DeWalt DCSNP2142Y2 User manual

If you have questions or comments, contact us.
Si tiene dudas o comentarios, comuníquese con nosotros.
Si vous avez des questions ou des commentaires, contactez-nous.
1-855-971-1123
Instruction Manual
Manual de Instrucciones
Manuel d’instructions
Form No. 769-26758
(May 31, 2023)
DCSNP2142Y2
DCSNP2142B
DCSNP2142Y2-CA
Single Stage Battery Powered Snow Blower
Soplador de Nieve de una etapa a batería
Souffleuse à neige à batterie monophasée

ENGLISH
English (original instructions) 1
Español (traducido de las instrucciones originales) 19
Français (traduction de la notice d’instructions originale) 37
© 2023 DEWALT. DEWALT® and GUARANTEED TOUGH® are registered trademarks of the DEWALT Industrial Tool Co., used under license. All rights
reserved. The yellow and black color scheme is a trademark for DEWALT Power Tools and Accessories.
© 2023 DEWALT. DEWALT® y GUARANTEED TOUGH® son marcas registradas de DEWALT Industrial Tool Co. usadas bajo licencia. Todos los derechos
están reservados. El esquema de color negro y amarillo es una marca comercial de DEWALT Power Tools and Accessories.
© 2023 DEWALT. DEWALT® et GUARANTEED TOUGH® sont des marques déposées de DEWALT Industrial Tool Co. utilisées sous licence. Tous droits
réservés. Le schéma de couleurs jaune et noir est une marque déposée pour les outils électriques et les accessoires DEWALT.

ENGLISH
1
WARNING!Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire, and/or seriousinjury.
NOTE: This Operator's Manual covers several models. Features may vary by model. Not all features in this manual are
applicable to all models and the model depicted may differ from yours.
If you have any questions or comments about this or any DeWALT tool, call us toll free at: 1-855-971-1123.
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your
risk of personal injury or property damage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderateinjury.
(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in
propertydamage.

2
SAFE OPERATION PRACTICES
TRAINING
1. Read, understand, and follow all instructions on the machine
and in the manual(s) before attempting to assemble and
operate. Keep this manual in a safe place for future and
regular reference and for ordering replacement parts.
2. Be familiar with all controls and their proper operation. Know
how to stop the machine and disengage them quickly.
3. Never allow children under 14 years of age to operate this
machine. Children 14 and over should read and understand
the instructions and safe operation practices in this manual
and on the machine and be trained and supervised by an
adult.
4. Never allow adults to operate this machine without proper
instruction.
5. Thrown objects can cause serious personal injury. Plan your
snow-blowing pattern to avoid discharge of material toward
roads, bystanders and the like.
6. Keep bystanders, pets and children at least 75 feet from the
machine while it is in operation. Stop machine if anyone
enters the area.
PREPARATION
Thoroughly inspect the area where the equipment is to be used.
Remove all doormats, newspapers, sleds, boards, wires and other
foreign objects, which could be tripped over or thrown by the
machine.
1. Always wear safety glasses or eye shields during operation
and while performing an adjustment or repair to protect your
eyes. Thrown objects which ricochet can cause serious injury
to the eyes.
2. Do not operate without wearing adequate winter outer
garments. Do not wear jewelry, long scarves or other loose
clothing, which could become entangled in moving parts.
Wear footwear which will improve footing on slippery
surfaces.
3. Disengage all control levers before starting the motor.
4. Never attempt to make any adjustments while motor is
running, except where specifically recommended in the
operator’s manual.
OPERATION
1. Do not put hands or feet near rotating parts, in the auger
housing or chute assembly. Contact with the rotating parts
can amputate hands and feet.
2. The auger control bail is a safety device. Never bypass its
operation. Doing so makes the machine unsafe and may
cause personal injury.
3. The auger control bail must operate easily in both directions
and automatically return to the disengaged position when
released.
4. Never operate with a missing or damaged guard or chute
assembly. Keep all guards and safety devices in place and in
working order.
5. The handle sensor is a safety device. Ensure the handle is
locked in the upright position and that the nub ofthe left
handle lever engages with the slot of the handle sensor.
6. Do not operate machine while under the influence of alcohol
or drugs.
7. Do not use on graveled surface. Exercise extreme caution and
disengage the auger crossing gravel surfaces. Stay alert for
hidden hazards or traffic.
8. Exercise caution when changing direction and while
operating on slopes. Do not operate on steep slopes.
9. Plan your snow-blowing pattern to avoid discharge towards
windows, walls, cars etc. Thus, avoiding possible property
damage or personal injury caused by a ricochet.
10. Never direct discharge at children, bystanders and pets or
allow anyone in front of the machine.
11. Do not overload machine capacity by attempting to clear
snow at too fast of a rate. It will perform better and safer at
the rate for which it was designed.
12. Never operate this machine without good visibility or light.
Don’t Overreach. Always be sure of your footing and balance.
Keep a firm hold on the handles. Walk, never run.
13. Release auger control bail to disengage power to the auger
when transporting or not clearing snow.
WARNING
Thissymbol points out important safetyinstructions which, if not followed,couldendangerthepersonal
safety and/orpropertyofyourself and others. Read and follow all instructionsinthismanualbefore
attemptingtooperatethis machine. Failureto comply with these instructions mayresultinpersonal injury.
When you see this symbol, HEED ITS WARNING!
DANGER
This machine was built to be operated according to the safe operation practices in this manual. As with any type of
powerequipment, carelessness or erroronthepart of the operator can resultin seriousinjury.This machine is capableof
amputatingfingers,hands, toes and feet and throwing debris. Failuretoobserve the followingsafety instructions could
resultinserious injuryordeath.

3
SAFE OPERATION PRACTICES
14. Never operate machine at high transport speeds on slippery
surfaces. Look down and behind and use care when backing
up.
15. After striking a foreign object or if the machine should start
to vibrate abnormally, stop the motor, remove the safety key.
Inspect thoroughly for damage. Repair any damage before
starting and operating.
16. Disengage the auger control bail, stop motor, and remove the
safety key before you leave the operating position (behind
the handles). Wait until the auger comes to a complete
stop before unclogging the chute assembly, making any
adjustments, or inspections.
17. Never put your hand in the discharge or collector openings.
Always use a clean-out tool to unclog the discharge opening.
Disengage the auger control bail, stop motor, and remove
the safety key. Remain behind handles until all moving parts
have stopped before unclogging.
18. Use only attachments and accessories approved by the
manufacturer (e.g. wheel weights, tire chains, cabs etc.). The
use of an unapproved accessory or attachment may increase
the risk of injury.
19. If situations occur which are not covered in this manual,
use care and good judgment. Contact Customer Support for
assistance and the name of your nearest servicing dealer.
CLEARING A CLOGGED DISCHARGE CHUTE
Hand contact with the rotating impeller or auger inside the
discharge chute is the most common cause of injury associated
with snow blowers. Never use your hand to clean out the
discharge chute.
To clear the chute:
1. SHUT THE Motor OFF!
2. Remove the safety key.
3. Wait 10 seconds to be sure the impeller or auger has stopped
rotating.
4. Always use a clean-out tool, not your hands.
MAINTENANCE & STORAGE
1. Never tamper with safety devices. Check their proper
operation regularly. Refer to the maintenance and
adjustment sections of this manual.
2. Before cleaning, repairing, or inspecting machine, disengage
the auger control bail, stop the motor, remove the safety
key and remove battery(ies). Wait until the auger comes to a
complete stop.
3. Check bolts and screws for proper tightness at frequent
intervals to keep the machine in safe working condition. Also,
visually inspect machine for any damage.
4. Snow blower shave plates are subject to wear and damage.
For your safety protection, frequently check all components
and replace with original equipment manufacturer’s (OEM)
parts only. Use of parts which do not meet the original
equipment specifications may lead to improper performance
and compromise safety!
5. Check control levers periodically to verify they engage and
disengage properly and adjust, if necessary. Refer to the
adjustment section in this operator’s manual for instructions.
6. Maintain or replace safety and instruction labels, as
necessary.
7. Prior to storing, run machine a few minutes to clear snow
from machine and prevent freeze up of auger.
8. Store Idle Snow Blowers Indoors – When not in use, snow
blowers should be stored indoors in a dry, locked-up place
with the safety key removed and out of reach of children.
9. According to the Consumer Products Safety Commission
(CPSC), a snow blower has an Average Useful Life of six
(6) years. At the end of the Average Useful Life have the
machine inspected annually by an authorized service dealer
to ensure that all mechanical, electrical, and safety systems
are working properly and not worn excessively. Failure to do
so can result in accidents, serious injuries or death.
DO NOT MODIFY SNOW BLOWER SPEED
To avoid serious injury of death, do not modify snow blower
speed in any way. Tampering with operating speed can lead to
unsafe operating conditions.
GENERAL ELECTRIC SAFETY
1. Do not expose the snow blower to rain or wet conditions.
2. Do not handle the snow blower with wet hands.
3. Wear rubber boots when operating the snow mover.
4. Avoid dangerous environments. Do not operate the unit in
the rain, in wet conditions or on wet surfaces. Moisture is a
shock hazard.
5. To reduce the risk of electric shock, avoid body contact with
grounded conductors, such as metal pipes or wire fences.
6. Do not operate the snow blower in explosive atmospheres,
such as in the presence of flammable liquids, gases or dust.
The battery pack is not fully charged out of the carton. Before
using the battery pack and charger, read the safety instructions
below and then follow charging procedures outlined below.
When ordering replacement battery packs, be sure to include the
catalog number and voltage.

4
SAFE OPERATION PRACTICES
IMPORTANT SAFETY INSTRUCTIONS FOR ALL BATTERY
PACKS
WARNING
Readallsafety warnings, instructionsandcautionary
markings for the battery pack, charger and product.
Failure to follow the warnings and instructions may
resultinelectric shock,fire and/orseriousinjury.
1. Do not charge or use the battery pack in explosive
atmospheres, such as in the presence of flammable liquids,
gases or dust. Inserting or removing the battery pack from
the charger may ignite the dust or fumes.
2. When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws or
other small metal objects, that can make a connection from
one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
3. NEVER force the battery pack into the charger. Do not modify
the battery pack in any way to fit into a non-compatible
charger as battery pack may rupture causing serious personal
injury.
4. Charge the battery packs only in original equipment
manufacturer chargers.
5. Do not splash or immerse in water or other liquids.
6. Do not store or use the tool and battery pack in locations
where the temperature may reach or exceed 104° F (40° C)
(such as outside sheds or metal buildings in summer). For
best life store battery packs in a cool, dry location.
7. Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium-ion battery packs are burned.
8. If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If battery
liquid gets into the eye, rinse water over the open eye for
15 minutes or until irritation ceases. If medical attention is
needed, the battery electrolyte is composed of a mixture of
liquid organic carbonates and lithium salts.
9. Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persist, seek medical
attention.
WARNING
Burn hazard. Battery liquid may be flammable if exposed
to spark or flame.
WARNING
Fire hazard. Never attempt to open the battery pack
for any reason. If the battery pack case is cracked or
damaged, do not insert into the charger. Do not crush,
drop or damage the battery pack. Do not use a battery
pack or charger that has received a sharp blow, been
dropped, run over or damaged in any way (e.g., pierced
with a nail, hit with a hammer, stepped on). Damaged
battery packs should be returned to the servicecenter
forrecycling.
IMPORTANT SAFETY INSTRUCTIONS FOR ALL BATTERY
CHARGERS
WARNING
Readallsafety warnings, instructionsandcautionary
markings for the battery pack, charger and product.
Failure to follow the warnings and instructions may
resultinelectric shock,fire and/orseriousinjury.
1. Do not attempt to charge the battery pack with any chargers
other than an original manufacturer charger. Original
manufacturer charger and battery pack are specifically
designed to work together.
2. These chargers are not intended for any uses other than
charging original manufacturer rechargeable batteries.
Any other uses may result in risk of fire, electric shock or
electrocution.
3. Do not expose the charger to rain or snow.
4. Pull by the plug rather than the cord when disconnecting the
charger. This will reduce the risk of damage to the electric
plug and cord.
5. Make sure that the cord is located so that it will not be
stepped on, tripped over or otherwise subjected to damage
or stress.
6. Do not use an extension cord unless it is absolutely necessary.
Use of improper extension cord could result in risk of fire,
electric shock or electrocution.
7. When operating a charger outdoors, always provide a dry
location and use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of
electric shock.

5
SAFE OPERATION PRACTICES
8. An extension cord must have adequate wire size (AWG or
American Wire Gauge) for safety. The smaller the gauge
number of the wire, the greater the capacity of the cable,
that is, 16 gauge has more capacity than 18 gauge. An
undersized cord will cause a drop in line voltage resulting
in loss of power and overheating. When using more than
one extension to make up the total length, be sure each
individual extension contains at least the minimum wire size.
The following table shows the correct size to use depending
on cord length and nameplate ampere rating. If in doubt, use
the next heavier gauge. The lower the gauge number, the
heavier the cord.
MINIMUM WIRE SIZE FOR EXTENSION CORDS FOR
120 VOLT APPLIANCES USING 0-6 AMPS
CordLength (ft.) 25 50 100 150
Wire Size (AWG) 18 16 16 14
9. Do not place any object on top of the charger or place the
charger on a soft surface that might block the ventilation
slots and result in excessive internal heat. Place the charger
in a position away from any heat source. The charger is
ventilated through slots in the top and the bottom of the
housing.
10. Do not operate the charger with a damaged cord or plug -
have them replaced immediately.
11. Do not operate the charger if it has received a sharp blow,
been dropped or otherwise damaged in any way. Take it to an
authorized service center.
12. Do not disassemble the charger; take it to an authorized
service center when service or repair is required.
Incorrect reassembly may result in a risk of electric shock,
electrocution or fire.
13. Disconnect the charger from the outlet before attempting
any cleaning. This will reduce the risk of electric shock.
Removing the battery pack will not reduce this risk.
14. NEVER attempt to connect two (2) chargers together.
15. The charger is designed to operate on standard 120V
household electrical power. Do not attempt to use it on any
other voltage.
WARNING
Shockhazard.Do not allowanyliquid to get inside the
charger. Electricshock mayresult.
WARNING
Burn hazard. Do not submerge the battery pack in any
liquid or allow any liquid to enter the battery pack. Never
attempt to open the battery pack for any reason. If the
plastic housing of the battery pack breaks or cracks,
return toaservicecenter for recycling.
CAUTION
Burnhazard. To reduce the risk ofinjury, charge only
originalmanufacturer rechargeablebattery packs.Other
types of batteries may overheat and burst resulting in
personal injuryandpropertydamage.
CAUTION
Undercertain conditions, with the charger plugged into
the power supply, the charger can be shorted by foreign
material. Foreign materials of a conductive nature, such
as,butnotlimitedto,grinding dust, metal chips, steel
wool,aluminum foil or any buildup of metallic particles
shouldbekeptawayfrom the chargercavities.Always
unplug the charger from the power supply when there is
no battery pack in the cavity. Unplug the charger before
attemptingtoclean.

6
SAFE OPERATION PRACTICES
DISPOSING OF DAMAGED OR WORNOUT BATTERIES
WARNING
The following toxic and corrosive material is used in this
unit’sbattery:
LITHIUM-ION, a toxic material.
WARNING
To preventcontaminationof theenvironment,contact
yourlocalwastedisposalagency forspecific instructions
before disposing of damagedor worn-out lithium-ion
batteries. Take batteries to a local recycling and/or
disposalcenter,certifiedforlithium-ionbattery disposal.
WARNING
Do not use broken or cracked batteries, even if there isn’t
leakage.Replacedamagedorworn-out batteries with
new batteries. DO NOT ATTEMPT TO REPAIR BATTERIES!
Repairattemptsmayresultinseverepersonalinjury,due
toexplosionorelectricalshock.
To avoid personal injury and damage to the environment:
1. Do not attempt to remove or destroy any of the battery
components. Do not open or mutilate the battery. If a leak
develops, released electrolytes are corrosive and toxic. Do
not get the solution in your eyes or on your skin, and do not
swallow it.
2. Do not dispose of the battery in the regular household trash.
3. Do not dispose of the battery in a fire. The cell may explode.
4. Do not dispose of the battery where it will become part of any
waste landfill or municipal solid waste stream.
5. Cover the battery terminals with heavy-duty adhesive tape.
6. Dispose of the battery according to local, state and federal
regulations.
7. Dispose of the battery promptly.
AboutCall2RecycleBatterySeals
Call2Recycle’s industry steward program
helps battery and product manufacturers
fulfill recycling requirements in the U.S.
and Canada, including compliance with
extensive state, provincial and federal
regulations, such as the Mercury-Containing
and Rechargeable Battery Act (The Battery Act). Call2Recycle®
Licensees/Industry Stewards, participating battery and product
manufacturers and marketers, purchase the rights to imprint the
Call2Recycle Battery Seals on their rechargeable batteries and
products. When you see the Call2Recycle Battery Seal, you can
feel confident knowing that your battery or product can be safely
and responsibly recycled.
AboutCall2Recycle
Since 1994, Call2Recycle has diverted more than 75 million
pounds of rechargeable batteries from local landfills and
established a network of 30,000 recycling drop-off locations.
More than 200 battery and/or product manufacturers,
Call2Recycle Industry Stewards, have united to ensure that
batteries are responsibly recycled when they reach their end of
life and fund the program that is operated by Call2Recycle, Inc., a
501(c)4 nonprofit public service organization.
To locate the nearest recycling center, please call 1-800-822-
8837.
FCC STATEMENT
WARNING
Changes or modifications not expressly approved by the
partyresponsibleforcompliancecouldvoidthe user’s
authority to operatetheequipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.

7
SAFETY SYMBOLS
This page depicts and describes safety symbols that may appear on this snow blower. Read, understand, and follow all instructions on
the snow blower before attempting to assemble and operate.
Symbol Description
OPESymbol.com
DANGER – READ OPERATOR’S MANUAL: Read, understand and follow all the safety
rules and instructions in the manual(s) and on the snow blower before attempting to
operate this snow blower. Failure to comply with this information may result in personal
injury or death. Keep this manual in a safe location for future and regular reference.
Using a Smart Phone, scan the QR code symbol to learn more information concerning the
warnings contained on this snow blower. You can also go to www.OPESymbol.com for
more information.
DANGER – AVOID AMPUTATION INJURY, DISCHARGE CHUTE: Do not put hands near or
into the discharge chute while the motor is running. Contact with the rotating impeller or
auger can amputate fingers and hands. Stop motor and remove safety key and wait until
all moving parts have stopped rotating. Always use clean-out tool to clear the discharge
chute, never use your hand.
CAUTION – THROWN OBJECT: Use for snow removal only.
WARNING — THROWN OBJECT/ENTANGLEMENT: Do not operate the snow blower
without the guards and discharge chute installed.
DANGER — AVOID THROWN OBJECT INJURY: Do not walk in front of running machine.
Do not direct discharge at bystanders.
DANGER — ROTATING BLADES: To reduce the risk of injury, keep hands and feet
away. Do not operate unless discharge chute is in its proper place. If damaged, replace
immediately.
DANGER – AVOID AMPUTATION INJURY, AUGER HOUSING: Do not put hands or feet
near or into the auger housing while the motor is running. Contact with the auger can
amputate fingers, hands, toes and feet.
WARNING — ELECTRIC SHOCK: Never douse or hose the snow blower with water.
WARNING — ELECTRIC SHOCK: Remove the battery before storing or attempting any
service.
WARNING
Your Responsibility—Restrict the use of this power machine to persons who read, understand and follow the
warnings and instructions in this manual and onthe machine- SAVE THESE INSTRUCTIONS!

8
BATTERIES & CHARGERS
The battery pack is not fully charged out of the carton. Before
using the battery pack and charger, read the safety instructions
in the Safe Operation Practices section and then follow charging
procedures outlined in this section. When ordering replacement
battery packs, be sure to include the catalog number and
voltage.
Important Charging Notes
1. Longest life and best performance can be obtained if
the battery pack is charged when the air temperature
is between (65° F - 75° F (18° C - 24° C). DO NOT charge
when the battery pack is below +40° F (+4.5° C), or above
+104° F (+40° C). This is important and will prevent
serious damage to the battery pack.
2. The charger and battery pack may become warm to the touch
while charging. This is a normal condition, and does not
indicate a problem. To facilitate the cooling of the battery
pack after use, avoid placing the charger or battery pack in a
warm environment such as in a metal shed or an uninsulated
trailer.
3. If the battery pack does not charge properly:
a. Check operation of receptacle by plugging in a lamp or
other appliance;
b. Check to see if receptacle is connected to a light switch
which turns power off when you turn out the lights;
c. Move the charger and battery pack to a location where
the surrounding air temperature is approximately 65°
F - 75° F (18° C - 24° C);
d. If charging problems persist, take the tool, battery pack
and charger to your local service center.
4. The battery pack should be recharged when it fails to produce
sufficient power on jobs which were easily done previously.
Do not CONTINUE to use under these conditions. Follow the
charging procedure. You may also charge a partially used
pack whenever you desire with no adverse effect on the
battery pack.
5. Foreign materials of a conductive nature such as, but not
limited to, grinding dust, metal chips, steel wool, aluminum
foil or any buildup of metallic particles should be kept away
from charger cavities. Always unplug the charger from the
power supply when there is no battery pack in the cavity.
Unplug the charger before attempting to clean.
6. Do not freeze or immerse the charger in water or any other
liquid.
Charging a Battery
NOTE: Only use DeWalt Flexvolt battery system chargers
(DCB1104 recommended) to charge the batteries used with this
snow blower.
NOTE: To ensure maximum performance and life of lithium-ion
battery packs, charge the battery pack fully before first use.
1. Plug the charger into an appropriate outlet before inserting
battery pack.
2. Connect the charger and battery pack (Figure 1), making
sure the battery is fully seated. The (charging) light will blink
continuously indicating that the charging process has started.
Figure 1
3. The completion of charge will be indicated by the light
remaining ON continuously. The battery pack is fully charged
and may be removed and used at this time or left in the
charger.
NOTE:To remove the battery pack, some chargers require the
battery pack release button to be pressed.
Indicators
Charging
FullyCharged
Hot/ColdPackDelay
A charger will not charge a faulty battery pack. The charger
refusing to light could indicate a problem with the charger.
NOTE:If the charger refuses to light, take the charger and
battery pack to be tested at an authorized service center.
HOT/COLD PACK DELAY
When the charger detects a battery pack that is too hot or too
cold, it automatically starts a Hot/Cold Pack Delay, suspending
charging until the battery pack has reached an appropriate
temperature. The charger then automatically switches to the
pack charging mode. This feature ensures maximum battery
pack life.
A cold battery pack may charge at a slower rate than a warm
battery pack.

9
BATTERIES & CHARGERS
Battery and Battery Charger Care
STORAGE RECOMMENDATIONS
1. The best storage place is one that is cool and dry, away
from direct sunlight and excess heat or cold.
2. For long storage, it is recommended to store a fully charged
battery pack in a cool dry place out of the charger for optimal
results.
NOTE:Battery packs should not be stored completely depleted
of charge. The battery pack will need to be recharged before use.
BATTERY PACK CLEANING INSTRUCTIONS
Dirt and grease may be removed from the exterior of the battery
using a cloth or soft non-metallic brush. Do not use water or any
cleaning solutions.
CHARGER CLEANING INSTRUCTIONS
WARNING
Shock hazard. Disconnect the charger from the AC
outlet before cleaning. Dirt and grease may be removed
from the exterior of the charger using a cloth or soft
non-metallic brush. Do not use water or any cleaning
solutions.
1. Keep the battery charger clean and clear of debris. Do not
allow foreign material into the charger connector (a) or onto
the terminals (b) (Figure 2). Inspect the battery charger for
foreign material before each use.
a
b
Figure 2
2. Make sure the charger has not been shorted by debris. Inspect
the terminals for soot and signs of melting. Do not attempt to
use a damaged charger.
Transportation
WARNING
Fire hazard. Do not store or carry the battery pack so that
metal objects can contact exposed battery terminals.
For example, do not place the battery pack in aprons,
pockets, tool boxes, product kit boxes, drawers, etc., with
loose nails, screws, keys, etc. Transporting batteries can
possiblycause firesifthebatteryterminalsinadvertently
come in contact with conductive materials such as
keys, coins, hand tools and the like. The US Department
ofTransportationHazardousMaterialRegulations
(HMR) actually prohibit transportingbatteries in
commerceoronairplanesincarry-onbaggageUNLESS
theyareproperly protected fromshort circuits.When
transporting individual batterypacks, make sure that
the battery terminals are protected and well-insulated
from materials that could contact them and cause a short
circuit.
NOTE: Li-ion batteries should not be put in checked baggage.

10
ASSEMBLY
Overview
• Remove packaging materials from snow blower.
• Rotate Handle into the upright position and lock the handles
in place. Refer to Handle Assembly.
• Install the chute. Refer to Chute Assembly Options.
• Complete snow blower assembly. Refer to Set-Up on page
11.
Tools Required
• Adjustable Wrench or Socket Set
Assembly
1. Charge batteries. Refer to Charging a Battery on page 8.
2. Remove nut (a) and bolt from (b) lower handle (Figure 3).
3. Using the nut and bolt removed in STEP 3, secure the handle
sensor (c) to the lower handle.
c
b
a
Figure 3
4. Flip the two handle levers down to the Unlocked position
(Figure4).
NOTE:if the handle lever does not flip down, loosen the wing
knob until the handle lever will flip down.
Figure 4
5. Pivot the upper handle into the operating position. Be sure not
to pinch any of the cables in the process (Figure 4).
6. Flip the two handle levers (unlocked in STEP 4) up to the
locked position to secure the upper handle in the operating
position (Figure5).
NOTE:Ensure the nub of the left handle lever engages the slot of
the handle sensor.
Figure 5
NOTE:If necessary, adjust the wing knob so that the handle
lever is tight enough to hold the upper handle in the operation
position but loose enough for the handle lever to flip down
to unlock the upper handle to be folded down to the storage
position.

11
ASSEMBLY
Chute Assembly
1. Remove the hex washer screws (a) in the chute base
(Figure 6).
a
a
a
Figure 6
2. Align the holes in the chute base with the three tabs (b) in
the lower chute.
3. Secure the chute base with the hex washer screws (a) removed
in Step 2 (Figure 7).
b
aaa
Figure 7
Set-Up
CHECKING THE BATTERY CHARGELEVEL
Press the charge meter button on the battery (Figure 8). The
number of lights that illuminate will indicate the current charge
level of the battery. If all three lights are dark, charge the battery
before any further use. Refer to Charging a Battery on page 8.
Charge Meter
Button
Low
(Charge Battery)
Medium Charge
Full Charge
Figure 8
NOTE:While in use, lithium-ion batteries provide power with
minimal power fade. When the battery is fully discharged, it will
immediately cut power to the snow blower and require charging.
WARNING
Do not expose the snow blower to rain or wet conditions.
INSTALLING BATTERY
IMPORTANT:Only use DeWalt Flexvolt battery system batteries
(DCB612 recommended) with this snow blower.
NOTE:The snow blower can operate with a single, fully
chargedbatterybutitisnotrecommendedas it will result in
less run time and reduced performance.
+=
60
V
60
V
Ah
4. Lift up the battery housing lid.
5. Slide one battery (a) into the battery port (b) so that the
battery indicator light faces up from the battery port (Figure
9).
6. Push the battery firmly until the battery locks into place.
There should be an audible “click” when the battery is in
position.
b
a
Figure 9
7. Repeat STEPS 2 and 3 to install a second battery into the
remaining battery port.
8. Close battery housing lid and ensure the battery housing lid
snaps into the shroud.

12
OPERATION
Model Features
D
G1 G2
E
F
A
B
C
H
L
J
I
M
K
K
Figure 10
FEATURES
Snow blower controls and features are described below and
illustrated above (Figure 10).
NOTE:This Operator’s Manual covers several models. Snow
blower features may vary by model. Not all features in this
manual are applicable to all snow blower models and the snow
blower depicted may differ from yours.
NOTE:All references to the left or right side of the snow blower
are from the operator’s position. Any exceptions will be noted.
A. BATTERY (IF EQUIPPED)
The batteries are used to power the snow blower.
NOTE:Select models are sold as snow blower only. Batteries are
available separately.
B. BATTERY CHARGER (IF EQUIPPED)
The battery charger is used to charge batteries.
NOTE:Select models are sold as snow blower only. Battery
chargers are available separately.
C. SAFETY KEY
The safety key is a safety device. It must be fully inserted in order
for the motor to start. Remove the safety key when the snow
blower is not in use.
D. START BUTTON
Turns power on/off to the snow blower motor.
E. MODE BUTTON
The mode button is used to cycle through the Three operational
modes of the snow blower:
1. Eco Mode - Reduces auger speed and power to increase
battery run time in light snow conditions.
2. Standard Mode-Normal operating speed and power,
used for most applications.
NOTE:The snow blower will start in standard mode.
3. Max Power Mode - Increases auger speed and power.
Used in heavy, wet snow conditions. This mode will
reduce run time.
F. INDICATOR PANEL
The indicator panel provides the following information:
1 1
23
45
1 1
23
45

13
OPERATION
1. Battery indicators - shows if a battery is installed in one
or both of the battery slots and how much charge each
battery has. When all indicator lights are lit the battery is
at full charge. As the battery is discharging, the indicator
lights will lower. When bottom battery indicator light
begins to flash, the battery(ies) are nearing complete
discharge.
NOTE:Battery Fault Indicator - Battery indicators will
flash when a battery fault is detected. Stop motor and
remove safety key and battery(ies). Reinstall battery(ies) and
safety key. Start then stop the motor. If problem persists,
contact an authorized service center.
2. Faultindicator- Indicates an error with the snow
blower and will be shutting down.
• Blinking Indicator - Snow blower is overheating from
being over worked. Release auger control bail and
allow snow blower to cool before continuing.
• Steady Indicator - Error or Failure in Electronics,
motor or battery and snow blower will shut down.
Stop motor and remove safety key and battery(ies).
Reinstall battery(ies) and safety key. Start then stop
the motor. If problem persists, contact an authorized
service center.
3. Heavy Load Indicator - Indicates the snow blower is in
a high load condition that will result in a lower run time.
Pause moving the snow blower forward. When the heavy
load indicator light goes out, Slowly move forward to
continue removing snow.
4. Eco Mode indicator - Shows eco mode is active. Reduced
auger speed to extend runtime.
NOTE:Snow blower will cycle into standard mode (no
indicator lights will be lit) before going into max power
mode.
5. Max Power Mode indicator - Shows max power mode
is active. - Increased auger speed to remove heavier snow.
Reduces run time.
G. CHUTE DIRECTION CONTROLS
The left side (G1) and a right side (G2) chute direction controls
are used to rotate the chute. Depress the right or left side chute
direction controls to rotate the chute assembly to the left or
right. Release the switch at desired position.
NOTE:Chute will also stop rotating when the chute has rotated
through full range of motion.
H. AUGER CONTROL BAIL
The auger control bail is used to engage or disengage the auger.
Squeeze the auger control bail against the upper handle and
press the start button to engage the auger, release the bail to
disengage.
I. HANDLE SENSOR
The handle sensor is located on the lower handle and detects
if the handle is completely folded or locked into the upright
position. The snow blower will not operate unless the handle is in
the full upright position.
J. MANUAL CHUTE PITCH
Tilt the upper chute assembly up or down to adjusts the angle
(pitch) and distance that snow is blown.
K. HEADLIGHTS
The headlights (front of snow blower) will remain ON when the
snow blower is running.
L. AUGER
When engaged, the auger rotation draws snow into the auger
housing and blows it out the chute assembly.
M. SHAVE PLATE
The shave plate maintains contact with the pavement as the
snow blower is pushed, allowing snow close to the pavement’s
surface to be discharged.
Using The Snow Blower
TURNING ON THE SNOW BLOWER
1. Insert the safety key into lower edge of the upper handle
until it snaps in place (Figure 11).
2. Pull the auger control bail against the upper handle.
3. Press the start button.
NOTE:Press the start button within 3 seconds of pulling the
auger control bail against the upper handle. If the snow blower
does not start, release the auger control bail and repeat STEPS
2-3.
3
2
1
Figure 11
ENGAGING THE AUGER
To engage the auger and start throwing snow, squeeze the auger
control bail against the upper handle and press the start button.
Release the auger control bail to stop the auger (Figure 11).

14
OPERATION
TURNING OFF THE SNOW BLOWER
1. Release the auger control bail to stop the motor and auger
(Figure 11).
2. Remove the safety key if snow blower is to be left unattended
ADJUSTING AUGER SPEED/POWER LEVEL
NOTE:The snow blower will start in standard mode.
The mode button is used to cycle through the Three operational
modes of the snow blower (Figure 12).
1. Press the mode button (a) to change from the standard
Mode to the max power mode. Max power mode indicator
(b) lights up.
2. Press the mode button again to change from max power
mode to eco mode. Max power mode indicator goes out and
the eco mode indicator (c) lights up.
3. Press the mode button again to change from eco mode to
standard mode. Both eco and max power mode indicators
will go out.
ab
c
Figure 12
Adjusting the Chute Direction and Pitch
NOTE:The Chute must be rotated to the left or right before
folding the handle.
CHUTE DIRECTION
• Rotating Chute to The Left - Press and hold the left side chute
direction control (b) until the desired position has been
achieved. Release the left side chute direction control.
• Rotating Chute to The Right - Press and hold the right side
chute direction control (a) until the desired position has been
achieved. Release the right side chute direction control.
b
a
Figure 13
CHUTE PITCH
NOTE:Chute pitch controls the angle and distance of how far
snow is blown.
1. Loosen wing nut (a) (Figure 14).
2. Pivot the upper chute assembly upward or downward to
desired position.
3. Tighten wing nut.
a
Figure 14
REMOVING THE BATTERYIES
IMPORTANT:Recommended use with two DCB612 batteries.
When one or both batteries need to be charged, follow the steps
below to remove them:
1. Lift up the battery housing lid.
2. Push in the battery release tab (a).
3. While pushing in the battery release tab, firmly pull the
battery (b) out from the battery port (c).
NOTE:If necessary, repeat STEPS 2 and 3 to remove the
remaining battery from the snow blower.
NOTE:To replace with charged battery, refer to Installing Battery
on page 11.
4. Close battery housing lid.
a
b
c
Figure 15
5. Repeat STEPS 2 and 3 to remove the second battery.
6. Close battery housing lid.

15
OPERATION
Folding and Unfolding the Handle
NOTE:When folding or unfolding the handle, If necessary, adjust
the wing knobs so that the handle levers are tight enough to hold
the upper handle in the operation position but loose enough for
the handle lever to flip down to unlock the upper handle to be
folded down to the storage position.
1. Rotate the chute completely to the right or left. Refer to
Adjusting the Chute Direction and Pitch on page 14.
2. Flip the two handle levers down to the Unlocked position
(Figure16).
Figure 16
3. Pivot the upper handle down to the folded position. Be sure not
to pinch any of the cables in the process (Figure 17).
4. Flip the two handle levers (unlocked in STEP 2) into the
locked position.
5. Reverse STEPS 1-4 to unfold the handle.
Figure 17
Clearing a Clogged Chute Assembly
WARNING
Never use your hands to clear a clogged chute assembly.
Shut OFF motor and remain behind handles until all
moving parts have stopped before using the clean-out
tooltoclearthechuteassembly.
Hand contact with the rotating auger inside the chute assembly
is the most common cause of injury associated with snow
blowers. Never use your hand to clean out the chute assembly.
To clear the chute (Figure 18):
1. TURN THE SNOW BLOWER OFF.
2. Remove safety key.
3. Wait 10 seconds to be sure the auger has stopped rotating.
IMPORTANT:Always use a clean-out tool (Part No. 931-2643),
not your hands. Refer to the separate supplement for clean-out
tool ordering information.
Figure 18

16
PRODUCT CARE
WARNING
Beforeservicing,repairingorinspecting the snow
blower,disengagetheaugercontrolbail.Stopthe motor
andremovesafety keytopreventunintendedstarting.
Troubleshooting
BATTERY WILL NOT CHARGE
1. The battery charger is not plugged in.
• Plug the battery charger into a 120V 60hz AC source.
2. The battery is not fully inserted into the battery charger.
• Remove and then reinsert the battery into the battery
charger.
3. The battery and/or charger are too hot or too cold.
• Make sure the battery and charger are in an environment
between 32° and 104° F (0° and 40° C). Allow time for the
battery and/or charger to warm up or cool down.
4. The battery and/or charger are no longer functional.
• Refer to the Warranty Supplement for replacement
information.
SNOW BLOWER FAILS TO START
1. Safety key not inserted into starter housing.
• Insert safety key fully into starter housing.
2. Auger control disengaged.
• Engage auger control bail.
3. Starting procedure incomplete or performed out of order.
• Press auger control bail against the handle then press the
start button to start motor.
4. Battery discharged.
• Charge battery.
5. The battery is not installed correctly.
• Remove safety key and battery(ies). Reinstall battery(ies)
and safety key.
6. Handle lock lever not fully engaged with handle sensor.
• Ensure handle lock lever is completely in the locked position
and nub of handle lock lever is engaged with the handle
sensor.
BATTERY DIES QUICKLY
1. The battery is not fully charged.
• Charge the battery completely.
2. The battery and/or charger are no longer functional.
• Refer to the Warranty Supplement for replacement
information.
3. Using unit outside temperature range.
• Battery(ies) too hot - Allow battery to cool.
• Battery(ies) too cold - Bring battery(ies) inside to warm up to
room temperature.
SNOW BLOWER STOPS WHILE REMOVING SNOW
1. Battery discharged or lacks sufficient charge.
• Charge battery completely.
2. Chute assembly clogged.
• Stop motor and remove safety key. Clean chute and inside of
the auger housing with clean-out tool.
3. Battery is over heated.
• Allow battery to cool.
4. Using unit outside temperature range.
• Battery(ies) too hot - Allow battery to cool.
• Battery(ies) too cold - Bring battery(ies) inside to warm up to
room temperature.
EXCESSIVE VIBRATION
1. Loose parts or damaged auger.
• Stop motor immediately and remove safety key and
battery(ies). Check for possible damage. Tighten all nuts
and bolts. Repair as needed. If the problem persists,
contact an authorized service center.
AUGERS CONTINUE TO ROTATE
1. Potential electrical issue.
• Stop motor and remove safety key and battery(ies). Reinstall
battery(ies) and safety key. Start then stop the motor. If
problem persists, contact an authorized service center.
FAILS TO DISCHARGE SNOW
1. Chute assembly clogged.
• Stop motor and remove safety key. Clean chute and inside of
the auger housing with clean-out tool.
2. Foreign object lodged in auger.
• Stop motor immediately and remove safety key. Remove the
object from auger.
3. Auger drive belt loose or damaged.
• Replace auger drive belt. See Replacing the Auger Drive Belt
in the Service section.
Maintenance
OFFSEASON STORAGE
If the snow blower will not be used until next season, follow the
storage instructions below.
1. Remove safety key and battery(ies).
2. Store in a clean, dry area.
3. Use air or a dry rag to clean the outside of the snow blower,
battery and battery charger.

17
PRODUCT CARE
REPLACING SHAVE PLATE
NOTE:The shave plate is attached to the bottom of the auger
housing and is subject to wear. It should be checked periodically.
1. Ensure the snow blower is turned off and the safety key is
removed.
2. Remove battery(ies).
3. Tip the snow blower back until it rests on the handles.
4. Remove the four star screws (a) securing the shave plate (b)
to the auger housing (c) (Figure 20).
NOTE:the two center star screws also secures the bottom shroud
to the auger housing.
5. Remove the existing shave plate.
6. Install the new shave plate.
7. Using the star four screws removed in STEP 4, secure the new
shave plate and bottom support plate to the auger housing.
a
b
c
Figure 20
Battery Disposal
THE RBRC® SEAL
The RBRC® (Rechargeable Battery
Recycling Corporation) Seal on the
nickel cadmium, nickel metal hydride
or lithium-ion batteries (or battery
packs) indicates that the costs to recycle
these batteries (or battery packs) at the end
of their useful life have already been paid by the manufacturer.
In some areas, it is illegal to place spent nickel cadmium, nickel
metal hydride or lithium-ion batteries in the trash or municipal
solid waste stream and the Call 2 Recycle® program provides an
environmentally conscious alternative.
Call 2 Recycle, Inc., in cooperation with the manufacturer and
other battery users, has established the program in the United
States and Canada to facilitate the collection of spent nickel
cadmium, nickel metal hydride or lithium-ion batteries. Help
protect our environment and conserve natural resources by
returning the spent nickel cadmium, nickel metal hydride or
lithium-ion batteries to an authorized service center or to your
local retailer for recycling. You may also contact your local
recycling center for information on where to drop off the spent
battery. RBRC® is a registered trademark of Call 2 Recycle, Inc.
IMPORTANT:DO NOT wash the snow blower with water. The
warranty will be voided if water is used on the snow blower.
IMPORTANT:When storing the snow blower or when it is
not being serviced, it is to remain in the upright position with
both wheels and auger housing on the ground.
NOTE:Refer to Battery Charger Operator’s Manual for
information on storing your batteries.
4. Fold Handle.
Service
REPLACING THE AUGER DRIVE BELT
1. Ensure the snow blower is turned off and the safety key is
removed.
2. Remove battery(ies).
3. Remove the four hex washer screws (a) that secure the belt
cover (b) to the motor plate (Figure 19). Remove the belt
cover.
a
b
c
d
e
f
g
h
Figure 19
4. Using a needle nose pliers or spring puller, release tension on
idler pulley spring (c) and disconnect the idler pulley spring
from the idler pulley bracket (d).
5. Lift the idler pulley (e) and remove the belt (f).
6. Routethenew auger belt aroundthedrive pulley (g) and under the
idler pulley.
7. Route the end of the belt around the auger pulley (h).
8. Reconnect the idler pulley spring to the idler pulley bracket.
9. Reinstall the belt coverremoved in Step3.

18
PRODUCT CARE
Replacement Parts
Part Number Description
BD-NA262050 Safety key
754P07144 Auger belt
BD-NA171659 Wheels
BD-NA110007 Battery
BD-N878449 Battery charger
Accesories
Part Number Description
931-2643 Chute Clean-out Tool
Three Year Limited Warranty
DeWALT will repair or replace, without charge, any defects due to
faulty materials or workmanship for three years from the date of
purchase. This warranty does not cover part failure due to normal
wear or tool abuse. For further detail of warranty coverage and
warranty repair information, visit www.dewalt.com or call
1-800-4-DeWALT (1-800-433-9258). This warranty does not
apply to accessories or damage caused where repairs have been
made or attempted by others. THIS LIMITED WARRANTY IS GIVEN
IN LIEU OF ALL OTHERS, INCLUDING
THE IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, AND EXCLUDES ALL INCIDENTAL OR
CONSEQUENTIAL DAMAGES. Some states do not allow limitations
on how long an implied warranty lasts or the exclusion or
limitation of incidental or consequential damages, so these
limitations may not apply to you. This warranty gives you specific
legal rights and you may have other rights which vary in certain
states or provinces. In addition to the warranty DeWALT tools are
covered by our:
1 YEAR FREE SERVICE
DeWALT will maintain the tool and replace worn parts caused
by normal use, for free, any time during the first two years after
purchase.
2 YEARS FREE SERVICE ON DEWALT BATTERY PACKS
DC9071, DC9091, DC9096, DC9182, DC9280, DC9360, DCB120,
DCB122, DCB124, DCB127, DCB201, DCB203BT, DCB207, DCB361
3 YEARS FREE SERVICE ON DEWALT BATTERY PACKS
DCB200, DCB203, DCB204, DCB204BT, DCB205, DCB205BT,
DCB206, DCB208, DCB230, DCB240, DCB606, DCB609, DCB612
NOTE:Battery warranty voided if the battery pack is tampered
with in any way. DeWALT is not responsible for any injury caused
by tampering and may prosecute warranty fraud to the fullest
extent permitted by law.
90 DAY MONEY BACK GUARANTEE
If you are not completely satisfied with the performance of your
DeWALT Power Tool or Nailer for any reason, you can return it
within 90 days from the date of purchase with a receipt for a full
refund – no questions asked.
LATIN AMERICA: This warranty does not apply to products sold
in Latin America. For products sold in Latin America, see country
specific warranty information contained in the packaging, call
the local company or see website for warranty information.
FREE WARNING LABEL REPLACEMENT: If your warning labels
become illegible or are missing, call 1-800-4-DeWALT
(1-800-433-9258) for a free replacement.
