DFI-ITOX EL332-IP User manual
EL332-IP
System Board
User’s Manual
A14910115
Copyright
This publication contains information that is protected by copyright. No part of it
may be reproduced in any form or by any means or used to make any transfor-
mation/adaptation without the prior written permission from the copyright hold-
ers.
This publication is provided for informational purposes only. The manufacturer
makes no representations or warranties with respect to the contents or use
of this manual and specifically disclaims any express or implied warranties of
merchantability or fitness for any particular purpose. The user will assume the
entire risk of the use or the results of the use of this document. Further, the
manufacturer reserves the right to revise this publication and make changes to
its contents at any time, without obligation to notify any person or entity of such
revisions or changes.
© 2011. All Rights Reserved.
Trademarks
All trademarks and registered trademarks of products appearing in this manual
are the properties of their respective holders.
FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandthereceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhich
the receiver is connected.
• ConsultthedealeroranexperiencedradioTVtechnicianforhelp.
Notice:
1. The changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the emission
limits.
1
4
Introduction
Table of Contents
Copyright........................................................................................... 2
Trademarks........................................................................................ 2
FCC and DOC Statement on Class B.............................................. 3
About this Manual ............................................................................. 6
Warranty .......................................................................................... 6
Static Electricity Precautions............................................................. 7
Safety Measures................................................................................. 7
About the Package ............................................................................ 8
Before Using the System Board........................................................ 8
Chapter 1 - Introduction .................................................................. 9
Specifications.................................................................................. 9
Features ...................................................................................... 11
Chapter 2 - Hardware Installation.................................................. 14
System Board Layout .................................................................... 14
System Memory ........................................................................... 15
Installing the DIM Module ......................................................... 16
CPU ............................................................................................ 18
Installing the CPU .................................................................... 18
Installing the Fan and Heat Sink ................................................ 22
Jumper Settings............................................................................. 24
Clear CMOS Data ..................................................................... 24
PS/2 Power Select.................................................................... 25
USB Power Select..................................................................... 26
Power-on Select....................................................................... 27
PCIEx16/DVISelect .............................................................. 28
RS232/RS422/RS485 Select ...................................................... 29
Rear Panel I/O Ports..................................................................... 31
COM (Serial) Ports ................................................................... 32
VGAPort................................................................................. 33
DVI-IPort ............................................................................... 34
USB Ports................................................................................ 35
RJ45 LAN Port ......................................................................... 37
1
5
Introduction
I/O Connectors............................................................................ 38
Front Audio ............................................................................. 38
KB/Mouse Connector ................................................................ 39
SATA (Serial ATA) Connectors .................................................... 41
IDE Connector ......................................................................... 42
GPIO Connectors...................................................................... 44
Cooling Fan Connectors............................................................. 46
Chassis Instrusion Connector .................................................... 47
Power Connectors .................................................................... 48
LAN LED Connector .................................................................. 49
Standby Power LED .................................................................. 50
Front Panel Connectors ............................................................. 51
Download Flash BIOS Connector ................................................ 52
Expansion Slots ....................................................................... 53
Battery ................................................................................... 54
Chapter 3 - BIOS Setup.................................................................. 55
Overview .................................................................................... 55
AMI BIOS Setup Utility ................................................................. 57
Main ....................................................................................... 57
Advanced ................................................................................ 58
PCIPnP.................................................................................... 77
Boot ....................................................................................... 78
Security .................................................................................. 84
Chipset ................................................................................... 87
Exit ........................................................................................ 91
Updating the BIOS........................................................................ 94
Chapter 4 - Supported Software ................................................... 95
Chapter 5 - RAID ........................................................................ 121
Appendix A - NLITE and AHCI Installation Guide ....................... 132
Appendix B - Truobleshooting....................................................... 144
Appendix C - System Error Message............................................ 148
1
6
Introduction
About this Manual
An electronic file of this manual is included in the CD. To view the user’s manual
in the CD, insert the CD into a CD-ROM drive. The autorun screen (Main Board
Utility CD) will appear. Click “User’s Manual” on the main menu.
Warranty
1. Warranty does not cover damages or failures that arised from misuse of the
product, inability to use the product, unauthorized replacement or alteration
of components and product specifications.
2. The warranty is void if the product has been subjected to physical abuse,
improper installation, modification, accidents or unauthorized repair of the
product.
3. Unless otherwise instructed in this user’s manual, the user may not, under
any circumstances, attempt to perform service, adjustments or repairs on the
product, whether in or out of warranty. It must be returned to the purchase
point, factory or authorized service agency for all such work.
4. We will not be liable for any indirect, special, incidental or consequencial
damages to the product that has been modified or altered.
1
7
Introduction
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board, components
or devices even before installing them in your system unit. Static electrical dis-
charge can damage computer components without causing any signs of physical
damage. You must take extra care in handling them to ensure against electro-
static build-up.
1. To prevent electrostatic build-up, leave the system board in its anti-static bag
until you are ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of the compo-
nents, contacts or connections.
5. Avoid touching the pins or contacts on all modules and connectors. Hold
modules or connectors by their ends.
Important:
Electrostatic discharge (ESD) can damage your processor, disk drive and
other components. Perform the upgrade instruction procedures described
at an ESD workstation only. If such a station is not available, you can
provide some ESD protection by wearing an antistatic wrist strap and
attaching it to a metal part of the system chassis. If a wrist strap is
unavailable, establish and maintain contact with the system chassis
throughout any procedures requiring ESD protection.
Safety Measures
To avoid damage to the system:
• UsethecorrectACinputvoltagerange.
To reduce the risk of electric shock:
• Unplug the power cord before removing the system chassis cover for instal-
lation or servicing. After installation or servicing, cover the system chassis
before plugging the power cord.
Battery:
• Dangerofexplosionifbatteryincorrectlyreplaced.
• Replace only with the same or equivalent type recommend by the manufac-
turer.
• Disposeofusedbatteriesaccordingtolocalordinance.
1
8
Introduction
About the Package
The system board package contains the following items. If any of these items are
missing or damaged, please contact your dealer or sales representative for as-
sistance.
One system board
One USB cable
Two Serial ATA data cables
Two Serial ATA power cables
One bracket mounted with a COM port cable
One I/O shield
One DVD
One QR (Quick Reference)
The system board and accessories in the package may not come similar to the
information listed above. This may differ in accordance to the sales region or
models in which it was sold. For more information about the standard package in
your region, please contact your dealer or sales representative.
Before Using the System Board
Before using the system board, prepare basic system components.
If you are installing the system board in a new system, you will need at least the
following internal components.
• ACPU
• Memorymodule
• Storagedevicessuchasharddiskdrive,CD-ROM,etc.
You will also need external system peripherals you intend to use which will nor-
mally include at least a keyboard, a mouse and a video display monitor.
1
9
Introduction
Processor
Chipset
System Memory
Expansion Slots
Graphics
Audio
LAN
Serial ATA
Interface
Chapter 1 - Introduction
•LGA775socketfor:
- Intel®CoreTM2 Quad Q9400
- Intel®CoreTM2DuoE8400/E7400/E6400/E4300
- Intel®Pentium®E6500/E5300/E2160
- Intel®Celeron®E3400/E1500/440
•SupportsIntelEnhancedMemory64Technology(EM64T)
•SupportsEnhancedIntelSpeedStepTechnology(EIST)
•1333/1066/800MHzFSB
•Intel®chipset
- Intel®G41Expresschipset
- Intel®ICH7RI/OControllerHub
•Two240-pinDDR3DIMMsockets
•SupportsDDR3800/1066MHzDIMM
•Maximum memory bandwidth of 17GB/s in dual-channel
modewhenusingDDR31066MHz
•Dualchannel(128-bitwide)memoryinterface
•Supportsupto4GBsystemmemory
•Supportsunbufferedx8andx16DIMMs
•1PCIExpressx16slot(PCIE1.1)
•2PCIExpressx1slots(PCIE1.1)
•1PCIslot(PCI2.3)
•IntegratedIntelGMAX4500
- Supports 3D, 2D and video capabilities, DX10 and
OpenGL1.5
•Displayports:DVI-I(ChrontelCH7307C)andVGA
•RealtekALC2622-channelHighDefinitionAudio
•DACswith100dBSNRandADCswith90dBSNR
•4IntelWG82574LPCIExpressGigabitEthernetcontrollers
•Supports10Mbps,100Mbpsand1Gbpsdatatransmission
•IEEE802.3u(10/100Mbps)andIEEE802.3ab(1Gbps)com-
pliant
•SATAspeedupto3Gb/s(SATA2.0)
•9 Serial ATA interfaces compliant with SATA 1.0 specifica-
tion
-4SATAportssupportedbyIntelICH7R
*SupportsRAID0/1/5/10
-4 SATA ports supported by Silicon Image SiI3114 PCI to
SATA controller
*PCILocalBusSpecificationRev.2.3compliant
*APMSpecificationRev.1.0compliant
*PCIIDEControllerSpecificationRev.1.0compliant
*SupportsRAID0/1/10
-1SATAportsupportedbyGenesysLogicGL830USBto
SATAbridgecontroller
*USBSpecificationRev.2.0compliant
*USBStorageClassSpecificationRev.1.0compliant
Specifications
1
10
Introduction
TPM - TRUSTED
PLATFORM
MODULE
(optional)
IDE
Rear Panel I/O
Ports
I/O Connectors
BIOS
Energy Efficient
Design
Damage Free
Intelligence
Temperature
Humidity
PCB
•ProvidesaTrustedPCforsecuretransactions
•Providessoftwarelicenseprotection,enforcementandpass-
wordprotection
•SupportsuptotwoIDEdevices
•SupportsUltraATA100/66/33
•2DB-9RS232/422/485serialports
•1DB-15VGAport
•1DVI-Iport(DVI-Dsignalonly)
•4RJ45LANports
•2USB2.0/1.1ports
•2connectorsfor4externalUSB2.0/1.1ports
•2connectorsfor2externalRS232/422/485serialports
•1frontaudioconnectorforline-outandmic-inatfront
panel
•1LANLEDconnector
•1PS/2connectorforkeyboard/mouseports
•9SerialATAconnectors
•140-pinIDEconnector
•136-bitGPIOconnector
•124-pinATXpowerconnector
•14-pin12Vpowerconnector
•1chassisintrusionconnector
•1frontpanelconnector
•3fanconnectors
•AMIBIOS
•8MbitSPIBIOS
•ACPIv3.0bspecification
•SystemPowerManagement
•Wake-On-Eventsinclude:
-Wake-On-PS/2Keyboard/Mouse
-Wake-On-USBKeyboard/Mouse
-Wake-On-LAN
-RTCtimertopower-onthesystem
•Microsoft®/Intel®APM1.2compliant
•ACpowerfailurerecovery
•MonitorsCPU/System/AUXtemperatureandoverheatalarm
• Monitors CPU/DIMM/3.3V/5V/12V/1.1V/VBAT voltages and
failure alarm
•MonitorsCPU/System/2ndfanspeedandfailurealarm
•Readbackcapabilitythatdisplaystemperature,voltageand
fan speed
•Watchdogtimerfunction
•0oCto60oC
•10%to90%
•microATXformfactor
•244mm(9.6”)x244mm(9.6”)
1
11
Introduction
Features
DDR3
DDR3 delivers increased system bandwidth and improved performance. It offers
peak data transfer rate of up to 21 Gb/s bandwidth. The advantages of DDR3
are its higher bandwidth and its increase in performance at a lower power than
DDR2.
Graphics
The Intel northbridge chip comes integrated with the Intel Graphics Media Accel-
erator X4500 delivering 3D, 2D and video capabilities. With support for Microsoft
DirectX 10 and OpenGL 2.1, Intel GMA X4500 delivers excellent video and 3D
graphics with outstanding graphics responsiveness. These enhancements deliver
the performance and compatibility needed for today’s and tomorrow’s business
applications.
PCI Express
PCI Express is a high bandwidth I/O infrastructure that possesses the ability to
scale speeds by forming multiple lanes. The x4 PCI Express lane supports trans-
fer rate of 1 Gigabyte per second. The PCI Express architecture also provides a
highperformancegraphicsinfrastructurebyenhancingthecapabilityofax16PCI
Expresslanetoprovide4Gigabytespersecondtransferrate.
Audio
TheRealtekALC262audiocodecprovides2-channelHighDefinitionaudiooutput.
Serial ATA
Serial ATA is a storage interface that is compliant with SATA 1.0a specification.
With speed of up to 3Gbps, it improves hard drive performance faster than the
standard parallel ATA whose data transfer rate is 100MB/s. Intel ICH7R supports
RAID0/1/5/10andSiliconImageSiI3114supportsRAID0/1/10..
Gigabit LAN
The Intel WG82574L PCI Express Gigabit controller supports up to 1Gbps data
transmission.
USB
Thesystemboardsupports USB 2.0and USB1.1 ports.USB1.1supports12Mb/
second bandwidth while USB 2.0 supports 480Mb/second bandwidth providing a
marked improvement in device transfer speeds between your computer and a
widerangeofsimultaneouslyaccessibleexternalPlugandPlayperipherals.
1
12
Introduction
Wake-On-LAN
This feature allows the network to remotely wake up a Soft Power Down (Soft-
Off) PC. It is supported via the onboard LAN port or via a PCI LAN card that uses
the PCI PME (Power Management Event) signal. However, if your system is in the
Suspend mode, you can power-on the system only through an IRQ or DMA inter-
rupt.
Important:
The 5V_standby power source of your power supply must support
≥720mA.
Wake-On-USB
This function allows you to use a USB keyboard or USB mouse to wake up a sys-
tem from the S3 (STR - Suspend To RAM) state.
Important:
If you are using the Wake-On-USB Keyboard/Mouse function for 2 USB
ports, the 5V_standby power source of your power supply must support
≥1.5A. For 3 or more USB ports, the 5V_standby power source of your
powersupplymustsupport≥2A.
Wake-On-PS/2
This function allows you to use the PS/2 keyboard or PS/2 mouse to power-on
the system.
Important:
The 5V_standby power source of your power supply must support
≥720mA.
ACPI STR
The system board is designed to meet the ACPI (Advanced Configuration and
Power Interface) specification. ACPI has energy saving features that enables PCs
to implement Power Management and Plug-and-Play with operating systems that
support OS Direct Power Management. ACPI when enabled in the Power Manage-
ment Setup will allow you to use the Suspend to RAM function.
With the Suspend to RAM function enabled, you can power-off the system at
once by pressing the power button or selecting “Standby” when you shut down
Windows®without having to go through the sometimes tiresome process of
closing files, applications and operating system. This is because the system is
capable of storing all programs and data files during the entire operating session
into RAM (Random Access Memory) when it powers-off. The operating session
will resume exactly where you left off the next time you power-on the system.
Important:
The 5V_standby power source of your power supply must support
≥720mA.
1
13
Introduction
Power Failure Recovery
When power returns after an AC power failure, you may choose to either power-
on the system manually or let the system power-on automatically.
14
2Hardware Installation
System Board Layout
Chapter 2 - Hardware Installation
COM 2
COM 1
DVI-I port
(DVI-D signal only)
VGA
DVI -I
USB 1
USB 0
LAN 1-2
LAN 3-4
COM1 RS232/422/485
select ( )JP1
1
2
5
6
1
+12V
power
1
2
5
6
COM2 RS232/422/
485 select ( )JP3
Chrontel
CH7307C
LGA 775
WG82574L
Intel
Intel
Intel
WG82574L
WG82574L
Intel
WG82574L
1
USB 0-1
power select
(JP2)
CPU fan
1
1
3PCIE x16 / DVI-D
select ( )JP10/JP11
A F
1
3
A
JP10 JP11
F
Intel
G41
Intel
ICH7R
PCIE x16
PCIE x1
PCIE x1
Realtek
ALC262
29
10
1
Front audio
Winbond
W83627DHG
1
Chassis
intrusion
PCI
Battery
1
15 11
91
91
91
USB 2-5
power select
(JP5)
Silicon
SiI3114
SATA 4
1
SATA 5
1
SATA 6
1
SATA 7
1
SATA 8
1
1
Clear CMOS
(JP6)
GL830 Standby
Power LED
2
Front panel
SATA 3
1
SATA 2
1
SATA 1
1
SATA 0
1
SPI Flash
BIOS
1
2
7
8
Download
Flash BIOS
1
System
fan
21
4443
GPIO
2 1
3940
IDE
1
2nd
fan
6
5
2
1
COM4 RS232/422/
485 select ( )JP8
6
5
2
1
COM3 RS232/422/
485 select ( )JP7
1
2
9
COM 4
13
1
12 24
ATX power
1
Power-on
select ( )JP9
DDR3_1 DDR3_2
1
2
9
COM 3
2
16 LAN LED
PS/2 power
select (J )P4
KB/MS
2
10
USB 4-5
2
10
USB 2-3
2
10 111
15
2
Hardware Installation
System Memory
Important:
Electrostatic discharge (ESD) can damage your system board, processor,
disk drives, add-in boards, and other components. Perform the upgrade
instruction procedures described at an ESD workstation only. If such a
station is not available, you can provide some ESD protection by wearing
an antistatic wrist strap and attaching it to a metal part of the system
chassis. If a wrist strap is unavailable, establish and maintain contact
with the system chassis throughout any procedures requiring ESD pro-
tection.
DDR3-1
DDR3-2
Standby
Power LED
Important:
When the Standby Power LED lit red, it indicates that there is power on
the system board. Power-off the PC then unplug the power cord prior to
installing any devices. Failure to do so will cause severe damage to the
motherboard and components.
Features
• Two 240-pin DDR3 DIMM sockets
• Supports DDR3 800/1066MHz
• Supports up to 4GB system memory
16
2Hardware Installation
Note:
The system board used in the following illustrations may not resemble
the actual board. These illustrations are for reference only.
Installing the DIM Module
1. Make sure the PC and all other peripheral devices connected to it has been
powered down.
2. Disconnect all power cords and cables.
3. Locate the DIMM socket on the system board.
4. Push the “ejector tabs” which are at the ends of the socket to the side.
Ejector tab
Ejector tab
5. Note how the module is keyed to the socket.
Key
Notch
17
2
Hardware Installation
7. Seatthe modulevertically,pressing it downrmlyuntil itiscompletely seat-
ed in the socket.
6. Grasping the module by its edges, position the module above the socket with
the “notch” in the module aligned with the “key” on the socket. The keying
mechanism ensures the module can be plugged into the socket in only one
way.
8. The ejector tabs at the ends of the socket will automatically snap into the
locked position to hold the module in place.
18
2Hardware Installation
CPU
The system board is equipped with a surface mount LGA 775 socket. This socket
is exclusively designed for installing a LGA 775 packaged Intel CPU.
Important:
1. Before you proceed, make sure (1) the LGA775 socket comes with a
protective cap, (2) the cap is not damaged and (3) the socket’s con-
tact pins are not bent. If the cap is missing or the cap and/or contact
pins are damaged, contact your dealer immediately.
2. Make sure to keep the protective cap. RMA requests will be accepted
and processed only if the LGA775 socket comes with the protective
cap.
Installing the CPU
1. Make sure the PC and all other peripheral devices connected to it has been
powered down.
2. Disconnect all power cords and cables.
3. Locate the LGA 775 CPU
socket on the system
board.
Important:
The CPU socket must not
come in contact with any-
thing other than the CPU.
Avoid unnecessary expo-
sure. Remove the protec-
tive cap only when you are
about to install the CPU.
19
2
Hardware Installation
4. The CPU socket comes
with a removable protec-
tive cap. The cap is used
to protect the CPU socket
against dust and harm-
ful particles. Remove the
protective cap only when
you are about to install the
CPU.
Protective cap
5. To remove the protective
cap, lift the cap on the lo-
cation pointed on the right
photo.
Lift this part up
6. Unlock the socket by push-
ing the load lever down,
moving it sideways until it
is released from the reten-
tion tab; then lift it up.
Load lever
Retention tab
7. Life the load plate.
Load plate
20
2Hardware Installation
8. Position the CPU above the
socket. The gold mark on
the CPU must align with
pin 1 of the CPU socket.
Important:
Handle the CPU by its edg-
es and avoid touching the
pins.
Pin 1
of the
socket
Gold mark
9. Insert the CPU into the
socket until it is seated
in place. The CPU will t
in only one orientation
and can easily be inserted
without exerting any force.
Important:
Do not force the CPU into
the socket. Forcing the
CPU into the socket may
bend the pins and damage
the CPU.
CPU
Table of contents
Other DFI-ITOX Motherboard manuals
DFI-ITOX
DFI-ITOX G4H875-N User manual
DFI-ITOX
DFI-ITOX 586ITOX User manual
DFI-ITOX
DFI-ITOX NP100-N16C User manual
DFI-ITOX
DFI-ITOX G4M100-MS12 User manual
DFI-ITOX
DFI-ITOX G4S600-B User manual
DFI-ITOX
DFI-ITOX G7VP2 User manual
DFI-ITOX
DFI-ITOX EL630-NR User manual
DFI-ITOX
DFI-ITOX LR905-B User manual
DFI-ITOX
DFI-ITOX G5G100-P User manual
DFI-ITOX
DFI-ITOX G7L630-B User manual
DFI-ITOX
DFI-ITOX CA61 User manual
DFI-ITOX
DFI-ITOX G4V300-D User manual
DFI-ITOX
DFI-ITOX G4C600-R User manual
DFI-ITOX
DFI-ITOX LT600-DR User manual
DFI-ITOX
DFI-ITOX SR330-L User manual
DFI-ITOX
DFI-ITOX G4S300-B User manual
DFI-ITOX
DFI-ITOX G4M300-M12 User manual
DFI-ITOX
DFI-ITOX GIC68-B User manual
DFI-ITOX
DFI-ITOX CB60-ZX User manual
DFI-ITOX
DFI-ITOX G4E606-P User manual
Popular Motherboard manuals by other brands
Microchip Technology
Microchip Technology Microsemi CoaXPress VIDEO-DC-CXP Quick start card
Microsemi
Microsemi SmartFusion2 MSS Quick start card
Wurth Elektronik
Wurth Elektronik PROTEUS-III user manual
Erone
Erone 024A Series Use and installation manual
Gigabyte
Gigabyte B365M D3H user manual
SOYO
SOYO SY-P4X400 DRAGON Lite quick start guide
