transmission rate ADSL: up to 25 Mbps
Wireless: up to 54 Mbps (IEEE 802.11g standard),
up to 125 Mbps (Turbo Mode g++, no standard)
WLAN frequency interval 2412 MHz – 2472 MHz
Firewall Stateful Packet Inspection
Stealth Mode
DoS-Blocking
NAT
IP-Masquerading
WLAN encryption WEP
WPA
WPA2
Ports
4 Ethernet LAN with Auto MDI/MDI-X
1 WLAN AccessPoint
1 ADSL WAN
WAN connection 1 Connector type: RJ11 (DSL)
LAN connection 4 Connector type: RJ45 (Ethernet)
WLAN connection Coaxial Connector for detachable, rotatable 2,4 Ghz antenna
LEDs
LEDs:
Internet status
Power
DSLstatus
WLAN status
Power supply Power adapter 9 V DC / 1000 mA, EU
Weight 440 g WLAN Router
10 g WLAN USB stick
Dimensions WLAN-Router: 202 x 152 x 38 mm (width x depth x height)
WLAN-USB-Stick: 72 x 19 x 9 mm (width x depth x height)

dsl
+
1100 WLAN
ADSL2+ Modem & WLAN-Router
+ WLAN-USB-Stick
devolo AG
Sonnenweg 11 • 52070 Aachen • Tel: [phone] • Fax: [phone] • www.devolo.de • [e-mail]
Stand: 20.05.08
Environment 0–40°C (32–104°F), 10–90% humidity (non-condensing )
Protocols TCP/IP
UDP
DHCP-Server
Dynamic DNS
UPnP
PPPoE
PPPoA
VPN Pass Through
ATM AAL5
System requirements CD ROM drive
Computerinterface wired: Ethernet (RJ45)
Computerinterface wireless: USB or WLAN Client 802.11b/g
One of the following operating systems:
WLAN-Router: Windows
®
2000, Windows
®
XP, Linux
®
, Mac OS
®
X
USB-Stick: Windows
®
2000, Windows
®
XP
For Internet access: DSL from any telecommunications provider
Miscellaneous Firmware Upgrade from file
Automatical DSL configuration by choosing a Service Provider from a
predefined list
Automatical setup of a secure WLAN connection (WECT)
 First setup also via WLAN cooection possible
Saving and reconstitution of the configuration data
Port Forwarding / Virtual Server
Quality of Service (TOS)
On/Off switch
WECT button – button for automatical setup of a WPA2 encrypted wireless
connection between WLAN USB Stick and Router with 802.11g++ (125 Mbps)
Approvals CE compliant in accordance with all technical requirements for all EU countries and
Switzerland: EN 60950, EN 55022, EN 55024, EN300328, EN301489
Sales information
Article number 01853 (DE, Annex B) 01852 (CH Annex B), 01851 (CH Annex A)
EAN code 4250059618534 (DE, Annex B), 4250059618527 (CH Annex B),
4250059618510 (CH Annex A)
Warranty 3 years
Service & Support Hotline For service and support telephone numbers please check up the following link:
http://www.devolo.com/co_EN/service/index.html
E-mail: [email protected]
On-site Service Tel.: [phone] (Germany only)
Sales Info-line Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Design Plastic case
Weight 1465 g
Packaging size 188 x 302 x 115 mm (width x depth x height)
Accessories
WLAN USB Stick (802.11g++)
Telephone cable (RJ11 – RJ45 alternatively RJ11 – RJ11))
Network cable (RJ45 – RJ45)
Mains power adapter: 9V DC/ 1000 mA, EU
Documentation: Install poster
CD ROM: manual PDF, Install wizard, Antivirus software, URL filter

dsl
+
1100 WLAN
ADSL2+ Modem & WLAN-Router
+ WLAN-USB-Stick
devolo AG
Sonnenweg 11 • 52070 Aachen • Tel: [phone] • Fax: [phone] • www.devolo.de • [e-mail]
Stand: 20.05.08
WEEE additional information
Weight WEEE 336,4 g
Paper (Green Dot) 326 g
Plastic (Green Dot) 10 g
Other (Green Dot) 0,4 g
